Gogo ES 8 User manual

32 Wedgwood Road
Bicester, Oxon OX26 4UL
ES 8
*INFMANU4194*

WARNING! An authorised Pride Dealer or qualified technician must perform the initial
setup of this Travel Scooter and must perform all of the procedures in this manual.
The symbols below are used throughout this owner's manual and on the scooter to identify warnings
and important information. It is very important for you to read them and understand them completely.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow
designated procedures can cause either personal injury, component damage or
malfunction. On the product, this icon is represented as a black symbol on a yellow
triangle with a black border.
MANDATORY! These actions should be performed as specified. Failure to perform
mandatory actions can cause personal injury and/or equipment damage. On the product,
this icon is represented as a white symbol on a blue dot with a white border.
PROHIBITED! These actions are prohibited. These actions should not be performed at
any time or in any circumstances. Performing a prohibited action can cause personal
injury and/or equipment damage. On the product, this icon is represented as a black
symbol with a red circle and red slash.
Please fill out the following information for quick reference:
SAFETY GUIDELINES
NOTE: This owner’s manual is compiled from the latest specifications and product information
available at the time of publication. We reserve the right to make changes as they become necessary.
Any changes to our products may cause slight variations between the illustrations and explanations in
this manual and the product you have purchased. The latest/current version of this manual is available
on our website.
Pride Dealer:___________________________________________________________________
Address:_________________________________________________________________________
Phone Number: _________________________
Purchase Date:________________________ Serial Number:____________________________
Copyright © 2011
Pride Mobility Products Ltd.
INFMANU4194/Rev A/July 2011

3
Go-Go ES8 www.pridemobility.com
CONTENTS
I. INTRODUCTION .......................................................................................................................4
II. SAFETY ........................................................................................................................................5
III. YOUR TRAVEL SCOOTER ...................................................................................................19
IV. BATTERIES AND CHARGING ..........................................................................................24
V. OPERATION .............................................................................................................................29
VI. COMFORT ADJUSTMENTS ..............................................................................................31
VII. DISASSEMBLY AND ASSEMBLY ...................................................................................33
VIII. BASIC TROUBLESHOOTING ..........................................................................................35
IX. CARE AND MAINTENANCE ..............................................................................................37
X. WARRANTY ..............................................................................................................................40

4www.pridemobility.com Go-Go ES8
I. INTRODUCTION
SAFETY
WELCOME to Pride Mobility Products (Pride). The product you have purchased combines state-of the-
art components with safety, comfort, and styling in mind. We are confident that these design features will
provide you with the conveniences you expect during your daily activities. Understanding how to safely
operate and care for this product should bring you years of trouble free operations and service.
Read and follow all instructions, warnings, and notes in this manual before attempting to operate your Travel
Scooter for the first time. You must also read all instructions, warnings, and notes contained in any
supplemental instructional booklets that accompanied your Travel Scooter before initial operation. Your
safety depends upon you, as well as your provider, carer, or healthcare professional in using good judgement.
If there is any information in this manual which you do not understand, or if you require additional
assistance for setup or operation, please contact your authorised Pride Dealer. Failure to follow the
instructions, warnings, and notes in this manual and those located on your Pride product can result
in personal injury or product damage and will void Pride’s product warranty.
PURCHASER’S AGREEMENT
By accepting delivery of this product, you promise that you will not change, alter, or modify this product
or remove or render inoperable or unsafe any guards, shields, or other safety features of this product; fail,
refuse, or neglect to install any retrofit kits from time to time provided by Pride to enhance or preserve the
safe use of this product.
SHIPPING AND DELIVERY
Before using your Travel Scooter, make sure your delivery is complete as some components may be
individually packaged. If you do not receive a complete delivery, please contact your authorised Pride
Dealer immediately. Where damage has occurred during transport, either to the packaging or content,
please contact the delivery company responsible.
INFORMATION EXCHANGE
We want to hear your questions, comments, and suggestions about this manual. We would also like to hear
about the safety and reliability of your new Travel Scooter, and about the service you received from your
authorised Pride Dealer. Please notify us of any change of address, so we can keep you apprised of
important information about safety, new products, and new options that can increase your ability to use
and enjoy your Travel Scooter. Please feel free to contact us at the address below:
Pride Mobility Products Ltd.
32 Wedgwood Road
Bicester, Oxon OX26 4UL
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact
us and we will be glad to send you a new one immediately.

