GE AHB05 User manual

Write the model and serial
numbers here:
Model #_________________
Serial # _________________
You can find the rating label on the
side of the air conditioner.
GE is a trademark of the General Electric Company. Manufactured under trademark license.
OWNER’S MANUAL
AIR CONDITIONER
ROOM
49-5000450 Rev. 1 10-19 GEA
SAFETY INFORMATION .........3
USING THE AIR CONDITIONER
Controls ..............................5
Remote Control .......................6
Cool Mode ............................6
Energy Saver Mode ....................6
Air Direction ..........................7
CARE AND CLEANING
Grille and Case ........................8
Air Filter..............................8
Outdoor Coils .........................8
Install Batteries in Remote ..............8
INSTALLATION INSTRUCTIONS
Before you begin ......................9
Electrical Requirements ................9
Parts Included ........................10
Window Requirements ................ 11
Prepare the Air Conditioner ............ 11
Install the Air Conditioner..............12
TROUBLESHOOTING TIPS......14
Normal Operating Sounds .............15
CONSUMER SUPPORT
Limited Warranty .....................17
Consumer Support ....................18
AHW05
AHB05
AHW06
ENGLISH/ESPAÑOL

249-5000450 Rev. 1
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GE Appliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the packing material.

49-5000450 Rev. 1 3
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
WARNING For your safety, the information in this manual must be followed to minimize the risk of
fire, electric shock or personal injury.
Ŷ8VHWKLVDSSOLDQFHRQO\IRULWVLQWHQGHGSXUSRVHDV
described in this Owner’s Manual.
ŶThis air conditioner must be properly installed in
accordance with the Installation Instructions before it is
used.
ŶNever unplug your air conditioner by pulling on the
power cord. Always grip plug firmly and pull straight
out from the receptacle.
ŶReplace immediately all electric service cords that
have become frayed or otherwise damaged. A
damaged power supply cord must be replaced with a
new power supply cord obtained from the manufacturer
and not repaired. Do not use a cord that shows cracks
or abrasion damage along its length or at either the
plug or connector end.
ŶTurn the unit OFF and unplug your air conditioner
before cleaning.
ŶFor your safety…do not store or use combustible
materials, gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
ŶIf the receptacle does not match the plug, the
receptacle must be changed out by a qualified
electrician.
Ŷ'RQRWXVHPHDQVWRDFFHOHUDWHWKHGHIURVWLQJSURFHVV
or to clean, other than those recommended by the
manufacturer.
ŶThe appliance shall be stored in a room without
continuously operating ignition sources (for example:
open flames, an operating gas appliance or an
operating electric heater.
ŶDo not pierce or burn refrigerant tubing. Be aware that
refrigerants may not contain an odor.
ŶKeep ventilation openings clear of obstruction.
ŶWhen handling, installing, and operating the appliance,
care should be taken to avoid damage to the
refrigerant tubing.
ŶDo not drill holes in the unit.
ŶMaintenance, cleaning, and service should only be
performed by technicians properly trained and qualified
in the use of flammable refrigerants.
ŶGE Appliances does not support any servicing of the
air conditioner.
ŶDispose of air conditioner in accordance with Federal
and Local Regulations. Flammable refrigerants require
special disposal procedures. Contact your local
authorities for the environmentally safe disposal of your
air conditioner.
WARNING
Risk of Fire or Explosion. This unit contains flammable refrigerant.
Additional safety precautions must be followed.

449-5000450 Rev. 1
SAFETY INFORMATION
WARNING USE OF EXTENSION CORDS
RISK OF FIRE. Could cause serious injury or death.
Ŷ'2127XVHDQH[WHQVLRQFRUGZLWKWKLV:LQGRZ$LU
Conditioner.
Ŷ'2127XVHVXUJHSURWHFWRUVRUPXOWLRXWOHWDGDSWRUV
with this Window Air Conditioner.
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third
(ground) prong from the power cord. For personal safety,
this appliance must be properly grounded.
DO NOT use an adapter plug with this appliance.
The power cord of this appliance is equipped with a
3-prong (grounding) plug which mates with a standard
3-prong (grounding) wall outlet to minimize the possibility
of electric shock hazard from this appliance.
Power cord includes a current interrupter device. A test
and reset button is provided on the plug case. The device
should be tested on a periodic basis by first pressing the
TEST button and then the RESET button while plugged
into the outlet. If the TEST button does not trip or if the
RESET button will not stay engaged, discontinue use of the
air conditioner and contact a qualified service technician.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Where a 2-prong wall outlet is encountered, it is your
personal responsibility and obligation to have it replaced
with a properly grounded 3-prong wall outlet.
The air conditioner should always be plugged into its
own individual electrical outlet which has a voltage rating
that matches the rating plate.
This provides the best performance and also prevents
overloading house wiring circuits which could cause a
fire hazard from overheated wires.
See the Installation Instructions, Electrical
Requirements section for specific electrical connection
requirements.
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
READ AND SAVE THESE INSTRUCTIONS
WARNING
Chemical Burn Hazard. Keep batteries away from children.
Ŷ7KLVSURGXFWFRQWDLQVDOLWKLXPEXWWRQFRLQFHOOEDWWHU\
,IDQHZRUXVHGOLWKLXPEXWWRQFRLQFHOOEDWWHU\LV
swallowed or enters the body, it can cause severe
internal burns and can lead to death in as little
as 2 hours. Always completely secure the battery
compartment. If the battery compartment does not
close securely, stop using the product, remove the
batteries, and keep it away from children.
ŶIf you think batteries might have been swallowed or
placed inside any part of the body, seek immediate
medical attention.
Ŷ7KHFHOOVVKDOOEHGLVSRVHGRISURSHUO\LQFOXGLQJ
keeping them away from children.
Ŷ Even used cells may cause injury.

