Ginnys EDF-3060 User manual

1 YEAR LIMITED WARRANTY
Ginny’s warrants this product free from defects in material and
workmanship for one year from provable date of purchase.
Within this warranty period, Ginny’s will repair or replace, at its option,
defective parts at no charge, provided the product is returned, freight
prepaid with proof of purchase to Ginny’s. Allow 2-4 weeks for return
shipping.
This warranty does not cover improper installation, misuse, abuse or
neglect on part of the owner. Warranty is also invalid in any case that the
product is taken apart or serviced by an unauthorized service station.
This warranty gives you specific legal rights and they may vary from state
to state.
THE FOREGOING WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES
AND CONDITIONS, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO THOSE OF MERCHANTIBILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
GINNY’S Customer Returns
2000 Harrison Drive Suite #100
Clinton, IA 52732-6676
Phone: [phone]
Fax: [phone]
8:00 am to Midnight, Monday through Friday or
www.ginnys.com
Dual Basket Deep Fryer
(3 QT. Capacity each)
Model EDF-3060
INSTRUCTION MANUAL
Before operating your new appliance, please read all instructions carefully and keep for future reference.
w w w . g i n n y s . c o m

IMPORTANT SAFEGUARDS ..
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions before operating.
2. Do not touch hot surfaces.
3. Remove all packaging plastics and other materials from unit before operating.
4. Wash all removable accessories before using for the first time.
5. To protect against electrical shock, do not immerse cord, plug or appliance itself
in water or other liquids.
6. Close supervision is necessary when appliance is used by or near children.
7. Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts.
8. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return the appliance to the
nearest authorized service facility for examination, repair or adjustment.
9. The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
10. Do not use outdoors.
11. Do not let cord hang over edge of table or counter or touch hot surfaces.
12. Do not place on or near a hot gas or electric burner, or in a heated oven.
13. Always attach plug to appliance first, then plug cord into wall outlet. To
disconnect, turn any control to OFF position, then remove plug from wall outlet.
14. A fire may occur if the appliance is covered or touching flammable material
including curtains, draperies, walls and the like when in operation.
15. Do not clean with metal scouring pads. Pieces can break off the pad and touch
electrical parts, involving a risk of electrical shock.
16. Do not place any of the following materials in the unit: Paper, cardboard, plastic
and the like.
SAVE THESE INTRUCTIONS
THIS PRODUCT IS FOR HOUSEHOLD USE ONLY!
1
KNOW YOUR DEEP FRYER ..
**It is recommended to plug the appliance into two separate power outlets
when using both units simultaneously.
*15) SAFETY HEAT SWITCH: This switch is to ensure that the heating element will
not power on when it is not safely in place. The control box and heating elements
must always be slid into place securely before operation or heating of the fryer will
start.
2
w w w . g i n n y s . c o m
w w w . g i n n y s . c o m

RECOMMENDATIONS ..
1. Always place the deep fryer on a stable heat resistant surface and keep all flammable
materials away from the unit during operation.
2. Make sure that the deep fryer is never near or on a switched-on stove or cooking
surface.
3. Before you use the deep fryer it must be filled with the required amount of oil or fat.
**Never use the deep fryer without oil or fat because this could damage the unit.
4. Never move the deep fryer during use. The oil becomes very hot. Wait until the unit
and the oil has completely cooled down before moving.
5. This deep fryer is protected with a thermal safety device which switches the machine
off automatically if it over heats.
6. It is recommended to plug the appliance into two separate power outlets when
using both units simultaneously.
7. Never immerse the appliance in water.
8. Never leave the deep fryer unattended while in use.
9. Always ensure the safety of children if they are near the deep fryer.
10. If the deep fryer and/or cord are damaged, they must be returned to original store of
purchase. Do not try to repair the unit yourself or replace the damaged cord. This
requires special tools.
11. Be sure not to damage the heating element. (Do not bend or dent)
12. The electrical component is equipped with a safety heat switch, which ensures that
the heating element can only function when the element is correctly placed on the
fryer.
