GDI-7202-01 / GDI-7203-01 / GDI-7206-01
2, 3 and 6 Person Steam Saunas
OWNER’S MANUAL
FOR STEAM MODEL SAUNAS
REQUIRES 240VAC /1PHASE (30/40AMP, depending on your electrical
code) DEDICATED CIRCUIT FOR THE STOVE
REQUIRES 120VAC 15 AMP CIRCUIT FOR THE SAUNA
Please Note: The stove must be installed by a certified electrician per the
manufacturer’s manual. The stove must be installed per the electrical
code in your area with reference to the breaker and wire sizes. Model and
parts are subject to change.

2
Thank you for the purchase of your new Steam Sauna! FOLLOW ALL INSTRUCTIONS
AND BE CAUTIOUS OF SAFETY SYMBOLS. All electrical wiring must be performed
by a qualified licensed electrician.
High Voltage Symbol: Be cautious as there is the presence of a high voltage current
that flows through the
equipment!
General Caution Symbol: Be cautious as the equipment uses electrical current that
can cause
serious injury.
1. Please read this Operating Instruction Manual thoroughly before use. This will allow
the user to become familiar with the operation of the control system. Please keep the
Operating Instruction Manual available for future reference. If any technical assistance
or repairing is needed, please contact the manufacturer.
2. The steam sauna must be installed indoors or can be installed outdoors within the
protection of a structure that includes a water-proof roof protecting it from the outdoor
weather elements. The sauna must be installed on water tolerable surfaces such as
concrete or tile. When not in use and placed outdoors, a water proof cover must be
used to cover the sauna room.
3. To reduce the risk of electric shock and/or fire, do not expose the control system to
direct water contact or rain. Do not open the cover to the control system as there are
high tension fittings that can be dangerous. Only dealer authorized qualified
technicians should make any needed or necessary repairs at any time.
4. Any repairs, alterations, or modifications to the control system are not authorized
unless by an approved repair technician. Any non-authorized repairs, alterations, or
modifications can lead to serious injuries and can cause the unit to work outside its
intended specifications parameters.
5. Any non-authorized repairs, alterations, or modifications will void the warranty.
6. Before connecting the unit to a power source, please make sure that all wires, cords,
and connections are connected properly.
7. Make sure that the control system is in a well-ventilated and dry area. Do not place it
next to any heat source, in direct sunlight, where there is any type of vibration, or in
any damp or dusty environment. It should not be place in an area with other thermal-
radiating objects.
8. When the equipment is not going to be used for an extended period of time, unplug

3
the unit from the power source.
9. Allow 30 seconds between turning the control system “On” and “Off”. By allowing 30
seconds between powering the control system “On” and “Off” will prolong the life of
the unit.
10. Confirm that you adhere to the correct power requirements of the control system.
Connecting the control system to other than the required voltage can damage the
control system and possibly cause serious injury. It is very important that the load
parameters are consistent with that needed by the control system.
11. Canadian Red Cedar and its rich aroma can cause an extremely small percentage of
the population to have an adverse reaction known as Multiple Chemical Sensitivity
(MCS). While this is not a universally recognized disorder in the medical field, certain
consumers have an adverse physical reaction to low levels of many common
chemicals and cannot tolerate any aromatic oils, shampoos with perfumes infused or
certain herbs with natural aromas. However, for the majority of the population,
Canadian Red Cedar is the sauna wood of choice.

4
CAUTION: Exit sauna immediately if you feel dizzy, sleepy, or
any discomfort.
READ ALL INSTRUCTIONS THOROUGHLY BEFORE ASSEMBLY
GDI-7202-01
*The above assembly diagram is for quick reference only. Read all
instructions before assembling. All sauna models may not be shown.
Parts and accessories may vary.

5
Schematics
*The above assembly diagram is for quick reference only. Read all
instructions before assembling. All sauna models may not be shown.
Parts and accessories may vary.

6
CAUTION: Exit sauna immediately if you feel dizzy,
sleepy, or any discomfort.
READ ALL INSTRUCTIONS THOROUGHLY BEFORE ASSEMBLY
GDI-7203-01
*The above assembly diagram is for quick reference only. Read all
instructions before assembling. All sauna models may not be shown.
Parts and accessories may vary.

7
Schematics
*The above assembly diagram is for quick reference only. Read all
instructions before assembling. All sauna models may not be shown.
Parts and accessories may vary.

