Genie Intellicode 1022 User manual

OVERVl F POTENTIALHAZARDS
READTHISSAFETYINFORMATI N
Garage doors arelarge, heavy objectsthat move with the help of springs under high tension and electric motors. Since moving
objects, springs under tension, and electric motorscan cause injuries, your safety and the safety of others depend on the owner or
user of this system to read, understandand implementthe informationin this manual. Ifyou havequestionsor do NOT
understandthe informationpresented,contact The Genie Companyor an authorized Genie®Dealer.
The safety alert symboland following signalwords DANGER,WARNING, and CAUTIONare used throughout this manualto call
attentionto and identifydifferent levels of hazard and special instructions.
,& This isthe safety alert symbol. This symbol isplaced next to signalwords and messagesto help you identify
importantsafety information
Theword:
,& DANGERindicatesan imminently hazardoussituation which, if NOT avoided,will result in death or serious injury.
,& WARNING indicatesa potentiallyhazardoussituation which, if NOT avoided, could result in death or serious injury.
,& CAUTION indicatesa potentially hazardoussituationwhich, if NOTavoided, may result in injuryor property damage.
Theword ,_0 is used to indicate importantstepsto be followed, importantconsiderations,or location of parts.
IMPORTANTSAFETYINSTRUCTIONS
READAND FOLLOWALL INSTRUCTIONS
SAVETHESEINSTRUCTIONS
POTENTIAL
HAZARD
MOVINGDOOR
ELECTRICAL
SHOCK
HIGH
SPRING
TENSION
PREVENTION
Keep people clear of openingwhile door is moving.
Do NOTallow children to playwith the door operator.
Do NOToperate a door that jams or one that hasa brokenspring.
Turn OFF power before removingoperator cover.
When replacingcover, make surewires are not pinchedor near
moving parts.
Operator mustbe properlygrounded.
Do NOTtry to remove,install,repair or adjustsprings or anythingto
which door springparts arefastened, suchas, wood blocks,steel
brackets,cablesor otherlike items.
Installations,repairsand adjustmentsmustbe done bya traineddoor
systemtechnicianusingpropertools and instructions.
PN# 3642036534, 02/26/2010 REV, 1

INTELLICODE ®Rolling Code Security System.
An electronic rolling code system that enhances the security of
the door opener by continuously changing the access code
each time the remote control is used. The door opener
responds to each new code only once. An access code copied
from a working system and tried again will not control the door
opener.
Lighted Wall Console*
Operates door opener from inside garage.
(Refer to section 3)
and Car2U ®compatible.
Follow the Homelink ®or Car2U ®instructions in your car
owner's manual.
Safe-T-Beam ®Non-Contact Reversing System**.
Puts an invisible beam across the door opening. The door stops
and reverses to the full open position if anything passes
through the beam. Red or green LED indicator lights on the
power head provide a self diagnostic code if an operational
problem exists. (Refer to Section 10.)
Safe-T-Reverse ®Contact Reversing System.
Automatically stops and reverses a closing door within 2
seconds of contact with an object. (Refer to Section 6.)
Safe-T-Stop ®Timed Reversed System.
Automatically opens a closing door if it fails to close completely
within 30 seconds.
Watch DogTM Monitoring System.
Monitors the Safe=T-Beam@ system to ensure proper function=
ality and will automatically stop and reverse a closing door if a
problem is detected.
Automatic Lighting System.
One bulb lighting supplies up to 75 watts of light for safer
evening exits and entries. Turns ON when door is activated and
automatically turns OFF 3 minutes later.
Manual Emergency Release.
Manually releases door from door opener. Use during a power
failure or other emergency to allow manual opening and closing
of door. (Refer to Section 6.)
PN# 3642036534, 02/26/2010 REV. 1 3

Check your ceiling where the power
head of your new unit will be mounted.
Plan how you will be mounting the power head.
It is possible that ceiling joists may not be in the
position needed with respect to the garage door
opener. It may be necessary to add an
additional bracket and fasteners (not included
with your new door opener kit).
(Refer to Section 2.)
You need a properly grounded 110-120 Volt
power supply available. The outlet should be
no more than 3 feet from the power head once it is
mounted. (Refer to Section 5.)
Check the wall directly above the garage
door. The door opener's header bracket
must be securely fastened to this wall. Insure
that the structure will provide a strong mounting
location. (Refer to Section 2.)
Check to see if the mounting location
for the Safe-T-Beam ®System is clear from
obstruction and has awood surface available
for attaching the mounting brackets. The
brackets may be attached to concrete if necessary
but extra tools and special fasteners (not supplied)
will be required. (Refer to Section 4 and 5.)
_z_t_,:_ code specifications
To avoid damage to your door and/or
opener, make sure you disable and/or
remove any door locks, ropes, and/or cables
(NOT door lift cables) prior to installing your
opener. (Refer to Section 1.)
insure that your door is properly balanced
and moving freely. (Refer to Section 2.)
is your sectional garage door made of
aluminum, light-weight steel, fiberglass
or glass panels? Additional support bracing
must be added to these type doors. If this is the
case, please contact the door manufacturer or
authorized dealer so that they can furnish you
with a "bracing kit." (Refer to Section 2.)
(NOT SHOWN) If your garage does not have
a separate entry door, you should consider
an emergency release kit (GER-2) for installation on
your garage door. (See emergency release kit
installation notes on page 21.)
PN# 3642036534, 02/26/2010 REV. 1

