Gomax MT-305A User manual

MT-305A
3G/HD/SD-SDI to HDMI & Audio Scaler Converter with
3.5” LCD Monitor & local loopout
User Manual
rev: 200827
Made in Taiwan
TABLE OF CONTENTS
INTRODUCTION.................................................................................................................1
FEATURES.........................................................................................................................1
PACKAGE CONTENTS......................................................................................................1
SPECIFICATIONS..............................................................................................................2
PANEL DESCRIPTIONS.....................................................................................................3
CONNECTION DIAGRAM...................................................................................................4
OSD MENU.........................................................................................................................5
WARRANTY .......................................................................................................................6
-1-
INTRODUCTION
The MT-305A 3G/HD/SD-SDI to HDMI & Audio Scaler Converter with 3.5” LCD Monitor & local
loopout is an advanced SDI monitor with multi-format and multi-pattern support. Not only receiving SDI
signal, MT-305A can also bypass SDI input to SDI output. It is equipped three buttons and 3.5” panel to
ease the control. With 3.5” panel, the output signal can be monitored and controlled through OSD, such
as the resolution and image adjustment. This device can also be used as a tool for scanning eye diagram
to check the quality of input SDI cable. In addition, it provides a variety of test patterns, which can be
used as a simple SDI pattern generator. MT-305A provides a cost effective way to monitor video devices
and displays.
FEATURES
OSD control interface
Push button for control
SDI loop-out
Supports eye diagram scanning
Supports audio level bars
Supports the cable length indicator
Supports output test patterns
Input bandwidth 2.970Gpbs
Output maximum pixel rate : 165MHz
Output video resolutions support multiple VESA standards
Deinterlacer supported
Supports nosie reduction and video enhancement features
Video H/V mirror supported
Active video area adjustment supported
USB firmware upgradable for expanding compatibility
PACKAGE CONTENTS
1x MT-305A
1x DC 5V 2A
1x User Manual
-2-
SPECIFICATIONS
Model Name
MT-305A
Technical
Role of usage
SDI to HDMI Converter with 3.5” LCD monitor
SDI standards
SD-SDI, HD-SDI & 3G-SDI
Input Video bandwidth
2.970 Gbit/s, 2.970/1.001 Gbit/s
Input Video support
[3G] 1080p @50/59.94/60Hz (4:2:2)
[HD] 720p @50/59.94/60Hz, 1080i @50/59.94/60Hz, 1080p @24/30Hz
[SD] NTSC @59.94Hz, PAL @50Hz
Output Video Frequency
bandwidth
165MHz
Audio support
PCM (48KHz only up to 8 channel)
ESD protection
[1] Human body model —±19kV [air-gap discharge] &
±12kV [contact discharge]
[2] Core chipset —±2kV
PCB stack-up
4-layer board [impedance control —differential 100; single 50]
Firmware update
Feasible via USB Port
CEC Channel
N/A
Input
1x BNC [SDI]
Output
1x HDMI + 1x BNC [SDI loop-out] +1x 3.5mm(Stereo)
BNC connector
3G 75Ωinter-locked socket
HDMI connector
Type A [19-pin female]
USB connector
Micro USB
Mechanical
Housing
Metal enclosure
Dimensions
[L x W x H]
Model
144 x 82 x 24mm [5.6" x 3.2" x 0.9"]
Package
264 x 170 x 77mm[10.3" x 6.7" x 3"]
Carton
430 x 358 x 291mm[1'4" x 1'2" x 11.5"]
Weight
Model
236g [8.3 oz]
Package
546g [1.2 lbs]
Fixedness
Wall-mounting case with screws
Power supply
5V DC
Power consumption
5 Watts [max]
Operation temperature
0~40C [32~104F]
Storage temperature
-20~60C [-4~140F]
Relative humidity
20~90% RH [no condensation]
-3-
PANEL DESCRIPTIONS
1. PUSH BUTTON: OSD up or Volume up (for stereo out) button
2. PUSH BUTTON: OSD down or Volume down (for stereo out) button
3. PUSH BUTTON: OSD Menu or selection button
4. SDI IN: Connect to a 3G/HD/SD-SDI source
5. LED INDICATOR: Input signal indicator LED
6. SDI LOOPOUT: Connect to a 3G/HD/SD-SDI display
7. POWER JACK: 5V DC power
8. POWER LED: Power LED indicator
9. STEREO AUDIO OUT: Connect to analog stereo audio speaker
10. HDMI OUT: Connect to a HDMI display
11. MICRO USB: F/W update
-4-
CONNECTION DIAGRAM
-5-
OSD MENU
Menu
Item
Remark
1. Output Setup
Output Format
Bypass, 600x480, 800x600, 1024x768,
1152x864, 1280x768, 1280x1024,
1360x768, 1440x900, 1600x1200,
1680x1050, SD (480p, 576p, 480i,
576i), HD (720p, 1080i, 1080p)
Test Pattern
Disable, Diagonal, W-VRamp, W-
HRamp, H-Ramp, Window, Gray,
Color, Hatch, Cross, White
Audio Mute
Off, On
2. Image
Contrast
0~255 of Contrast Level
Brightness
0~255 of Brightness Level
Saturation
0~255 of Saturation Level
Hue
0~255 of Hue Level
Gamma Adjust
Off, 1.1, 1.3, 0.7, 0.9
Color Tone
Off, Green, Skin
Edge Enhance
Off, Max, Mid, Min
3. H/V Mirror
H-Mirror
Off, On
V-Mirror
Off, On
H-Shift
0~200 of H-Shift Level
V-Shift
0~100 of V-Shift Level
4. System
Input Format
Input Format information
F/W Version
Firmware Version information
Factory Rest
No, Yes
Eye Diagram
Quit, Scan
OSD Enabled
All Enabled, All Disabled, Only
Audio, Only Format, Format & Audio,
Format & Range*
5. Exit
* The display of Range depends on the characteristics, length and quality of the coaxial
cable. Take the Belden 1694A coaxial cable as an example. For the length of 1m, 5m, 50m,
100m, the range will display short, short, long and long.
!
-6-
WARRANTY
The SELLER warrants the MT-305A 3G/HD/SD-SDI to HDMI & Audio Scaler Converter with 3.5” LCD
Monitor & local loopout to be free from defects in the material and workmanship for 1 year from the date
of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working
order within 1 year warranty period, The SELLER, at its option, repair or replace the unit, provided that the
unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including
static discharge and power surges.
Unit that fails under conditions other than those covered will be repaired at the current price of
parts and labor in effect at the time of repair. Such repairs are warranted for 90 days from the day of
reshipment to the BUYER. If the unit is delivered by mail, customers agree to insure the unit or assume
the risk of loss or damage in transit. Under no circumstances will a unit be accepted without a return
authorization number.
The warranty is in lieu of all other warranties expressed or implied, including without limitations,
any other implied warranty or fitness or merchantability for any particular purpose, all of which are
expressly disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan are responsible
for shipping charges to and from the SELLER. Cables are limited to a 30 day warranty and cable must be
free from any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be accurate. However, The
SELLER assumes no responsibility for any inaccuracies that may be contained in this manual. The
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting
from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the
technical information contained herein regarding the MT-305A features and specifications is subject
to change without further notice.
