Genie gS-1530/32 Installation and operating manual

Service and Repair Manual
GS-1530/32
This manual includes:
Repair procedures
Fault Codes
Electrical and
Hydraulic
Schematics
GS-1930/32
GS-2032
GS-2632
GS-3232
For detailed maintenance
procedures, refer to the
appropriate Maintenance
Manual for your machine.
GS-2046
GS-2646
GS-3246
GS-4047
Part No. 1272217
Rev B
April 2017

Service and Repair Manual April 2017
Introduction
ii GS-30 • GS-32 • GS-46 • GS-47 Part No. 1272217
Intr od ucti o n Intr od ucti o n
Important
Read, understand and obey the safety rules and
operating instructions in the appropriate Operator's
Manual on your machine before attempting any
procedure.
This manual provides troubleshooting and repair
procedures for qualified service professionals.
Basic mechanical, hydraulic and electrical skills are
required to perform most procedures. However,
several procedures require specialized skills, tools,
lifting equipment and a suitable workshop. In these
instances, we strongly recommend that
maintenance and repair be performed at an
authorized Genie dealer service center.
Compliance
Machine Classification
Group A/Type 3 as defined by ISO 16368
Machine Design Life
Unrestricted with proper operation, inspection and
scheduled maintenance.
Technical Publications
Genie has endeavored to deliver the highest
degree of accuracy possible. However, continuous
improvement of our products is a Genie policy.
Therefore, product specifications are subject to
change without notice.
Readers are encouraged to notify Genie of errors
and send in suggestions for improvement. All
communications will be carefully considered for
future printings of this and all other manuals.
Contact Us:
Internet: www.genielift.com
E-mail: [e-mail]
Find a Manual for this Model
Go to http://www.genielift.com
Use the links to locate Service Manuals,
Maintenance Manuals, Service and Repair
Manuals, Parts Manuals and Operator's Manuals.
Copyright © 2016 by Terex Corporation
1272215GT Rev B, April 2017
First Edition, Second Printing
Genie is a registered trademark of Terex South Dakota, Inc. in
the U.S.A. and many other countries.
“GS” is a trademark of Terex South Dakota, Inc.

April 2017 Service and Repair Manual
Introduction
Part No. 1272217 GS-30 • GS-32 • GS-46 • GS-47 iii
Serial Number Range
Use the following chart to identify the specific serial
number for models included in this manual.
Models
Serial number
GS
-1530 / GS-1532
GS
-1930 / GS-1932
from SN GS3010A
-110000
from SN GS3011C
-10000 to
GS3016C
-23999
from SN GS3014D
-101 to
GS3016D
-607
from SN GS3016P
-151487 to
GS3016P
-160599
from GS30C
-24000
from GS30D
-6080
from GS30P
-160600
GS
-2032/2632/3232
from SN GS3211A
-110000
from SN GS3212C
-10000 to
GS3216C
-17299
from SN GS3216P
-142676 to
GS3216P
-148699
from GS32C
-17300
from
GS32P-148700
GS
-2046/2646/3246
from SN GS4612A
-110000
from SN GS4612C
-10000 to
GS4616C
-18099
from SN GS4614D
-101 to
GS4616D
-5029
from SN GS4616P
-138362 to
GS4616P
-141799
from GS46C
-18100
from GS46D
-5030
from GS46P
-141800
GS
-4047
from SN GS4712C
-101 to
GS
4716C-4499
from SN GS4714D
-101 to
GS4716D
-3959
from GS4716P
-101 to
GS4716P
-999
from GS47C
-4500
from GS47D
-3960
from GS47P
-1000

Service and Repair Manual April 2017
Introduction
iv GS-30 • GS-32 • GS-46 • GS-47 Part No. 1272217
Revision History
Revision Date Section Procedure / Page / Description
A 3/2016 Initial Release
A1 5/2016 Repair Procedures 2-3, 2-4, 9-11
Diagnostics H067 fault
A2 5/2016 Repair Procedure 2-6
Diagnostics Type CXXX and UXXX fault codes
A3 9/2016 Introduction Serial Number Legend
Specifications Add drive speed stowed parameters
B 4/2017 Repair Procedure 11-1
Diagnostics Battery charger and fault codes
Reference Examples:
Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Repair Procedure, 4-2
Section – Fault Codes, All charts
Section – Schematics, Legends and schematics

