Ger Detect Gold Hunter User manual

•
Section 1:
Critical Warning
•
Section 2:
Overview
•
Section 3:
Definition of the main unit buttons & leds
•
Section 4:
The device features and specifications
•
Section 5:
Gold Hunter Smart device parts connection
•
Section 6:
Gold Hunter Smart device operation steps
•
Section 7:
The device parts and accessories
•
Section 8:
The technical specifications
1

- Please be sure that all precautions are taken against risks.
- Do not use your device while it is raining.
- Turn on the device after you make sure that all parts are in place and
connected.
- Make sure that the device battery is fully charged before you start
searching.
- If the indicator on the side of the device starts flashing, turn off the device
and recharge the battery.
- When the battery will almost die the device will turn off automatically.
- It is recommended to read the user manual before starting on the device to
understand everything and to avoid mistakes through the search.
- Be aware of (energy sources - phone network - metals - mobile phones -
electronic devices), and do not use any charger other than the original one of
the device.
- The device main unit is under two (2) years warranty against all electronic
breakdowns, any damages caused by user errors (falls, opening the main
unit, hits, harms etc.) are not covered within this warranty.
- Battery and charger are not under the warranty.
- You should strictly follow the instructions in this user manual to minimize
faults and to use your device correctly.
- If the device is not used correctly, or there is a high rate of noise, in these
cases the device will not be capable to confirm the target and determine the
depth.
We wish you all the best of luck in your search……
Critical Warning
2

Dear customer,
“Thank you for choosing GOLD HUNTER SMART”
✓A long-range system device with the addition of more systems and the
development of the device's characteristics to the imaging sensor
system and two-dimensional imaging technology.
✓The Gold Hunter Smart device has multiple features to search for gold,
buried treasures, precious metals and diamonds underground.
✓The system of searching for precious and non-precious metals: such
as buried antique gold - raw gold - veins of gold - meteorites - silver
- zircon - bronze - cobalt - coltan - mercury - copper - iron.
✓Super speed in capturing targets and locating them accurately.
✓Super Antenna which enables the device to cover large areas of
research .
✓The search depth of the Gold Hunter Smart device reaches 50 meters
in the ground and the forward range is 3000 meters square.
✓The device works in six languages: German - English - French -
Spanish - Italian –Arabic.
✓The Gold Hunter Smart device is one of the best German
manufactures. It has the European CE certificate according to
international specifications, in addition to the international ISO 9001
certificate according to international specifications and standards.
✓This device is designed to be compatible with its functioning in all
countries and regions.
(Overview)
3

-Definition of the main unit buttons & leds
Super antenna
Enhancer antennas
Recipient antenna
The device handle
Dish receiver and signal
purifier
4
Charge indicator
:
It lights up intermittently when
the battery is about to run out.
Charge input

The device features and specifications
The Gold Hunter Smart device has multiple features to search for gold,
buried treasures, precious metals and diamonds in the ground:
-Super speed in capturing targets and locating them accurately.
-The system for determining the target depth easily and accurately.
-The system for specifying the continent in which you search.
-A screen that supports the touch system which contains many
advantages and features.
-An electronic thermometer within the device screen which measures
the weather temperature.
-A digital clock
-The possibility of muting and activating the device's sound.
-Super Antenna which enables the device to cover large areas of
research.
-A radar search dish to receive and improve the signal.
5

Gold Hunter Smart device parts connection
Install the device handle
Install the Super Antenna
Install enhancer antennas
6

Install recipient antenna
Install the receiver dish for reference
Open the foldable screen
Increase the length of the antenna to
raise the front-sense range of the device
up to 3000 meters
7

Gold Hunter Smart device operation steps
Turn on the device by
pressing the power
button for two seconds
After turning on the device, the following data will appear on the main
screen:
Battery level indicator - clock - temperature - activate and mute
button.
8

1- Settings icon:
It contains the working
languages of the device, which
are:
German - English - French -
Spanish - Italian - Arabic
Device settings icon through
which you can set:
Sound level - brightness level -
time settings - device
information
Locate and choose the continent
icon you want to search in.
This unique feature was added
due to the different frequencies
of underground minerals from
one continent to another.
9

2- Search options:
Choose the type of target you want to search
underground.
Determine the front range of the device.
10

3- Search icon:
When you press the search icon, the device will directly start
searching, depending on the preset settings saved by the
prospector, which are (target type - front range - continent).
11

You can choose the target you want to search for.
(Example: Gold), which also appears in the front range screen
Then choose the front range you want to reach (from 100 meters to 500
meters - 1000 meters - 1500 meters - 2000 meters - 2500 meters -
3000 meters) (for example, 500 meters)
12

Example: If the front range of the target to be searched is expected to
be within an area of 500 square meters, it is sufficient to specify the
front range within 500 meters.
But if the front range of the target to be searched is unknown, you can
specify the front range up to 3000 meters.
Note: The explorer must stand facing north to south.
Whereas, the ionic fields are radiation emitted by gold, minerals, buried
treasures, and voids after being underground for a long time, and their
overlap and interaction with the soil and the nature of the earth’s
formation and its regularity with magnetic lines to the north and south.
13

The balance of the device must be maintained during the search by
fixing the yellow dot in the middle of the circle icon.
The device will start sending and receiving signals directing you
towards the target with a continuous sound.
When getting any signal, the device will directly turn towards the target
with the target direction indicator appearing on the screen and the
sound accelerating.
Confirm the direction of the target from all four directions to ensure
that the target is reached more precisely.
9⁰0
14

Follow the signal and when the device turns back you will have passed
the target
Limit the search site by placing a mark that will be the center for target
confirmation.
Then confirm the location of the target from the four directions (from
south to north - from north to south - from west to east - from east to
west).
When standing above the center of the target, the device will rotate
directly above the target.
North to south
South to north
East to west
West to east
15

After you have confirmed the location of the target, click on the
depth button to determine the depth and then move away from
the center of the target a distance of at least two meters.
Point the device towards the target while maintaining the
balance of the device, press the start button, wait until you hear
a beep from the device, then walk towards the target until the
device rotates backwards with the appearance of an icon
indicating the rotation of the device towards the back.
16

Turn in the opposite direction, press the start button, wait until
you hear a beep emanating from the device, and the icon shifts
from the rotation position to the forward position, then walk until
the device rotates backwards, the device will analyze and show
the final results automatically.
17

Important Note: The ratio to analyze the results in the Gold Hunter
Smart is as follows:
If the result of the noise is high and the target confirmation rate is
low: The device does not give depth, it is rather to retry the search
again.
If it gives us depth and the noise percentage is greater than 30% It is
preferable to try the search again.
if the target confirmation rate is less than 90% it is recommended to
try the search again.
The following results and conditions will appear on the device screen
when confirming the presence of a target:
Noise:
It is the percentage of noise in the search area, which results
from the proximity of (energy sources - phone networks - metals -
mobile phones - electronic devices)
Target confirmation:
the percentage of confirmation of the presence
of the target in the search area.
Depth:
The depth within which the target is likely to be located.
Example: the depth is between 160 cm to 202 cm.
-Noise 5%
- Target confirmation 99%
-In addition to
a(2D) two-dimensional
figure that expresses the
percentage of void or metal within the detected target.
18

- If the figure appears in Green
and
Yellow
: the target is buried in
the soil without being inside a
void or a metal box.
- If the figure appears gradient in
Red
: it is likely that the target is
inside a metal box.
- If the figure appears gradient in
Blue
: it is likely that the target is
within a void.
