Getac EX80 User manual

Rugged Mobile Computing Solution
EX80
USER MANUAL

August 2017
TRADEMARKS
The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc.
All brand and product names are trademarks or registered trademarks of
their respective companies.
NOTE
The information in this manual is subject to change without notice.
For the latest version of the manual, please visit the Getac website
at www.getac.com.

i
Table of Contents
Chapter 1 Getting Started.................................................................1
Getting the Tablet PC Running................................................. 2
Unpacking .............................................................................. 2
Installing the SIM Card (Optional)........................................ 3
Connecting to AC Power....................................................... 4
Turning On and Off the Tablet PC ....................................... 5
Identifying Hardware Components .......................................... 6
EX80........................................................................................ 6
Charging Cradle..................................................................... 9
Using Accessories ..................................................................... 10
Using the Tether .................................................................. 10
Using the Stylus Holder ....................................................... 11
Using the Hand Strap .......................................................... 12
Chapter 2 Operating Your Tablet PC ..............................................15
Using the Touchscreen............................................................. 16
Using Network and Wireless Connections ............................. 19
Using the LAN ...................................................................... 19
Using the WLAN................................................................... 20
Using the Bluetooth Feature .............................................. 21
Using the WWAN Feature (Optional) ................................ 23
Using the GPS Feature ............................................................. 25
Using the NFC/RFID Reader ..................................................... 26
Connecting USB Devices .......................................................... 27
Chapter 3 Managing Power ............................................................28
AC Adapter............................................................................... 29
Battery Pack.............................................................................. 30
Charging the Battery Pack .................................................. 30
Initializing the Battery Pack................................................ 31
Checking the Battery Level ................................................. 31
Battery Low Signals and Actions ........................................ 32

ii
Power-Saving Tips .................................................................... 33
Chapter 4 Using BIOS Setup............................................................34
When and How to Use............................................................. 35
Menu Descriptions ................................................................... 36
Information Menu ............................................................... 36
Main Menu........................................................................... 36
Advanced Menu................................................................... 36
Security Menu ...................................................................... 37
Boot Menu ........................................................................... 38
Exit Menu ............................................................................. 38
Chapter 5 Using Getac Software ....................................................39
G-Manager ............................................................................... 40
G-Camera.................................................................................. 41
Chapter 6 Care and Maintenance ...................................................42
Taking Care of the Tablet PC .................................................. 43
Location Guidelines ............................................................. 43
General Guidelines .............................................................. 44
Cleaning Guidelines............................................................. 44
Battery Pack Guidelines....................................................... 44
Touchscreen Guidelines....................................................... 45
When Traveling........................................................................ 47
Chapter 7 Troubleshooting .............................................................48
Preliminary Checklist................................................................ 49
Solving Common Problems...................................................... 50
Battery Problems ................................................................. 50
Bluetooth Wireless Transmission Problems ....................... 50
Display Problems.................................................................. 51
Hardware Device Problems ................................................. 51
Power Management Problems ........................................... 52
Sensor Problems................................................................... 52
Software Problems .............................................................. 53
Sound Problems ................................................................... 54
Startup Problems ................................................................. 54
WAN Problems..................................................................... 54
Other Problems.................................................................... 56
Resetting the Tablet PC ........................................................... 57
System Recovery....................................................................... 58
Using the Driver Disc (Optional) ............................................. 59

iii
Appendix A Specifications .................................................................60
Appendix B Regulatory Information.................................................62
On the Use of the System........................................................ 63
Class B Regulations .............................................................. 63
Safety Notices....................................................................... 64
On the Use of the RF Device.................................................... 67
USA and Canada Safety Requirements and Notices.......... 67
European Union CE Marking and Compliance Notices..... 69
User Notification of Take-back Service................................... 72
ENERGY STAR 6.1 ..................................................................... 73

1
Chapter 1
Getting Started
Congratulations on purchasing this rugged Tablet PC.
This chapter first tells you step by step how to get the Tablet PC up and
running. Then, you will find a section briefly introducing the external
components of the Tablet PC.

2
Getting the Tablet PC Running
Unpacking
NOTE: This packing list applies to standard models. Select models may have
different items.
After unpacking the shipping carton, you should find these standard items:
EX80 Tablet PC
Hand strap
Charging cradle Stylus holder
Stylus
AC adapter
Tether
Power plugs Cleaning cloth
Document(s) Driver disc (optional)
Inspect all the items. If any item is damaged or missing, notify your dealer
immediately.

3
Installing the SIM Card (Optional)
1. The SIM card slot is on the right side of the Tablet PC. Unfasten two
screws and flip open the cover.
2. Noting the orientation, insert the SIM card all the way into the slot.
NOTE: To remove the SIM card, just push in the card to release it and then
pull it out.
3. Close the cover and tighten the screws.
CAUTION: To ensure sealing capability and IP67 protection performance,
always have the cover closed with the screws tightened unless you need to
open it for inserting or removing a card.

4
Connecting to AC Power
CAUTION: Use only the AC adapter included with your Tablet PC. Using
other AC adapters may damage the Tablet PC.
NOTE: The battery pack is shipped to you in power saving mode that
protects it from charging/discharging. It will get out of the mode to be ready
for use when you connect AC power to the Tablet PC for the very first time.
You must use AC power when starting up the Tablet PC for the very first time.
1. Align the center line of the Tablet PC with the center line of the charging
cradle, and place the Tablet PC in the cradle.
2. Fit the power plug to the AC adapter (). Connect the DC jack end of
the AC adapter to the cradle () and the other end to a wall outlet ().

5
3. The Power indicator on the charging cradle lights green. Now, you are
ready to turn on the Tablet PC.
Turning On and Off the Tablet PC
Turning On
Press the power button ( ). The Windows operating system should start.
NOTE: Tapping the screen during startup may invoke a pre-boot menu
(unless the default settings have been changed). If the menu appears, simply
select Continue.
Turning Off
When you finish a working session, you can stop the system by turning off
the power or leaving it in Sleep or Hibernation mode:
To... Do this...
Power off
(Shutdown)
Tap Power Shut down.
Sleep Press the power button.*
-or-
Tap Power Sleep.
Hibernate By default, this option is not shown in the Start menu. If
you want to use the feature, set up accordingly in
Windows settings.
* “Sleep” is the default setting of the power button. You may change what
the power button does in Windows settings.
