GEZE Perlan AUT-NT User manual

1
GEZE Perlan
AUT-NT
Wood tting 1-/2-leaf
GB Mounting instructions

GEZE Perlan AUT-NT
2
Table of contents
1 Symbols and means of representation............................................................................................................3
1.1 Warnings..............................................................................................................................................................................................................3
1.2 Further symbols and means of representation.....................................................................................................................................3
2 Product liability ........................................................................................................................................................3
3 Safety ...........................................................................................................................................................................3
3.1 Intended use.......................................................................................................................................................................................................3
3.2 Important safety instructions......................................................................................................................................................................4
3.3 Safety-conscious working.............................................................................................................................................................................4
3.4 Inspection of the mounted system............................................................................................................................................................4
3.5 Additionally applicable documents ..........................................................................................................................................................4
4 Transportation and storage .................................................................................................................................5
5 Tools and aids ...........................................................................................................................................................5
6 Product description ................................................................................................................................................5
6.1 Technical data....................................................................................................................................................................................................5
6.2 Function description.......................................................................................................................................................................................5
7 Mounting instructions ...........................................................................................................................................6
8 Mounting....................................................................................................................................................................6
8.1 Mounting tracks................................................................................................................................................................................................6
8.2 Mounting the drive unit.................................................................................................................................................................................8
8.3 Hanging in the door leaves.........................................................................................................................................................................11
8.4 Positioning the door leaf to the main closing edge..........................................................................................................................13
8.5 Positioning the door leaf to the side closing edge............................................................................................................................15
8.6 Mounting the oor guide............................................................................................................................................................................19
8.7 Mounting the toothed belt........................................................................................................................................................................ 20
9 EC-Declaration of Conformity .......................................................................................................................... 27

GEZE Perlan AUT-NT
3
Symbols and means of representation
Symbols and means of representation1
Warnings1.1
In these instructions, warnings are used to warn against material damage and injuries.
Always read and observe these warnings.
X
Observe all the measures that are marked with the warning symbol and warning word.
X
Warning
symbol
Warning word Meaning
WARNING Danger for persons.
Non-compliance can result in death or serious injuries.
CAUTION Danger for persons.
Non-compliance can result in minor injuries.
– CAUTION Information on avoiding material damage, understanding a concept or optimising the
processes.
Further symbols and means of representation1.2
Important information and technical notes are emphasised in order to illustrate the correct operation.
Symbol Meaning
means "important note"
means "additional information"
XSymbol for an action: Here you have to do something.
Observe the sequence if there are several action steps.
X
Product liability2
In accordance with the liability of manufacturers for their products as dened in the German "Produkthaftungs-
gesetz" (Product Liability Act), the information contained in these instructions (product information and proper
use, misuse, product performance, product maintenance, obligations to provide information and instructions) is
to be observed. Non-compliance releases the manufacturer from its statutory liability.
Safety3
Intended use3.1
The PERLAN AUT-NT sliding door drive is designed for the automatic opening and closing of the sliding leaves.
The PERLAN AUT-NT sliding door drive is suitable for use in dry rooms in private areas.
The PERLAN AUT-NT sliding door drive may not be used at re or smoke protection doors and in a hazardous (Ex)
area.
The PERLAN AUT-NT sliding door drive may not be used to open and close vertical sliding leaves.
Any other use than the proper use, such as permanent manual operation, as well as all changes to the product
are impermissible.
.