5
Go-Go ES8 www.pridemobility.com
PRODUCT SAFETY SYMBOLS
The symbols below are used on the Travel Scooter to identify warnings, mandatory actions, and prohibited
actions. It is very important for you to read and understand them completely.
II. SAFETY
Pinch/Crush points created during assembly.
Maximum seating weight.
Read and follow the information in the owner’s manual.
Place unit on level ground and stand to one side when changing from drive mode
to freewheel mode or freewheel mode to drive mode.
Locked and in drive mode.
Unlocked and in freewheel mode.
EMI/RFI - This product has been tested and passed at an immunity level of 20 V/m.
Corrosive chemicals contained in battery.
Indicates electrical shock hazard.
Do not place the Travel Scooter in freewheel mode when on an incline.
Do not place the Travel Scooter in freewheel mode when on a decline.

6www.pridemobility.com Go-Go ES8
II. SAFETY
Removal of grounding prong can create electrical hazard. If necessary, properly
install an approved 3-pronged adapter to an electrical outlet having 2-pronged
plug access.
Do not use a cell phone, walkie/talkie, laptop or other radio transmitter while
operating.
Do not connect an extension lead to the AC/DC converter or the battery charger.
Do not remove anti-tip wheels.
Avoid exposure to rain, snow, ice, salt or standing water whenever possible. Main-
tain and store in a clean and dry condition.
Keep tools and other metal objects away from battery terminals. Contact with
tools can cause electrical shock.
Do not allow unsupervised children to play near the Travel Scooter while the
batteries are charging.
Keep your hands away from the tyres when driving. Be aware that loose fitting
clothing can become caught in the drive tyres.
Do not expose to heat sources such as open flame or sparks. Do not transport
batteries with flammable or combustible items.

7
Go-Go ES8 www.pridemobility.com
II. SAFETY
Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and
new batteries. Always replace both batteries at the same time.
Battery posts, terminals and related accessories contain lead and lead
compounds. Wear goggles and gloves when handling batteries and wash hands
after handling.
Disposal and recycling - Contact your authorised Pride Dealer for information on
proper disposal of your Pride product and its packaging.
Explosive conditions exist!
Battery charger for indoor use only.
Fully charge batteries before operating.
Remove key from an unattended Travel Scooter.
Do not mix AGM and Gel-Cell batteries. Always use batteries of the same type and
chemistry.
Use only AGM or Gel-Cell batteries to reduce the risk of leakage or explosive
conditions.

8www.pridemobility.com Go-Go ES8
II. SAFETY
Contains sealed, non-spillable batteries that meet DOT CRF 173.159 (d), IATA
packing instructions 806, IATA provision A67 for safe transportation.
Keep area dry.
Manufactured in.
Keep area clean.
Travel Scooter does not conform to ISO 7176-19 for transport of an occupied
Travel Scooter in a motor vehicle.
II. SAFETY
Travel Scooter information label.
Indicates tie-down points on the scooter.
Battery charger maximum amp-hour (Ah) charging information label.

