GIGAIPC QBiX-WP Series User manual

System - QBiX-WP Series (Waterproof) QBiX-WP-APLA3940H-A1
1www.gigaipc.com
QBiX-WP-APLA3940H-A1
(QW-3940A-SI)
QBiX-WP Waterproof Industrial Embedded System
Quick Start Guide

2
www.gigaipc.com
Copyright Notice
This document is copyrighted, 2019. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for any
infringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and
is subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its accuracy,
GIGAIPC assumes no liabilities resulting from errors or omissions in this
document, or from the use of the information contained herein.
GIGAIPC reserves the right to make changes in the product design
without notice to its users.

System - QBiX-WP Series (Waterproof) QBiX-WP-APLA3940H-A1
3www.gigaipc.com
Acknowledgement
All other products’ name or trademarks are properties of their
respective owners.
• AMD is trademark of Advanced Micro Devices.
• Microsoft Windows is a registered trademark of Microsoft Corp.
• Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel
Corporation
• Core, Atom are trademarks of Intel Corporation
• ITE is a trademark of Integrated Technology Express, Inc.
• IBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

4
www.gigaipc.com
Packing List
Before setting up your product, please make sure the following items
have been shipped:
Item Quantity
COM Cable, waterproof (25CF8-1K8400-O0S) 3
USB 2.0 Cable, waterproof (25CFA-1K8000-O0R) 2
RJ45 Cable, waterproof (25CR0-1K8401-O0S) 2
SIGNAL Cable, waterproof (25CR5-1K8500-O0R) 1
HDMI Cable, waterproof (25CRC-180720-O0S) 1
DC JACK Cable, waterproof (25CRD-1K8300-O0S) 1
Wall mount (25HBA-826520-H5R) 2
Exsiccator (10g) 1
If any of these items are missing or damaged, please contact your
distributor or sales representative immediately.

System - QBiX-WP Series (Waterproof) QBiX-WP-APLA3940H-A1
5www.gigaipc.com
About this Document
This User’s Manual contains all the essential information, such as
detailed descriptions and explanations on the product’s hardware
and software features (if any), its specifications, dimensions, jumper/
connector settings/definitions, and driver installation instructions (if
any), to facilitate users in setting up their product.
Users may refer to the GIGAIPC.com for the latest version of this
document.

6
www.gigaipc.com
Safety Precautions
Please read the following safety instructions carefully. It is advised that
you keep this manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the
device.
3. Position the power cord so that people cannot step on it. Do
not place anything over the power cord.
4. Always completely disconnect the power before working on the
system’s hardware.
5. No connections should be made when the system is powered
as a sudden rush of power may damage sensitive electronic
components.
6. If the device is not to be used for a long time, disconnect it from
the power supply to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before
cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray
detergents.
9. Make sure the device is installed near a power outlet and is
easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent
falls
12. Do not cover the openings on the device to ensure optimal heat
dissipation.

System - QBiX-WP Series (Waterproof) QBiX-WP-APLA3940H-A1
7www.gigaipc.com
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is
running
15. Never pour any liquid into the openings. This could cause fire or
electric shock.
16. As most electronic components are sensitive to static electrical
charge, be sure to ground yourself to prevent static charge
when installing the internal components. Use a grounding
wrist strap and contain all electronic components in any static-
shielded containers.
17. If any of the following situations arises, please the contact our
service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described
in this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED
ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S
PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO
PREVENT DAMAGE.

8
www.gigaipc.com
FCC Statement
This device complies with Part 15 FCC Rules. Operation
is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device
must accept any interference received including
interference that may cause undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions and your local government’s
recycling or disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du fabricant
et les directives gouvernementales de recyclage.
High Temperature Warning
(1) This equipment is intended to be used in
Restrict Access Location. The access can only be
gained by Skilled person or by Instructed person
who have been instructed about the metal chassis
of the equipment is so hot that Skilled person have
to pay special attention or take special protection.
Only authorized by well trained professional person can access the
restrict access location.
(2) External metal parts are hot!! Before touching it, special attention
or protection is necessary