13. In the case of overheating, the thermal protective device will switch off the fryer
automatically. This device is located within a small hole on the back of the controls. It
can be re-activated by pushing the button in again with a pointed object (e.g. a
paperclip) and hold for 5-seconds and let go. **Disconnect from power outlet
before re-activating!
PREPARING YOUR FRYER ..
BEFORE USING FOR THE FIRST TIME:
Remove all printed documents and any other packaging materials.
Pull out all removable parts and wash gently with hot water.
Do not immerse the power cord and Control Box Assembly & Heating Element
of the deep fryer into any liquids.
Dry all parts thoroughly before assembling.
Do not operate the fryer without enough oil in the oil tank.
The Deep Fryer should always be placed on a flat heat resistant surface where
the power cord is out of reach of children and away from accidentally tripping
over it.
Tips:
When you fry several different kinds of food, always fry the food that uses the
lowest temperature setting first.
Do not mix different types of oil for frying.
Frying already pre-cooked foods may take less time to fry than completely raw
food.
Replace the oil after each 10-15 uses; or earlier if the oil becomes brown and
thick.
4
SAFETY TIPS ..
THIS DEEP FRYER IS ONLY SUITABLE FOR USE WITH OIL OR LIQUID FAT
AND NOT FOR USE WITH SOLID FAT.IF SOLID FAT IS USED, WATER CAN
BECOME TRAPPED INSIDE AND THE HOT FAT MAY SPURT OUT WITH
CONSIDERABLE FORCE.
Never switch on the deep fryer without oil or fat, as this could damage the
controller and heating element. Also, do not place any other liquids such as water
or other substances in the pan.
Place the deep fryer on a dry, stable heat resistant surface. Since the deep fryer
becomes hot during use, make sure that it is not too close to other objects.
OPERATING INSTRUCTIONS ..
Always make sure the Deep Fryer is unplugged before preparing it to cook.
Remove the frying basket and make sure the handle is swung out and locked.
Use only good quality frying oil such as Peanut oil, Vegetable oil, pure Corn oil,
Sunflower oil, Canola oil, or Light Olive oil. (Recommended not to mix oil)
Fill oil into the oil container approximately between the MIN marking and the
MAX marking.
Do not fill over the MAX marking or lower than the MIN marking.
Make sure the temperature control knob is set to the OFF or 0 position.
Attach the magnetic plug to the controller, then plug the power cord into an outlet.
Note: The magnetic plug will attach to the controller in only one direction. The plug is
marked "This Side Up".
Move the Thermostat knob to desired temperature setting according to the
particular recipe you are using. The RED indicator light will turn on.
While the oil is preheating, prepare the food that is going to be fried.
When placing the food into the basket, make sure it is as dry as possible. Do not
add water, ice or wet food, it may cause HOT OIL SPLATTER.
When frying Frozen food, clear off any ice particles and thaw food thoroughly.
Do not fill the basket over ¾ full. Food should always be fully immersed in oil
when basket is lowered.
When the selected temperature has been reached, the red indicator light will turn
OFF.
Slowly lower basket of food into hot oil and cover fryer w/ lid.
WARNING: DO NOT TOUCH THE CONTROL KNOB WHEN THE FOOD IS
FRYING. HOT STEAM MAY BE ESCAPING AND CAUSE BODILY HARM.
Remove food after desired cooking time has elapsed. Take care to remove
foods before it starts soaking up too much oil.
Turn the Timer Control and other settings to OFF.
5
www . g i n n y s . c o m
w w w . g i n n y s . c o m

FRYING GUIDE ..
The frying times given in the chart are only a guide and should be adjusted
accordingly to the quantity of food being fried.
FOOD
Temp. °F
Weight
(ounces)
Estimated Time
Shrimp
285°
8.5 oz.
3-5 minutes
Onion
285°
5.5 oz.
3-4 minutes
Mushrooms
285°
10.5 oz.