8
CAUTION: Exit sauna immediately if you feel dizzy,
sleepy, or any discomfort.
READ ALL INSTRUCTIONS THOROUGHLY BEFORE ASSEMBLY
GDI-7206-01
*The above assembly diagram is for quick reference only. Read all
instructions before assembling. All sauna models may not be shown.
Parts and accessories may vary.

9
Schematics
*The above assembly diagram is for quick
reference only. Read all
instructions before assembling. All sauna models may not be shown.
Parts and accessories may vary.

10
TABLE OF CONTENTS
Product Introduction 10
Wall Panel Descriptions 10
Assembly Instructions 14
Control Panel Operation 22
Tips for Using Your Sauna 24
Safety Instructions 25
Safeguards for Your Sauna 26
Warranty 27
Warranty Card 29
WARNING: Visually inspect all parts before assembly to make sure they are not
damaged. Any excessive vibrations during transport could cause damage to the
sauna components. DO NOT START the sauna if damage is detected! Contact
your dealer or manufacturer for troubleshooting and replacement parts.
PLEASE NOTE: The pictures and diagrams shown within this owner’s manual are
representations of this model. Actual model may vary. Design and construction
are subject to change. The sauna cannot be placed directly in the weather
elements. It is highly recommended to keep the weather elements from reaching
the sauna by placing the sauna under a covered patio or structure with a roof to
fully protect the sauna.
1. Product Introduction
The steam sauna room is composed of a wood cabin. The wood cabin includes a
FRONT WALL PANEL with GLASS, REAR WALL PANEL, LEFT SIDE WALL PANEL,
RIGHT SIDE WALL PANEL with Glass, FLOOR PANEL, ROOF, and BENCHE(S).
Other smaller wood items will also be included and can be identified in the schematics
on pages 4, 6, and 8.
2. Wall Panel Descriptions
A. The REAR WALL PANEL can be seen in the image below. It will have
the control panel for the radio and lights on the interior. It will also have
the vent to the right of the control panel. (see Figure 1)

11
Control Panel for Radio & Lights Vent
Figure 1
B. The LEFT SIDE WALL PANEL will have a vent near the bottom of the
wall for the stove ventilation. The RIGHT SIDE WALL PANEL will have
a stationary glass panel. The FRONT WALL PANEL will have the
GLASS DOOR. (see Figure 2)
Vent
Front Glass Door
Stationary Glass Panel
Vent Speaker
Figure 2
NOTE: The pictures and diagrams shown above/below are for representational
purposes only. Actual model may vary. Parts subject to change.

12
Highlights
I. Buckles
A. External Buckles
The external buckles are used to connect the LEFT and RIGHT SIDE
PANELS to the REAR PANEL. (see Figure 3)
Figure 3
B. Guide and Guide Inserts
The guide and guide inserts are used to connect the FRONT PANEL
to the RIGHT SIDE PANEL and the LEFT SIDE PANEL. (see Figure
4)
Figure 4
II. Panel Descriptions
For easier assembly, please understand and distinguish the differences between
each panel.
A. Floor Panel
The floor panel will be a lattice piece of wood and it will not cover the
entire floor (does not cover under the bench). (see Figure 5)

13
FLOOR PANEL
Figure 5
B. Understanding the Difference Between the Top and Bottom of
the Wall Panels
The (4) Wall Panels will have white plastic feet on the bottom of the
wall panels. (see Figure 6)
Plastic Feet are on the Underside
of the Wall Panels
Figure 6

14
Assembly Instructions
A. Choose a good location to install the sauna
1. The location must be dry, leveled, and away from any source of water.
2. The stove must be installed by a certified electrician.
3. Two adults are required for installation on model GDI-7289-01 and three
adults for installation on models GDI-7389-01/GDI-7689-01.
4. Wood cabin installation order: FRONT WALL PANEL LEFT SIDE WALL
PANEL RIGHT SIDE WALL PANEL FLOOR PANEL REAR
WALL PANEL BENCH SUPPORT PANELS BENCH BACK
BACKREST ROOF PANEL
5. Tools Required: Battery Operated Screwdriver or Hand-Held Philips
Screwdriver, Rubber Mallet, and Ladder.
B. Installing the FRONT WALL PANEL and LEFT SIDE WALL PANEL
1. Place the FRONT WALL PANEL upright and in the desired location.
Next, stand the LEFT SIDE WALL PANEL upright and next to the FRONT
WALL PANEL. Align the metal Guide Insert Brackets on the LEFT SIDE
WALL PANEL and the FRONT WALL PANEL. Now you will need to lift
the LEFT SIDE WALL PANEL up and onto the FRONT WALL PANEL
locking the metal Guide Insert Brackets into one another. (see Figure 7)
Figure 7

