Genie GS-2046 User manual

Service Manual Part No. 72972
September 2006
Rev B2
800-610-4101
ActionRental.com

Genie GS-2046 and GS-2646 and GS-3246 Part No.72972
June 2003
ii
Introduction
Important
Read, understand and obey the safety rules and
operating instructions in the Genie GS-2032 and
GS-2632 and GS-2046 and GS-2646 and GS-3246
Operator's Manual before attempting any
maintenance or repair procedure.
This manual provides detailed scheduled
maintenance information for the machine owner
and user. It also provides troubleshooting and
repair procedures for qualified service
professionals.
Basic mechanical, hydraulic and electrical
skills are required to perform most procedures.
However, several procedures require specialized
skills, tools, lifting equipment and a suitable
workshop. In these instances, we strongly
recommend that maintenance and repair be
performed at an authorized Genie dealer
service center.
Technical Publications
Genie Industries has endeavored to deliver the
highest degree of accuracy possible. However,
continuous improvement of our products is a Genie
policy. Therefore, product specifications
are subject to change without notice.
Readers are encouraged to notify Genie of errors
and send in suggestions for improvement. All
communications will be carefully considered for
future printings of this and all other manuals.
Contact Us:
PO Box 97030
Redmond, WA 98073-9730 USA
www.genieindustries.com
e-mail: [email protected]
Copyright © 1997 by Genie Industries
72972 Rev B June 2003
Second Edition, Second Printing
"Genie" is a registered trademark of Genie
Industries in the USA and many other countries.
"GS" is a trademark of Genie Industries.
Printed on recycled paper
Printed in U.S.A.
Serial Number Information
Genie Industries offers the following Service
Manuals for these models:
Title Part No.
Genie GS-2046 and GS-2646 and GS-3246
Service Manual (before serial number 17408) .... 48339
800-610-4101
ActionRental.com

Part No. 72972 Genie GS-2046 and GS-2646 and GS-3246
June 2003
iii
Safety Rules
Section 1 • Safety Rules
Danger
Failure to obey the instructions and safety rules
in this manual and the Genie GS-2032 and
GS-2632 and GS-2046 and GS-2646 and GS-3246
Operator's Manual
will result in death or serious
injury.
Many of the hazards identified in the
operator’s manual are also safety hazards
when maintenance and repair procedures
are performed.
Do Not Perform Maintenance
Unless:
You are trained and qualified to perform
maintenance on this machine.
You read, understand and obey:
- manufacturer’s instructions and safety rules
- employer’s safety rules and worksite
regulations
- applicable governmental regulations
You have the appropriate tools, lifting
equipment and a suitable workshop.
800-610-4101
ActionRental.com

Genie GS-2046 and GS-2646 and GS-3246 Part No.72972
June 2003
SAFETY RULES
Personal Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Read each procedure thoroughly. This
manual and the decals on the machine,
use signal words to identify the following:
Safety alert symbol—used to alert
personnel to potential personal
injury hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Red—used to indicate the
presence of an imminently
hazardous situation which, if not
avoided, will result in death or
serious injury.
Orange—used to indicate the
presence of a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
Yellow with safety alert symbol—
used to indicate the presence of a
potentially hazardous situation
which, if not avoided, may cause
minor or moderate injury.
Yellow without safety alert
symbol—used to indicate the
presence of a potentially
hazardous situation which, if not
avoided, may result in property
damage.
Green—used to indicate operation
or maintenance information.
iv
Be sure to wear protective eye wear and
other protective clothing if the situation
warrants it.
Be aware of potential crushing hazards
such as moving parts, free swinging or
unsecured components when lifting or
placing loads. Always wear approved steel-toed
shoes.
Workplace Safety
Be sure to keep sparks, flames and
lighted tobacco away from flammable and
combustible materials like battery gases
and engine fuels. Always have an approved fire
extinguisher within easy reach.
Be sure that all tools and working areas
are properly maintained and ready for
use. Keep work surfaces clean and free of
debris that could get into machine components and
cause damage.
Be sure any forklift, overhead crane or
other lifting or supporting device is fully
capable of supporting and stabilizing the
weight to be lifted. Use only chains or straps that
are in good condition and of ample capacity.
Be sure that fasteners intended for one
time use (i.e., cotter pins and self-locking
nuts) are not reused. These components
may fail if they are used a second time.
Be sure to properly dispose of old oil or
other fluids. Use an approved container.
Please be environmentally safe .
Be sure that your workshop or work area
is properly ventilated and well lit.
Section 1 • Safety Rules
800-610-4101
ActionRental.com