Pg. 13
TYPICAL SUPPORT
BRACKET
(NOT PROVIDED)
Pg. 12-13
ADDED
HEADER BRACKET
MOUNTING BOARD
BRACES
POWER CORD
(APPROX. 45 IN.)
TO 120V GROUNDED
OUTLET
EXTENSION SPRING
OR
TORSION SPRING
NOTE: This opener is designed for
use with SECTIONAL doors only. Pg. 17-18
MIN. 5
SAFE-T-BEAM _
SECTIONAL DOOR
Pg. 17-18
Pg. 12
PN# 3642036534, 02/26/2010 REV. 1 5

Stepladder
Drill
Safety Glasses
3/16" DrillBit
Ratchet
Phillipsscrewdriver
Pencil
Tapemeasure
Carpenter'slevel
Adjustablewrench Wire strippers
1/4",7/16", 3/8"and
1/2" Sockets
Hammer
Safety Brochures
AN
ARRA.GI.G_×CO.TE.TSrORASSe,,B_
Child can be pinned under automatic 9arage door
Dea*hor _eriou_injury canre_ul_
°Neverle_chIdwalkor,un undermovingdoor¸
°Newt le_chIdus_doo,openercontTol_
°AIway_ke_pmovingdoor_n_ght
°. pe,son_sp_n_d pushcontrolbu_onorus_
_mergency,e_ease
Te_,_oorol,_n_rmonthly¸
_o _................. _o_o_
..........°:n::::'X_,::':r:i:,__o_o.__'r4.........
Entrapment Warning
Label
Safe-T-Beam_Source Safe-T-Beam_Sensor
with wire with wire
(Red LED) (Green LED) Wire
Safe-T-Beam_
Sensor Bracket
0000000
0000000000000
DoorArm
o) WallConsole
,-.......................................................................................................................................
Pro Rail (Chain) Section
Header Bracket
OR
Three-button
Door RemoteControl
Bracket
Center Rail Section
,/
Head Rail (Chain) Section
PNi/3642036534, 02/26/2010 REV. 1

0 RAIL SECIlON CLAMP 2
RAILCLAMP BOLT - 5/16"-18 x 5/8" 8
HEX FLANGE NU1- 5/16"-18 8
1 BOLl - 5/16"-18 x 1/2" 3
2 CLEVIS PiN, LONG ---5/16" x 3" 1
COI1ER PiN 1
LHEADER BRACKE 1 1
LAG SCREW - 5/16" x 2" 2
3 HEX BOLt - 5/16".18 x 3/4" 5
HEX FLANGE NUi - 5/16"-18 5
LAG SCREW - 5/16" x 2" 2
4 SELF DRILLING SCREW - 1/4"-20 x 3/4" 3
DOOR BRACKE1 1
5 HEX BOLt - 5/16".18 x 3/4" 3
SELF LOCKING NUi - 5/16".18 1
HEX FLANGE NUi - 5/16".18 2
CLEVIS PIN - 5/16" x 3/4" 1
COTiER PIN 1
6 WALL CONSOLE ASSEMBLY 1
PAN HEAD PHILLIPS SCREW - #4.24 x 1" 2
7 13 MM INSULATED STAPLE 30
8 Safe r-Beam_ SOURCE/SENSOR BRACKE 1 2
PHILLIPS HEX SCREW ---#10-16 x 1- 1/4" 4
WIRE NDI (GREY) 4
NONUMBER REMOTE WITH BATTERY 1
NO BAG Safe r-Beam_ SOURCE/SENSOR & WIRE BE1 1
NONUMBER LIGHi COVER -WHITE 1
NONUMBER LIGH1 COVER -COLOR 1
Rail Clamp Bolt - 5/16"-18 x 5/8"
#10-16 x 1-1/4" Phillips Hex Screw
#4-24 x 1" Pan Head
Phillips Screw
Lag screw - 5/16" x 2"
Wire Nut
©
Self Locking Nut
5/16"-18
©
Hex Flange Nut
5/16"-18
©
Hex Flange Nut
1/4"-20
Self-drilling Screw
1/4"-20 x 3/4" 0
Clevis pin, long 5/16" x 3"
C[] Clevis pin
5/16" x 3/4"
Cotter pin
Hex Bolt - 5/16"-18 x 3/4" Hex Bolt - 5/16"-18 x 1/2" mml
Shoulder Bolt
5/16"-18 x 1"
MISSING ANY PARTS? Please call toll free- 1.800.354.3643
DO NOT RETURNTO POINT OF PURCHASE.
IMPORTANT!- Information needed when calling
, Model number- (located onpackaging)
• Store, city, state, and date ofpurcHase
PNi/ 3642036534, 02/26/2010 REV. 1 7