System - QBiX-WP Series (Waterproof) QBiX-WP-APLA3940H-A1
9www.gigaipc.com
Table Contents
QBiX-WP Waterproof Industrial Embedded System 1
Quick Start Guide
Copyright Notice .......................................................................... 2
Acknowledgement ....................................................................... 3
Packing List................................................................................... 4
About this Document ................................................................... 5
Safety Precautions ....................................................................... 6
FCC Statement.............................................................................. 8
High Temperature Warning ......................................................... 8
Chapter 1 - Product Specifications 11
1.1 Specifications ............................................................... 13
Chapter 2 – QBiX-WP-APLA3940H-A1 (QW-3940A-SI) 15
Waterproof Industrial Embedded System Kit
2.1 Dimension .................................................................... 16
2.2 Getting Familiar with Your Unit..................................... 17
2.3 COM 1 Connector for RS-232/422/485 & RI/5V/12V ... 19
2.4 COM 2/3 Connector for RS-232.................................... 19
2.5 DIO Connector .............................................................. 19
2.6 DC-IN Connector .......................................................... 20
2.7 LAN 1/2 Connectors .................................................... 20
2.8 USB 1/2 Connectors for USB 2.0 .................................. 20
2.9 HDMI 1.4 Connector .................................................... 21
2.10 Support ........................................................................ 22

10
www.gigaipc.com
2.11 Safety and Regulatory Information............................... 23
Chapter 3 – Hardware Information 25
3.1 Jumpers and Connectors ............................................. 26
3.2.1 FAN (FAN connector) ................................................... 29
3.2.2 DC IN (DC IN 1 x 4-pin power connector) .................... 30
3.2.3 COM1, COM2, COM3, COM4 (Serial port header) ....... 31
3.2.4 SPK_OUT (Speaker out connector) ............................... 32
3.2.5 JCOM11 (RI# pin RI#/5V/12V Select jumper for COM1 port)
................................................................................................. 33
3.2.6 JRS11-JRS14 (RS11-14 select jumper for serial port)..... 34
3.2.7 AT_CN (AT/ATX power mode select jumper) ................ 35
3.2.8 LSW (LVDS resolution jumper)...................................... 36
3.2.9 LVDS (LVDS connector).................................................. 37
3.2.10 BKL_CN (Backlight brightness control connector)........ 38
3.2.11 BUZZER.......................................................................... 39
3.2.12 BATTERY ....................................................................... 40
3.2.13 SATAPW (SATA power connector) ............................... .41
3.2.14 SATAIII (SATA 6Gb/s Connector) .................................. 42
3.2.15 FUSB20_1, FUSB2_2 (USB 2.0 header).......................... 43
3.2.16 GPIO_CNT (General Purpose input/output header) ... 44
3.2.17 SYS_PANEL (Front panel header) .................................. 45
3.2.18 CLS_CMOS (Clean CMOS jumper)................................. 46

11 www.gigaipc.com
System - QBiX-WP Series (Waterproof) QBiX-WP-APLA3940H-A1
Chapter 1
Chapter 1 - Product Specifications

12
www.gigaipc.com

13 www.gigaipc.com
System - QBiX-WP Series (Waterproof) QBiX-WP-APLA3940H-A1
1.1 Specifications
System QBiX-WP-APLA3940H-A1 (QW-3940A-SI)
Dimension System Size : 188W x 155D x 72H (mm)
CPU
Intel® Atom® x5-E3940 Processor
14nm, 4 cores, 4 threads, up to 1.80 GHz
TDP 9.5W
Chipset SoC
Memory
2 x DDR3L SO-DIMM sockets, Max. Capacity 8 GB
Support Dual channel DDR3L 1866 MHz memory modules
(Integrated memory 8GB)
Ethernet 2 x GbE LAN Ports (Intel® I211AT)
Graphic support
Integrated Graphics Processor - Intel® HD Graphics 500:
1 x HDMI port, supporting a maximum resolution of
3840x2160 @30Hz
Audio Realtek® Audio Codec
Storage 1 x 2.5” HDD/SSD (SATA 6Gb/s)
Expansion Slots
1 x 2242 M.2 M-Key (SATA 6Gb/s)
1 x Full-size Mini PCIe with SIM slot (PCIe x1 + USB2.0) --
support 3G/4G module
(Integrated M.2 SSD 256GB)
Front I/O
2 x (M12) LAN Ports
2 x (IP67) USB 2.0 connector
1 x (IP67) HDMI connector
1 x (IP67) Power switch
1 x (M8) Power & HDD LED
Rear I/O
1 x (M12) COM Port (RS-232/422/485 & RI/5V/12V)
2 x (M12) COM Port (RS-232)
1 x (M12) GPIO (8 bits)
1 x (M12) DC Jack
TPM —
Power +9V~36VDC (Full Range)
Operation
temperature
Operating temperature: -20°C to 80°C
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -20°C to 70°C
Non-operating humidity: 0%-95% (non-condensing)
Use wide temperature range memory and storage