15
C. Installing the RIGHT SIDE WALL PANEL, FLOOR PANEL and
REAR WALL PANEL
1. Place the RIGHT SIDE WALL PANEL upright and next to the
FRONT WALL PANEL. Align the metal Guide Insert Brackets on the
RIGHT SIDE WALL PANEL and the FRONT WALL PANEL. Now
you will need to lift the RIGHT SIDE WALL PANEL up and onto the
FRONT WALL PANEL locking the metal Guide Insert Brackets into
one another. Next, place the FLOOR PANEL on the floor and next
to the FRONT WALL PANEL. The REAR WALL PANEL can now be
placed up against the RIGHT SIDE WALL PANEL and LEFT SIDE
WALL PANEL. You will use the buckles to latch the REAR WALL
PANEL to both the RIGHT SIDE WALL PANEL and LEFT SIDE
WALL PANEL. (see Figure 8)
Figure 8
D. Installing the SIDE BENCH SUPPORT PANEL, BENCH SUPPORT
PANEL, BENCH, and BACKREST
1. First, you will need to locate the SIDE BENCH SUPPORTS. See
Figure 9. The SIDE BENCH SUPPORTS will be the same for sauna
models GDI-7202-01 & GDI-7203-01. The SIDE BENCH SUPPORT
for sauna model GDI-7206-01 will be different. The SIDE BENCH
SUPPORT will need to be screwed to the RIGHT SIDE WALL
PANEL using the 1 7/8” screws. The SIDE BENCH SUPPORT will
have predrilled holes.

16
SIDE BENCH SUPPORTS
For GDI-7202-01
&
GDI-7203-01
BENCH SUPPORT PANEL will
slide within the vertical slot on
the SIDE BENCH SUPPORTS
For GDI-7206-01
Figure 9
2. It is time to locate the BENCH SUPPORT PANEL. Depending on
your sauna model will determine how many BENCH SUPPORT
PANELS you have. For sauna models GDI-7202-01 and
GDI-7203-01, you will have only one BENCH SUPPORT PANEL.
For sauna model GDI-7206-01, you will have two BENCH
SUPPORT PANELS. The BENCH SUPPORT PANEL will side
downward within the vertical slots on both the LEFT SIDE WALL
PANEL and the SIDE BENCH SUPPORT PANEL(S) (see Figure 10)

17
GDI-7202-01
&
GDI-7203-01
BENCH SUPPORT PANELS
GDI-7206-01
Figure 10
3. See Figure 10 and locate the BACKREST. You will need to screw
the BACKREST to the wood plank on the REAR WALL PANEL.
(see Figure 11)
Wood Plank on REAR WALL PANEL Predrilled
Installing BACKREST screw holes
Figure 11

18
I. Installing the GLASS DOOR HANDLE and ROOF PANEL
1. Locate the GLASS DOOR HANDLE. The GLASS DOOR will
need to sit between the plastic washer (on the outside) and the
wood handle (on the inside). (see Figure 12)
2. Place the ROOF PANEL over the wall panels carefully. Be
cautious when feeding the wires for the lights from the
REAR WALL PANEL to the top of the ROOF PANEL. (see
Figure 13)
3. Next, carefully slide the ROOF PANEL into place. You will need
to connect the wire connections for the lights up on the rooftop.
4. It is optional to use the 1 7/8” screws to screw the roof panel to
the side wall panels.
Exterior Side: Interior Side:
(metal handle + Metal Ring (wood handle)
+ Plastic Washer)
Figure 12
Figure 13
Note: Be sure to remove the black plastic protection corners from around the glass
door corners, if present.

19
J. Installing the Stove
Please Note: The stove must be installed by a certified electrician per the manufacturer’s
manual. The stove must be installed per the electrical code in your area with reference
to the breaker and wire sizes & wire material. Be sure to follow the manufacturer’s
manual for proper and safe installation of the stove. For the Harvia The Wall Heater, it is
very important to run the stove power cord through the vent hole in the wall panel and
close the vent before installing the stove as you will not be able to open the vent once
the stove is installed. See Figure 14. After the stove is mounted, you can install the
wood housing for the stove. The wood housing does vary in styles.
Vent Hole
Figure 14
1. First, you will need to locate the wood housing for the stove and assemble it using
the provided screws. (see Figure 15)
Figure 15

20
2. Next, you will need to mount the wood housing to the sauna wall panel using the
provided screws. You will install the wood housing around the stove as the
stove does get very hot. (see Figure 15)
Figure 15
ASSEMBLY COMPLETED!
