UM ENGLISH
USER MANUAL
AKRON®
BOBATH
Models
4411, 4412, 4421, 4422
792-077-07

AKRON 4411, 4412, 4421, 4422
1
Contents
1. Introduction 2
Warnings, Cautions 2
General Warnings 2
2. Installation 3
3. Operation 4
5
4. Accessories – Operating Instructions 5
Breathing Hole and Plug 5
5. Cleaning and Decontamination 6
6. Troubleshooting 7
7. Maintenance 7
8. Warranty and Service 8
9
9. Revision Status 9
10. Technical Specification 10
11. Transport and Storage 11
12. Environmental Protection 11
The mark on this product demonstrates conformity with the EC Directive 93/42/EEC.

AKRON 4411, 4412, 4421, 4422
2
1. Introduction
Always keep this Operating Manual available for reference.
Warnings & Cautions
General Warnings
WARNINGS
Warnings identify possible hazards in procedures or conditions which, if not correctly followed,
could result in death, injury or other serious adverse reactions.
CAUTIONS
Cautions identify conditions or procedures which, if not correctly followed, could result in equipment
failure or damage.
WARNINGS
Use only accessories that have been designed or approved for use with this couch.
Do not use electric couches in the presence of flammable gasses such as an
anaesthetic agent.
Maximum Load 225 Kg (495 lbs) distributed evenly.
Do not concentrate weight on either side of the couch.
Plug acts as a disconnect device.
Do not allow children to play with the couch at any time.
Adequately supervise children in the proximity of the couch.

AKRON 4411, 4412, 4421, 4422
3
2. Installation
Adjustable Foot
Electric Models
Ensure mains supply cable is not stretched when connected.
Ensure, during couch use, no obstacles are in its path.
Ensure hand / foot switch tubes or leads are not trapped by moving parts of the couch.
WARNING
Lock castors before adjusting.
A) Lock castors first.
B) Adjust foot.
C) Lock foot by tightening half nut.
WARNING
Do not insert the 2-pin mains connector directly into a 3-pin 13A mains outlet.
Always use the adapter provided.
Plug acts as a disconnect device.
Use adapter if 3 pin 13A plug is required.
(Order reference 5S0409Z)
CAUTION
When not in use, switch couch off.

AKRON 4411, 4412, 4421, 4422
4
3. Operation
Elevation Controls
Hydraulic Models
Hydraulic Pedal
Electric Models
Handswitch
Footswitch
WARNING
Safely position patient before elevating couch.
Position all electrical cables away from the moving parts.
Position Hand/Foot switch where accidental operation is not possible.
PUMP PEDAL TO
RAISE COUCH
LIFT PEDAL TO
LOWER COUCH
Press to raise table.
Press to lower table.
AUF
Press to raise tabl
e.
AB
Press to lower table.

AKRON 4411, 4412, 4421, 4422
5
3. Operation
Wheel Locking
Castors
Castors Unlocked Castors Locked
Head Section
Head Section Operating Lever Angles = +85° - 0°
4. Accessories – Operating Instructions
Breathing Hole and Plug
WARNING
Lock couch wheels/castors prior to patient transfer or treatment.
The retractable castors are not designed for transportation of patients.
Disconnect and coil electrical cord away from moving parts prior to
repositioning couch.
A) Press lever UP to alter section angle.
B)
Support section when altering angle.
C)
Release lever to lock section in position.
Remove plug for patient prone position
Press out from underneath
CAUTION
Support upholstery section while manually altering angle.

AKRON 4411, 4412, 4421, 4422
6
5. Cleaning and Decontamination
Frequency of routine couch cleaning will depend on exact application.
CLEANING / DECONTAMINATION
Locate couch in a suitable cleaning area with castors disengaged or wheels locked.
1. Wear protective clothing: plastic disposable apron and gloves.
2. Disconnect any mains supply and lock couch wheels.
3. Control handsets can be wiped over using a 70% Isopropranol alcohol wipe.
4. Prepare a solution of warm water and neutral detergent.
5. Start at the top of the couch and work your way downwards.
6. Wipe over head end working towards mid torso.
7. Wipe over remaining horizontal patient surface, working towards foot end.
8. Wipe all horizontal parts under the patient surface.
9. Wipe all vertical parts under the patient surface.
10. Wipe over shroud (if fitted).
11. Wipe over all parts of wheels.
12. Ensure all parts of the couch are dry before re-use.
13. Safely discard cleaning materials.
14. Wash hands thoroughly.
If DECONTAMINATING then repeat steps 1) to 14) using a dilute Hypochlorite / warm water mixture
(10,000ppm) instead of warm water and soap.
Put couch back into service.
WARNING
Do not use Alkalis or other organic solvents for routine cleaning.
Replace torn or damaged vinyl immediately.
Always cover vinyl with fresh paper or sheet between patients.
If contamination is known or suspected always decontaminate couch before use.

