Gazer MIB-4 User manual

Version17:11.2017HW:CAM(V82)GDRL3-MIB4
MIB-4
CompatiblewithAudi vehicleswith MMINavigationPlusbasedonMIB
Bentley vehicles with MIB with 8“ monitor
LamborghinivehicleswithMIBwithmonitorininstrument
Porschevehicleswith PCM4.0
SeatvehicleswithMediaSystemPlus-MIBHigh/Standard
SkodavehicleswithMIBSTD2PQ/+NAV,AmundsenandBolero
VWvehicleswithMIB/MIB2/MQBHigh/DiscoveryProand
Standard/CompositionMedia
Video-inserterforfrontandrear-viewcameraandonemorevideoinput
Productfeatures
Video-inserterforfactory-infotainmentmonitors
Back- and frontcameraCVBSInput
CVBSVideo-Inputforafter-marketVideosources(e.g.DVD-Player,DVB-TTuner, …)
Automaticswitchingtorear-viewcamerainputonengagementofthereverse gear
Manual switchingtofrontcamerabykeypadorfactorybutton
Activatableparkingguidelinesforrear-viewcamera(vehiclespecificrestrictions
possible)
Video-in-motion(ONLY forconnectedvideo-sources)
Compatiblewithfactoryrear-viewcamera
AV-inputsPAL/NTSCcompatible
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page2
Contents
1. Priortoinstallation
1.1.Deliverycontents
1.2.Checkingthecompatibilityofvehicleandaccessories
1.3.Boxesandconnectors
1.3.1.Video-Interface
1.4.Settingsofthe8Dipswitches(black)
1.4.1.1.Enabling the interface’s video inputs (dip 2-3)
1.4.1.2.Vehiclespecificsettings(Dip4)
1.4.1.3.Rear-viewcamerasetting(dip5)
1.4.1.4.Monitorselection(Dip6-8)
1.5.Settings ofthe4Dipswitches(CANfunction–red)
2. Installation
2.1.Place ofinstallation
2.2.Connectionschema
2.3.Connectiontothe vehicle’s head unit
2.4.Connectionandpowersupplyforthevideointerface
2.5.Connectingofvideo-sources
2.5.1.Audioinsertion
2.5.2.……After-marketrear-viewcamera
2.5.2.1.Case1:CAN-boxreceivesthereversegearsignal
2.5.2.2.Case2:CAN-boxdoesnotreceivethereversegearsignal
2.6.Connectingvideo-interface andkeypad
2.7.Picturesettings andguidelines
3. Interface operation
3.1.Byfactoryinfotainmentbutton
3.2.Bykeypad
4. Specifications
5. FAQ–TroubleShooting-Interface functions
6. Technical support
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page3
LegalInformation
Bylaw,watchingmovingpictureswhiledrivingisprohibited,thedrivermustnotbe
distracted.Wedonotacceptanyliabilityformaterialdamageorpersonalinjuryresulting,
directlyorindirectly,frominstallationoroperationofthisproduct.Apartfromusingthis
productinanunmovedvehicle,itshouldonlybeusedtodisplayfixedmenusorrear-view-
cameravideowhenthevehicleismoving(forexampletheMP3menuforDVDupgrades).
Changes/updates of the vehicle’s software can cause malfunctions of the interface. Up to
oneyearafterpurchaseweofferfreesoftware-updatesforourinterfaces.To receiveafree
update,theinterfacehastobesentinatowncost.Wagesforde-and reinstallationand
otherexpendituresinvolvedwiththesoftware-updateswill notberefunded.
1. Priorto installation
Readthemanualpriortoinstallation.Technicalknowledgeisnecessaryforinstallation.The
place ofinstallationmustbefreeofmoistureandawayfromheatsources.