9
Go-Go ES8 www.pridemobility.com
II. SAFETY
GENERAL
MANDATORY! Do not operate your new Travel Scooter for the first time without
completely reading and understanding this owner’s manual.
Your Travel Scooter is a state-of-the-art life-enhancement device designed to increase mobility. Pride
provides an extensive variety of products to best fit the individual needs of the Travel Scooter user. Please
be aware that the final selection and purchasing decision regarding the type of Travel Scooter to be used
is the responsibility of the Travel Scooter user who is capable of making such a decision and his/her
healthcare professional (i.e., medical doctor, physical therapist, etc.).
The contents of this manual are based on the expectation that a mobility device expert has properly fitted
the Travel Scooter to the user and has assisted the prescribing healthcare professional and/or the authorised
Pride Dealer in the instruction process for the use of the product.
There are certain situations, including some medical conditions, where the Travel Scooter user will need
to practice operating the Travel Scooter in the presence of a trained attendant. A trained attendant can be
defined as a family member or care professional specially trained in assisting a Travel Scooter user in
various daily living activities.
As you begin using your Travel Scooter during daily activities, you will probably encounter situations in
which you will need some practice. Simply take your time and you will soon be in full and confident control
as you maneouver through doorways, on and off lifts, up and down ramps and over moderate terrain.
Below are some precautions, tips and other safety considerations that will help you become accustomed
to operating the Travel Scooter safely.
MODIFICATIONS
Pride has designed and engineered your Travel Scooter to provide maximum mobility and utility. A wide
range of accessories is available from your authorised Pride Dealer to further customise your Travel
Scooter to better suit your needs and/or preferences. However, under no circumstances should you modify,
add, remove or disable any feature, part or function of your Travel Scooter.
WARNING! Do not modify your Travel Scooter in any way not authorised by Pride. Do not
use accessories if they have not been tested or approved for Pride products.
REMOVABLE PARTS
WARNING! Do not attempt to lift or move your Travel Scooter by any of its removable
parts, including the armrests, seat or shroud. Pride recommends use of only solid, non-
removable frame components such as Travel Scooter securement points or the front and
rear frame weldments to lift or move your Travel Scooter.
WARNING! Lifting the Travel Scooter should be accomplished with no fewer than three
people, one at the front and two at the rear of the unit.
PRE-RIDE SAFETY CHECK
Get to know the feel of your Travel Scooter and its capabilities. Pride recommends that you perform a
safety check before each use to make sure your Travel Scooter operates smoothly and safely.

10 www.pridemobility.com Go-Go ES8
Perform the following inspections prior to using your Travel Scooter:
Check for proper tyre inflation. Maintain but do not exceed the psi/bar/kPa air pressure rating indicated
on each tyre if equipped with pneumatic tyres.
Check all electrical connections. Make sure they are tight and not corroded.
Check all harness connections. Make sure they are secured properly.
Check the brakes.
Check battery charge.
If you discover a problem, contact your authorised Pride Dealer for assistance.
TYRE INFLATION
If your Travel Scooter is equipped with pneumatic tyres, you should check or have the air pressure checked
at least once a week. Proper inflation pressures will prolong the life of your tyres and help ensure the
smooth operation of your Travel Scooter.
WARNING! It is critically important that the psi/bar/kPa air pressure indicated on each
tyre be maintained in pneumatic tyres at all times. Do not underinflate or overinflate your
tyres. Low pressure may result in loss of control, and overinflated tyres may burst.
Failure to maintain the psi/bar/kPa air pressure rating indicated on pneumatic tyres at all
times may result in tyre and/or wheel failure.
WARNING! Inflate your Travel Scooter tyres from a regulated air source with an available
pressure gauge. Inflating your tyres from an unregulated air source could overinflate
them, resulting in a burst tyre.
NOTE: If tyres on your Travel Scooter list the psi rating only, use the following conversion formulas to
find the bar or kPa rating: bar = psi x 0.06895; kPa = psi x 6.89476.
WEIGHT LIMITATIONS
Your Travel Scooter is rated for a maximum weight capacity. Refer to the specifications table for
information. Keep in mind that the maximum weight capacity includes the combined weight of the user
and any accessories mounted to the Travel Scooter.
MANDATORY! Stay within the specified weight capacity for your Travel Scooter.
Exceeding the weight capacity voids your warranty. Pride will not be held responsible for
injuries and/or property damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your Travel Scooter. Carrying passengers on your
Travel Scooter may affect the centre of gravity, resulting in a tip or a fall.
INCLINE INFORMATION
More and more buildings have ramps with specified degrees of inclination, designed for easy and safe
access. Some ramps may have turning switchbacks (180-degree turns) that require you to have good
cornering skills on your Travel Scooter.
Proceed with extreme caution as you approach the downgrade of a ramp or other incline.
Take wide swings with your Travel Scooter around any tight corners. If you do that, the Travel
Scooter’s rear wheels will follow a wide arc, not cut the corner short and not bump into or get hung up
on any railing corners.
When driving down a ramp, keep the Travel Scooter’s speed adjustment set to the slowest speed setting
to ensure a safely controlled descent.
Avoid sudden stops and starts.
II. SAFETY