Power Cord
Carriage Assembly
Rail with chain
Tensioner
t
Header
Bracket
CHAIN
Clevis Pin, Long
& Cotter Pin
Chain
Chain Connector Power Head
Power Cord
Carriage Assembly
CHAIN
Rail Clamp Bolts
End Rail
Tensioner
Chain
Header
Bracket
Clevis Pin, Long
& Cotter Pin
Rail Clamps
Rail with chain
\
Chain Connector Power Head
--...
Rail Clamp Nuts
Center Rail
Release
Knob Rail with belt
_ _,. __
S
_Belt Center Rail
BELT
PNi/3642036534, 02/26/2010 REV. 1

IMPORTANTiNSTALLATiONiNSTRUCTiONS
1. READAND FOLLOW ALL SAFETY, INSTALLATION 5.
AND OPERATION INSTRUCTIONS.f v:_
d n_i nd_)nd_n 6.
,:: ,::......., >' ........ ,:: <) D:,
2. Installonly on a properly balancedsectional garage door.
An improperly balanced door could cause severe injury.
Have a trained door system technician make repairs or
adjustments to cables, spring assemblies, and other 7.
hardware before installing the opener.
3. Removeall ropesand removeor makeinoperativeall
locksconnectedtothe garagedoor beforeinstallingopener.
4. Wherepossible,installthe dooropener7 feet or more 8.
above the floor.Forproductshavingan emergency
release, mount the emergencyreleasewithin reach, but at
least6 feet abovethe floorand avoiding contactwith
vehiclesto avoid accidentalrelease.
Do NOT connect the opener to source of power
until instructed to do so.
Locate the control button:
. Within sight of door,
. At minimum height of 5 feet so small children are not
able to reach it, and
. Away from all moving parts of the door.
Installthe Entrapment WARNING Label next to the Wall
Control button in a prominent location. Installthe
Emergency Release Tagon or next to the emergency
release.
After installing the opener,the door must reverse within
2 seconds when it contacts a 1-1/2 inch high object (or a
2 x 4 board laid flat) on the floor.
I
1oo_h}£Jhdoos
Cleara workspaceareatounpackand organizebox
and contentsforassembly.
1. There are 4 boxes inside the carton. Each box is
numbered 1 - 4. Note that some openers will
contain the same parts and be packaged with
fewer boxes. Carefully remove the three
internal boxes (Labeled #1, 2, and 3) and place
them on the floor for easy access (Fig. 1-1).
These boxes contain assembly parts and the
contents are organized by assembly tasks. For
quick reference inside the lid of each box there is
a label illustrating the components inside.
2. Remove the motor power head and place it on
the floor for later use. Remove box #4 and
place it on the floor for later use.
Bag 1
P_w_r h£ad _
Lag Srews
Bag 3 _/
Box Label Example
PN# 3642036534, 02/26/2010 REV. 1 9

Rail Assembly for CHAIN DRIVE OPENER
3. Remove the two rail sections that are not
connected to the chain and place them on
floor (Fig. 1-2, A).
4. Carefully remove the third rail section with
chain and plastic sleeve. Place rail section on
floor and extend chain straight out
(Fig. 1-2, B). Chain and rail should extend
approximately 7 feet.
5. Remove wire ties and plastic bag from chain.
Leave chain extended straight out on floor.
Avoid kinks in the chain by careful handling and
keeping chain flat on the floor.
6. Align the three rail sections by pulling the
chain straight and wrapping it around the
chain tensioner pulley (Fig. 1-3 & 1-4).
7. Attach the two rail clamps to the rail section
joints with (4) bolts and nuts. After both rail
clamps have been assembled to the rail sections,
securely tighten the bolts and nuts.
Rail Assembly for BELT DRIVE OPENER
3. Remove the two rail sections that are not
connected to the belt and place them on floor
(Fig. 1-2, A).
4. Carefully remove the third rail section with
belt. Place rail section on floor, remove ties on
belt and extend belt straight out (Fig. 1-2, B).
Avoid twists and kinks in the belt by careful
handling and keeping belt flat on the floor. Belt
and rail should extend approximately 7 feet.
5. Align the three rail sections by pulling the belt
straight and wrapping it around the tensioner
pulley (Fig. 1-3 & 1-4).
6. Attach the two rail clamps to the rail section
joints with (4) bolts and nuts. After both rail
clamps have been assembled to the rail sections,
securely tighten the bolts and nuts.
CHAIN DRIVE RAILS
BELT DRIVE RAILS
Belt Rail
Center Rail
Chain
Carriage Assem[ _.
End Rail
Center Rail
Wrap around tensioner pulley
Power Head
Rail with belt
0PN# 3642036534, 02/26/2010 REV. 1

