Glide BB2 User manual
USER
MANUAL
LITHIUM
INTRODUCTION
To Owner
Thanks for choosing Glide BB series. This Owner’s Manual contains information
needed for proper operation, maintenance and care. Please always read the manual
before using the vehicle to ensure your safety and obtain the maximum enjoyment.
NOTE:
Glide continually seeks advancements in products and quality. Therefore, while this
manual contains the most current product information available at the time of pub
lishing, there may be minor discrepancies between your vehicle and this manual. If
there is any question concerning to this manual, please consult your dealer.
The standard accessories are used as a base for the explanations and illustrations in
this manual. Therefore, some items may not apply to every model.
CAUTION:
1.
2.
3.
4.
It is prohibited to drive this BB by those people as following:
Children and drunk drivers.
Who has heart disease.
Who is colorblindness or partially colorblind of red, yellow and green.
Deafmute and people who is disable to drive this vehicle.
Always hold the handlebar properly while driving (never leave the handlebar
while the vehicle is moving under any circumstances.
Always use both rear and front brakes to stop the vehicle.
Don’t load the vehicle more than 400kg
1
LITHIUM
FUNDAMENTAL STRUCTURE
FEATURES (BASIC INFORMATION FOR MOST PRODUCTS, NOT FOR ALL MODELS)
1.
2.
3.
4.
5.
6.
Equipped Halltype speed adjustable handle bar. Press the power on button
then you can control the speed by rolling the handle bar lightly. There are
some other functions of this handle bar, such as indicating power, cutting the
power off when you use brake or in the case to protect vehicle from overcur
rent and lowvoltage.
High efficiency, less noise, no pollution, free maintenance and long service life
can be getting by using leadacid maintenance free batteries and DC brushless
motor (not for all models) properly.
Both of the right and left handle bars can cut the power off while using brake
to protect the driver.
Safety guaranty: loud horn and bright lights.
Lowvoltage protection: the protection device will cut the power off when the
voltage is lower than specified data to avoid damage to batteries. The tricycle
can be used again after charging.
Overcurrent protection: the protection device will cut the power off when the
current is higher than specified data to avoid damage to motor and controller.
It often happens due to the following factors: uphill road, wind and over load
ing. When you encounter this problem, please turn off firstly and then turn on
by key again, then the tricycle can work normally.
2
LITHIUM
1.
2.
3.
Batteries are very important to your tricycle. Please charge them after using
your vehicle and keep them properly. Do not only charge them under
overlow voltage status, but after using your vehicle. Doing this can extend the
using life of your tricycle.
The performance of batteries is affected by temperature: perform better at
high temperature (above 20oc) but degradation appears at low temperature
(especially below 0oc). Do not worry about your tricycle when the mileage is
much shorter in winter. The spring will come soon!
Almost all of the batteries are automatic discharging even at power off status.
If you do not use the tricycle for a long time, please store batteries with 100%
capacity and then charge them per 2030 days.
1.
2.
3.
Please use the charger matched to the batteries. Using other chargers may
cause damage to you and your tricycle.
Put the output plug of charger into the charge slot of batteries, then connect
the input plug of charger and 220V alternating current power supply. When
the indicator light turns to red, the charger is working.
Full charging time is usually 6 to 10 hours per time. When the indicator light of
the charger turns to green, it means the power is full, however, the batteries
can get more power if add 1 or 2 hours after it is “full”. Do not charge more
than 12 hours per time otherwise it will cause the overheat to batteries or
other problems.
ELECTRICAL SYSTEM
A. BATTERIES
Otherwise the life will be shorter.
B. CHARGING METHOD
CAUTION
STOP CHARGING IF THE INDICATOR LIGHT DOES NOT TURN TO GREEN AFTER
CHARGER WORKING OVER 10 HOURS AND SEND THE CHARGER TO YOUR
DISTRIBUTOR TO CHECK AND REPAIR.
3
LITHIUM
1.
2.
3.
It is normal to hear little noise when the motor starting to work.
It is normal if you feel the tricycle is heavier when backing off.
Slow down the speed when it is rainy. Do not use your tricycle when water
elevation is higher to the position of motor, otherwise the water may cause
damage to motor and other electric parts.
1.
2.
3.
4.
Do not cover the controller by anything, otherwise it will cause overheat. Do
not make the tricycle work under heavy load or uphill for a long time over half
an hour.
Do not rotate the handle sharply, because it may cause the tricycle out of
control.
Do not use brake frequently and sharply. Release the speed handle while using
brake.
Avoid expose your tricycle from sunshine or rain.
C．MOTOR
D．OTHER ELECTRIC SYSTEM
THIS PART CONTAINS CONTROLLER, INSTRUMENT, HANDLE BAR AND BRAKE.
WARNING!
4
LITHIUM
1.
2.
3.
4.
Before riding your tricycle, please read this manual and check to be sure that
all of the components can work normally. Consult your dealer if any problem
founded.
The surface of your tricycle is water proof, but some slight problems of out
side electric lines maybe caused by water. It can work normally after the water
dry. So, please keep your vehicle as far as possible from water.
If the speed is out of your control when riding, please shut down the power
and use brakes immediately, then send the tricycle to your dealer to repair.
Please check bolts and nuts on your tricycle after using it for a period. Please
fasten them if any is loose. Please maintain the fasteners frequently during your
daily use.
1.
2.
3.
4.
5.
6.
7.
8.