11
Go-Go ES8 www.pridemobility.com
II. SAFETY
Figure 1. Maximum Recommended Incline Angle
125 kg
19 stone, 9 lbs.
(275 lbs.)
10.5% (6°)
When climbing an incline, try to keep your Travel Scooter moving. If you must stop, start up again slowly,
and then accelerate cautiously. When driving down an incline, do so by setting the speed adjustment dial to
the slowest setting and driving in the forward direction only. If your Travel Scooter starts to move down the
incline faster than you anticipated or desired, allow it to come to a complete stop by releasing the throttle
control lever. Then push the throttle control lever forward slightly to ensure a safely controlled descent.
WARNING! When on any sort of an incline or decline, never place the Travel
Scooter in freewheel mode while seated on it or standing next to it.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face
of the incline. Drive your Travel Scooter straight up the incline. This greatly
reduces the possibility of a tip or a fall. Always exercise extreme caution when
negotiating an incline.
WARNING! Do not drive your Travel Scooter across the side of an incline or
diagonally up or down an incline; do not stop, if possible, while driving up or down
an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e.,
areas covered with snow, ice, cut grass, or wet leaves).
WARNING! Even though your Travel Scooter is capable of climbing slopes greater
than those illustrated in figure 1, do not, under any circumstances, exceed the
incline guidelines or any other specifications presented in this manual. Doing so
could cause instability in your Travel Scooter.
Handicap public access ramps are not subject to government regulation in all countries, and therefore do
not necessarily share the same standard percent of slope. Other inclines may be natural or, if man-made,
not designed specifically for Travel Scooters. Figure 1 illustrates your Travel Scooter’s stability and its
ability to climb grades under various weight loads and under controlled testing conditions.
These tests were conducted with the Travel Scooter’s seat in the highest position and adjusted rearward on
the seat base to its farthest rearward position. Use this information as a guideline. Your Travel Scooter’s
ability to travel up inclines is affected by your weight, your Travel Scooter’s speed, your angle of approach
to the incline and your Travel Scooter setup.
WARNING! Any attempt to climb or descend a slope steeper than what is shown in figure
1 may put your Travel Scooter in an unstable position and cause it to tip.
WARNING! Never carry an oxygen tank weighing more than 6 kg (13 lbs.). Never fill the
front or rear basket with contents exceeding 6 kg (13 lbs.).

12 www.pridemobility.com Go-Go ES8
II. SAFETY
Figure 2A. Increased Stability Driving Position
Figure 2. Normal Driving Position
When you approach an incline, it is best to lean forward. See figures 2 and 2A. This shifts the centre of
gravity of you and your Travel Scooter toward the front of the Travel Scooter for improved stability.
NOTE: When negotiating ramps, if the throttle control lever is released while moving forward, the
powered Travel Scooter may "roll back" approximately 30.5 cm (1 foot) before the brake engages. If
the throttle control lever is released while moving in reverse, the powered Travel Scooter may "roll
back" approximately 1 metre (3 feet) before the brake engages.
CORNERING INFORMATION
Excessively high cornering speeds can create the possibility of tipping. Factors which affect the possibility
of tipping include, but are not limited to, cornering speed, steering angle (how sharply you are turning),
uneven road surfaces, inclined road surfaces, riding from an area of low traction to an area of high traction
(such as passing from a grassy area to a paved area – especially at high speed while turning) and abrupt
directional changes. High cornering speeds are not recommended. If you feel that you may tip over in a
corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your Travel
Scooter from tipping.
WARNING! When cornering sharply, reduce your speed and maintain a stable centre of
gravity. When using your Travel Scooter at higher speeds, do not corner sharply. This
greatly reduces the possibility of a tip or fall.
BRAKING INFORMATION
Your Travel Scooter is equipped with these powerful brake systems:
Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the
centre/stop position.
Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop, or
when power is removed from the system for any reason.