NOTE: Standing at the powerhead, facing the door,
the bullet MUST be on the RIGHT side of the rail.
1. Attach rail assembly to power head by aligning
the sprocket onto the motor shaft. Use (3)
bolts, 5/16"-18 × 1/2" (Fig. 1-5).
2. Tighten the chain by turning the adjustment
nut clockwise. The chain adjustment nut is
located in the Chain Pulley Bracket (opposite rail
end from the power head) (Fig. 1-6).
3. Tighten chain until chain is approximately 1/8
inch above the base of the rail at midpoint on
the rail (Fig. 1-6). Do NOT over tighten chain.
Set assembled power head and rail aside. Begin with
Section 2 INSTALLATION.
Assembly for BELT DRIVE OPENER
_FOTE: seAaF nus*_4_be," _?om po%_?_-head
NOTE: Standing at the powerhead, facing the door,
the bullet MUST be on the RIGHT side of the rail.
1. Attach rail assembly to power head by aligning
the sprocket onto the motor shaft. Use (3)
bolts, 5/16"-18 x 1/2" (Fig. 1-5).
2. Tighten the belt by turning the adjustment nut
clockwise. The belt adjustment nut is located in
the Belt Pulley Bracket (opposite rail end from the
power head) (Fig. 1-7).
3. Tighten belt until belt is approximately 1/8 inch
above the base of the rail at midpoint on the
rail (Fig. 1-7). Do NOT over tighten belt.
Set assembled power head and rail aside. Begin with
Section 2 INSTALLATION.
Chain Pulley Bracket (at wall end of rail)
2-'Ose 1, "soc,et
_, on adjustment nut
Tighten nut to move pulley this direction
Chain
"T-Rail
T-Rail at center of rail assembly
i#iii#i!iiiii#iiiii!i'i_iiii!il¸i_iiii_iiii!i¸ili#iiiiiill¸i_iii!i¸ili#iiiiiill¸i_iii!i¸ili#iiiiiill¸i_iii!i¸ili#iiiiiill¸i_iii!i¸ili#iiiiiill¸i_iii!_ii@i;i_iii!ii!i¸i_i_ii_i_i_i_!ili=i!i!i!i;iiii_iil¸i_iiii!i_i_i#!i_i_i_i_=i_;_ii_i_:_i_i;;_!i!_i!i_!i_i_i_i_!!!!_!_i!;_!!_!_ii:i_i_i_¸IIIII¸_!_ili!_¸i_i_ii_ii;i_i_i_i_ii_i_II!¸II_I¸ii!i_#iiiiii!!iiiiiii!!iiiiiii!!iiiiiii!!iiiiiii!!iii!i!i_ii!#_i_iiiiii¸i_ii#i¸i_iii!i¸ili#iiiiiill¸i_iii!i¸ili#iiiiiill¸i_iii!i¸ili#iiiiiill¸i_iii!i¸ili#iiiiiill¸i_iii!i¸ili#iiiiiill¸i_iii!i¸ili#iiiiiill¸i_iii!i¸ili#iiiiiill¸i_iii!i¸ili#i!i_i!!!#¸i=ili¸i=ili¸i¸i!il
Belt Pulley Bracket (at wall end of rail)
_b,_/Use 1/2" socket
_- I t _\_._/l_d on adjustment nut
Tighten nut to move pulley this direction
Belt
T-Rail at center of rail assembly
Belt
Remove
Remove
"T-Rail
PN# 3642036534, 02/26/2010 REV. 1 1 1

12
1. Finding header bracket mounting location.
• Close garage door.
-Use a pencil and level.
a) Mark center of garage door (one-half overall
width) on the wall with 6" vertical line at top
edge of door.
b) Continue this line on wall above door for
about 12" (Fig. 2-1, a).
•Raise garage door until top edge of door
reaches its maximum height (Fig, 2-2).
•With door at highest point.
- Measure height from top edge of door to floor
(Fig. 2-2).
•Close door again.
°Mark height measurement on wall above door
(Fig. 2-1, c),
- Make your mark across vertical line made earlier,
° Add 2-1/2' to height mark just made on wall. This
is location for header bracket (Fig. 2-1, d).
NOTE: ff header bracket _ocaZion needs to be
above header for garage door opening, you need
to add a "mounting surface." A 2" x 6" board
securdy adached (board and fasteners not
#ncluded) to waft studs on either side of your mark
is sufficient (Fig. 2o3).
NOTE: For header bracket and bolts locate Bag 2
from Box f.
NOTE: The bol_s supplied in Bag 2 are designed
[o be used on pressure trea_ed lumber.
2. Mounting the header bracket.
• Hold header bracket against wall (Fig. 2-3).
• Position bracket as shown.
- Place center on vertical line,
- Bottom edge on final height line.
° Mark screw hole locations on wall.
• Drill 3/16" pilot holes at each screw hole mark.
- Fasten header bracket with 2 lag screws
(provided) (Fig. 2-3).
b) -extend
vertical line
SECTIONAL
DOOR
FROM HERE !
il ::
PN# 3642036534, 02/26/20t0 REV !