1.1. Deliverycontents
Takedowntheserialnumber oftheinterfaceand store thismanualforsupport
purposes:____________________
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page4
Requirements
Brand
Compatiblevehicles
Compatiblesystems
Audi
A3(8V) since05/2012-,A4(8W)
since08/2015-,A5(8T)since
07/2016-,A6(4G) since09/2014-,
A7(4G) since05/2014-,Q2(GA)
since09/2016-,Q5since2017-,Q7
(4M)since 03/2015-
MMINavigationPluswithMMI
Touch7",8"or8.3"- MIB/MIBII
Main-Unit
A3(8V) since05/2012-,A4(8W)
since08/2015-,A5(8T)since
07/2016-,Q2(GA)since 09/2016-,
Q5from2017-,Q7(4M)since
03/2015-
MMINavigation7"- MIBStd
Nav/MIBStd Plus
MMIRadioPlus5.8"or7"- MIB
Entry Plus/MIBStd
R8 (4S) since 05/2015-, TT (8S) since
07/2014-
MMINavigationPlus - MIBII
Main-Unit withmonitorin
instrument
Bentley
Bentayga
MIBwith8"monitor
Lamborghini
Huracan2016-
MIBwithmonitor ininstrument
Porsche
911 (991.2face-lift)from12/2015-,
Cayenne,Macanandother vehicles
with
PCM4.0
Seat
Ateca,Leon3(5F) from2013,
Toledo
MediaSystemPlus - MIB
High/Standard
Skoda
Fabia3(NJ)from11/2014, Octavia3
(A7)andother vehicles with
MIBHigh/Columbusund
Standard/Bolero/Amundsen -
5.8inch,6.5inchor8inch
monitor.
NOT 2018 9.2inch
VW
Crafter about 2015-2016
Crafter 2017-, Golf7,Passat2016,
Polo5(6C)andother vehicles with
MIB/MIB2/MQB High/Discovery
Pround Standard/Composition
Media - 5.8inch,6.5inch,7inch
or8inchmonitor.
NOT 2018 9.2inch.
Limitations
VideoonlyTheinterfaceinsertsONLYvideosignalsintotheinfotainment.
For insertingAudiosignalseither the possiblyexistingfactory
audio-AUX-input ora FM-modulatorcanbeused.
Factoryrear-view camera Automaticallyswitching-backfrominserted videotofactory
rear-viewcamera is only possible while the reversegear is
engaged.Todelay theswitch-backan additionalelectronicpart
isrequired.
1.2. Checkingthecompatibilityofvehicleand accessories
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page5
1.3. Boxes and connectors
1.3.1.VideoInterface
Thevideo-interface convertstheconnectedafter-marketsourcesvideosignalsintoaLVDS
signalwhichisinsertedinthefactorymonitorusingseparatetriggeroptions.Furtheritreads
the vehicle’s digital signals out of the vehicle’s CAN-busandconvertsthemforthevideo
interface.
1.4. Settingsofthe8Dipswitches(black)
Some settings mustbeselectedbythedip-switchesonthe
videointerface.DippositiondownisONand positionup isOFF.
Seethefollowingchaptersfordetailedinformation.
Dip
Function
ON(down)
OFF (up)
1
Nofunction
settoOFF
2
CVBSVideo1-input
enabled
disabled
3
CVBSVideo2-input
enabled
disabled
4
Vehiclespecific
settings
ForAudiTT vehicles
allothervehicles
5
Rear-viewcam type
after-market
factoryornone
6
Monitor
adjustment
Tryall6possiblecombinationsofDips6,7and8to
receivethebestpicture(qualityandsize) orseechapter
“Monitor adjustment (Dip 6-8)”
7
8
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page6
1.4.1.1.Enabling the interface’s video inputs (dip 2-3)
Only the enabled video inputs can be accessed by switching through the interface’s video
sources.Itisrecommendedtoenableonlytherequiredinputs.So thedisabledinputswillbe
skippedwhileswitchingthroughthevideointerfacesinputs.
1.4.1.2.Vehiclespecificsettings(Dip4)
SetDipswitch4toONforAudi TTvehicles.ForallothervehiclesithastobesettoOFF.
1.4.1.3.Rear-viewcamerasetting(dip5)
IfsettoOFF,theinterface switchestofactoryLVDSpicturewhilethereversegearisengaged
todisplayfactoryrear-viewcameraorfactoryopticalparksystempicture.
IfsettoON,theinterfaceswitchestoitsrear-viewcamerainputwhilethereversegearis
engaged.