13
Go-Go ES8 www.pridemobility.com
KERB
II. SAFETY
Figure 3. Correct Kerb Approach Figure 3A. Incorrect Kerb Approach
OUTDOOR DRIVING SURFACES
Your Travel Scooter is designed to provide optimum stability under normal driving conditions—dry, level
surfaces composed of concrete, blacktop or tarmac. However, Pride recognises that there will be times
when you will encounter other surface types. For this reason, your Travel Scooter is designed to perform
admirably on packed soil, grass, and gravel. Feel free to use your Travel Scooter safely on lawns and in
park areas.
Avoid driving on uneven terrain and/or soft surfaces.
Avoid tall grass that can become tangled in the running gear.
Avoid loosely packed gravel and sand.
Do not use your Travel Scooter in fresh or salt water.
Do not use your Travel Scooter at the edge of a stream, lake or ocean.
If you feel unsure about a driving surface, avoid that surface.
PUBLIC STREETS AND ROADWAYS
WARNING! Exercise extreme caution when operating the scooter on footpaths,
pavements, bridleways, pedestrian areas and roads. Obey all local pedestrian traffic rules.
STATIONARY OBSTACLES (STEPS, KERBS, ETC.)
WARNING! Do not drive near raised surfaces, unprotected ledges and/or drop-offs (kerbs,
porches, stairs, etc.).
WARNING! Do not attempt to have your Travel Scooter climb or descend an obstacle that
is inordinately high.
WARNING! Do not attempt to have your Travel Scooter proceed rearward down any step,
kerb or other obstacle. This may cause the Travel Scooter to tip.
WARNING! Be sure your Travel Scooter is traveling perpendicular to any kerb you may
be required to ascend or descend. See figures 3 and 3A.
WARNING! Even though your Travel Scooter may be capable of handling greater
obstacles, Pride recommends that you do not attempt to negotiate a kerb that has a
height greater than 5 cm (2 in.). Doing so could cause instability in your Travel Scooter.
KERB

14 www.pridemobility.com Go-Go ES8
II. SAFETY
INCLEMENT WEATHER PRECAUTIONS
Exposure of your Travel Scooter to inclement weather conditions should be avoided whenever possible.
If suddenly caught up in rain, snow, severe cold or heat while operating your Travel Scooter, proceed to
shelter at the earliest opportunity. Thoroughly dry your Travel Scooter before storing, charging or
operating your Travel Scooter.
PROHIBITED! Operating in rain, snow, salt, mist/spray conditions and on icy/slippery
surfaces can cause damage to the scooter and electrical system. Maintain and store
your Travel Scooter in a dry and clean condition.
WARNING! Prolonged exposure to hot or cold conditions may affect the temperature of
upholstered and non-upholstered items on the Travel Scooter, possibly resulting in skin
irritation. Exercise caution when using your Travel Scooter in extremely hot or cold
conditions or when exposing your Travel Scooter to direct sunlight for prolonged periods
of time.
FREEWHEEL MODE
Your Travel Scooter is equipped with a manual freewheel lever that, when pushed forward, allows the
Travel Scooter to be pushed. For more information about how to place your Travel Scooter into and out
of freewheel mode, see III. “Your Travel Scooter.”
WARNING! When your Travel Scooter is in freewheel mode, the braking system is
disengaged.
 Disengage the drive motors only on a level surface.
 Ensure the key is removed from the key switch.
 Stand to the side the Travel Scooter to engage or disengage freewheel mode. Never sit
on a Travel Scooter to do this.
 After you have finished pushing your Travel Scooter, always return it to the drive mode
to lock the brakes.
An added feature built into the Travel Scooter is “push-too-fast” protection which safeguards the Travel
Scooter against gaining excessive speed while in freewheel mode.
“Push-too-fast” operates differently depending on which of two conditions exists:
If the key is switched “off” while in freewheel mode, the Travel Scooter’s controller activates
regenerative braking when the Travel Scooter is pushed faster than a maximum threshold which has
been preprogrammed. In this case, the controller is acting as a speed governor.
If the key is switched “on” while in freewheel mode, you will encounter considerable resistance at any
speed. This prevents the Travel Scooter from gaining unwanted momentum should the manual
freewheel lever inadvertently be released while driving the Travel Scooter.
WARNING! Pride recommends that you do not disconnect the batteries when the Travel
Scooter is in freewheel mode as this may interfere with the function of the controller.
STAIRS AND ESCALATORS
Travel Scooters are not designed to travel up or down stairs or escalators. Always use an lift.
WARNING! Do not use your Travel Scooter to negotiate steps or escalators.
DOORS
Determine if the door opens toward or away from you.
Use your hand to turn the knob or push the handle or push-bar.
Drive your Travel Scooter gently and slowly forward to push the door open. Or drive your Travel
Scooter gently and slowly rearwards to pull the door open.