1. Getting started.
, Position assembled rail on wall next to header
bracket (Fig. 2-4).
-Place material on floor under power head to
protect from scratching. (A box, stool, or
similar device may be needed to clear a
torsion spring.)
Sos< 1=
=Mounting the assembly.
, Attach rail to header bracket using clevis pin
and cotter pin (Fig. 2-5).
, Support power head on step-ladder to prevent
interference with header mounted (torsion)
spring.
NOTE: SeF0_,e [JY?ss schryen ito c®_ng_ ms_: _
ths sssery b?y _:;mpmd;_e_°sh:_i?myen (F: _3 2.-4)
3_bom Bo:_" I
, On finished ceilings, locate ceiling joists or
trusses using a stud finder or similar device.
Attach angle iron (not provided) to joists or
trusses through finish material using (provided)
lag screws (Fig. 2-6).
, On unfinished ceilings or open ceilings, straps
may attach directly to joists or trusses.
Depending on the garage construction, extra
framing material (not provided) which may be
required should be installed using appropriate
construction techniques (Fig. 2-6).
NOTE: Ref'e _o you Ioc_t bu)i_r_j codes _;1_"
, Attach mounting straps (not provided) to ceiling
using lag bolts (Fig. 2-6).
, Set height of power head to following (Fig. 2-6).
a) Rail must clear door at door's highest point
of travel.
b) Be level or power head slightly below level.
, Securely tighten power head mounting bolts
and nuts.
, Carefully raise and lower door manually. Ensure
door does not contact any section of power head
or rail.
, Check that rail clamp bolts and nuts are tight.
, DO NOT PLUG OPENER IN YET!
COTTER PIN
(Chain drive
shown)
ANGLE IRON ON FINISHED CEILING
_/DRYWALL
_J©_o oooo oo£01
Attach angle iron to beams
UNFINISHED OR OPEN BEAM
Extra framing
not needed
Mounting Straps
(not provided
bolts & nuts
bolts & nuts
Extra framing
NEEDED
iJ!iiiii_il_iiiiiiiiii! ii_iii _;!i,l!_!i!_, ;,:i_!_ai,i,!,,,,,!,,i!,

Iuos oc,s, eS_?{;I
fro_, £!;os'2
I,
2,
Finding door bracket mounting location.
.Door bracket is mounted as high on door as
possible along vertical centerline and NO LOWER
THAN top set of rollers (Fig. 2-7).
Mounting the door bracket.
• Proper bracing should be verified at this point.
- Align door bracket centered on your vertical
centerline (Fig. 2-8).
- Attach using 3 self-drilling screws for sheet
metal or other light weight material.
- Use lag screws (not provided for solid
wooden sectional doors.
NOICE: _:_;,"door am? nuIs and bo Is, cMds snd
co_/_y piJ?s oca_e Bag 5i7o_yBox 2
1. Attach the arms.
,Fasten short branch of curved door arm to door
bracket using bolt and locking nut (Fig. 2-9).
,Fasten straight arm to carriage using short
clevis pin and cotter pin (Fig. 2-9).
2. Connecting the arms.
, Slide carriage back and forth to adjust arm length.
-Position the straight arm 50 ° down from the
rail.
, With the arms arranged in this position, fasten
arms together using bolts and nuts spaced as
far apart as possible (Fig. 2-9).
i
short clevis pin & cotter pin
bolts as far
apart as
possible
4PN# 3642036534, 02/26/2010 REV. 1