GEZE Perlan AUT-NT
4
Safety
Important safety instructions3.2
To ensure personal safety, it is important to follow these instructions.à
Keep these instructions.à
The prescribed mounting, maintenance and repair work must be performed by properly trained personnelà
authorised by GEZE.
GEZE shall not be liable for injuries or damage resulting from unauthorised modication of the system.à
GEZE shall not be liable if products from other manufacturers are used with GEZE equipment.à
Only original GEZE parts may be used for repair and maintenance work.à
The connection to the power supply must be made by a professional electrician. Perform the power connec-à
tion in accordance with DIN VDE 0100-610.
The electrical installation at the customer has to have an all-pole power disconnector that can be secured reli-à
ably against reactivating (e.g. lockable switch with at least 3 mm contact opening).
A customer-side 10 A overload cut-out must be used as the line-side disconnecting device.à
Observe the latest versions of guidelines, standards and country-specic regulations, in particular:à
BGR 232 "Guidelines for power-operated windows, doors and gates"à
DIN 18650, Part 1 and 2 "Automatic door systems"à
DIN VDE 100-600 "Installation of low-voltage systems - Part 6 Tests"à
DIN EN 60335-1 "Safety of electrical devices for home use and similar purposes"à
Accident-prevention regulations, especially BGV A1 (VBG1) "General regulations", BGV A3 (VBG4) "Electricalà
systems and equipment"
Safety-conscious working3.3
Protect the workplace against unauthorised entry.
X
Use only cables specied in the cable plan and shield in accordance with the wiring diagram.
X
Before working on the electrical system disconnect the drive from the 230 V mains network and check the
X
safe isolation from supply.
Note that the system will still be supplied with power, despite the fact that the power supply is disconnected,à
if an uninterruptible power supply (UPS) is used.
Always use insulated wire-end ferrules for wire cores.
X
Danger of injury by sharp edges in the drive!à
Inspection of the mounted system3.4
Safety analysis (danger analysis)
In accordance with Machinery Directive 2006/42/EC and DIN 18650, a risk analysis must be performed and the
door system identied in accordance with CE Identication Directive 98/68/EEC before commissioning the door
system.
This includes:
Enter the classication in accordance with DIN 18650-1 on the information plate and adhere the information
X
plate onto the drive housing so that it is visible from below.
Check the measures for security and prevention of crushing, impact, shearing or drawing-in spots.
X
Check the electrical fusing.à
Check the system for avoidable operating errors.à
Additionally applicable documents3.5
Drawing No. Type
10421-9-9609 PERLAN AUT-NT wiring diagram
10421-9-9610 PERLAN AUT-NT cable plan
10421-9-9624 PERLAN AUT-NT user manual
The diagrams are subject to change.
Use only the most recent versions.

GEZE Perlan AUT-NT
5
Transportation and storage
Transportation and storage4
CAUTION!
Damage to the PERLAN AUT-NT sliding door drive through hard knocks and falls.
Do not throw or let drop the PERLAN AUT-NT.
X
CAUTION!
Storage temperatures under –15°C and above +60°C can result in damage to the device.
Store dry. Protect from moisture during transportation and storage.
X
Tools and aids5
Tape measureà
Marking penà
Allen keyà
Screwdriver setà
Side-cutting pliersà
Crimping pliers for cablesà
Wire stripperà
Multimeterà
Product description6
Technical data6.1
Mechanical data (drive)
Dimensions (WxHxL): 55 mm x 45 mm x 145 mmà
Ambient temperature: 0°C to +50°Cà
Drive mass: approx. 0.75 kgà
Electrical data
Mains connection: 230 Và
Power consumption: max. 35 W, standby approx. 3.5 Wà
Externally connectable devices: 24 V DC, max. 50 mAà
Function description6.2
The system is an electrical sliding door drive. The controller drives a 24 V DC motor that moves a linear sliding
door via a toothed belt.
Track6.2.1
Almost the complete technology is located in the track. In addition to the sliding and stop elements, this also
contains the drive with the corresponding guide pulleys.
Floor guide6.2.2
A oor guide is used to guide the sliding element correctly. Its use is mandatory.
Roller carriage/suspension6.2.3
The roller carriage consists of supported rollers. The leaves are fastened adjustable in height to the suspension.
Toothed belt6.2.4
The toothed belt forms the connection to the sliding elements via pulley guides. The toothed belt is cut to size as
required and connected by means of a toothed belt lock.