15
Go-Go ES8 www.pridemobility.com
II. SAFETY
LIFTS
Modern lifts have a door edge safety mechanism that, when pushed, reopens the door(s).
If you are in the doorway of a lift when the door(s) begin to close, push on the rubber door edge or
allow the rubber door edge to contact the Travel Scooter and the door will reopen.
Use care that handbags, packages or Travel Scooter accessories do not become caught in lift doors.
NOTE: If your Travel Scooter’s turning radius is greater than 152.4 cm (60 in.), it may be difficult to
maneouver in lifts and building entrances. Use caution when attempting to turn or maneouver your
Travel Scooter in small spaces and avoid areas that might pose a problem.
LIFT SYSTEMS/ELEVATION PRODUCTS
If you will be transporting your Travel Scooter during travel, you may find it necessary to use a vehicle-
mounted lift system or elevation product to aid in transportation. Pride recommends that you closely
review the warnings, instructions, specifications and safety information set forth by the manufacturer of
the lift/elevation product before using that product.
WARNING! Not all lift systems/elevation products are rated for use with an occupied
mobility device. Pride recommends that you do not remain seated in your Travel Scooter
when it is being used in connection with any type of lift system/elevation product unless:
That product is rated for occupied use by the manufacturer.
You are able to occupy your mobility device in strict conformity with the warnings,
instructions, specifications and safety guidelines set forth by the manufacturer.
WARNING! Always turn off the power to the Travel Scooter when you are being
transferred via an elevation product. Failure to do so may result in accidental throttle
control lever contact, resulting in unintended movement and personal injury or product
damage.
BATTERIES
In addition to following the warnings below, be sure to comply with all other battery handling information.
MANDATORY! Battery posts, terminals, and related accessories contain lead and
lead compounds. Wear goggles and gloves when handling batteries and wash
hands after handling.
WARNING! Travel Scooter batteries are heavy. See specifications table. If you are
unable to lift that much weight, be sure to get help. Use proper lifting techniques
and avoid lifting beyond your capacity.
WARNING! Always protect the batteries from freezing and never charge a frozen
battery. Charging a frozen battery may result in damage to the battery.
WARNING! Connect the battery harnesses in the proper manner. RED (+) cables
must be connected to positive (+) battery terminals/posts. BLACK (-) cables must
be connected to negative (-) battery terminals/posts. Protective caps should be
installed over all battery terminals. REPLACE cables immediately if damaged.
BATTERIES AND RECYCLING
If you encounter a damaged or cracked battery, immediately enclose it in a plastic bag. Contact your local
waste disposal agency or authorised Pride Dealer for instructions on disposal and battery recycling, which
is our recommended course of action.