April 2017 Service and Repair Manual
Introduction
Part No. 1272217 GS-30 • GS-32 • GS-46 • GS-47 v
Revision History(continued)
Revision Date Section Procedure / Page / Description
Reference Examples:
Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Repair Procedure, 4-2
Section – Fault Codes, All charts
Section – Schematics, Legends and schematics

Service and Repair Manual April 2017
Introduction
vi GS-30 • GS-32 • GS-46 • GS-47 Part No. 1272217
Serial Number Legend
To August 31, 2016
1 Model
2 Model year
3 Facility code
1 Sequence number
2 Serial label (located on chassis)
3 Serial number (stamped on chassis)
From September 1, 2016
1 Model
2 Facility code
3 Sequence number
1 Serial label (located on chassis)
2 Serial number (stamped on chassis)

April 2017 Service and Repair Manual
Safety Rules
Part No. 1272217 GS-30 • GS-32 • GS-46 • GS-47 vii
Section 1 Safet y R ul es
Danger
Failure to obey the instructions and safety rules in
this manual and the appropriate Operator's Manual
on your machine will result in death or serious
injury.
Many of the hazards identified in the operator's
manual are also safety hazards when maintenance
and repair procedures are performed.
Do Not Perform Maintenance
Unless:
You are trained and qualified to perform
maintenance on this machine.
You read, understand and obey:
•manufacturer's instructions and safety rules
•employer's safety rules and worksite
regulations
•applicable governmental regulations
You have the appropriate tools, lifting
equipment and a suitable workshop.

Service and Repair Manual April 2017
Safety Rules
viii GS-30 • GS-32 • GS-46 • GS-47 Part No. 1272217
Personal Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Read each procedure thoroughly. This
manual and the decals on the machine,
use
signal words to identify the following:
Safety alert symbol
—
used to alert
personnel to potential personal
injury hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Indicates a imminently hazardous
situation which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous
situation which, if not avoided,
could result in death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may cause mi
nor or moderate
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may result in property damage.
Be sure to wear protective eye wear and
other protective clothing if the situation
warrants it.
Be aware of potential
crushing hazards
such as moving parts, free swinging or
unsecured components when lifting or
placing loads. Always wear approved
steel
-toed shoes.
Workplace Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Be sure to keep sparks, flames and
lighted tobacco away from flammable and
combustible materials like battery gases
and engine fuels. Always have an
approved fire
extinguisher within easy
reach.
Be sure that all tools and working areas
are properly maintained and ready for
use. Keep work surfaces clean and free of
debris that could get into machine
components and cause damage.
Be sure any forklift, overhead cr
ane or
other lifting or supporting device is fully
capable of supporting and stabilizing the
weight to be lifted. Use only chains or
straps that are in good condition and of
ample capacity.
Be sure that fasteners intended for one
time use (i.e., cotter
pins and self-locking
nuts) are not reused. These components
may fail if they are used a second time.
Be sure to properly dispose of old oil or
other fluids. Use an approved container.
Please be environmentally safe.
Be sure that your workshop or
work area
is properly ventilated and well lit.

April 2017
Table of Contents
Part No. 1272217 GS-30 • GS-32 • GS-46 • GS-47 ix
Introduction Introduction...........................................................................................................ii
Important Information ............................................................................................. ii
Find a Manual for this Model .................................................................................. ii
Serial Number Range ............................................................................................ iii
Revision History..................................................................................................... iv
Serial Number Legend .......................................................................................... vi
Section 1 Safety Rules ........................................................................................................vii
General Safety Rules ........................................................................................... vii
Section 2 Specifications .......................................................................................................1
Machine Specifications...........................................................................................1
Performance Specifications (models without proportional lift function)..................3
Performance Specifications (models with proportional lift) ....................................5
Hydraulic Oil Specifications....................................................................................7
Hydraulic Component Specifications....................................................................10
Manifold Component Specifications .....................................................................11
Hydraulic Hose and Fitting Torque Specifications ...............................................12
Torque Procedure ................................................................................................13
Section 3 Repair Procedures .............................................................................................15
Introduction...........................................................................................................15
Platform Controls ...............................................................................................17
1-1 Circuit Board...................................................................................................19
1-2 Joystick...........................................................................................................20
1-3 Platfrom Controls Alarm .................................................................................20
1-4 Platform Emergency Stop Button...................................................................21

