1 About This Manual
1.1 Applicable Model
1.2 Target Audience
This manual describes the product information, installation, electrical connection,
commissioning, troubleshooting, and maintenance. Read through this manual before
installing and operating the product. All the installers and users have to be familiar with the
product features, functions, and safety precautions. This manual is subject to update without
notice. For more product details and latest documents, visit https://en.goodwe.com/.
This manual applies to trained and knowledgeable technical professionals. The technical
personnel has to be familiar with the product, local standards, and electric systems.
This manual applies to the listed inverters below (MIS for short):
Model Nominal Output Power Nominal Output Voltage
GW1600-MIS 1600W
220/230/240GW1800-MIS 1800W
GW2000-MIS 2000W

2
01 About This Manual
评审文档
User Manual V1.0-2023-07-30
1.3 Symbol Denition
1.4 Updates
The latest document contains all the updates made in earlier issues.
V1.0 2023-07-30
First Issue
Dierent levels of warning messages in this manual are dened as follows:
DANGER
Indicates a high-level hazard that, if not avoided, will result in death or serious injury.
WARNING
Indicates a medium-level hazard that, if not avoided, could result in death or serious injury.
CAUTION
Indicates a low-level hazard that, if not avoided, could result in minor or moderate injury.
NOTICE
Highlights key information and supplements the texts. Or some skills and methods to solve
product-related problems to save time.

3
02 Safety Precaution
评审文档
User Manual V1.0-2023-07-30
2 Safety Precaution
2.1 General Safety
2.2 PV String Safety
NOTICE
• The information in this user manual is subject to change due to product updates or other
reasons. This manual cannot replace the safety instructions or labels on the equipment
unless otherwise specied. All descriptions here are for guidance only.
• Before installations, read through the manual for product information and installation
precautions.
• All operations should be performed by trained and knowledgeable technicians who are
familiar with local standards and safety regulations.
• Use insulating tools and wear personal protective equipment when operating the
equipment to ensure personal safety. Wear anti-static gloves, cloths, and wrist strips when
touching electron devices to protect the inverter from damage.
• Strictly follow the installation, operation, and conguration instructions in this manual.
The manufacturer shall not be liable for equipment damage or personal injury if you do
not follow the instructions. For more warranty details, please visit https://en.goodwe.com/
warranty.
NOTICE
The inverters are designed and tested strictly complies with related safety rules. Read and
follow all the safety instructions and cautions before any operations. Improper operation might
cause personal injury or property damage as the inverters are electrical equipment.
DANGER
When connecting the PV input cable, make sure that the PV connector model matches
the PV connector model on the inverter side. The manufacturer shall not be liable for the
equipment damage if other connectors are used.
WARNING
• Ensure the component frames and the bracket system are securely grounded.
• Ensure that the positive or negative poles of PV module do not short-circuit to the ground.
Otherwise, severe damage might happen, which is beyond the manufacturer’s liability.
• Ensure the DC cables are connected tightly, securely and correctly.
• Ensure that the voltage of the PV module is within the permissible range of the inverter.
• Connect one PV module to each input of the inverter. Do not connect the battery or other
power source to the inverter input.

4
02 Safety Precaution
评审文档
User Manual V1.0-2023-07-30
2.4 Inverter Safety
DANGER
• All labels and warning marks should be visible after the installation. Do not scrawl,
damage, or cover any label on the device.
• Unauthorized dismantling or modication may damage the equipment, the damage is not
covered under the warranty.
• Do not touch the running equipment to avoid being hurt as its temperature may exceed
60℃. Do not install the equipment at a place within children's reach.
• Install the product away from electromagnetic interference. Install the product away from
electromagnetic interference. If there is any radio or wireless communication equipment
below 30MHz near the equipment, you have to:
• Add a low pass EMI lter or a multi winding ferrite core to the DC input cable or AC
output cable of the inverter.
• Install the inverter at least 30m far away from the wireless equipment.
• Warning labels on the inverter are as follows.
High-temperature hazard. Do
not touch the product under
operation to avoid being
burnt.
Delayed discharge. Wait
5 minutes after power o
until the components are
completely discharged.
Read through the user
manual before any
operations.
Potential risks exist. Wear
proper Personal Protective
Equipment before any
operations.
Do not dispose of the inverter
as household waste.Discard
the product in compliance
with local laws and
regulations, or send it back to
the manufacturer.
Grounding point
CE mark TÜV mark
RCM mark - -
2.3 AC Side
WARNING
• The voltage and frequency at the connection point meet the on-grid requirements.
• Additional protective devices like circuit breakers or fuses are recommended on the AC
side. Specication of the protective device should be at least 1.25 times the maximum AC
output current.
• Make sure that all the grounding cables are tightly connected. When there are multiple
inverters, make sure that all the grounding points on the enclosures are equipotential
connected.

