Glide Gear SNC 100 User manual

For more informaon please visit our website: www.glidegear.net
PART LIST
Main Telescopic Pole (A)
Main Hinge (B)
Front Chest Plate (C).
Arm (D)
Camera Plaorm (E)
SNC 100 – USER MANUAL

1
For more informaon please visit our website: www.glidegear.net
1
2
2
3
3
4
5
ASSEMBLY
Slide the Main Hinge (B) onto the Main
Telescopic Pole (A). See Fig 1.
Fig 1.
Connect the Main Telescopic Pole (A) to
the hinge at the boom of the Front
Chest Plate (C). See Fig. 1.
Connect the Arm (D) to the Main Hinge
(B) and the Chest Plate (C) as shown in
Fig. 2.
Fig 2.
Insert the Camera Pole (E) in the Main Telescopic Pole (A) as
shown in Fig. 3.
Fig 3
Mount your camera on the Camera Plaorm €.

PUTTING THE VEST ON
WARNING:
Make sure to ghten and lock all the hinges and thumb screws into posion before pung the vest on.
1To put the vest on, simply connect the 2 sets of straps on the side of each plate around your torso.
2
For extra support, you also have the opon of using the 2 over-the-shoulder straps in which case the
SNC 100 will sit a lile bit higher on your torso. See picture B.
3
Loosen the straps and move the SNC 100 along your tor-
so to the desired height as seen in Picture A.
Firmly ghten the straps once the SNC 100 is in posion.
NOTE: the Shoulder Straps come assembled on the SNC
100 but can be easily removed.
Picture B:
SNC 100 in the front with both
side straps and over-the-shoulder
straps.
Picture A:
Snorricam in the back with side straps and over-the-
shoulder straps removed.
Picture C:
The SNC 100 can also be mount-
ed in the back.
For more informaon please visit our website: www.glidegear.net

ADJUSTMENTS
1
Adjust the distance Torso-Camera by loosening up the clamp connecng the Main Telescopic Pole (A)
and the Camera Pole (D). Once set, make sure to ghten the clamp to lock the Camera Pole (D) into
posion.
2
Use the hinge at the base of the Camera Plaorm (E) to adjust the camera orientaon.
WARNING: Make sure to lock the camera’s posion before any further adjustments..
3
To adjust the angle between the Main Telescopic Pole (A) and the Front Chest Plate (C):
• Make sure that the hinges and clamps from Step 1 and Step 2 are fully ghtened before
proceeding further.
• Loosen up the 4 joints circled in the picture below.
• While holding the rig together, slide the Main Hinge (B) along the Main Telescopic Pole (A)
to adjust the angle of the Main Telescopic Pole and the posion of the Camera.
• Once the camera is in posion, lock the 2 hinges on the Front Chest Plate (C) and the 2
locking screws on the Main Hinge (B).
1
2
3
Camera angle
adjustment
Torso-Camera Distance
Adjustment
Main Telescopic Pole
Angle Adjustment