1.4.1.4.Monitorselection(Dip6-8)
Dips6-8customizethemonitor-specificvideosettings whichsometimesevenvarywithin
headunitsofthesameversion,causedbydifferentmonitorspecifications.Itisnecessaryto
tryallpossiblecombinationswhileaworkingvideosourceisconnectedtothechoseninput
oftheinterface.Oneofthesixcombinationswillshowthebestpicturesizeandquality
(some maygivenopicture).Itispossibletofirsthotplugthroughthedipcombinations.If
thereisnochangeofpicturevisibleaftertryingall6options,retryanddisconnectthe10pin
plugoftheQuadlockconnectorbetweeneverychangeofthedipsetting.
Empirical value:
Vehicle
Monitor
Dip4
Dip6
Dip7
Dip8
VWGolf7
8“
OFF
OFF
OFF
OFF
5.8“
OFF
OFF
OFF
ON
AudiA3 (8V)
7“
OFF
OFF
ON
OFF
5.8“
OFF
OFF
ON
ON
AudiA4(8W),A5 (8T)
8.3“
OFF
ON
OFF
OFF
7“
OFF
OFF
OFF
OFF
AudiA6/A7(4G)
8“
OFF
OFF
ON
ON
AudiQ7(4M)Touch
8.3“
OFF
ON
ON
OFF
AudiQ7(4M)MMI
7“
OFF
OFF
OFF
OFF
Porsche
OFF
OFF
OFF
OFF
VWTouran
OFF
OFF
OFF
OFF
AudiTT (8S)
ON
OFF
OFF
OFF
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page7
1.5. Settingsofthe4Dipswitches(CANfunctions –red)
All4dip-switchesoftheCAN-boxhavenofunctionfornormaluse
exceptPorschevehicleswithPCM4.0andmustbesettoOFF.
DippositiondownisONandpositionupisOFF.
Vehicle/Navigation
Dip1
Dip2
Dip3
Dip4
Allvehicles
OFF
OFF
OFF
OFF
PorschewithPCM4.0
OFF
ON
OFF
ON
AftereachDip-switch-changeapower-resetoftheCan-boxhastobeperformed!
2. Installation
To install the interface, first switch off the ignition and disconnect the vehicle’s battery.
Please readtheowner`s manual ofthecar,regardingthebattery`s disconnection! If
required,enablethecar`s Sleep-mode(hibernationmode)
Incase thesleep-modedoes notsucceed,thedisconnectionofthebatterycanbedone
witharesistorlead.
Ifthenecessarystabilized powersupplyfortheinterface isnottakendirectlyfromthe
battery,thechosenconnectionhastobecheckedforbeingconstantlystabile.
Theinterface needsapermanent12Vsource!
2.1. Place ofinstallation
Theinterface isbuilttobeconnectedbehindthevehicle`shead-unit.
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page8
2.2. Connectionschema
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page9
2.3. Connectionstothehead-unit
Removethehead-unit.
Connectthefemale8pinconnectorofthe4pinHSDLVDS
cabletothevideo-interface’s male8pinconnector.
Disconnectthefemale4pinHSDLVDSconnectorofthevehicle
harnessfromtherearofthehead-unitandconnect
ittothemale4pinHSDLVDSconnectorofthe8pinHSDLVDScable.
Note:Ifrequired,themarkedlugofthe
female4pinHSDLVDSconnectorhastobe
cutoff! Further,thecolourofthefemale
4pinHSDLVDSconnectormayvarybetween
pinkand grey,dependingontheinstalledmonitor.
Connectfemale4pinconnectorofthe8pinHSDLVDSinterfacecabletothemale4pin
HSDLVDSconnectorofthehead-unit(coloursmay vary!).
RemovethefemaleQuadlockconnectorofthe
vehicleharnessfromtherearofthe
head-unitand connectthepreviously
clippedoutwhitefemale12pin
connector(seegraphic)tothemale
12pinconnectorofthePNPharness.
Clipinthefemale12pinconnectorofthePNPharnessinthepreviouslybecome free
positionofthefemaleQuadlockconnectorbeforefinishingtheQuadlock
reconnectionattherearofthehead-unit
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page10
2.4. Connectionand powersupplyforthevideointerface
Connect the interface cable’s female 20pin connector to the 20pin connector of the
interface and connecttheinterfacecable’s male 10pin connector to the female 10pin
connectorofthePNPharness
Connectthesingle,yellowwire“BATT” ofthePNPharnessto+12Vpermanentand
stabilepowersupply.