Part No. 72972 Genie GS-2046 and GS-2646 and GS-3246
June 2003
Table of Contents
v
Introduction
Important Information ...................................................................................................... ii
Section One Safety Rules
General Safety Rules ..................................................................................................... iii
Section Two Specifications - Rev B
Machine Specifications ............................................................................................. 2 - 1
Performance Specifications ...................................................................................... 2 - 2
Hydraulic Specifications ............................................................................................ 2 - 3
Manifold Component Specifications .......................................................................... 2 - 4
Hydraulic Hose and Fitting Torque Specifications ..................................................... 2 - 6
Section Three Scheduled Maintenance Procedures
Introduction ............................................................................................................... 3 - 1
Pre-delivery Preparation Report ................................................................................. 3 - 3
Maintenance Inspection Report ................................................................................. 3 - 5
Checklist A Procedures - Rev B
A-1 Perform Pre-operation Inspection .................................................................... 3 - 6
A-2 Perform Function Tests ................................................................................... 3 - 6
A-3 Perform 30 Day Service .................................................................................. 3 - 7
A-4 Grease the Steer Yokes .................................................................................. 3 - 7
800-610-4101
ActionRental.com

Genie GS-2046 and GS-2646 and GS-3246 Part No.72972
September 2006
TABLE OF CONTENTS
vi
Section Three Maintenance Procedures, continued
Checklist B Procedures - Rev C
B-1 Inspect the Batteries ....................................................................................... 3 - 8
B-2 Inspect the Electrical Wiring ............................................................................ 3 - 9
B-3 Inspect the Tires and Wheels (including castle nut torque) ............................ 3 - 10
B-4 Test the Key Switch ...................................................................................... 3 - 10
B-5 Test the Automotive-style Horn (if equipped) ................................................. 3 - 11
B-6 Test the Drive Brakes.................................................................................... 3 - 12
B-7 Test the Drive Speed - Stowed Position ........................................................ 3 - 14
B-8 Test the Drive Speed - Raised Position ......................................................... 3 - 15
B-9 Perform Hydraulic Oil Analysis ...................................................................... 3 - 16
B-10 Replace the Hydraulic Tank Return Filter ....................................................... 3 - 16
B-11 Check the Module Tray Latch Components ................................................... 3 - 17
Checklist C Procedure - Rev C
C-1 Check the Scissor Arm Wear Pads ............................................................... 3 - 19
Checklist D Procedure - Rev A
D-1 Test or Replace the Hydraulic Oil .................................................................. 3 - 20
800-610-4101
ActionRental.com

