GIGAIPC QBiX-JMB-CMLA47EH-A1 Installation and operation manual

1
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
QBiX-JMB-CMLA47EH-A1
Industrial Fanless System with Intel® Q470E Chipset,
Support for Intel® 10th Gen. Core™ i Processor
Startup Manual
Packing List
Before you begin installing your card, please make
sure that the following items have been shipped:
1. Screw HDD x 20 pcs (25984G-1C014-S00)
2. 4-pin Terminal Blocks Male Plug x 1 pcs
(25IO0-2ESDV0-D2R)
Dimension Specifications
Dimension System Size: 224W x 256.1D x 77.7H(mm)
CPU Support for 10th Generation Intel® Core™
i7/i5/i3, Pentium® and Celeron® processors
in the LGA1200 package, TDP under 65W
Chipset Intel® Q470E Express Chipset
Memory 2 x DDR4 SO-DIMM sockets supporting up to
64 GB,
Dual channel DDR4 3200 MHz
Ethernet 1 x GbE LAN Port (Intel® I219V)
3 x GbE LAN Ports (Intel® I211AT)
Graphic
support
Integrated Graphics Processor - Intel® HD
Graphics support:
1 x DVI-D port, supporting a maximum
resolution of 1920x1080 @60Hz
1 x D-Sub port, supporting a maximum
resolution of 1920x1200 @60Hz
1 x DP port, supporting a maximum resolution
of 4096x2160 @60Hz
3 independent displays output
Audio Realtek® Audio Codec
Storage 4 x 2.5" HDD/SSD (SATA 6Gb/s)
Expansion
Slots
1 x 2280 M.2 M-Key (PCIe x4, SATA 6Gb/s)
1 x 2230 M.2 E-Key (WiFi/BT)
1 x Full-size Mini PCIe with SIM slot
224.0
21.2 36.5 60.7 27.0 18.9 21.0 18.3
31.713.0
196.014.0
36.0 35.4 38.0 35.328.7
77.7
256.1
264.3
34.7
224.132.0
75.8
Caution: DANGER OF EXPLOSION IF
BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE RECOMMENDED
BY THE MANUFACTURER, DISCARD
USED BATTERIES
ACCORDING TO THE MANUFACTURER’S
INSTRUCTIONS.

2www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Front I/O 1 x DC IN (4-pin Terminal Block +12V~48V)
1 x VGA / 1 x DVI-D /1 x DP
2 x COM Ports (RS-232/422/485 & RI/5V/12V)
2 x COM Ports (RS-232)
4 x RJ45 LAN Ports
4 x USB 3.2 Gen 1
6 x USB 2.0
3 x Audio Jacks (Line in, Line out & Mic in)
2 x External Antenna Holes (Optional)
Rear I/O —
Power DC in +12V~48Vdc (Full Range)
Operation
Temperature
Operating temperature: -20°C to 50°C (CPU
65W TDP)
Operating temperature: -20°C to 60°C (CPU
35W TDP)
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -40°C to 85°C
Non-operating humidity: 0%-95% (non-
condensing)
Use wide temperature range memory and
storage
Vibration
During
Operation
Operation: IEC 60068-2-64, 3 Grms, random,
5 ~ 500 Hz, 1 hr / Per Axis, with SSD/M.2
2280
Non-operation: IEC 60068-2-6, 2 G, Sine, 10 ~
500 Hz, 1 Oct/min, 1 hr / Per Axis
Shock During
Operation
Operation: IEC 60068-2-27, 50 G, half sine, 11
ms duration, With SSD
Packaging
Content
Carton size: 300 x 315 x 166 (mm)
Packing Capacity : 1
Including:
Terminal Blocks Male Plug x 1pc
(25IO0-2ESDV0-D2R)
Screw M3x4L x 20pcs (25984G-1C014-S00)
Order
Information
System : 6BQJQ47EAMR-SI (Box packing)
Jumpers and Connectors
The board has a number of jumpers that allow
you to configure your system to suit your
application. The table below lists the function
of each of the jumpers and connectors.
Front I/O Connectors
No. Code Scription
1VGA VGA Connector
2DVI-D DVI-D Connector
3DP Digital Display Port
4COM 1/2 RS-232/422/485
5COM 3/4 RS-232
6USB 1 4 x USB 3.2 Gen 1
7USB 2 4 x USB 2.0
8USB C1 2 x USB 2.0
9 LAN 1 Intel® I219V
10 LAN 2 Intel® I211AT
11 LAN A Intel® I211AT
12 LAN B Intel® I211AT
13 LED Power and Storage Device Status LED
14 DC-12-48V Power connector
15 Audio Audio Jacks (Line in, Line out & Mic in)
System I/O Interface
LAN 1
LAN BLAN ACOM 4
DVI-D
COM 3
External Antenna (optional) External Antenna (optional)
VGA
HDD LED
Power switch
COM 1/2
Digital Display
USB2 (USB2.0)
USB1 (USB3.0)
USBC1 (USB2.0)
Audio Jacks
LAN 2
DC IN (4-pin Terminal block, 12V~48V)