April 2017
Table of Contents
x GS-30 • GS-32 • GS-46 • GS-47 Part No. 1272217
Ground Controls ................................................................................................ 22
2-1 Software Revision Level ................................................................................ 23
2-2 Machine Setup ............................................................................................... 24
2-3 Loading or Updating Machine Software ........................................................ 25
2-4 Using a Wi-Fi Router to Connect to the SmartLink Web Service Tool.......... 30
2-5 Service Override Mode .................................................................................. 32
2-6 Level Sensors ................................................................................................ 34
2-7 Manual Platform Lowering Cable................................................................... 49
2-8 Outrigger Calibration...................................................................................... 51
Hydraulic Tank ................................................................................................... 52
3-1 Hydraulic Tank ............................................................................................... 52
Hydraulic Pump.................................................................................................. 53
4-1 Hydraulic Pump ............................................................................................. 53
How to Remove the Hydraulic Pump.............................................................. 54
Manifolds ............................................................................................................ 56
5-1 Function Manifold Components –
GS-1530, GS-1532, GS-1930 and GS-1932 ............................................... 56
5-2 Function Manifold Components – GS-2032, GS-2632, GS-3232,
GS-2046, GS-2646 and GS-3246 ................................................................ 58
5-3 Function Manifold Components – GS-4047 .................................................. 60
5-4 Check Valve Manifold Components – GS-1530, GS-1532,
GS-1930 and GS-1932 ................................................................................ 62
5-5 Lift Pressure Selector Manifold Components – GS-4047.............................. 63
5-6 Outrigger Function Manifold Components – GS-3232 .................................. 64
5-7 Outrigger Cylinder Manifold Components – GS-3232................................... 65
5-8 Valve Adjustments – Function Manifold ........................................................ 66
5-9 Valve Coils ..................................................................................................... 72
Steer Axle Components .................................................................................... 74
6-1 Yoke and Drive Motor .................................................................................... 74
6-2 Steer Cylinder ................................................................................................ 75
6-3 Steer Bellcrank .............................................................................................. 76

April 2017
Table of Contents
Part No. 1272217 GS-30 • GS-32 • GS-46 • GS-47 xi
Non-Steer Axle Components.............................................................................77
7-1 Drive Brake.....................................................................................................77
Brake Release Hand Pump Components.........................................................78
8-1 Brake Release Hand Pump Components ......................................................78
Scissor Components .........................................................................................79
9-1 Scissor Assembly, GS-1530 and GS-1532....................................................80
9-2 Scissor Assembly, GS-1930 and GS-1932....................................................86
9-3 Scissor Assembly, GS-2032 and GS-2046....................................................94
9-4 Scissor Assembly, GS-2632 and GS-2646..................................................101
9-5 Scissor Assembly, GS-3232 and GS-3246..................................................109
9-6 Scissor Assembly, GS-4047 ........................................................................118
9-7 Scissor Arm Wear Pads ...............................................................................126
9-8 Platform Height Sensor ................................................................................128
9-9 Lift Cylinder ..................................................................................................130
9-10 Pressure Transducer..................................................................................141
9-11 Platform Overload System .........................................................................143
9-12 Platform Overload Recovery ......................................................................148
Platform Components......................................................................................150
10-1 Platform ......................................................................................................150
10-2 Platform Extension Deck............................................................................151
Battery Charger ................................................................................................152
11-1 Battery Charger ..........................................................................................152
Selecting a Charge Profile ............................................................................153