AKRON 4411, 4412, 4421, 4422
7
6. Troubleshooting – Electric Actuator
Symptom
Possible cause
Action
Actuator will not work
Power disconnected
Fuse blown
Hand/footswitch disconnected
Ensure mains supply is connected
Replace fuse in socket
Check that the hand/foot switch is
fully inserted into the actuator
If the problem persists consult your local Akron Supplier.
7. Maintenance
Check couch visually before use.
Carry out routine servicing every six months or more frequently if in heavy use.
Routine servicing or repair must only be performed by suitably qualified person.
Examine the couch for any signs of damage. Make sure that all nuts, bolts and other fasteners are tight.
Do not over tighten as this may cause binding.
Upholstery fasteners should be checked, tightened or replaced if necessary.
Check section hinge pins to ensure that no pin protrudes.
Check gas strut controls, throughout the full range of movement for locking and assistance.
Check hydraulic couches for smooth operation and signs of leakage.
Examine the flexible cables for cuts, abrasions, kinking or other deterioration and replace if necessary.
Ensure that the power supply connector plug is securely attached.
Check mains plug connections are tight and fuse is correctly rated (5A).
WARNING
Before commencing any maintenance activity, disconnect the couch from the
electrical supply. Plug acts as disconnect device.
WARNING
All electrical checks should be performed by a suitably qualified and licensed
electrician.
Neither BLUE or BROWN wires are to be connected to the earth terminal of a
three pin plug.

AKRON 4411, 4412, 4421, 4422
8
8. Warranty and Service (UK only)
ArjoHuntleigh AB standard terms and conditions apply to this couch. A copy is available upon request.
These contain full details of warranty terms and do not limit the statutory rights of the consumer.
For service or maintenance please contact:
Service Department
Huntleigh Healthcare
310-312 Dallow Road
Luton
Beds
LU1 1TD
Telephone: [phone]
Fax: [phone]
For information on this product, regarding warranty and spare parts, please contact:
ArjoHuntleigh AB
Verkstadsvägen 5
241 38 Eslöv
SWEDEN
www.arjohuntleigh.com
If for any reason your couch is being returned, please inform ArjoHuntleigh AB prior to sending, and:
1. Clean the product, as described in the cleaning section.
2. Pack it in suitable packing.
3. Attach the decontamination certificate (or other written statement declaring that the product has
been cleaned) to the outside of the package.
4. Mark the package “Service Department”.
Manufactured in Poland by ArjoHuntleigh AB. As part of the ongoing development programme this
company reserves the right to modify specifications and materials of this couch without notice.

AKRON 4411, 4412, 4421, 4422
9
8. Warranty and Service (Outside UK)
ArjoHuntleigh AB standard terms and conditions apply to this couch. A copy is available upon request.
These contain full details of warranty terms and do not limit the statutory rights of the consumer.
For service, maintenance and any questions regarding this, or any other ArjoHuntleigh AB Product,
please contact:
ArjoHuntleigh AB
Verkstadsvägen 5
241 38 Eslöv
SWEDEN
www.arjohuntleigh.com
If for any reason your couch is being returned, please inform ArjoHuntleigh AB prior to sending and:
1. Clean the product, as described in the cleaning section.
2. Pack it in suitable packing.
3. Attach the decontamination certificate (or other written statement declaring that the product has
been cleaned) to the outside of the package.
4. Mark the package “Service Department”.
Manufactured in Poland by ArjoHuntleigh AB. As part of the ongoing development programme this
company reserves the right to modify specifications and materials of this couch without notice.
9. Revision Status
4411, 4412, 4421, 4422
PAGES
ISSUE
WRITTEN
DATE
ALL PAGES
UM - 01
S.Rees
26/05/98
ALL PAGES
UM - 02
S.Rees
07/01/99
PAGES 8 & 9
UM - 03
J. Austin
18/11/99
PAGE 2
UM - 04 (DCN958)
J. Barker
30/10/00
VARIOUS
UM - 05 (DCN1058)
J. Barker
25/09/03