NOTE: For 14,9}IfConsole, _,Nreand ,_}suia_d
staples tecate _9-s 6 and 7 Dom Box 2,
1. Wall Console location.
• Wall Console location should be in direct sight
of door.
- It should be at least five feet (5') above floor to
prevent small children from operating door.
• tt must be away from any moving parts. ('You
should NOT be able to reach the garage door
while standing at Wall Console,)
• Wall Console board screw connections are
polarized.
2a. Wiring (if pre-wired).
• Locate wall console pre-wired wire ends
(Fig. 3-1) (They should be located within the
guidelines mentioned above.)
• Split and strip ends of wire (Fig. 3-2).
• Fasten wire to wall console board screws on
back of wall console.
- Striped wire to the B (plus) terminal.
- White wire to the W (minus) terminal.
2b. Wiring (If NOT pre-wired).
. Pick a convenient location for mounting
wall console using the guidelines mentioned
above (Fig. 3.1).
• Run wire from wall console to power head
(Fig. 3-1).
• Split and strip ends of wire (Fig. 3-2).
• Fasten wire to control board screws on back of
wall console.
- Striped wire to the B (plus) terminal.
- White wire to the W (minus) terminal.
Wire from
_oOWer head
wanconsole.
Separate
entry door
Wall
console
[_ "Ent_ment'[
warning laDel
___ EXAMPLE ONLY!
This is an example of wire routing
when NOT pre-wired. Your wire
------------ routing may be different.
:_:i:i!'i 7}!7iiii!ii_ii}777!:!i!i;i!ii_ii!_:;iiiii_i?;Ti;ii!':i!i!ii!ili!i_::_!iii7i<i_11!_!!;!!;:_ii!!;!i _:i
::[i_:i: :_]!__i_:!_i[:iii_il:i_:::<IXli ::iii:::i:7:it[:::::::77:L:_i:::}i',7::i_}it}!tiii ti_!_iT,:t:::::7: :::7i
:i!:::::!<!_i_7:ii_i;iiiiii!ii!iiii_klii_iiiiiiiiTii!i7!i:i7'_!i!:;iiTki_iiii!iii(iiii!iiiii_i:ii:::_;i_ii::i;!:i_;:::i(;i;i!iii
;:! :::}:}i_::i::_ii!_iiiiiii!iJiiii!ii}ii:!_!i:!iifil!i_;iiiiT!ili¢i!i!ii!':_i_,!i!i__!!!_!!!!;i!;iiiiiii_ii'_itii!tiii!!;!it}
7::7i_;}::ii !'_iiiii!iiT;'Tii}i:i!_iiTi:i iiliihi![!i_i:"!i!iiTii}iTi_!i}iTi}iii!7_,i,i2}!i_f._t7[7_5i;[!i7,iiiDi_}[ii_;_!iiiiiii._?#
i ::i; i:!:i1177iTiiiiii;iiiililill!i_:i!iiili_17iiii!iiiTiiii!!!!iiiiii iiii_:_!iiiiT!i!i :_
i)ii)iiiii!Tiiiiili il)
:::_!7 1!i _P!if!!,g _g _ifiPi[_i!' 7: _:_ : ; i
:7:::::::c777:7::{7::;Tt_{{77_TL;f: :7+7{{f{{7{,,777{7f:i{{7]:{_,7::::f:7,.Y. 7 {_,i,,{:7] 7 7.: } 7,{ 7:;+{,;,: 7::7::_: L,7
7:_7777:77i{77!i_!i=,iii!i_ _:_1177f_LT'7_7{{7777]{;{71'7::17777',7_"k;77 7_:7,:7:!77
{:77:{i{:2:{7i_{:{i{'{77{7{7{!{f{7{{:2{}77{{77{{7{{7{7i7f{{'7:,71f{ 7:7{7{777f{ 11{{{{{7{7 {71177{){i77{:{77)27iifir7:j7{
77i:iT:iiTi!!i!i{7i77:17i7777:77::: 777777::7;7;{,:777777 ::7!7i77: 7: :77i-177 i
7}: ;; _i:;:i:il;:_ii!;_!};_ii!i)i!)71;i;'.iDi!7_!!!:ii!it;i;!i;_;_ii!i:_!; i<i;_)i::7_>/:i:{i;ii!!i)!i!ii!i_!)?iii:;i;
7{::]777{!{7 [Z]][ 7<7{7 ]{]_}{7_'7_77_?777;7777{7?71{__!"7_7!!{7{77(_!{7_7!}!'77{'7"7777_1_7t[YT;{77"7{7"3{:i!_7!7{+}+_77::_}H7!_7_I{72_77{{:777J
I
!_i_ii!ii_i!iii_i_!ii!7iiiiiiiii_iiii_iii_!i_ii7_i_i7i!ii_!!_!_!_!i!iii_i_i_i_i!iii!_iii_iiii_iii!:_!_iii7!_ii_i_7_!iii_ii_ii_!_i_i7i7i_!ii!_ii!i
PAl#3642036534. 02/26/20t0 REV.. 7 15

i
16
3.Securely fasten wires.
• Securely fasten wires to ceiling and
wall using insulated staples provided.
-Use insulated staples.
- Staples should be snug only. Insulated
•If rear cover is attached to power head, Staple
remove it,
•On power head:
- Route wall console wires through wire guide on
power head.
- Split and strip ends of wire (Fig. 3-2 on
previous page).
-Insert wire into terminal holes and lightly press in
the orange locking clips above each terminal
hole. (You can use a pencil or small screwdriver
to comfortably press in locking clips,) The white
wire into #t terminal hole and striped wire into
the #2 terminal hole.
- Confirm wire lock by lightly tugging on the wire,
The wire should remain in the terminal hole.
• Do NOT install rear cover yet.
4. Mounting,
• Fasten wall console to wall with 2 screws
(provided) (Fig. 3-4).
• Remove protective backing from "Entrapment"
warning label (Fig. 3-5). The "Entrapment" label
is located in the center of this manual.
- Stick label on wall near wall console.
_ii_.E|6_ii_:_3i_ii_i|_e_i._:i_es::_!i_i_ii_iii:i!i!ii!iii_ii:ii_ii_i_ii:_:iii_ii:_ii!_:;!ii!i_ii_:!;1_!!_ti!i_:_ii_::ii;ii!ii
_iii_i!_i_!i_!i!ii_i_i_!i_!iiiiiiiii_ii_ii_i!_ii_i_:ii!i!_i_!?i_iiiii:i_:::iiii!iii!i_i_!i_!_iiiii_ii:i_i:ii_i_!:!i:_i:_i!!i!!!_>_ii_ii_!Ki!:_i_iii:i!
PN# 3642036534, 02/26/2010 REV. I