April 2017
Table of Contents
xii GS-30 • GS-32 • GS-46 • GS-47 Part No. 1272217
Section 4 Diagnostics....................................................................................................... 155
Introduction ........................................................................................................ 155
GCON I/O Map without Load Sense (all machines except GS-3232) ............... 158
GCON I/O Map with Load Sense (all machines except GS-3232) .................... 159
GCON I/O Map without Load Sense GS-3232 only) ......................................... 160
GCON I/O Map with Load Sense (GS-3232 only) ............................................. 162
Operation Indicator Codes (OIC) ....................................................................... 164
Diagnostic Trouble Codes (DTC)....................................................................... 164
Troubleshooting "HXXX" and "PXXX" Faults..................................................... 165
Fault Inspection Procedure ................................................................................ 166
Type "HXXX" Faults ........................................................................................... 168
Type "PXXX" Faults ........................................................................................... 172
Type "UXXX" Faults ........................................................................................... 173
Type "FXXX" Faults ........................................................................................... 176
Type "CXXX" Faults ........................................................................................... 179
Battery Charger.................................................................................................. 181
Charger Fault Codes .................................................................................... 182
Charger Error Codes .................................................................................... 183

April 2017
Table of Contents
Part No. 1272217 GS-30 • GS-32 • GS-46 • GS-47 xiii
Section 5 Schematics........................................................................................................187
Introduction.........................................................................................................187
Electrical Component and Wire Color Legends .................................................188
Wiring Diagram Ground and Platform Controls..................................................190
Limit Switch Legend ...........................................................................................191
Electrical Symbol Legend...................................................................................192
Hydraulic Symbols Legend.................................................................................193
Hydraulic Schematics ......................................................................................194
Hydraulic Component Reference Legend ..........................................................194
Hydraulic Component Abbreviation Legend.......................................................195
Hydraulic Schematic, GS-1530, 1532, 1930, 1932
(from serial number GS3010A-110000, GS3011C-10000,
GS3014D-101, GS3016P-142281).............................................................196
Hydraulic Schematic, GS-2032, 2632, 3232, 2046, 2646, 3246
(from serial number GS3211A-110000 to GS3214A-119070,
GS3212C-10000 to GS3214C-11873, GS4612A-110000 to
GS4614A-117177, GS4614C-10000 to GS4614C-12073) ........................197
Hydraulic Schematic, GS-2032, 2632, 3232, 2046, 2646, 3246
(from serial number GS3214A-119071, GS3214C-11874,
GS4614A-117178, GS4614C-12074, GS4614D-101) ...............................198
Hydraulic Schematic, GS-3232 (from serial number
GS3211A-110000, GS3212C-10000, GS3216P-142677) .........................199
Hydraulic Schematic, GS-4047
(from serial number GS4712C-101 to GS4714C-1459).............................200
Hydraulic Schematic, GS-4047
(from serial number GS4714C-1460, GS4714D-101, GS4716P-101) .......201

April 2017
Table of Contents
xiv GS-30 • GS-32 • GS-46 • GS-47 Part No. 1272217
Electrical Schematics – ANSI / CSA Models ................................................. 203
Electrical Schematic GS-1530 / GS-1930, ANS / CSA
(from serial number GS3010A-110000 to GS3011A-110827)................... 204
Electrical Schematic, GS-1530 / GS-1930, ANSI / CSA
(from serial number GS3011A-110828 to GS3014A-136972,
GS3014D-101 to GS3015D-1113) ............................................................. 208
Electrical Schematic, GS-1530 / GS-1930 (from serial number
GS3014A-136973, GS3015D-1114 to GS3016D-5426,
GS3016P-142281 to GS3016P-158208) ................................................... 212
Electrical Schematic, GS-1530/1930, ANSI/CSA
(from GS3016D-5427, GS3016P-158209)................................................. 216
Electrical Schematic, GS-3232, ANSI / CSA
(from serial number GS3211A-110000 to GS3214A-135714)................... 218
Electrical Schematic, GS-3232, ANSI / CSA
(from serial number GS3214A-135715 to GS3215A-141898)................... 222
Electrical Schematic, GS-3232, ANSI / CSA (from serial number
GS3215A-141899, GS3216P-142677 to GS3216P-146462) .................... 226
Electrical Schematic, GS-3232, ANSI / CSA from (GS3216P-146463)............. 230
Electrical Schematic, GS-2032, 2632, 2046, 2646, ANSI / CSA
(from serial number GS3211A-110000 to GS3214A-135714,
GS4612A-110000 to GS4614A-135366,
GS4613D-101 to GS4615D-1303) ............................................................. 234
Electrical Schematic, GS-2032, 2632, 2046, 2646, ANSI/CSA
(from serial number GS3214A-1135715 to GS3215A-141898,
GS4614A-135367 to GS4615A-137959, GS4615D-1304) ........................ 238
Electrical Schematic, GS-2032, 2632, 2046, 2646, ANSI / CSA
(from serial numbers GS3215A-14189, GS3216P-142676 to
GS3216P-146462, GS4615A-137960, GS4615A-137960,
GS4615D-1305 to GS4616D-4432, GS4616P-138362 to
GS4616P-139710) ..................................................................................... 242
Electrical Schematic, GS-2032, 2632, 2046, 2646, ANSI / CSA
(from serial number GS3216P-146463, GS4616D-4433,
GS4616P-139711) ..................................................................................... 246
Electrical Schematic, GS-3246 / GS-4047, ANSI / CSA
(from serial number GS4612A-110000 to GS4614A-135366,
GS4614D-101 to GS4615D-1303, GS4714D-101 to GS4715D-749)........ 248
Electrical Schematic, GS-3246 / GS-4047, ANSI / CSA (from serial number
GS4614A-135367 to GS4615A-137959, GS4615D-1304 to
GS4616D-4432, GS4616P-138362 to GS4616P-139710,
GS4715D-750 to GS4716D-3101) ............................................................. 252
Electrical Schematic, GS-3246, GS4047 ANSI / CSA (from serial numbers
GS4616D-4433, GS4616P-139711, GS4716D-3102, GS4716P-101) ...... 256