AKRON 4411, 4412, 4421, 4422
10
10. Technical Specification
4411
4412
4421
4422
Head Length (cm)
71±1.5
71±1.5
71±1.5
71±1.5
Foot Length (cm)
124±1.5
124±1.5
124±1.5
124±1.5
Width (cm)
106±1.5
106±1.5
125±1.5
125±1.5
Overall Length (cm)
196±3
196±3
196±3
196±3
Height Range (cm)
46±1.5
91±1.5
46±1.5
91±1.5
46±1.5
91±1.5
46±1.5
91±1.5
Max. Load Weight
225 Kg
225 Kg
225 Kg
225 Kg
Elevation Control
Hydraulic
Electric
Hydraulic
Electric
Electrical Data 230v
Actuator
220-240v
220-240v
Internal Fuse Rt
T1.6A x 1
T1.6A x 1
Current
1.6A
1.6A
Power
480W
480W
Mains Plug Fuse Rt (UK)
5.0A x 1
5.0A x 1
Electrical Data 115v
Actuator
115v
115v
Internal Fuse Rt
F4.0A x 1
F4.0A x 1
Current
3.3A
3.3A
Power
380W
380W
IEC 601-1 Classification
Check serial number label for classification
230v
115v
115v
Double Insulated Double Insulated Class 1
Type B equipment Type B equipment Type B equipment
Attention consult this
manual Attention consult this manual Attention consult this manual

AKRON 4411, 4412, 4421, 4422
11
11. Transportation and Storage
Handle with care. Do not drop. Avoid shock or violent impact.
The equipment should be stored in a clean, dry and well ventilated area. The following limits apply
during transport and for a storage period of up to 15 weeks:
Ambient temperature -25°C to +70°C
Relative humidity 10% to 75%
Air pressure 50 kPa to 106 kPa
The following limits apply to operating conditions or longer periods of storage:
Ambient temperature +10°C to +40°C
Relative humidity 30% to 75%
Air pressure 70 kPa to 106 kPa
12. Environmental Protection
Dispose of unit in compliance with local regulations.

AKRON 4411, 4412, 4421, 4422
Intentionally left blank

AKRON 4411, 4412, 4421, 4422
Intentionally left blank

AKRON
BOBATH
型号
4411
，
4412,4421,4422
用户手册

目录
1.
介绍
2
警告，注意 2
常规警告 2
2.
安装
3
3.
操作
4
5
4.
附件
-
操作指示说明书
5
呼吸孔和塞子 5
5.
清洁以及消毒
6
6.
发现并解决故障
7
7.
维护
7
8.
保修及服务
8
9.
修订状况
9
10.
技术详细说明
10
11.
运输以及存储
11
12.
环境保护
11
产品上标记的 标识证实该产品符合 EC Directive 93/42/EEC 的标准要求。

1.
介绍
本操作手册便于操作人员参考。
警告
&
注意
警告
警告定义了在产品使用过程中可能的危险，或者因为没有正确的遵守产品的条件要求而
可能导致的伤害，包括可能会造成死亡，伤害或者其他严重的不良反应。
注意
注意定义了一些条件和使用过程，如果在使用产品过程中没有遵守这些要求，则可能会
导致失败或者损坏。
常规警告
警告
只能使用经过设计与批准用于与此诊疗床共同工作的附件。
不要在存在易燃气体比如麻醉剂的环境下使用电动诊疗床。
最大均匀分布载重重量为 225Kg（495lbs）。
不要将重量集中在诊疗床的任何一边上。
插头作为断开连接的装置。
任何时候都不要让孩子在诊疗床上随意玩耍。
当孩子靠近诊疗床时要时刻保持监督。

2.
安装
可调节诊疗床脚
警告
在调节前请锁定车轮
A) 首先请锁定车轮
B)调节诊疗床脚
C) 通过拧紧半螺丝来锁定诊疗床脚
警告
不要在
3-pin 13A
电源插座上插入
2-pin
的电源连接器。
请始终使用提供的适配器。
插头作为断开设备连接的设置。
电子模式
如果需要 3 pin 13A 插头，请使用转换器
请确认当连接时电源支持电缆没有被拉伸。
请确认当使用诊疗床时，在通过的通道上没有障碍物存在。
请确认手脚控制器的管线和引导线不会被诊疗床可移动部件妨碍截留。
注意
当不使用诊疗床时，请使其处于关闭状态。