Part No. 72972 Genie GS-2046 and GS-2646 and GS-3246
June 2003
TABLE OF CONTENTS
vii
Section Four Repair Procedures
Introduction ............................................................................................................... 4 - 1
Platform Controls - Rev B
1-1 Circuit Boards .................................................................................................. 4 - 2
1-2 Joystick Controller ........................................................................................... 4 - 3
1-3 Controller Adjustments .................................................................................... 4 - 5
1-4 Software Configuration .................................................................................. 4 - 13
Platform Components - Rev A
2-1 Platform ........................................................................................................ 4 - 16
2-2 Platform Extension ........................................................................................ 4 - 17
Scissor Components - Rev A
3-1 Scissor Assembly, GS-2046 ......................................................................... 4 - 18
3-2 Scissor Assembly, GS-2646 ......................................................................... 4 - 24
3-3 Scissor Assembly, GS-3246 ......................................................................... 4 - 32
3-4 Lift Cylinder ................................................................................................... 4 - 42
Ground Controls - Rev B
4-1 Manual Platform Lowering Cable, GS-2046 and GS-2646 .............................. 4 - 46
4-2 Manual Platform Lowering, GS-3246 .............................................................. 4 - 47
4-3 Toggle Switches ............................................................................................ 4 - 48
4-4 Control Relays ............................................................................................... 4 - 49
4-5 Tilt Level Sensor (before serial number 50444) .............................................. 4 - 50
4-6 Tilt Level Sensor (after serial number 50443) ................................................. 4 - 54
800-610-4101
ActionRental.com

Genie GS-2046 and GS-2646 and GS-3246 Part No.72972
June 2003
TABLE OF CONTENTS
viii
Section Four Repair Procedures, continued
Hydraulic Pump - Rev A
5-1 Function Pump .............................................................................................. 4 - 58
Function Manifold - Rev B
6-1 Function Manifold Components
(from serial number 17408 to 17481) .............................................................. 4 - 60
6-2 Function Manifold Components
(from serial number 17482 to 36044) .............................................................. 4 - 62
6-3 Function Manifold Components
(after serial number 36044) ............................................................................ 4 - 64
6-4 Function Manifold Components - Models with Traction Control ...................... 4 - 66
6-5 Valve Adjustments - Function Manifold ......................................................... 4 - 68
6-6 Platform Lift Relief Valve Manifold Components, GS-3246 Models
(before serial number 36045) ......................................................................... 4 - 75
6-7 Valve Adjustments - Lift Relief Manifold, GS-3246 Models
(before serial number 36045) ......................................................................... 4 - 76
6-8 Valve Coils .................................................................................................... 4 - 78
Hydraulic Tank - Rev A
7-1 Hydraulic Tank .............................................................................................. 4 - 80
Steer Axle Components - Rev A
8-1 Yoke and Drive Motor .................................................................................... 4 - 81
8-2 Steer Cylinder ................................................................................................ 4 - 83
8-3 Steer Bellcrank .............................................................................................. 4 - 84
Non-steer Axle Components - Rev A
9-1 Drive Brake ................................................................................................... 4 - 85
Brake Release Hand Pump Components - Rev A
10-1 Brake Release Hand Pump Components ....................................................... 4 - 86
800-610-4101
ActionRental.com

Part No. 72972 Genie GS-2046 and GS-2646 and GS-3246
June 2003
TABLE OF CONTENTS
ix
Section Five Troubleshooting Flow Charts and Fault Codes
Introduction ............................................................................................................... 5 - 1
Fault Code Chart (after serial number 17407) - Rev A................................................ 5 - 3
Chart
Number Chart Title
1 All Functions Will Not Operate - Rev A ..................................................................... 5 - 4
2 Pump Motor Will Not Operate - Rev A ....................................................................... 5 - 6
3 All Functions Inoperative, Power Unit Starts and Runs - Rev A................................. 5 - 8
4 Ground Controls Inoperative,
Platform Controls Operate Normally - Rev A ............................................................ 5 - 9
5 Platform Controls Inoperative,
Ground Controls Operate Normally - Rev A............................................................ 5 - 10
6 Platform Up Function Inoperative - Rev A............................................................... 5 - 11
7 Platform Down Function Inoperative - Rev A .......................................................... 5 - 12
8 Steer Left Function Inoperative - Rev A .................................................................. 5 - 14
9 Steer Right Function Inoperative - Rev A ................................................................ 5 - 16
10 All Drive Functions Inoperative,
All Other Functions Operate Normally - Rev A ........................................................ 5 - 18
10A Brake Release Function Inoperative - Rev A ........................................................... 5 - 19
11 Drive Forward Function Inoperative - Rev A ............................................................ 5 - 20
12 Drive Reverse Function Inoperative - Rev A ............................................................ 5 - 21
13 Machine Will Not Drive At Full Speed - Rev A ......................................................... 5 - 22
14 Machine Drives At Full Speed With Platform Raised - Rev A .................................. 5 - 23
15 Limit Switch Function Inoperative - Rev A ............................................................... 5 - 24
16 Fault Code 02 - ECM / Platform Communication Error - Rev A ................................ 5 - 26
17 Fault Code 59 - Parallel/Series Coil Fault - Rev B ................................................... 5 - 29
800-610-4101
ActionRental.com

