Gates AVCCAM AG-3DA1 Guide

Gates Underwater Products, Inc •GatesHousings.com
13685 Stowe Dr, Suite A • Poway, CA • 92064 • [phone] • Fax [phone]
Pa^N=eçìëáåÖ=
3D High Definition Imaging
New to the Gates family of ‘bulletproof’ housings is the 3DA1,
specifically designed for the Panasonic AG-3DA1 3D camera.
Professional features include access to all controls including
White Balance and Convergence, nano3D support, HD-SDI
surface feed, and adjustable trim weights for perfect
buoyancy / trim. And the 3DA1 is classic Gates heritage:
durable machined aluminum, 100% reliable mechanical
controls and 2 year renewable warranty.
Reaching the far corners of the globe, Gates housings
are tasked with critical projects extending from marine
research and military to television and cinema
productions. Experts know that failure is not an option, so
they never take a chance…. they take a Gates!
hÉó=cÉ~íìêÉë=
Durable, "Bulletproof"
machined aluminum, black
type III 'hard' anodize finish,
and sealed with a nickel-
acetate process.
Reliable Fingertip
Controls are 100%
Mechanical -- no sticky
buttons, faulty electronics or
dead batteries!
External Color Monitor
The 4.3”/109mm hi-res
monitor makes framing and
focus easy. (Optional)
Seal Check is included with
every 3DA1 and assures
housing integrity
before
entering the water.
Pro Controls such as White
Balance, Focus and
Convergence are all
standard.
2-Year Warranty. Only
Gates offers a 2-year
renewable warranty on all
housings.
Changeable
Buoyancy and Trim
Add / remove trim weights
for ideal balance -- just the
way you like it.
Nano3D support.
Hardware and cables
optionally available to mount
inside the housing.
Home of the World’s Most Reliable Underwate
r
Housin
g
s
WHITE BALANCE

Gates Underwater Products, Inc •GatesHousings.com
13685 Stowe Dr, Suite A • Poway, CA • 92064 • [phone] • Fax [phone]
=
péÉÅáÑáÅ~íáçåë=EmêÉäáãáå~êóF=
* Controls (All Mechanical)
* Power On/Off * Record/Standby
* Iris / Convergence * Iris / Conv Dial
* Auto Focus / Infinity * Zoom
* Internal "Flip" Color Correction Filter
* User 1/2/3D Guide * WB Set
* Focus Bar * Manual Focus
* WB Presets
* Dimensions
* 23" L x 11.5" H x 10.5" W ” (16” w/handles)
* 58 cm L x 30 cm H x 27 cm W (40 cm w/handles)
* Construction
* Machined Aluminum, Type III ‘Hard’ Anodize
finish. Stainless steel hardware.
* Weight in Air
* 25 lbs / 11.3 kg (without camera)
* Weight in Water
* Slightly negative and adjustable
* Depth Rating
* 450 feet / 137 meters
* Batteries
* Accepts all Panasonic batteries sizes
* Warranty
* 2 Years Renewable
mçêí=léíáçåë=EmêÉäáãáå~êóF=
Flat Port FP55-R
Basic Flat Port for shooting
3D.
TBD
Flat Port FP55-R
TBD
iáÖÜí=léíáçåë=
TBD
Gates VL24 LED
Powerful, 7000+ Lumens
LED light is designed by
SubAqua Imaging for Gates.
1hr/2hr burn at full/half
power, respectively.
Tungsten (3200K) or
Daylight (5500K) color
available.
^î~áä~ÄäÉ=^ÅÅÉëëçêáÉë=
Gates Pak, Water Alarm, Tripod Mount and more.
See www.GatesHousings.com for more information
Don’t Take a Chance….Take a Gates!