GEZE Perlan AUT-NT
6
Mounting instructions
Mounting instructions7
Follow the installation diagrams.
The technical company is responsible for the selection of the suitable mounting technology as well as the suit-
X
able mounting material. The specied representations have to be adapted in accordance with the situation.
The PERLAN AUT-NT roller-guided sliding door system is oered in the following variants:
  




 









Direct ceiling mounting1
Ceiling mounting with ceiling bracket2
Wall mounting with wall bracket3
Further variants are shown on the Drawings 10421-EP-53 and 10421-EP-55.
Mounting8
Mounting tracks8.1
Take accessibility into account:
If after mounting there is not enough space on the side to slide in the roller carriage, buer and guide roller
X
(e.g. in case of wall recess mounting), these parts have to be slid in before the track is mounted.
Wall mounting with wall bracket8.1.1
Drill holes for the wall bracket (1) in the wall.
X
Screw the wall bracket (1) onto the wall.
X
1
1
Use only countersunk screws to fasten the track to the wall bracket.
X

GEZE Perlan AUT-NT
7
Mounting
Fasten the track (2) to the wall brackets (1) with
X
screws and sliding blocks (3).
2
3
Wall mounting with concealed wall bracket8.1.2
Drill holes for the concealed wall bracket (4) in
X
the wall.
Screw the concealed wall bracket (4) onto the
X
wall.
4
Use only countersunk screws to fasten the concealed wall bracket.
X
Screw the track (2) onto the concealed wall
X
bracket (4).
4
2
4 Nm

GEZE Perlan AUT-NT
8
Mounting
Ceiling mounting8.1.3
Drill holes into the ceiling.
X
Use only countersunk screws to fasten the track to the ceiling.
X
Use screws to screw the track (2) to the ceiling.
X
2
Mounting the drive unit8.2
Mounting the drive unit for a 1-leaf system8.2.1
Slide the roller carriage (5) into the track (2).
X
5
5
2

GEZE Perlan AUT-NT
9
Mounting
Slide the rst buer (6) and guide roller (7) into
X
the track (2).
62
7
Slide the second buer (6) into the track (2).
X
2
6
Slide the drive (8) into the track (2) until it stops.
X
8
2
Tighten the clamping of the drive with an Allen
X
key Size 4 to 5 Nm.

GEZE Perlan AUT-NT
10
Mounting
Mounting the drive unit for a 2-leaf system8.2.2
Slide the buer (6) into the track (2).
X
2
6
Slide the roller carriage (5) into the track (2).
X
5
5
2
Slide the buer (6) and guide roller (7) into the
X
track (2).
6
2
7
Slide the roller carriage (5) into the track (2).
X
5
5
2

GEZE Perlan AUT-NT
11
Mounting
Slide the buer (6) into the track (2).
X
2
6
Slide the drive (8) into the track (2) until it stops.
X
8
2
Tighten the clamping of the drive with an Allen
X
key Size 4 to 5 Nm.
Hanging in the door leaves8.3
Hanging in the door leaf for a 1-leaf system8.3.1
Mounting with a carrier plate on a wooden leaf is shown here.
For other types of mounting (e.g. concealed carrier plate): see Drawing 10421-EP-38.à
Mount the carrier plate (9) and carrier bracket
X
(10) on the door leaf in accordance with Drawing
10421-EP-53.



GEZE Perlan AUT-NT
12
Mounting
Mount the carrier bracket (10) at a distance of
X
5.5 mm to the door leaf middle.



Hang in the door leaf and align to the wall.
X
The bottom edge of the door leaf should have a
distance of less than 8 mm from the oor and may
not have more than 8 mm under any circum-
stances.
Adjust the height of the door leaf with the ad-
X
justing screws (12).
Adjust the door leaf horizontally using the ad-
X
justing screws (12).
Lock with the hexagon nut (11).
X



Hanging in the door leaf for a 2-leaf system8.3.2
Mount the carrier plate (9) and carrier bracket
X
(10) for the toothed belt lock on the door leaf in
accordance with Drawing 10421-EP-55.