3
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Internal I/O Connectors
COM3
2 x DDR4 SO-DIMM
sockets
SATA Power Connector
4 x SATA 6 Gb/s
Connector
TPM Connector
M2E Slot
M2M Slot
MINI-PCIe Slot Supports SIM
SIM Card Slot
PCIE X8 Slot PCIE X16 Slot
COM4

4www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Memory Installation
QBiX-JMB-CMLA47EH-A1 supports DDR4 SO-DIMM type memory module.
1. Loosen 7 screws and remove the bottom cover.
2. Loosen 4 screws to remove memory thermal cover.
3. Remove the release paper, and assemble memory.
4. Install 4 screws and memory thermal cover.
Note : Thermal pad and memory thermal cover must be fully mated and compacted.
5. Replace the bottom cover and secure with screws.
Simple Installation Process
1
12
34

5
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
M2E (Support NGFF-2230 Wifi/BT) Installation
1. Loosen 7 screws and remove the bottom cover.
2. Loosen 4 screws to remove M2E thermal cover.
3. Install the module in the M2E (Support NGFF-2230 Wifi/BT) slot and secure with screws.
4. Remove the release paper on the thermal pad.
5. Install 4 screws and M2E thermal cover.
6. Replace the bottom cover and secure with screws.
1
11 2
1
31
4

6www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Storage Installation 1 (2.5” HDD/SSD)
1. Loosen 7 screws and remove the bottom cover
2. Loosen 4 screws to remove storage tray.
3. Secure storage with 4 x screws.
4. Assemble SATA cable/power cable and replace storage tray securely with 4 x screws.
5. Replace the bottom cover and secure with screws.
1
11 2
1
31 4

7
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Storage Installation 2 (M2M Storeage)
1. Loosen 7 screws, and then remove the bottom cover
2. Loosen 4 screws to remove the hard disk storage aluminum sheet
3. Loosen the 2 screws to remove the aluminum heat sink.
4. Assemble the M2M (NGFF-2280 SATA) storage hard drive, and remove the release paper which is
on the aluminum heat sink.
5. Install the 2 screws to securely replace the aluminum heat sink and heat sink paste.
6. Install 4 screws to firmly install the hard disk storage aluminum sheet
7. Replace the bottom cover and secure with screws.
1
11
2
1
31 4

8www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Mini-PCIe Slot (PCIex1 + USB2.0) and SIM Card Slot Installation
QBiX-JMB-CMLA47EH-A1 supports one full size Mini-PCIe.
1. Loosen 7 screws, and then remove the bottom cover
2. Loosen 4 screws to remove the hard disk storage aluminum sheet
3. Assemble the Mini-PCIe expansion Card (Mini-PCIex1 + USB2.0) or 3G/4G SIM Card in SIM Slot.
4. Install 4 screws to firmly install the hard disk storage aluminum sheet
5. Replace the bottom cover and secure with screws.
1
11
2
1
3

9
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this Startup Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or
spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily
accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may cause
damage.
7. The openings on the enclosure are for air convection. Protect the equipment from overheating. DO
NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to the power
outlet.
9. Position the power cord so that people cannot step on it. Do not place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by
transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified
service personnel.
14. If one of the following situations arises, get the equipment checked by service personnel:
• The power cord or plug is damaged.
• Liquid has penetrated into the equipment.
• The equipment has been exposed to moisture.
• The equipment does not work well, or you cannot get it to work according to the user’s manual.
• The equipment has been dropped and damaged.
• The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE TEMPERATURE
MAY GO BELOW -40°C (-40°F) OR ABOVE 85°C (185°F). THIS COULD DAMAGE THE EQUIPMENT. THE
EQUIPMENT SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED
BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.
17. RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted Access Area.
18. DISCLAIMER: This set of instructions is given according to IEC 704-1. GIGAIPC disclaims all
responsibility for the accuracy of any statements contained here in.