NOTE: For SaYe-T.BeamC_,screws, _Mre,and
insulated s_ap_es_ocate _,,_:emsa,,d Bag 8 frown Box 3,
1, Mounting brackets.
• Mark both sides of garage door frame or wall no
higher than 6" and no lower than 5" above floor
(Fig. 4-1),
• Hold bracket against door frame or wall.
- Check if brackets extend out from wall far
enough, so tongue of bracket is beyond door,
tracks or any door hardware.
-If not:
a) Mounting bracket extensions are available
through an authorized Genie _ Dealer.
b) Blocks of wood, etc. may be substituted for
extensions.
• Center bracket on your mark (Fig. 4-2).
• Fasten each with 2 screws (Fig. 4-2).
NOTE: M,oun_ing bmcket_ _._,,'_'_b_,_a_ached to _._he.
fioo_o_concrete _":_t_us,_:_gconcrd_ _nch_'_
_ot pro_e,d).
2. Mounting Safe-T-Beam _'Source (Red LED) and
Sensor (Green LED),
• If garage has only one garage door.
- Determine which side of garage receives most
direct sunlight (Fig. 4-4).
- Red LED should always be on sunny side
whenever possible (Fig. 4-4).
,For multiple doors.
- Preventing crossed signals is critical.
-Place source and sensor modules on adjacent
doors facing in opposite directions (Fig. 4-4).
N077i; ?_ he_p _rever# fni°e_'f_rence from su_,
_hough extended no further out from _'he waft
where f_will spend morn time in shadow.
• Slide sourcelsensor onto tongue of bracket until
it clicks into place (Fig. 4-3).
3a. Wiring (If NOT pre-wired).
• Route wire from Safe-T-Beam" to power
head using method shown in (Fig. 4-5a).
• Securely fasten wires to wall and ceiling 5:P
as you go (Fig. 4-6 on next page).
-Use insulated staples.
-Staples should be snug only, Insulated
Staple
i!ii ii !! i!i! iiiiiiiiiiiiiii!iii iiiii!i!iii!!iiiiiiiiiiiii!iiiii!i!ii!iiii!iii!iiii iiiiii
:_!i;iil;:iiiiii_}iiiiii}iiili!i;i_i_;i_!ii;iii!iii,iiii_ii_,iiii_i_i!i}ili i} i,:! ili:,:,!i;_!
::'.::!i:[_i!i[i!-_if_[i[i_fil![i:iii_[i[i!-'.- )_'_ _i i_!iiii,ili: if_i!iiii:_ili,;h::,! i f i:i
I
PN# 3642036534, 02/26/2010 REV. tt7

I
3b.
®
®
®
Wiring (pre-wired).
Route wire from wall to Safe-T-Beam _sensors
(Fig. 4-5b).
Splice pre-wiring to shortened sensor wire,
match wire pairs dash-to-dash and
plain-to-plain.
- Trim sensor wire to approximately one foot
(1 ft) from sensor.
- Split and strip ends of sensor wires and
pre-wired wires (Fig. 4-7).
- Splice wires together with (provided)
wire nuts.
Route wire from ceiling to power head Wire Nut
(Fig. 4-5b).
Securely fasten wires where they exit
wall and ceiling as you go.
-Use insulated staples.
-Staples should be snug only. Insulated
Staple
4. Split and strip ends of sensor wires (Fig. 4-7).
5. Attach Safe-T-Beam ®wire to power head wire
terminal.
• Route Safe-T-Beam _wires through wire guide.
-Insert wire into terminal holes and lightly press
in the orange locking clips above each terminal
hole. (You can use a pencil or small
screwdriver to comfortably reach in and lightly
press down locking clips.) Insert white wires to
'even' numbered terminal holes and striped
wires into 'odd' terminal holes (Fig. 4-5b).
Locking
i,l_s x_ Terminal
F_/Holes
/F%q F%q
- Confirm wire lock by lightly tugging on the wire.
The wire should remain in the terminal hole,
• Install rear cover, The rear cover is the same
color as the power head clips and body
(Fig. 4-9).
, Do not install the white (lamp) cover at this time.
Power (
Head
'1 '1
I I
i6S 43 21]or165 43 211
)Dashed Line = striped wire Solid Line = white wire
Insert Wire
Wire Into Connector .... "'"
__ Wires
i IlJ_: _=_ _ _ [=_' ' i[ wirer°utinged
Source or Sensor
Source or Sensor ro ec ion rea
Cover clips
8PNi/ 3642036534, 02/26/2010 REV. 1