April 2017
Table of Contents
Part No. 1272217 GS-30 • GS-32 • GS-46 • GS-47 xv
Electrical Schematics – CE and Australia Models ........................................257
Electrical Schematic GS-1530, 1532, 1930, 1932, (from serial number
GS3010A-110000 to GS3011A-110827) AS / CE......................................258
Electrical Schematic, GS-1530/32_GS-1930/32 (from serial number
GS3011A-110828 to GS3014A-136972, GS3011C-10000 to
GS3015C-18038, GS3014D-101 to GS3015D-1113) ................................262
Electrical Schematic, GS-1530, 1532, 1930, 1932, AS/CE
(from serial number GS3014A-136973, GS3015C-18039,
GS3015D-1114 to GS3016D-5426, GS3016P-142281 to
GS3016P-158208)......................................................................................266
Electrical Schematic, GS-1530, 1532, 1930, 1932, AS/CE
(from serial numbers GS3015D-5427, GS3016P-158209) ........................270
Electrical Schematic, GS-3232, AS / CE (from serial number
GS3211A-110000 to GS3214A-135714, GS3212C-10000 to
GS3215C-14503) .......................................................................................272
Electrical Schematic, GS-3232, AS / CE (from serial number
GS3214A-135715 to GS3215A-141898, GS3215C-14504) ......................276
Electrical Schematic, GS-3232, AS / CE (from serial numbers
GS3215A-141899, GS3216P-142676 to GS3216P-146462).....................280
Electrical Schematic, GS-3232, CE / AS (from serial number
GS3216P-146463)......................................................................................284
Electrical Schematic, GS-2032, 2632, 2046, 2646, AS / CE
(from serial number GS3211A-110000 to GS3214A-135714,
GS3212C-10000 to GS3215C-14377, GS4612A-110000 to
GS4614A-135366, GS4612C-10000 to GS4615C-14503,
GS4613D-101 to GS4615D-1303) .............................................................288
Electrical Schematic, GS-2032, 2632, 2046, 2646, AS/CE
(from serial number GS3214A-1135715 to GS3215A-141898,
GS3215C-14378, GS4614A-135367 to GS4615A-137959,
GS4615C-14504, GS4615D-1304) ............................................................292
Electrical Schematic, GS-2032, 2632, 2046, 2646, AS / CE
(from serial number GS3215A-141899, GS3216P-142676 to
GS3216P-146462, GS4615A-137960, GS4616P-138362 to
GS4616P-139710)......................................................................................296
Electrical Schematic, GS-2032, 2632, 2046, 2646, AS / CE
(from serial numbers GS3216P-146463, GS4616P-139711) ....................300