16 www.pridemobility.com Go-Go ES8
II. SAFETY
PREVENTING UNINTENDED MOVEMENT
WARNING! If you anticipate being seated in a stationary position for an extended period
of time, turn off the power. This will prevent unexpected motion from inadvertent throttle
control lever contact.
MOTOR VEHICLE TRANSPORT
Pride recommends that you do not remain seated in your Travel Scooter while traveling in a motor vehicle.
The Travel Scooter should be stowed in the boot of a car or in the back of a truck or van with the batteries
removed and/or properly secured. In addition, all removable Travel Scooter parts, including the armrests,
seat and shroud should be removed and/or properly secured during motor vehicle transport.
WARNING! Although your Travel Scooter may be equipped with a positioning belt, this
belt is not designed to provide restraint during motor vehicle transport. Anyone travelling
in a motor vehicle should be properly secured in the motor vehicle seat with safety belts
fastened securely.
WARNING! Do not sit on your Travel Scooter while it is in a moving vehicle.
WARNING! Always be sure your Travel Scooter and its batteries are properly secured
when it is being transported. Batteries should be secured in an upright position and
protective caps should be installed on the battery terminals. Batteries should not be
transported with any flammable or combustible items.
GETTING ONTO AND OFF OF YOUR TRAVEL SCOOTER
Getting onto and off of your Travel Scooter requires a good sense of balance. Please observe the following
safety tips when getting onto and off of your Travel Scooter:
Remove the key from the key switch.
Ensure that your Travel Scooter is not in freewheel mode. See III. “Your Travel Scooter.”
Make certain that the seat is secured into place.
Pivot the armrests up to make getting onto and off of the Travel Scooter easier.
WARNING! Position yourself as far back as possible in the Travel Scooter seat to prevent
the Travel Scooter from tipping and causing injury.
WARNING! Avoid putting all of your weight on the Travel Scooter armrests and do not use
the armrests for weight bearing purposes, such as transfers. Such use may cause the
Travel Scooter to tip, resulting in a fall from the Travel Scooter and personal injury.
WARNING! Avoid putting all of your weight on the floorboard. Such use may cause the
Travel Scooter to tip.
REACHING AND BENDING
Avoid reaching or bending while driving your Travel Scooter. Bending forward creates the risk of
accidental throttle control lever contact. Bending to the side while seated creates the risk of tipping. It is
important to maintain a stable centre of gravity and keep the Travel Scooter from tipping. Pride
recommends that the Travel Scooter user determine his/her personal limitations and practice bending and
reaching in the presence of a qualified attendant.
WARNING! Do not bend, lean or reach for objects if you have to pick them up from the
Travel Scooter deck or from either side of the Travel Scooter. Movements such as these
may change your centre of gravity and the weight distribution of the Travel Scooter and
cause your Travel Scooter to tip.
PROHIBITED! Keep your hands away from the tyres when driving. Be aware that loose
fitting clothing can become caught in drive tyres.

17
Go-Go ES8 www.pridemobility.com
II. SAFETY
POSITIONING BELTS
Your authorised Pride Dealer, therapist(s) and other healthcare professionals are responsible for
determining your requirement for a positioning belt in order to operate your Travel Scooter safely.
WARNING! If you require a positioning belt to safely operate your Travel Scooter, make
sure it is fastened securely.
PRESCRIPTION DRUGS/PHYSICAL LIMITATIONS
The Travel Scooter user must exercise care and common sense when operating his/her Travel Scooter.
This includes awareness of safety issues when taking prescribed or over-the-counter drugs or when the
user has specific physical limitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter
medication or if you have certain physical limitations. Some medications and limitations
may impair your ability to operate your Travel Scooter in a safe manner.
ALCOHOL/SMOKING
The Travel Scooter user must exercise care and common sense when operating his/her Travel Scooter.
This includes awareness of safety issues while under the influence of alcohol or while smoking.
WARNING! Do not operate your Travel Scooter while you are under the influence of
alcohol, as this may impair your ability to drive safely.
WARNING! Pride strongly recommends that you do not smoke cigarettes while seated on
your Travel Scooter, although the Travel Scooter seat has passed the necessary testing
requirements for cigarette smoking. You must adhere to the following safety guidelines
if you decide to smoke cigarettes while seated on your Travel Scooter.
 Do not leave lit cigarettes unattended.
 Keep ashtrays a safe distance from the seat cushions.
 Always make sure cigarettes are completely extinguished before disposal.
FLAMMABILITY PRECAUTIONS
WARNING! Even though the plastics used on your Travel Scooter have been tested and
have passed the applicable flammability standards, Pride recommends that you do not
expose your Travel Scooter to open flames.
WARNING! Replace worn or damaged upholstery immediately to reduce the risk of fire
hazard.
WARNING! Be aware that washing of upholstered items may reduce the resistance to
flammability of the fabric.