Genie GS-2046 and GS-2646 and GS-3246 Part No.72972
June 2003
x
TABLE OF CONTENTS
Section Six Schematics
Introduction ............................................................................................................... 6 - 1
Control Relay Layout - Rev A .................................................................................... 6 - 2
ECM Pin-out Legend - Rev B .................................................................................... 6 - 4
Platform Controls Wiring Diagram
(from serial number 17408 to 48054) - Rev B ............................................................ 6 - 6
Platform Controls Wiring Diagram
(after serial number 48054) - Rev A ........................................................................... 6 - 7
Ground Controls Wiring Diagram, GS-2046 and GS-2646 - Rev B ............................. 6 - 8
Ground Controls Wiring Diagram, GS-3246 - Rev B ................................................... 6 - 9
Level Sensor Box Wiring Diagram - Rev A .............................................................. 6 - 10
Electrical Symbols Legend - Rev B ......................................................................... 6 - 12
Electrical Schematic
(from serial number 17408 to 21064) - Rev B .......................................................... 6 - 13
Electrical Schematic
(from serial number 21065 to 21262) - Rev B .......................................................... 6 - 15
Electrical Schematic
(from serial number 21263 to 24438) - Rev B .......................................................... 6 - 17
Electrical Schematic
(from serial number 24439 to 25141) - Rev B .......................................................... 6 - 19
Electrical Schematic
(from serial number 25142 to 27181) - Rev B .......................................................... 6 - 21
Electrical Schematic
(from serial number 27182 to 28936) - Rev B .......................................................... 6 - 23
Electrical Schematic
(from serial number 28937 to 33721) - Rev B .......................................................... 6 - 25
Electrical Schematic
(from serial number 33722 to 40925) - Rev B .......................................................... 6 - 27
800-610-4101
ActionRental.com

Part No. 72972 Genie GS-2046 and GS-2646 and GS-3246
June 2003
Section Six Schematics, continued
Electrical Schematic
(from serial number 40926 to 48054) - Rev B .......................................................... 6 - 29
Electrical Schematic
(from serial number 48055 to 48717) - Rev A .......................................................... 6 - 31
Electrical Schematic
(from serial number 48718 to 49199) - Rev A .......................................................... 6 - 33
Electrical Schematic
(after serial number 49199) - Rev A ......................................................................... 6 - 35
Hydraulic Symbols Legend and Component Reference - Rev B ............................... 6 - 37
Hydraulic Schematic, GS-2046 and GS-2646
(from serial number 17408 to 36044) - Rev A .......................................................... 6 - 38
Hydraulic Schematic, GS-2046 and GS-2646
(after serial number 36044) - Rev A ......................................................................... 6 - 39
Hydraulic Schematic, GS-2046 and GS-2646
Models with Traction Control - Rev A ...................................................................... 6 - 40
Hydraulic Schematic, GS-3246
(from serial number 17408 to 22446) - Rev A .......................................................... 6 - 41
Hydraulic Schematic, GS-3246
(from serial number 22447 to 27181) - Rev A .......................................................... 6 - 42
Hydraulic Schematic, GS-3246
(from serial number 27182 to 36044) - Rev A .......................................................... 6 - 43
Hydraulic Schematic, GS-3246
(after serial number 36044) - Rev A ......................................................................... 6 - 44
Hydraulic Schematic, GS-3246
Models with Traction Control - Rev A ...................................................................... 6 - 45
TABLE OF CONTENTS
xi
800-610-4101
ActionRental.com