April 2017
Table of Contents
xvi GS-30 • GS-32 • GS-46 • GS-47 Part No. 1272217
Electrical Schematic, GS-3246, AS / CE (from serial number
GS4612A-110000 to GS4614A-135366, GS4612C-10000 to
GS4615C-14503, GS4614D-101 to GS4615D-1303)................................ 302
Electrical Schematic, GS-3246, AS / CE (from serial number
GS4614A-135367 to GS4615A-137959, GS4615C-14504,
GS4615D-1304) ......................................................................................... 306
Electrical Schematic, GS-3246, AS / CE (from serial number
GS4615A-137960, GS4616P-138362 GS4616P to GS4616P-139710).... 310
Electrical Schematic, GS-3246, AS / CE (from serial number
GS4616D-4433, GS4616P-139711) .......................................................... 314
Electrical Schematic, GS-4047, AS / CE (from serial number
GS4712C-101 to GS4715C-2130, GS4714D-101 to GS4715D-749)........ 316
Electrical Schematic, GS-4047, AS / CE (from serial number
GS4715C-2131, GS4715D-750 to GS4716D-3101).................................. 320
Electrical Schematic, GS-4047, AS / CE (from serial number
GS4716D-3102) ......................................................................................... 324
Electrical Schematic – Foot Switch (option) All Models.............................. 325
Foot Switch (option) All Models ......................................................................... 326

April 2017 Service and Repair Manual
Specifications
Part No. 1272217 GS-30 • GS-32 • GS-46 • GS-47 1
Section 2 Speci fi c ati ons
Machine Specifications
Batteries, Standard
All models except GS
-4047
Voltage
6V DC
Group
GC2
Type
T-
105
Quantity
4
Battery capacity, maximum
C20 = 225AH
Reserve
capacity @ 25A rate 447 m
inutes
Weight, each
62
lbs
28
kg
Batteries, Standard GS-4047
Voltage
12V DC
Group
GC2
Type
T-
1275
Quantity
4
Battery capacity, maximum
C20 = 150AH
Reserve capacity @ 25A rate
280 m
inutes
Weight, each
82 l
bs
37 k
g
Batteries, Maintenance
-free (option)
All models except GS-4047
Voltage
6V
DC
Group
GC2
Type
6V-
AGM
Quantity
4
Battery capacity, maximum
200AH
Reserve capacity @ 25A rate
380 m
inutes
Weight, each
62
lbs
28
kg
Platform Overload Pressure Transducer
(if equipped) All models except GS-3232 and
GS-4047
Input voltage
8 t
o 30 VDC
Signal voltage
1 t
o 5 V
Platform Overload Pressure Transducer
(if equipped) GS
-3232 and GS-4047
Input voltage
8 t
o 30 VDC
Signal
voltage 0.25 t
o 6.25 V
Angle Sensor (if equipped)
Input voltage
8 t
o 30 VDC
Signal voltage
3 t
o 4 V, PMW output
Outrigger Pressure Transducer, GS
-3232 only
Input voltage
8 t
o 30 VDC
Signal voltage
1 t
o 5 V
For operational specifications, refer to the
Operator's Manual.

Service and Repair Manual April 2017
Specifications
2 GS-30 • GS-32 • GS-46 • GS-47 Part No. 1272217
Fluid capacities
Hydraulic tank
All models except GS
-4047
3.4 g
allons
12.9 l
iters
Hydraulic tank
GS
-4047
5.9 g
allons
22.4 l
iters
Hydraulic system (including tank)
GS
-1530, GS-1532, GS-1930 and
GS
-1932
3.8 g
allons
14.2 l
iters
Hydraulic system (including tank)
GS
-2032, GS-2632, GS-2046 and
GS
-2646
4.5 g
allons
17 l
iters
Hydraulic system (including tank)
GS
-3232 and GS-3246
5.5 g
allons
20.8 l
iters
Hydraulic system (including tank)
GS
-4047
7.5 g
allons
28.4 l
iters
Tires and whe
els
GS
-1530, GS-1532, GS-1930, GS-1932
Tire size (solid rubber)
12 x 4.5
in
30.5 x 11.4
cm
Tire contact area
9 s
q in
58 cm
2
Castle nut torque, dry
300 ft-
lbs
406.7 Nm
Castle nut torque, lubricated
225 ft-
lbs
305 Nm
GS
-2032, GS-2632, GS-3232, GS-2046, GS-2646,
GS
-3246, GS-4047
Tire size (solid rubber)
15 x 5 i
n
38.1 x 12.7 c
m
Tire contact area
15 s
q in
96.7 cm
2
Castle nut torque, dry
300 ft-
lbs
406.7 Nm
Castle nut torque, lubricated
225 ft-
lbs
305 Nm