18 www.pridemobility.com Go-Go ES8
II. SAFETY
ELECTROMAGNETIC AND RADIO FREQUENCY INTERFERENCE (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency
waves can have an adverse effect on the performance of electrically-powered mobility
vehicles.
Electromagnetic and Radio Frequency Interference can come from sources such as cellular phones, mobile
two-way radios (such as walkie-talkies), radio stations, TV stations, amateur radio (HAM) transmitters,
wireless computer links, microwave signals, paging transmitters and medium-range mobile transceivers
used by emergency vehicles. In some cases, these waves can cause unintended movement or damage to
the control system. Every electrically-powered mobility vehicle has an immunity (or resistance) to EMI.
The higher the immunity level, the greater the protection against EMI. This product has been tested and
has passed at an immunity level of 20 V/M.
WARNING! Be aware that cell phones, two-way radios, laptops and other types of radio
transmitters may cause unintended movement of your electrically-powered mobility
vehicle due to EMI. Exercise caution when using any of these items while operating your
mobility vehicle and avoid coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered
mobility vehicle can increase the susceptibility of the vehicle to EMI. Do not modify your
Travel Scooter in any way not authorised by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance
of other electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Centre on www.pridemobility.com. If
unintended motion or brake release occurs, turn the Travel Scooter off as soon as it is safe to do so.
Contact your authorised Pride Dealer to report the incident.

19
Go-Go ES8 www.pridemobility.com
III. YOUR TRAVEL SCOOTER
TILLER CONSOLE
The tiller console houses all controls needed to drive your Travel Scooter, including the key switch,
throttle control lever, horn button, speed adjustment dial and the battery condition meter. See figure 4.
PROHIBITED! Do not expose the tiller console to moisture. In the event that the tiller
console does become exposed to moisture, do not attempt to operate your Travel
Scooter until the tiller console has dried thoroughly.
Key Switch
Insert the key into the key switch and turn it clockwise to power up (turn on) your Travel Scooter.
Turn the key anticlockwise to power down (turn off) your Travel Scooter.
Although the key can be left in the key switch when the Travel Scooter is powered down, it is
recommended that it be removed to prevent unauthorised use of your Travel Scooter.
WARNING! If the key is turned to the “off” position while your Travel Scooter is in motion,
the electronic brakes will engage and your Travel Scooter will come to an abrupt stop!
Throttle Control Lever
This lever allows you to control the forward speed and the reverse speed of your Travel Scooter up to the
maximum speed you preset with the speed adjustment dial.
Place your right hand on the right handgrip and your left hand on the left handgrip.
Use your right thumb to push the right side of the lever to disengage your Travel Scooter’s brakes and
move forward.
Release the lever and allow your Travel Scooter to come to a complete stop before pushing the other
side of the lever to move in reverse.
When the throttle is completely released, it automatically returns to the centre “stop” position and
engages your Travel Scooter’s brakes.
Horn Button
This button activates a warning horn. Your Travel Scooter must be powered up for the horn to be
operational. Do not hesitate to use the warning horn when doing so may prevent accident or injury.
Figure 4. Tiller Console Components
HORN BUTTON
KEY SWITCH
BATTERY CONDITION METER
SPEED ADJUSTMENT DIAL
THROTTLE CONTROL LEVER
(FORWARD)
THROTTLE CONTROL LEVER
(REVERSE)

20 www.pridemobility.com Go-Go ES8
CHARGER POWER LEAD
RECEPTACLE
Speed Adjustment Dial
This dial allows you to preselect and limit your Travel Scooter’s top speed.
The image of the tortoise represents the slowest speed setting.
The image of the hare represents the fastest speed setting.
Battery Condition Meter
When the key is fully inserted into the key switch and turned clockwise to power up your scooter, this
meter indicates approximate battery strength. For further information on the battery condition meter,
see IV. “Batteries and Charging.”
Charger Power Lead Receptacle
The 3-pin end of the charger power lead plugs into this receptacle. See figure 5.
Off-Board Charger Fuse
The fuse located on the underside of the tiller console protects the batteries during charging. See figure 6.
In the event the batteries will not charge, check this fuse. See VIII. “Basic Troubleshooting” for fuse
replacement instructions.
III. YOUR TRAVEL SCOOTER
Figure 5. Charger Power Lead Receptacle Figure 6. Off-board Charger Fuse
FUSE LOCATION