6-8 minutes
Fish Fillet
300°
8.5 oz.
5-6 minutes
Fish Fillet in batter
300°
14 oz.
6-8 minutes
Fish Cakes or Balls
300°
14 oz.
6-8 minutes
Sliced Meat
340°
14 oz.
7-10 minutes
Steak
340°
14 oz.
7-10 minutes
Chicken Strips
360°
17.5 oz.
7-10 minutes
French Fries (1st time)
375°
17.5 oz.
6-10 minutes
French Fries (2nd time)
375°
8.5 oz.
3-5 minutes
*French Fries being fried a 2nd time will be lighter and crispier.
AFTER THE FOOD IS FRIED:
1. Make sure to turn the temperature control knob to the OFF position and
unplug the deep fryer.
2. Once food is done cooking, remove the lid, and hang the basket on the hook
and let excessive oil drip into the oil pot.
Warning: Removing the lid will release hot steam. Take extreme care
when handling. Keep face and bare skin clear of the steam release.
3. Take out the basket and place the food on paper towels to absorb excess oil.
Do not touch the basket while it is still hot. Always use the handle.
4. Transfer food to a clean dish without the paper towels.
5. Place the basket into the deep fryer.
6. Do not move the deep fryer until it is cooled entirely.
7. Unplug the power cord and store away.
6
CLEANING THE DEEP FRYER ..
1. Remove the lid and basket.
WARNING: Before cleaning the deep fryer, make sure that it is
disconnected from the power outlet, make sure the unit and the oil has
completely cooled. Oil retains its temperature for a long period after use.
Do not attempt to carry or move the deep fryer while the oil is hot.
2. Wait for the fryer to cool, lift out the Control Box Assembly & Heating element.
3. Remove the oil pot and pour out the oil. It is recommended to filter the oil after
each use if you are to re-use the oil again.
4. After removing the oil pot, the fryer can be divided into several separate
assemblies to clean.
5. The oil pot and the body can immerse into water to clean.
WARNING: Do not immerse the Control Box & Heating Element into water
to clean.
6. The Control Box & Heating Element should be wiped clean with absorbent power
towels. Then use a damp cloth and a mild soap to clean.
7. The stainless steel lids can be wiped clean with a damp cloth and mild soap to
clean. If you are to immerse the lid of the deep fryer into water, make sure to
remove the filter and filter panel first.
Note: Remove the single screw that holds the filter panel. The panel will come off
exposing the filter. Wash or replace the filter and latch panel back on and tighten
screw.
8. Dry thoroughly all parts.
Note: Do not use abrasive scrubbing brushes or chemical cleaners to
clean the unit.
7
w w w . g i n n y s . c o m
w w w . g i n n y s . c o m

CARING FOR YOUR DEEP FRYER ..
STORING YOUR DEEP FRYER:
Always allow the appliance to cool completely before storing. Store the appliance in a
dry location. Keep the power cord out of reach of children.
CHANGING THE FILTER IN THE LID:
The panel located on the underside of the stainless steel lids can be removed by
pressing down firmly on the panel, then carefully rotating the tab. The panel will
release and the filter can be removed.
To secure the panel back into place, carefully place the panel into position at the two
notches at the other end of the lid, press down firmly and carefully rotate the tab back
into place to secure the panel.
Filter should be changed out after 20 uses or when the oil smell becomes too strong.
.. SHORT CORD PURPOSE ..
1) A short power-supply cord is provided to reduce risks of injuring yourself from
becoming entangled in or tripping over a longer cord.
2) Longer extension cords are available and may be used if you exercise caution
during use.
3) If a longer cord is used please note the following:
-The marked electrical rating of the extension cord should be at least as
great as the electrical rating of the appliance.
The longer cord should be arranged so that it will not drape over the counter top of
tabletop where it can be pulled on by children or tripped over unintentionally.