April 2017 Service and Repair Manual
Specifications
Part No. 1272217 GS-30 • GS-32 • GS-46 • GS-47 3
Performance Specifications
(models without proportional lift)
Drive speed, maximum
GS-1530, GS-1532, GS-1930, GS-1932
Platform stowed, fast
2.5 m
ph
40 ft / 10.9 s
ec
4 k
m/h
12.2 m / 10.9 s
ec
Platform raised
0.5 m
ph
40 ft / 55 s
ec
0.8 k
m/h
12.2 m / 55 s
ec
GS
-2032, GS-2632, GS-3232, GS-2046, GS-2646,
GS
-3246
Platform stowed, fast
t
o serial number:
GS3216P
-145830
GS4616P
-139575
2.2 m
ph
40 ft / 12.4 s
ec
3.5 k
m/h
12.2 m / 12.4 s
ec
Platform stowed, fast
from serial number
:
GS3216P
-145831
GS4616P
-139576
2.0 m
ph
40 ft / 12.4 s
ec
3.2 k
m/h
12.2 m / 12.4 s
ec
Platform raised
0.5 m
ph
40 ft / 55 s
ec
0.8 k
m/h
12.2 m / 55 s
ec
GS
-4047
Platform stowed, fast
2.0 m
ph
40 ft / 13.6 s
ec
3.2 k
m/h
12.2 m / 13.6 s
ec
Platform raised
0.5 m
ph
40 ft / 55 s
ec
0.8 k
m/h
12.2 m / 55 s
ec
Braking distance, maximum
High range on paved surface
1 - 3 f
t
0.3 - 0.9
m
Gradeability
GS
-1930, GS-1932,
GS
-2632,GS-3232, GS-3246 and
GS
-4047
25%
GS
-1530, GS-1532, GS-2032,
GS
-2046 and GS-2646
30%
Airborne
noise emissions
Sound pressure level at ground
workstation
< 70 d
BA
Sound pressure level at platform
workstation
< 70 d
BA

Service and Repair Manual April 2017
Specifications
4 GS-30 • GS-32 • GS-46 • GS-47 Part No. 1272217
Function speed, maximum from platform controls
(with
1 person in platform)
GS
-1530 and GS-1532
Platform up (fast mode)
Platform
up (slow mode)
Platform down
15 to 17 s
econds
30 to 32 s
econds
28 to 30 s
econds
GS
-1930 and GS-1932
Platform up (fast mode)
Platform up (slow mode)
Platform down
15 to 17 s
econds
30 to 32 s
econds
28 to 30 s
econds
GS
-2032 and GS-2632
Platform up (fast
mode)
Platform up (slow mode)
Platform down
28 to 32 s
econds
58 to 62 s
econds
32 to 36 s
econds
GS
-2046 and GS-2646
Platform up (fast mode)
Platform up (slow mode)
Platform down
28 to 32 s
econds
58 to 62 s
econds
32 to 36 s
econds
GS
-3232 and GS-3246
Platform up (fast mode)
Platform up (slow mode)
Platform down
55 to 59 s
econds
108 to 112 s
econds
33 to 37 s
econds
GS
-4047
Platform up (fast mode)
Platform up (slow mode)
Platform down
71 to 76 s
econds
83 to 87 s
econds
41 to 46 s
econds
Rated work load at full height, maximum
GS
-1530 and GS-1532 600 lbs
272
kg
GS
-1930, GS-1932,
GS
-2632 and GS-3232
500 lbs
227
kg
GS
-2032 800 l
bs
363 k
g
GS
-2046 1200 l
bs
544 k
g
GS
-2646 1000 l
bs
454 k
g
GS
-3246 700 l
bs
317 k
g
GS
-4047
(CE and AS models)
770 l
bs
350 k
g
GS
-4047
(ANSI and CSA models)
550 l
bs
250 k
g
GS
-3232 Outrigger leveling capacity, maximum
Side to side
Front to rear
5°
3°