49-5000450 Rev. 1 5
Controls
Controls
1. Power Pad
Turns air conditioner on and off. When turned on, the
display will show the room temperature.
2. Display
Shows the room temperature or time remaining on the
Delay timer. Shows the Set temperature while setting
the temperature in Cool or Energy Saver modes.
3. Temp and Delay Increase + /Decrease –Pads
8VHWRVHWWHPSHUDWXUHRUGHOD\WLPH7HPSHUDWXUH
can be set in Cool and Energy Saving mode.
4. Mode Pad
8VHWRVHWWKHDLUFRQGLWLRQHUWR Fan Only, Cool, or
Energy Saver mode.
5. Fan Speed Pad
In Cool, Energy Saving mode:
8VHWRVHWWKHIDQVSHHGWR Auto, High, Med or Low
on the unit.
In Fan Only mode:
8VHWRVHWWKHIDQVSHHGWR High, Med, or Low
on the unit.
6. Delay Pad
Delay ON—When the air conditioner is off, it can be
set to automatically come on in 1 to 24 hours at its
previous mode and fan settings.
Delay OFF—When the air conditioner is on,
it can be set to automatically turn off in 1 to
24 hours.
How to set:
Press the Delay 1–24hr pad on the unit or the remote
control. Each touch of the Increase + / Decrease –
pads on the unit or the remote control will set the timer
in 1-hour intervals.
To review the remaining time on the Delay 1–24hr
timer, press the Delay 1–24hr pad on the unit or the
UHPRWHFRQWURO8VHWKH Increase +/ Decrease –
pads on the unit or on the remote control to set a new
time if desired.
To cancel the timer, press Decrease – pad on the
unit or the remote control until the set time is zero.
After 3 seconds the light on the Delay 1-24 hour pad
goes off.
7. Filter Reset Pad
This feature automatically notifies you that the air filter
must be cleaned. The indicator light will come on after
240 hours of operation. Clean the air filter (refer to
page 6), place it back in the front panel, and press the
Filter Reset pad. The light will go off.
Features and appearance will vary.
Lights below the touch pads on the air conditioner control panel indicate the selected settings.
+
-
DELAY
MODE
ON/OFF
SPEED
TEMP/TIME
TEMP/TIME
8QLWSRZHU
RQRII
Mode select
Fan speed
Delay 1–24hr
Temperature
VHW'HOD\7LPHU
Increase and
Decrease
Air Conditioner Controls Remote Control
2
6
3
4
5
7
1
CONTROLS

649-5000450 Rev. 1
Using the Air Conditioner
Remote Control
Ŷ To ensure proper operation, aim the remote control at the
signal receiver on the air conditioner.
Ŷ The remote control signal has a range of up to 20 feet.
Ŷ Make sure nothing is between the air conditioner and the
remote control that could block the signal.
Ŷ Make sure batteries are fresh and installed correctly as
indicated on the remote control.
Do Not Operate in Freezing Outdoor Conditions
This cool-only air conditioner was not designed for freezing
outdoor conditions. It must not be used when the outdoor
temperature is below freezing (32°F).
Cool Mode
8VHWKH&RROPRGHDWLow, Med, High or Speed for
FRROLQJ8VHWKHTemperature Increase +  Decrease –
pads to set the desired temperature between 64°F and
86°F in 1°F increments.
An electronic thermostat is used to maintain the room
temperature. The compressor will cycle on and off
to keep the room at the set level of comfort. Set the
thermostat at a lower number and the indoor air will
become cooler. Set the thermostat at a higher number
and the indoor air will become warmer.
NOTE: If the air conditioner is off and is then turned on
while set to a Cool setting or if turned from a fan setting
to a Cool setting, it may take approximately 3 minutes for
the compressor to start and cooling to begin.
Cooling Descriptions
For Normal Cooling—Select the Cool mode and
High or Med fan with a middle set temperature.
For Maximum Cooling—Select the Cool mode
and High fan with a lower set temperature.
For Quieter and Nighttime Cooling—Select the
Cool mode and Low fan with a middle set temperature.
Energy Saver Mode
Controls the fan.
ON—The fan will cycle on and off with the compressor.
This may result in wider variations of room temperature
and humidity. NOTE: the fan may continue to run
for a short time or may pulse intermittently after the
compressor cycles off to sample the room air.
OFF—The fan runs all the time, while the compressor
cycles on and off.
Fan Only Mode
8VHWKH)DQ2QO\0RGHDW/RZ0HGRU+LJKIDQVSHHG
to provide air circulation and filtering without cooling.
Since fan-only settings do not provide cooling, a Set
temperature cannot be entered. The room temperature
will appear in the display.
USING THE AIR CONDITIONER