Genie GS-2046 and GS-2646 and GS-3246 Part No.72972
June 2003
This page intentionally left blank.
800-610-4101
ActionRental.com

Part No. 72972 Genie GS-2046 and GS-2646 and GS-3246 2 - 1
Section 2 • SpecificationsMay 2003
REV B Specifications
Machine Specifications
Batteries
Type 6V DC
Group T-105
Quantity 4
Battery capacity, maximum 225AH
Reserve capacity @ 25A rate 447 minutes
Fluid Capacities
Hydraulic tank capacity 51/2gallons
(before serial number 26566) 20.8 liters
Hydraulic system capacity (including tank) 6 gallons
(before serial number 26566) 22.7 liters
Hydraulic tank capacity 7 gallons
(after serial number 26565) 26.5 liters
Hydraulic system (including tank) 7 gallons
(after serial number 26565) 26.5 liters
Tires and wheels
Tire size (solid rubber) 15 x 5 in
38.1 x 12.7 cm
Tire contact area 10 sq in
64.5 cm2
Castle nut torque, dry 300 ft-lbs
406.7 Nm
Castle nut torque, lubricated 225 ft-lbs
305 Nm
For operational specifications, refer to the
Operators Manual.
800-610-4101
ActionRental.com

2 - 2 Genie GS-2046 and GS-2646 and GS-3246 Part No. 72972
Section 2 • Specifications May 2003
REV BSPECIFICATIONS
Performance Specifications
Drive speed, maximum
Platform stowed 2.2 mph
40 ft / 12.4 sec
3.5 km/h
12.2 m / 12.4 sec
Platform raised 0.5 mph
40 ft / 54.5 sec
0.8 km/h
12.2 m / 54.5 sec
Braking distance, maximum
High range on paved surface 2 ft
61 cm
Load capacity, maximum
GS-2046 1200 lbs
544 kg
GS-2646 1000 lbs
454 kg
GS-3246 (ANSI & CE models) 700 lbs
(before serial number 24439) 318 kg
GS-3246 (CSA models) 500 lbs
(before serial number 24439) 227 kg
GS-3246 700 lbs
(after serial number 24438) 318 kg
Extension deck load capacity, maximum 250 lbs
113.4 kg
Function speed, maximum from platform controls
(with 1 person in platform)
GS-2046
Platform up 28 to 32 seconds
Platform down 26 to 30 seconds
GS-2646
Platform up 28 to 32 seconds
Platform down 22 to 26 seconds
GS-3246
Platform up 55 to 59 seconds
Platform down 38 to 42 seconds
Gradability
GS-2046, GS-2646 30%
GS-3246 25%
Continuous improvement of our products is a
Genie policy. Product specifications are
subject to change without notice.
800-610-4101
ActionRental.com