GEZE Perlan AUT-NT
13
Mounting
During mounting ensure that one carrier
X
bracket (10) points to the wall and the other
carrier bracket in the opposite direction.
Mount the carrier bracket (10) at a distance of
X
5.5 mm to the door leaf middle.
Hang in the door leaf, adjust with the adjusting
X
screw and lock with the hexagon nut, see Sec-
tion 8.3.1.




Positioning the door leaf to the main closing edge8.4
Information on positioning the leaves:
1-leaf wooden door: Drawing 10421-EP-53à
2-leaf wooden door: Drawing 10421-EP-55à
Positioning the door leaf for a 1-leaf system to the main closing edge8.4.1
Slide the door leaf to the desired position.
X
Slide the buer (6) to the door leaf or the roller
X
carriage.
�

GEZE Perlan AUT-NT
14
Mounting
Slide the door leaf 200 mm towards the side
X
closing edge.
Tighten the clamping of the buer (6) slightly
X
with an Allen key.
Tighten the buer (6) with 5 Nm.
X
�
Positioning the door leaf for a 2-leaf system to the main closing edge8.4.2
Slide the door leaf to the desired position.
X
�
Slide the buer (6) to the door leaf or the
X
roller carriage on the left and right.
�

GEZE Perlan AUT-NT
15
Mounting
Slide the door leaf 200 mm towards the side
X
closing edge.
Tighten the clamping of the left- and right-
X
hand buer (6) slightly with an Allen key.
Tighten the left- and right-hand buer (6)
X
with 5 Nm.
�
Positioning the door leaf to the side closing edge8.5
Information on the toothed belt lock mounting set:
1-leaf wooden door: Drawing 10421-EP-53à
2-leaf wooden door: Drawing 10421-EP-55à
Positioning the door leaf for a 1-leaf system to the side closing edge8.5.1
Slide the door leaf to the desired position.
X

GEZE Perlan AUT-NT
16
Mounting
Slide the buer (6) to the door leaf or the roller
X
carriage.
�
Slide the door leaf 200 mm towards the main
X
closing edge.
Tighten the clamping of the buer (6) slightly
X
with an Allen key.
Clamp the buer (6) with 5 Nm.
X
�

GEZE Perlan AUT-NT
17
Mounting
Positioning the door leaf for a 2-leaf system to the side closing edge left8.5.2
Slide the door leaf to the desired position.
X
Slide the buer (6) to the door leaf or the roller
X
carriage.
�

GEZE Perlan AUT-NT
18
Mounting
Slide the door leaf 200 mm towards the main
X
closing edge.
Tighten the clamping of the buer (6) slightly
X
with an Allen key.
Clamp the buer (6) with 5 Nm.
X
�
Positioning the door leaf for a 2-leaf system to the side closing edge right8.5.3
Slide the door leaf to the desired position.
X

GEZE Perlan AUT-NT
19
Mounting
Slide the buer (6) to the door leaf or the roller
X
carriage.
�
Slide the door leaf 200 mm towards the side
X
closing edge.
Tighten the clamping of the buer (6) slightly
X
with an Allen key.
Clamp the buer (6) with 5 Nm.
X
�
Mounting the oor guide8.6
Information on mounting the oor guide:
1-leaf wooden door: Drawing 10421-EP-53à
2-leaf wooden door: Drawing 10421-EP-55à
Mount the oor guide in accordance with the mounting instructions 10421-6-993.
X

GEZE Perlan AUT-NT
20
Mounting
Mounting the toothed belt8.7
Mounting the toothed belt for a 1-leaf system8.7.1
Fasten the toothed belt beginning with the toothed belt lock
Information on mounting the toothed belt lock:
Wooden leaf: Mounting slip 10421-9-0931à
1-leaf wooden leaf: Drawing 10421-EP-53à
2-leaf wooden leaf: Drawing 10421-EP-55à
Thread the toothed belt (14) into the toothed
X
belt lock with the smooth side facing outwards.



Knock in the locking pin (15).
X



Thread in the toothed belt
Thread the toothed belt (14) into the motor with
X
the smooth side facing outwards.