Although the surface is waterproof, your tricycle can be damaged by water,
especially when the rear wheelmotor and batteries are in water.
Do not touch the two points on the top of battery box by hand or metal
material! Otherwise, it may cause an accident.
Do not disassemble components by yourself. Consult your dealer if you need
to do so. Buy standard parts as per your dealer’s suggestion.
Slow down the speed when riding your tricycle if the road is wet or rugged.
Please contact your dealer for problem resolving. Any actions to change the
tricycle without our authorization are prohibited. We are not responsible for
any results caused by doing so. You can also lose the warranty service from us.
If the speed is out of control during your riding, please shut down the power
and brake immediately, then send the tricycle to your dealer to repair.
Do not remove the speed limit equipment; otherwise, it may cause accident
due to high speed!
Please check the fasteners during your using, and please fasten the loose ones
at once. We suggest you maintain the vehicle frequently to avoid any possible
harm.
1.
2.
Please add lubricant (used for bearing) into front axle block bowl, forks and
middleaxle block bowl at least one time per year. Add lubricant into rear axle
at least one time per 1000km. You can ask for help from your dealer to do this.
Please add lubricant oil into wheel bearing and universe axle one time per
month. Add the same oil into chain and brake pipe one time per 6 months.
SAFETY INFORMATION
LUBRICATION
WARNING
5
LITHIUM
TROUBLESHOOTING
ProblemNO. Reasons Solutions
Throttle does not
work or speed is too
slow at highspeed
mode
1. (1) low voltage of battery;
(2) the wire in throttle is loose;
(3) the spring in throttle loses
efficacy
(1) recharge the battery;
(2) rewelding the wire;
(3) replace a new throttle
Charger does not
work
4. (1) connection between plugs of
charger and vehicle is loose or
charger is damaged;
(2) the fuse of battery box or
charger has a blowout;
(3) connecting wires of batteries
loose
(1) fasten and tighten the
plugs;
(2) replace fuse (2A for
charger while 20A for
batteries); (3) fasten the
connecting wires of
batteries
Feeling hard to
move the vehicle
and always low
speed during riding
5. (1) brake locked;
(2) tires are underinflation;
(3) low capacity of batteries;
(4) front and rear axles of wheels
need lubricant;
(5) connecting of axles is too tight
(1) adjust the brake;
(2) inflate the tires;
(3) recharge the batteries;
4) clean and lubricate the
axles;
(5) adjust the axles
Loud noises6. (1) fasteners are loose;
(2) wheels is touching forks or
chassis; (3) chain is touching the
chain cover;
(4) the steel balls in bearing are
damaged
(1) tighten the fasters;
(2) adjust the wheels;
(3) adjust the chain cover;
(4) replace steel balls or
bearing
others7. The problems do not in the above
descriptions
Please ask for help from
your dealer or special
repair shop
The running distance
after charging is
much shorter than
specified
3. (1) the tires are underinflation;
(2) the batteries are not full fueled
or problems occur in charger;
(3) batteries are old or damaged;
(4) in winter
(1) reinflate the tires;
2) recharge the batteries
or use a new charger;
(3) replace batteries
(4) it is normal
Motor does not
work when power
on
2. (1) low voltage of battery;
(2) the wire in throttle is loose;
(3) the switch connecting motor
and battery is damaged
(1) recharge the battery;
(2) rewelding the wire;
(3) ask for help from your
dealer or special repair
shop
6
LITHIUM
7
LITHIUM
WARRANTY
Manufacture warrants to the original retail purchaser ("you") that the ESCOOTER
for which this warranty has been issued is free from defects in material and
workmanship as follows:
This warranty is not transferable to a subsequent purchaser. The manufacture's sole
obligation under this warranty is to repair or replace the product at manufacture's
option. Manufacture must be notified in writing of any claim under this warranty
within 15 days of any claimed lack of conformity of the product. Immediate report
to ESCOOTER dealer is required if abnormal behavior of the product is noticed.
The duration of any implied warranty or condition, of merchantability for a particular
purpose, or otherwise, on this product shall be limited to the duration of the
express warranty set forth above. In no event shall ESCOOTER dealers be liable for
any loss, inconvenience or damage, whether direct, incidental, consequential or
otherwise, resulting from breach of any express or implied warranty or condition, of
merchantability for a particular purpose, or otherwise with respect to this product,
except as set forth herein. Some provinces or countries do not allow limitation on
how long an implied warranty lasts and some do not allow exclusions or limitations
of incidental or consequential damages, so the above limitations or exclusions may
not apply to you.
This warranty gives you specific legal rights, and you may also have other rights,
which may vary, from location to location. This warranty will be interpreted pursuant
to the laws of EUROPE or NA. The original English language version/meaning of this
warranty controls over all translations and XINRI is not responsible for any errors in
translation of this warranty or any product instructions. This warranty is not intended
to confer any additional legal, jurisdictional or warranty rights to you other that
those set forth herein or required by law. If any portion of this warranty is held to
be invalid or unenforceable for any reason, such finding will not invalidate any other
provision.
For products purchased in countries please contact a ESCOOTER authorized distrib
utor in that respective country.
12 months warranty
Frame,
Electric Motor,
Controller and electric circuits
GEL Battery and charger
WARRANTY LIMITATIONS:
8
LITHIUM
!
( , , ,) •
. •
, •
220 •
•
. •
.
.
. 18
, •
. 16
This manual suits for next models
1
Table of contents
Other Glide Scooter manuals