…POLARIZED PLUG …
If this appliance has a polarized plug (meaning one blade is wider than the other
one), please follow the below instructions:
To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet
only in one direction. If the plug does not fit fully into the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. Do not attempt to modify the plug in
any way.
MAGNETIC PLUG: This appliance is supplied with a magnetic plug that attaches to
the back of the appliance. This is to reduce injury caused by accidental tangling of
the power cords. The magnetic plug will detach to reduce spillage of hot oil.
This appliance is intended for Household Use Only.
IT IS RECOMMENDED TO PLUG THE APPLIANCE INTO TWO SEPARATE
POWER OUTLETS WHEN USING BOTH UNITS SIMULTANEOUSLY.
8
w w w . g i n n y s . c o m

…RECIPES ……
BATTER VARIETY:
The following are a few quick recipes for different kinds of batter to use with a variety
of foods to fry up in the deep fryer for a delicious meal.
Beer Batter:
Mix together 1 ½ cups of flour and 1 ½ cups of any kind of beer in a large mixing
bowl. Cover the bowl after mixing and allow the batter to sit at room temperature for
approximately 3 hours. When ready to fry, dip desired food into the batter and follow
the directions for frying battered foods in this booklet.
Egg Batter:
Combine 2 egg yolks, ¾ cup of flour, 1-½ teaspoons of vegetable oil, ½ teaspoon of
salt and 1 cup of milk. Mix thoroughly. Add more milk if desired to adjust the density
of the mixture. When ready to fry, dip desired food into the batter and follow the
directions for frying battered foods in this booklet.
Egg Coating:
Combine 2 whole eggs with 1-½ teaspoons of vegetable and a pinch of salt and
pepper to taste. When ready to fry, dip desired food into the mixture and follow the
directions for frying foods in this booklet.
Extra Crispy Coating:
Beat together ½ cup milk and one whole egg in a small mixing bowl. In a separate
bowl, mix together ½ cup of flour and any of your favorite seasonings such as salt,
pepper, chili powder, garlic powder, etc. When read to fry, dip desired food into the
wet mixture first, then dip into the dry flour mixture. Then follow the directions for
frying foods in this booklet.
Bread Crumb Coating:
Beat together 1 ½ teaspoons of vegetable oil and 2 egg yolks in a small mixing bowl.
IN a separate bowl, mix together ½ cup of bread crumbs, 1/3 cup of flour plus any of
your favorite seasonings such as salt, pepper, chili powder, garlic powder, etc. When
read to fry, dip desired food into the wet mixture first, then dip into the dry bread
crumb mixture. Then follow the directions for frying foods in this booklet.
TIPS FOR FRYING FOOD WITH BATTER COATING:
Make sure food is always sliced thinly and evenly. This helps the food
to be fried evenly.
Shake off any excess flour or bread crumb coating to prevent any
clumps to form when frying.
If you wish to use the basket when frying foods coated with batter, it is
recommended to lower the basket into the hot oil first and then gently
and carefully place battered foods into the oil directly. This will prevent
the batter from catching and sticking to the wiring of the basket.
Never fill the basket more than 2/3 full. In order to cook evenly, the food
needs space for the frying oil to fry each side.
10
BEIGNETS:
Vegetable oil for frying
1 c. all-purpose flour
4 tsp. sugar
1/4 tsp. nutmeg
1 c. water or milk
1/3 c. butter
1/4 tsp. salt
1 tsp. vanilla extract
4 eggs, at room temp.
In a large heavy skillet or deep-fat fryer, heat 3 inches oil to 350 degrees.
Meanwhile, combine flour, sugar and nutmeg, set aside. In medium
saucepan heat water or milk, butter and salt over medium heat until boiling
and butter is melted. Add vanilla, then add flour mixture all at once.
Stir briskly with a wooden spoon until mixture leaves sides of pan and forms
a ball. Continue stirring a few minutes more to dry.
Remove from heat and beat until slightly cooled.
Add eggs, one at a time, beating well after each addition. Using 2 spoons,
shape a generous tablespoon dough into an oblong and drop into hot oil.