Connect the single, black wire “GND” of the PNP harness to the vehicle’s negative
ground.
IncaseofamissingCANcommunicationbetweenthevehicleandtheinterface,the
single,white-blackwireofthe20pininterface cablehastobeconnected
additionatelytoastabile+12V accessorypowersupply.
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page11
2.5. Connectingvideosources
Itispossibletoconnectanafter-marketrear-viewcamera,anafter-marketfrontcameraand
anAV sourcetothevideo-interface.
Beforeafinal installationoftheperipheral devices,werecommend atest-run toensure
thecompatibilityofvehicleand interface.Duetochangesintheproductionofthevehicle
manufacturer there’s always a possibility of incompatibility.
Note: Theinterface cable’s greycolouredIRcableandtheaudioswitchcableareoutof
functionandshouldbeisolated.
Connectthefemale20pinconnectoroftheinterfacecabletothemale20pin
connectorofthevideo-interface.
ConnectthevideoRCAoftheFrontcameratothefemaleRCAconnector“Video IN1”
ofthe20pininterfacecable.
ConnectthevideoRCAoftheRear-viewcameratothefemaleRCAconnector
“camera IN” ofthe20pininterface cable(referalsotochapter“Videosignal
connectionoftherear-viewcamera”)
ConnectthevideoRCAoftheAV sourcetothefemaleRCAconnector”Video IN 2” of
the20pininterface cable.
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page12
2.5.1.Audio-insertion
Thisinterface isonlyabletoinsertvideosignalsintothefactoryinfotainment.IfanAV-
sourceisconnected,theaudioinsertionhastobedonebythefactoryaudioAUX inputoran
FM-modulator.Theinsertedvideo-signalcanbeactivatedsimultaneouslytoeachaudio-
modeofthefactoryinfotainment.
Note:Thepink-andblackcolouredaudioswitchcableisoutoffunction!
2.5.2.After-marketrear-viewcamera
Some vehicleshaveadifferentreversegearcodeontheCAN-buswhichthevideo-interface
isnotcompatiblewith.Inthiscasetherearetwodifferentwaysofinstallation.Ifthevideo-
interfaceis able to detect an enabled vehicle’s reverse gear, the green wire of the 6pin to
12pincableshouldcarry+12Vwhilethereversegearisengaged.
Note:Donotforgettosetvideo interface’s dip5toONbeforetesting.
2.5.2.1.Case 1:CAN-boxreceivesthereverse gearsignal
Ifthe interfacedelivers+12Vonthegreenoutputwireofthe 20pininterface cablewhile
reversegearisengaged,thevideointerfacewillautomaticallyswitchtotherear-view
camerainput“Camera IN” whilethereversegearisengaged.
Additionally,the+12V(max.500mA) powersupplyfortherear-viewcameracanbe
takenfromthegreenwireofthe20pinconnectioncable.
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page13
2.5.2.2.Case 2:CAN-boxdoes notreceivethereverse gearsignal
Ifthe videointerfacedoesnotdeliver+12Vonthegreenwireofthe20pincablewhen
reversegearisengaged(notallvehiclesarecompatible),anexternalswitchingsignalfrom
thereversegearlightisrequired.Asthereversegearlight’s power supply isn’t voltage-
stableallthetime,anordinaryopenrelay(e.gAC-RW-1230withwiringAC-RS5)orfilter(e.g.
AC-PNF-RVC)isrequired.Thediagram belowshowstheconnectiontypeoftherelay.
Disconnect the green cable’s preconnected male-andfemaleconnectorsofthe20pin
cable and connect the green input cable “Reverse-IN” to the output connector (87) of
therelay.
Note:Notleasttoavoidshortcircuits,thebestsolutionshouldbe,tocrimpamale
4mm connector to the relay’s output cable and connect it to the green cable’s female
4mm connector.Theoutput-cable “Reverse-OUT” remains disconnected as it’s out of
function.
Connect the Reverse light’s power-cable to coil (85) and the vehicle’s ground to coil
(86)oftherelay.
Connecttheoutputconnector(87)oftherelaytotherear-view camera’s power-
cable, like you did it to the green “Reverse-IN” cable before.
Connect permanent power / 12V to the relay’s input connector (30).
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page14
2.6. Connectingvideo-interface and keypad
Connectthefemale4pinconnectorofthekeypadtothemale4pinconnectorofthe
20pininterfacecable.