i[ Motor Cover Screws
ii!ii!}iiiiii!¸}iiiii!i!iiiii!iiiiiii ili!i! iii!il¸ ii i ii! il¸i
Plug the opener into a properly grounded
electrical outlet (Fig. 5-1).
Instructions for Electrician.
• Remove power from circuit.
° Remove rear cover and motor cover.
- Remove four motor cover screws (Fig. 5-2}.
• Remove existing power cord and strain relief
from the 7t8" dia. hole and discard (Fig. 5-3).
- Connect permanent wiring to power head using
7/8" diameter hole.
- White to white/black to black!ground to green.
- Use only UL recognized wire nuts.
• Wires inside the power head must be at least 6"
in length.
• Replace motor cover and rear cover and
re-energize the circuit.
_OZ_: The Gen_ C_paRy is no_ responJ.b_ _%_
/r__t et'_ctricf_zr_,
Check Safe-T-Beam" alignment (Fig. 5-4).
• Insure that no part of door or its hardware is
in path between lenses of source and sensor.
•Insure that tops of lenses are between 5" - 6"
above the floor (Fig. 5-4). The brackets are
flexible, and can be adjusted slightly if needed.
• Adjust the Red LED source by aiming the
unit directly at the Green LED sensor. Use the
adjustment screw located on the top of the
source housing to make adjustments.
•The Red LED source will blink ifthere is a
misalignment. When the LED units are aligned
the Red LED will remain ON continuously.
• After the alignment is finished tighten the
adjustment screws on Safe-T-Beam®.
i!! Ii!
• Do NOT use an extension cord. I
• Do NOT use a portable generator. This product
is designed to operate using standard
household current.
• Do NOT use alternate power supplies,
1. When the garage door is opening, its movement
will not be influenced if the Safe-T-Beam" is
obstructed.
2. If the Safe-T-Beam _ is obstructed before the
garage door fully closes, the door will not close.
3. When the garage door is closing, if Safe-T-Beam''
is cut off by people or obstacle, the garage door
will reverse automaticallyto its fully opened position.
(Meanwhile, the opener lightwill keep blinking until
door moves to its fully opened position.)
4. If the Safe-%Beam _ System fails, loses power,
or is installed improperly, you will have to press
and hold the wall control "close" button until the
door reaches its fully closed position. The LED
indicator light on the power head will be green
and blink twice (Pattern: _ pause -_ pause)
to inform you to eliminate problem first.
Otherwise, the door will reverse automatically to
its full_ opened position if you release the
"close' button on the wall control during the
closing movement.
PN#3642036534, 02/26/2010 REV. I 19

I
The OPEN (UP) and CLOSE (DOWN) door positions
are controlled by making the adjustments on the
panel located on the bottom of the power head. The
adjustments that can be made are:
•Close Travel Limit,
• Open Travel Limit,
Maximum Closing Force
Maximum Opening Force
Transmitter Programming
ENGAGE CHAIN/BELT CONNECTOR TO
CARRIAGE
1. Press and hold the "Close Travel Limit" D button
until the chain or belt connector advances and
engages to the Carriage Assembly (FIG 6-2).
CLOSE TRAVEL LIMIT
1. Press and hold the "Close Travel Limit" D button
until the door is fully closed.
2. You can quickly press and release the "Close
Travel Limit" [] button to move the door in small
increments. You can also use the "Open Travel
Limit"[] button to move the door slightly in the
UP direction.
3. Door is fully closed when the bottom edge of door
presses firmly onto the ground.
4. Once the door is in the desired position, press and
release the "Close SET Limit" [] button for 5
seconds. The LED indicator light will blink green
once. This stores the closed position in memory.
OPEN TRAVEL LIMIT
1. Press and hold the "Open Travel Limit" [] button
to move the door to its fully opened position. This
starts the opener moving in the UP direction.
2. Hold the "Open Travel Limit" [] button until the
door is in the fully opened position that you desire,
then release this button.
3. You can quickly press and release the "Open
Travel Limit"[] button to move the door in small
increments. You can also use the "Close Travel
Limit" [] button to move the door slightly in the
DOWN direction.
4. Once the door is in the desired position, press
and release the "Open SET Limit" [] button for 5
seconds. The LED indicator light will blink green
twice. This stores the opened position in memory.
To
Garage Door
LED
Indicator Light Open Open Bet Limit Up Force
\ ..... Travel Limit Button OPEN Control
//_ I /!_(1'_x 2 [ _L_/_)_ustment
i A,
',\ "-_' '\ /SET
....I II
LEARN MANUAL LIMIT FORCE
\
Code CODE Close CLOSE Down Force
Button Close
Travel Limit Set Limit Control
Button Adjustment
Latch
Movement
Carriage Assembly
Latch
Movement
Carriage Assembly
Belt Connector
Latch
Movement
0PN# 3642036534, 02/26/2010 REV, 1