Fry 3 or 4 at a time, turning beignets as they rise to the surface. Fry 3 to 4
minutes, until golden brown.
Drain on paper towels and sprinkle immediately with sifted confectioners'
sugar. Repeat with remaining batter.
Makes about 2 dozen beignets
SHRIMP EGG ROLLS:
1 c. sifted flour
3 eggs
2 c. minced cooked shrimp
1 c. finely chopped celery
1/4 c. minced bamboo shoots
1/4 c. minced water chestnuts
1 tbsp. finely chopped onion
1 qt. corn oil
1/2 tsp. salt
1/4 tsp. Accent
Combine flour, 1-cup water and 2 eggs. Beat at low speed of electric mixer
for 5 minutes. Set aside for at least 15 minutes.
Mix shrimp, celery, bamboo shoots, water chestnuts, onion, 2 tablespoons
corn oil and seasonings thoroughly.
Heat heavy 6-inch skillet until drop of water will sizzle. Grease lightly with
corn oil before cooking each skin. Hold skillet off heat; pour 2 to 3
tablespoons batter into pan, moving and tilting pan while pouring. Pour
excess back into bowl of batter; return skillet to heat. Batter will set very
quickly.
Cook just until set and edge curls slightly. Turn out onto dry dishtowel until
ready to roll.
Place about 2 tablespoons filling in center of each skin; brush edge with
beaten egg. Fold nearest edge over filling; fold over sides about 1 inch. Roll
skin; seal with beaten egg. Pour enough of remaining corn oil into deep fryer
or skillet to fill 1/3 full.
Heat over medium heat to 375 degrees or until 1-inch square of bread turns
brown in 10 seconds.
Add several egg rolls slowly; fry until lightly browned on all sides, turning as
needed. Drain on absorbent paper. Repeat with remaining rolls. Yield: 15
egg rolls.
11
w w w . g i n n y s . c o m
w w w . g i n n y s . c o m

FUNNEL CAKE:
2 c. flour
1 tsp. baking powder
1/2 tsp. salt
2 eggs
1 1/2 c. milk
Combine all the above ingredients in order. Mix thoroughly.
Heat cooking oil in deep fryer until hot.
Put batter in funnel (be sure to cover hole with one finger), then, holding the
funnel over hot oil (be very careful!), release some of the batter in circular
motion, then criss-crossing motions to form one funnel cake.
The funnel cake will rise quickly and expand - so be careful how much batter
you use.
Cook to light golden brown on both sides.
Remove from oil and place on paper towels.
Sprinkle with powdered sugar and serve warm.
GOLDEN FRIED ONION RINGS:
6 med. mild white onions
1 1/8 c. sifted flour
1/2 tsp. salt
1 egg, slightly beaten
1 c. milk
Slice onion 1/4 inch thick and separate into rings.
Combine remaining ingredients in a bowl and stir just until dry ingredients
are moistened.
Dip onion rings into flour mixture.
Fry several at a time in a deep fryer until golden brown. Drain on paper towel
and sprinkle with salt.
BUFFALO WINGS:
24 wings (4 lbs.)
Salt & pepper (optional)
4 c. cooking oil
1/4 c. butter
2 to 5 tsp. hot sauce
1 tsp. white vinegar
Cut off tips and separate wings at joint; sprinkle with salt and pepper, to
taste.
Heat oil in deep fat fryer or large heavy pot. When quite hot, add 12 wings
and cook 10 minutes, stirring occasionally.
When wings are golden brown and crisp, remove and drain well. Add rest of
wings; repeat process.
Meanwhile, melt butter in saucepan; add hot sauce, to taste and vinegar.
Pour sauce over wings and mix well to cover.
Serve with Blue Cheese Dressing and celery sticks.