14
www.gigaipc.com
System QBiX-WP-APLA3940H-A1 (QW-3940A-SI)
Vibration During
Operation
Operation: IEC 60068-2-64, 3 Grms, random, 5 ~ 500 Hz, 1 hr
/ Per Axis, With SSD/M.2 2242
Non-operation: IEC 60068-2-6, 2 G, Sine, 10 ~ 500 Hz, 1 Oct/
min, 1 hr / Per Axis
Shock During
Operation
Operation: IEC 60068-2-27, 50 G, half sine, 11 ms duration,
with SSD
Packaging Content
Carton size: 305 x 285 x 265 (mm)
Packing Capacity: 1pc
Including:
COM Cable, waterproof, x 3 (P/N: 25CF8-1K8400-O0S)
USB 2.0 Cable, waterproof, x 2 (P/N: 25CFA-1K8000-O0R)
RJ45 Cable, waterproof, x 2 (P/N: 25CR0-1K8401-O0S)
SIGNAL Cable, waterproof, x 1 (P/N: 25CR5-1K8500-O0R)
HDMI Cable, waterproof, x 1 (P/N: 25CRC-180720-O0S)
DC JACK Cable, waterproof, x 1 (P/N: 25CRD-1K8300-O0S)
Wall mount bracket (P/N: 25HBA-826520-H5R)
Order Information
System: 9BQW3940AMR-SI (Box packing)
(Built in Components: Please contact with your sales
representative for more information
or e-mailed to : [e-mail])

15 www.gigaipc.com
System - QBiX-WP Series (Waterproof) QBiX-WP-APLA3940H-A1
Chapter 2
Chapter 2 – QBiX-WP-APLA3940H-A1 (QW-3940A-SI)
Waterproof Industrial Embedded System Kit

16
www.gigaipc.com
2.1 Dimension

17 www.gigaipc.com
System - QBiX-WP Series (Waterproof) QBiX-WP-APLA3940H-A1
2.2 Getting Familiar with Your Unit
[Rear Side]
[Front Side]
2 x (IP67) USB 2.0 Connector
1 x (IP67) HDMI Connector
1 x (M8) Power LED
1 x (M8) HDD LED
1 x (IP67) Power switch
1 x (M12) COM1 (RS-232/422/485 & RI/5V/12V)
1 x (M12) GPIO (8 bits)
2 x (M12) COM2, COM3 (RS-232)
1 x (M12) DC IN
2 x (M12) LAN ports

18
www.gigaipc.com
[Right Side]
[Bottom Side]
[Left Side]

19 www.gigaipc.com
System - QBiX-WP Series (Waterproof) QBiX-WP-APLA3940H-A1
Pin Asignments
Front View
Pin No. Pin Define Pin No. Pin Define
1DCD 6RTS
2RXD 7CTS
3TXD 8RI
4DTR Shield GND
5DSR — —
2.3 COM 1 Connector for RS-232/422/485 & RI/5V/12V
Pin Asignments
Front View
Pin No. Pin Define Pin No. Pin Define
1DCD 6RTS
2RXD 7CTS
3TXD 8RI
4DTR Shield GND
5DSR — —
2.4 COM 2/3 Connector for RS-232
Pin Asignments
Front View
Pin No. Pin Define Pin No. Pin Define
1GPO1 7GPO4
2GPI1 8GPI4
3GPO2 9SMB_CLK
4GPO2 10 SMB_DATA
5GPO3 11 5V/ 1A
6GPI3 — —
2.5 DIO Connector

20
www.gigaipc.com
Pin Asignments
Front View
Pin No. Pin Define
1V-
2V+
3
4Chassis Ground
Pin Asignments
Front View
Pin No. Pin Define Pin No. Pin Define
1 TX + 5 No Singal
2 TX - 6 RX-
3RX+ 7No Singal
4No Singal 8No Singal
2.6 DC-IN Connector
2.7 LAN 1/2 Connectors
Conn.1 & Conn.2 Pin Asignments Front View
2.8 USB 1/2 Connectors for USB 2.0