Part No. 72972 Genie GS-2046 and GS-2646 and GS-3246 2 - 3
Section 2 • SpecificationsMay 2003
REV B SPECIFICATIONS
Hydraulic Specifications
Hydraulic Oil Specifications
Before serial number 52640
Hydraulic oil type Shell Donax TG (Dexron III)
After serial number 52639
Hydraulic oil type Chevron Rykon MV equivalent
Approximate SAE grade 5W-20
Viscosity index rating 200
Chevron Rykon MV oil is fully compatible and
mixable with Shell Donax TG (Dexron III) oils.
Genie specifications require hydraulic oils which are
designed to give maximum protection to hydraulic
systems, have the ability to perform over a wide
temperature range, and have a minimum viscosity index
rating of 150. They should provide excellent antiwear,
oxidation, corrosion inhibition, seal conditioning, and
foam and aeration suppression properties.
Optional fluids
Biodegradable Petro Canada Premium ECO 46
Statoil Hydra Way Bio Pa 32
BP Biohyd SE-S
Fire resistant UCON Hydrolube HP-5046
Quintolubric 822
Mineral based Shell Tellus T32
Shell Tellus T46
Chevron Aviation A
Genie specifications require
additional equipment and special
installation instructions for the
approved optional fluids. Consult
the Genie Industries Service
Department before use.
Function pump
Type: gear
Displacement per revolution 0.244 cu in
4 cc
Flow rate 4 gallons per minute
@ 2500 psi / 172 bar 15.1 L/min
Hydraulic tank 10 micron with
return line filter 25 psi / 1.7 bar bypass
Function manifold, GS-2046 & GS-2646
System relief valve pressure 3500 psi
241.3 bar
Steer relief valve pressure 1500 psi
103.4 bar
Lift relief valve pressure 3000 to 3200 psi
(after serial number 36044) 207 to 221 bar
Function manifold, GS-3246
System relief valve pressure 3500 psi
241.3 bar
Steer relief valve pressure 1500 psi
103.4 bar
Lift relief valve pressure 2000 psi
(before serial number 36045) 137.9 bar
Lift relief valve pressure 3000 to 3200 psi
(after serial number 36044) 207 to 221 bar
800-610-4101
ActionRental.com

2 - 4 Genie GS-2046 and GS-2646 and GS-3246 Part No. 72972
Section 2 • Specifications May 2003
REV BSPECIFICATIONS
Manifold Component
Specifications
Plug torque
SAE No. 2 50 in-lbs / 6 Nm
SAE No. 4 13 ft-lbs / 18 Nm
SAE No. 6 18 ft-lbs / 24 Nm
SAE No. 8 50 ft-lbs / 68 Nm
SAE No. 10 55 ft-lbs / 75 Nm
SAE No. 12 75 ft-lbs / 102 Nm
Valve Coil Resistance
Description Specification
Solenoid valve, N.C. 23 - 25Ω
2 position 2 way 20V DC
(schematic item D, before serial number 28937)
Solenoid valve, N.C. 23 - 25Ω
2 position 2 way 20V DC with diode
(schematic item D, after serial number 28936)
Solenoid valve, 2 position 2 way N.O. 25 to 27Ω
20V DC with diode
(schematic items AI, BK, CI and CL)
Solenoid valve, 2 position 4 way 18 to 20Ω
20V DC with diode
(schematic items AH, AJ, BI, BL, CJ and CN)
Solenoid valve, 3 position 4 way 18 to 20Ω
20V DC with diode
(schematic items AK, BJ and CK)
Solenoid valve, 3 position 4 way 25 to 27Ω
20V DC with diode
(schematic items AG, BH and CH)
800-610-4101
ActionRental.com

Part No. 72972 Genie GS-2046 and GS-2646 and GS-3246 2 - 5
Section 2 • SpecificationsMay 2003
REV B
This page intentionally left blank.
SPECIFICATIONS
800-610-4101
ActionRental.com