12
CORN DOGS:
1/2 c Yellow corn meal
1/2 c Flour
1 tsp Honey
1/2 tsp Salt
1 ea Egg, lightly beaten
6-8 Hot Dogs / Frankfurters
6 ea Skewers or sticks
1 tbsp Sugar
1 tsp Baking powder
1/2 c Milk
1 tbsp Melted shortening
Combine the cornmeal, flour, sugar, mustard, baking powder and salt, mixing
well.
Add the milk, egg and shortening, mixing until very smooth.
Pour the mixture into a tall glass. Put the frankfurters on sticks.
Dip them into the cornmeal batter to coat them evenly.
Deep fry in oil heated to 375 degrees until golden brown, about two minutes.
Drain on paper towels.
FRIED GREEN TOMATOES:
3-4 lg. green tomatoes
2 c. flour
1 tbsp. salt
1 tbsp. pepper
1 tbsp. seasoning salt
2 eggs
2 c. milk
Oil for frying
Cut tomatoes into almost 1/2-inch thick slices.
Mix flour, salt, pepper and seasoning salt in one bowl.
Mix eggs and milk in another bowl. Dip each tomato slice into the milk mixture,
then into the flour, back to the milk and then to the flour again, coating well.
Heat oil in a deep fryer to 350 degrees and add battered tomato slices a few at a
time, and cook for 5 minutes or until golden brown.
CHURROS:
Vegetable for frying
1 cup water
1/2 cup margarine or butter
1/4 teaspoon salt
1 cup all-purpose flour
3 eggs
1/4 cup sugar
1/4 teaspoon ground cinnamon
Prepare to fry the churros by heating oil in deep fryer to 360 degrees F.
To make churro dough, heat water, margarine and salt to rolling boil in
3-quart saucepan; stir in flour.
Stir vigorously over low heat until mixture forms a ball, about 1 minute;
remove from heat.
Beat eggs all at once; continue beating until smooth and then add to
saucepan while stirring mixture.
Spoon mixture into cake decorator’s tube with large star tip (like the kind
use to decorate cakes).
Squeeze 4-inch strips of dough into hot oil. Fry 3 or 4 strips at a time
until golden brown, turning once, about 2 minutes on each side. Drain
on paper towels.
Mix Sugar and the optional cinnamon; roll churros in sugar mixture.
w w w . g i n n y s . c o m

13
SWEET & SOUR CHICKEN:
MARINADE:
1/2 tsp. salt
1 1/2 tsp. soy sauce
1 tbsp. cornstarch
1 tbsp. cold water
BATTER:
1/2 c. chicken coating mix
1/2 c. ice water
1 egg yolk
SWEET AND SOUR SAUCE:
1/2 c. Kraft Sweet and Sour Sauce
1/4 c. chicken broth
1/4 c. water
1/2 tsp. cornstarch
1 green pepper, cut into 1 inch pieces
1 med. carrot, sliced inch long then lengthwise
1/2 c. sliced water chestnuts
1 can chunk pineapple
Combine marinade ingredients in a small bowl. Add chicken, mix well. Let
stand 30 minutes.
Combine batter ingredients in a medium bowl until just mixed. Do not stir to
blend.
Combine Sweet and Sour Sauce, chicken broth, water and cornstarch in a
small bowl, set aside.
Heat oil in deep fryer to 350 degrees
While oil is heating, coat each piece of chicken with batter. Reduce heat to
medium.
Carefully lower coated chicken into hot oil with fryer basket.
Deep fry chicken 3 minutes or until browned. Remove from oil.
Turn heat up to high and heat oil to 400 degrees.
Carefully place chicken all at once in hot oil and deep-fry until crisp, about 30
seconds.
Remove chicken, draining well. Place on platter.
Using a fry pan, place 2 tablespoons oil. Heat to medium. Stir-fry green
peppers, carrots and water chestnuts 2 minutes.
Add Sweet and Sour Sauce mixture. Stir in pineapple. Stir-fry until sauce
has thickened. Remove from heat.
Stir in chicken and serve immediately. Makes 4 servings.
14
w w w . g i n n y s . c o m
w w w . g i n n y s . c o m