49-5000450 Rev. 1 7
Using the Air Conditioner
USING THE AIR CONDITIONER
Auto Fan Mode
Set to Auto for the fan speed to automatically set to the
speed needed to provide optimum comfort settings with
the set temperature.
If the room needs more cooling, the fan speed will
automatically increase. If the room needs less cooling,
the fan speed will automatically decrease.
Air Direction
8VHWKHOHYHUWRDGMXVWWKHDLUGLUHFWLRQOHIWWRULJKW

849-5000450 Rev. 1
CARE AND CLEANING
Care and Cleaning
Grille and Case
Turn the air conditioner off and remove the plug from the
wall outlet before cleaning.
To clean, use water and a mild detergent. Do not use
bleach or abrasives.
Air Filter
The air filter behind the front grille should be checked
and cleaned at least every 30 days or more often if
necessary.
To remove:
Slide the filter from the left side of the unit. Remove the
filter.
Clean the filter with warm, soapy water. Rinse and let the
filter dry before replacing it. Do not clean the filter in a
dishwasher.
CAUTION
DO NOT operate the air conditioner
without a filter because dirt and lint will clog it and reduce
performance.
Outdoor Coils
The coils on the outdoor side of the air conditioner should
be checked regularly. If they are clogged with dirt or soot,
they may be professionally cleaned.
How to Insert the Battery in the Remote Control
1. Remove the screw on the back of the battery cover.
2. Pinch the slide lock and pull the battery tray out at the
same time.
3. Insert new battery, making sure that the (+) and (–) of
battery are installed correctly.
4. Reinsert the battery tray and reinstall the screw.
NOTES:
Ŷ8VHRQH&59/LWKLXPEDWWHU\
ŶRemove the battery from the remote control if the
system is not going to be used for a long time.

49-5000450 Rev. 1 9
Installation Instructions
INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•IMPORTANT – Save these
instructions for local inspector’s use.
•IMPORTANT – Observe all
governing codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Skill level – Installation of this appliance requires
basic mechanical skills.
• Completion time – Approximately 1 hour
• We recommend that two people install
this product.
• Proper installation is the responsibility
of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
 <RX0867XVHDOOVXSSOLHGSDUWVDQGXVHSURSHU
installation procedures as described in these
instructions when installing this air conditioner.
Questions? Visit our Website at: GEAppliances.com
ELECTRICAL REQUIREMENTS
7KHVHPRGHOVUHTXLUHDYROW$&
60-Hz grounded outlet protected with a
15-amp time-delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the possibility
of electric shock hazard. If the wall outlet you plan to
use is only a 2-prong outlet, it is your responsibility
to have it replaced with a properly grounded 3-prong
wall outlet.
CAUTION
Do not, under any circumstances, cut or remove the
third (ground) prong from the power cord.
Do not change the plug on the power cord of this air
conditioner.
Aluminum house wiring may present special
problems—consult a qualified electrician.
Power cord includes a current interrupter device. A
test and reset button is provided on the plug case.
The device should be tested on a periodic basis
by first pressing the TEST button and then the
RESET button while plugged into the outlet. If the
TEST button does not trip or if the RESET button
will not stay engaged, discontinue use of the air
conditioner and contact a qualified service technician.
TOOLS YOU WILL NEED
Phillips head screwdriver
Ruler or tape measurePencil
Level Scissors or knife
'ULOODQG´GULOOELW

10 49-5000450 Rev. 1
Installation Instructions
INSTALLATION INSTRUCTIONS
Temp / Delay Hrs
-
Side Curtain
Frame
Type B (9)
Foam top window gasket
Side
Curtain (2)
Top mounting rail
Air
conditioner
Window locking
bracket (1)
Side Brackets
(2)
PARTS INCLUDED
(Appearance may vary)
Remote
Control
Left Right
Type A (3)
+
-
DELAY
MODE
ON/OFF
SPEED
TEMP/TIME
TEMP/TIME