2 - 6 Genie GS-2046 and GS-2646 and GS-3246 Part No. 72972
Section 2 • Specifications May 2003
REV A
Hydraulic Hose and Fitting Torque Specifications
Your machine is equipped with either 37° flared fittings and hose ends OR Parker Seal-Lok®fittings and
hose ends. Genie specifications require that fittings and hose ends be torqued to specification when they
are removed and installed or when new hoses or fittings are installed.
SAE O-ring Boss Port
(tube fitting - installed into Aluminum)
SAE Dash size Torque
-4 11 ft-lbs / 14.9 Nm
-6 23 ft-lbs / 31.2 Nm
-8 40 ft-lbs / 54.2 Nm
-10 69 ft-lbs / 93.6 Nm
-12 93 ft-lbs / 126.1 Nm
-16 139 ft-lbs / 188.5 Nm
-20 172 ft-lbs / 233.2 Nm
-24 208 ft-lbs / 282 Nm
SAE O-ring Boss Port
(tube fitting - installed into Steel)
SAE Dash size Torque
-4 16 ft-lbs / 21.7 Nm
-6 35 ft-lbs / 47.5 Nm
-8 60 ft-lbs / 81.3 Nm
-10 105 ft-lbs / 142.4 Nm
-12 140 ft-lbs / 190 Nm
-16 210 ft-lbs / 284.7 Nm
-20 260 ft-lbs / 352.5 Nm
-24 315 ft-lbs / 427.1 Nm
Seal-Lok®Fittings
(hose end)
SAE Dash size Torque
-4 18 ft-lbs / 24.4 Nm
-6 27 ft-lbs / 36.6 Nm
-8 40 ft-lbs / 54.2 Nm
-10 63 ft-lbs / 85.4 Nm
-12 90 ft-lbs / 122 Nm
-16 120 ft-lbs / 162.7 Nm
-20 140 ft-lbs / 190 Nm
-24 165 ft-lbs / 223.7 Nm
JIC 37° Fittings
(swivel nut or hose connection)
SAE Dash size Thread Size Flats
-4 7/16-20 2
-6 9/16-18 1 1/4
-8 3/4-16 1
-10 7/8-14 1
-12 1 1/16-12 1
-16 1 5/16-12 1
-20 1 5/8-12 1
-24 1 7/8-12 1
SPECIFICATIONS
800-610-4101
ActionRental.com

Part No. 72972 Genie GS-2046 and GS-2646 and GS-3246 2 - 7
Section 2 • SpecificationsMay 2003
REV A
Torque Procedure
JIC 37° fittings
1 Align the tube flare (hex nut) against the nose of
the fitting body (body hex fitting) and tighten the
hex nut to the body hex fitting to hand-tight,
approximately 30 in-lbs / 3.4 Nm.
2 Make a reference mark on one of the flats of the
hex nut, and continue it on to the body hex
fitting with a permanent ink marker.
a hydraulic hose
b hex nut
c reference mark
d body hex fitting
3 Working clockwise on the body hex fitting, make
a second mark with a permanent ink marker to
indicate the proper tightening position.
Use the JIC 37° Fittings table on
the previous page to determine
the correct number of flats for the
proper tightening position.
The marks indicate that the correct
tightening positions have been
determined. Use the second mark
on the body hex fitting to properly
tighten the joint after it has been
loosened.
a body hex fitting
b reference mark
c second mark
4 Tighten the hex nut until the mark on the hex
nut is aligned with the second mark on the body
hex fitting.
5 Operate all machine functions and inspect the
hoses and fittings and related components to
confirm that there are no leaks.
b
c
a
d
a
b
c
b
SPECIFICATIONS
800-610-4101
ActionRental.com

2 - 8 Genie GS-2046 and GS-2646 and GS-3246 Part No. 72972
Section 2 • Specifications May 2003
REV A
Seal-Lok® fittings
1 Replace the O-ring. The O-ring must be
replaced anytime the seal has been broken.
The O-ring cannot be re-used if the fitting or
hose end has been tightened beyond finger
tight.
The O-rings used in the Parker
Seal Lok® fittings and hose ends
are custom-size O-rings. They are
not standard SAE size O-rings.
They are available in the O-ring
field service kit.
2 Lubricate the O-ring before installation.
3 Be sure that the face seal O-ring is seated and
retained properly.
4 Position the tube and nut squarely on the face
seal end of the fitting and tighten the nut finger
tight.
5 Tighten the nut or fitting to the appropriate
torque per given size as shown in the table.
6 Operate all machine functions and inspect the
hoses and fittings and related components to
confirm that there are no leaks.
SPECIFICATIONS