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page15
2.7. Picturesettingsand guidelines
Thepicturesettings areadjustablebythe3push-buttonsonthevideo-interface.Pressthe
MENUbuttontoopentheOSDsettings menuortoswitchtothenextmenuitem.PressUP
andDOWNtochangetheselectedvalue.Thebuttonsareplacedinsideinthehousingto
avoidaccidentalchangesduringoraftertheinstallation.Picturesettings mustbedone
separatelyforAV1andAV2 whilethecorrespondinginputisselectedand visibleonthe
monitor.
Note:TheOSDmenuisonlyshownwhenaworkingvideosourceisconnectedtothe
selectedvideo-inputoftheinterface.
Thefollowingsettings areavailable:
Contrast
Brightness
Saturation
PositionH(horizontal)
PositionV(vertical)
IR-AV1/2(nofunction)
GuideL/R(nofunction)
UI-CNTRL (guidelinesON/OFF)-
adjustments:
“All ON/AllOFF”-Guidelines+PDCON/OFF
Guideon-onlyguidelines
PDCon-onlyPDC
SizeH/V(picturesizehorizontal/vertical)
Note:IfthereisnocommunicationbetweentheCANboxandthevehicle`sCAN-bus
(severalvehicles aren’t compatible), the reversegearguide-linescan`tbeshownduringthe
vehicle’s operation, even if they once appear after having switched the system to powerless!
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page16
3. Interfaceoperation
3.1. Byfactoryinfotainmentbutton
Oneofthefactoryinfotainment buttonscanbeusedtoexecuteinterface functions.
ForSkoda/Volkswagen/Audivehicles
PressMENUbutton toswitchthevideo-source
ForAudi A3vehicles
Press NAVIbuttontoswitchthevideo-source.
ForPorschevehicles
Press NAVbuttontoswitchthevideo-source.
Eachpresswill switchtothenextenabledinput.Inputswhicharenotenabledwillbe
skipped.
Switchover by vehicle buttons isn’t possible in all vehicles. In some vehicles the external
keypadhastobeused.
3.2. Bykeypad
Alternatively or additionally to the factory infotainment buttons the interface’s external
keypadcanbeusedtoswitchtheenabledinputs.
4. Specifications
BATT/ACCrange7V -25V
Stand-bypowerdrain<30mA
Power0.3A@12V
Videoinput0.7V -1V
VideoinputformatsPAL/NTSC
RGB-videoamplitude0.7V with75 Ohmimpedance
Temperaturerange-40°Cto+85°C
Dimensionsvideo-box122 x22 x85 mm(WxHxD)
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page17
5. FAQ –TroubleshootingInterfacefunctions
Foranytroubleswhichmayoccur,checkthefollowingtableforasolutionbeforerequesting
supportfromyourvendor.
Symptom
Reason
Possiblesolution
No picture/black
picture(factory
picture).
Notallconnectorshavebeen
reconnectedtofactoryhead-
unitormonitorafter
installation.
Connectmissingconnectors.
No poweronCAN-busbox (all
LEDCAN-busbox areoff).
Check powersupplyofCAN-busbox.CheckCAN-bus
connectionofCAN-busbox.
CAN-busbox connectedto
CAN-businwrongplace.
RefertothemanualwheretoconnectedtotheCAN-
bus.Ifnotmentioned,tryanotherplacetoconnectto
the CAN-bus.
No poweron video-interface
(allLEDvideo-interfaceare
off).
CheckwhetherCAN-busboxdelivers+12VACC onred
wireoutputof8pinto6pincable.Ifnotcut wireand
supplyACC +12Vdirectlytovideo-interface.
No picture/black
picture/white picture
(inserted picture)but
factorypictureisOK.
No picturefromvideosource.
CheckonothermonitorwhethervideosourceisOK.
No video-sourceconnectedto
the selectedinterfaceinput.
Checksettingsdips1to3ofvideointerfacewhich
inputsareactivatedand switchtocorresponding
input(s).
LVDScablespluggedinwrong
place.
Double-checkwhetherorderofLVDScablesisexactly
connected accordingtomanual.Pluggingintohead-
unitdoesnotworkwhen the manualsaystopluginto
monitorand viceversa.
Wrongmonitorsettingsof
video-interface.
Trydifferentcombinationsofdips7and8ofvideo-
interface.Unplug6pinpoweraftereachchange.
Insertedpicturetotally
wrongsizeorposition.
Insertedpicturedouble
or4timesonmonitor.
Insertedpicture
distorted,flickeringor
runningvertically.
Videosourcesoutputsetto
AUTOorMULTIwhichcauses
aconflictwiththeinterfaces
autodetection.
Set video sourceoutputfixedtoPALorNTSC.Itisbest
toset allvideo sourcestothesamestandard.
Iferroroccursonlyafter
sourceswitching:Connected
sourcesarenotsettothe
sameTVstandard.
Set allvideosourcestothesamestandard.
Someinterfacescanonly
handleNTSCinput.
CheckmanualwhetherthereisalimitationtoNTSC
mentioned.Ifyes,set sourcefixedtoNTSCoutput.
Insertedpictureb/w.
Insertedpicturequal.
bad.
Picturesettingshavenotbeen
adjusted.
Usethe3buttonsandtheinterface'sOSDtoadjustthe
picturesettingsforthecorrespondingvideoinput.
Insertedpicturesize
slightlywrong.
Insertedpicture
positionwrong.
Camerainputpicture
flickers.
Cameraisbeingtestedunder
fluorescentlightwhichshines
directlyintothecamera.
Testcameraundernaturallight outsidethegarage.
Camerainputpictureis
bluish.
Protectionstickernot
removedfromcameralens.
Remove protectionstickerfromlens.
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com

Version17.11.2017HW:CAM(V82)GDRL3-MIB-4
Page18
Symptom
Reason
Possiblesolution
Camerainputpicture
black.
Camerapowertakendirectly
fromreversegearlamp.
Userelayorelectronicsto"clean"reversegearlamp
power.Alternatively,ifCAN-busboxiscompatible
with the vehicle,camerapowercanbetakenfrom
greenwireof6pinto8pincable.
Camerainputpicture
hasdistortion.
Camerainputpicture
settingscannotbe
adjusted.
Camerainputpicturesettings
canonlybe adjusted inAV2
mode.
Set dip3ofvideo-interfacetoON(ifnotinput AV2is
notalreadyactivated)and connectthecameratoAV2.
SwitchtoAV2andadjustsettings.Reconnectcamera
tocamerainputanddeactivate AV2ifnotused for
othersource.
Graphicsofacarin
camerainputpicture.
FunctionPDCisONinthe
interfaceOSD.
Incompatiblevehicles,the graphicswilldisplaythe
factoryPDCdistance.Ifnotworkingornotwanted,set
interfaceOSDmenuitemUI-CNTRLtoALLOFF.
Chinesesignsin
camerainputpicture
FunctionRETorALL isON
(functionforAsianmarket)in
the interfaceOSD.
Set interfaceOSDmenuitemUI-CNTRLtoALLOFF or
PDCON.
Notpossibletoswitch
videosourcesbyOEM
button.
CAN-businterfacedoesnot
supportthisfunctionfor
vehicle.
Useexternalkeypadorcutwhitewireof6pinto8pin
cableandapply+12VimpulsesforAV-switching.
Pressedtooshort.
Forvideosourceswitchingalongerpressofabout 2.5
secondsisrequired.
Notpossibletoswitch
videosourcesby
externalkeypad.
SW-versionofinterfacedoes
notsupportexternalkeypad.
UseOEM-buttonorcutwhite wireof6pinto8pin
cableandapply+12VimpulsesforAV-switching.
Interfacedoesnot
switchtocamerainput
when reversegearis
engaged.
CAN-businterfacedoesnot
supportthisfunctionforthe
vehicles.
Cut thegreenwireofthe6pinto8pincableandapply
+12Vconstantfromreversegear-lampsignal.Use
relayto"clean"R-gearlamppower.
Interfaceswitches
video-sourcesby itself.
CAN-businterface
compatibilitytovehicleis
limited.
Cut thegrey wireof6pinto8pinandisolateboth
ends.Ifproblemstilloccurs,additionallycut the white
wireof6pinto8pincableandisolatebothends.
10R-035384
www.eldibg.com
car audio, multimedia & security systems
All manuals and user guides at all-guides.com