5
02 Safety Precaution
评审文档
User Manual V1.0-2023-07-30
2.5 Personal Requirements
2.6 EU Declaration of Conformity
NOTICE
• Personnel who install or maintain the equipment must be strictly trained, learn about
safety precautions and correct operations.
• Only qualied professionals or trained personnel are allowed to install, operate, maintain,
and replace the equipment or parts.
GoodWe Technologies Co., Ltd. hereby declares that the inverter with wireless communication
modules sold in the European market meets the requirements of the following directives:
• Radio Equipment Directive 2014/53/EU (RED)
• Restrictions of Hazardous Substances Directive 2011/65/EU and (EU) 2015/863 (RoHS)
• Waste Electrical and Electronic Equipment 2012/19/EU
• Registration, Evaluation, Authorization and Restriction of Chemicals (EC) No 1907/2006
(REACH)
You can download the EU Declaration of Conformity on https://en.goodwe.com.
GoodWe Technologies Co., Ltd. hereby declares that the inverter without wireless
communication modules sold in the European market meets the requirements of the following
directives:
• Electromagnetic compatibility Directive 2014/30/EU (EMC)
• Electrical Apparatus Low Voltage Directive 2014/35/EU (LVD)
• Restrictions of Hazardous Substances Directive 2011/65/EU and (EU) 2015/863 (RoHS)
• Waste Electrical and Electronic Equipment 2012/19/EU
• Registration, Evaluation, Authorization and Restriction of Chemicals (EC) No 1907/2006
(REACH)
You can download the EU Declaration of Conformity on https://en.goodwe.com.

6
03 Product Introduction
评审文档
User Manual V1.0-2023-07-30
3 Product Introduction
3.1 Product Overview
The MIS inverter is a micro single-phase grid-tied PV inverter. The inverter converts the DC
power generated by the PV module into AC power and feeds it into the utility grid. The intended
use of the inverter is as follows:
3.2 Supported Grid Types
For the grid type with neutral wire, the N to ground voltage must be less than 10V.
Inverter Inverter Inverter Inverter
PV string Power distribution unit Utility grid
Inverter

7
03 Product Introduction
评审文档
User Manual V1.0-2023-07-30
3.3 Features
Module level monitoring
The inverter supports 4 independent Maximum Power Point Tracking(MPPT for short). Each
MPPT is connected to one PV module and tracks the maximum power point of each module.
Power derating
To satisfying the local laws or regulations and ensuring a safe operation, the inverter will
automatically reduce the output power when the operating environment is not ideal.
The following are the factors that may occur power derating. Please try to avoid then during
operations.
• Unfavorable environmental conditions, e.g., direct sunlight, high temperature, etc.
• Inverter's output power percentage has been set.
• Over-frequency derating.
• Higher input voltage value.
• Higher input current value.
Communication
Setting the inverter via bluetooth in a short distance; or connecting the inverter to the server via
WiFi to monitor the inverter and power plant working status.
• Bluetooth: meets Bluetooth 5.1 standard
• WiFi: supports 2.4G frequency band. Set the router to 2.4G or 2.4G/5G mode.
• The router wireless signal name supports a maximum input of 32 bytes.
• Check the WiFi signal intensity via SolarGo app. It is recommended to move the router closer
to the inverter or clear the signal blocking objects to enhance the signal intensity when it is
less than -60.
When multiple inverters are connected, these inverters can form a tree network via WiFi and
communicate with the server through the one selected as the communication root node. Specify
one inverter as the communication root node via SolarGo app if the communication is poor. For
more detailed instructions, refer to the SolarGo APP User Manual
WiFi Router Server
SolarGo app
SEMS Portal
app/web
Inverter Blue-
tooth

8
03 Product Introduction
评审文档
User Manual V1.0-2023-07-30
3.4 Circuit Diagram
The inverter can communicate with the EzLogger 3000R product for functions such as power
limit, remote shutdown, etc. For more detailed instructions, refer to the user manual of EzLog-
ger 3000R.
PV1+
PV1-
PV2+
PV2-
PV3+
PV3-
PV4+
PV4-
EMI Filter
EMI Filter
SPD
EMI Filter
EMI Filter
EMI Filter
L
N
WiFi
WiFi WiFi
Router Server
SEMS Portal
app/web
Bluetooth < 5m
Bluetooth
Bluetooth
Inverter n Inverter 2
Inverter 1

9
03 Product Introduction
评审文档
User Manual V1.0-2023-07-30
3.5 Appearance
3.5.1 Parts
No. Parts Description
1Antenna Wireless communication; supports WiFi.
2 Handle Moves or hangs the inverter.
3 Grounding Point Connects grouding cables to the grouding points
for protection.
4AC connector Connects the AC branch of the inverter to the trunk
cable.
5 Heat sink Used to cool the inverter.
6 LED Indicators Indicates working state of the inverter.
7 PV connector Connects the inverter to the PV module.
3.5.2 Dimensions
1234
5
6
77
473±20mm
100mm 42.5mm
330.5mm
200mm
157mm
266.7mm
8mm

10
03 Product Introduction
评审文档
User Manual V1.0-2023-07-30
3.5.3 Indicators
3.5.4 Nameplate
The nameplate is for reference only.
GW
trademark,
product type
and product
model
Technical
parameters
Safety
symbols and
certication
marks
Contact
information
and serial
number
Model: GW****-MIS
Product:
Micro Inverter
P.F. ~**...**ind,: Toperating: ** ℃
Output
UDCma x:** Vd.c. UMPP:**...**Vd.c.
IDC,max:**Ad.c. ISC PV:**Ad.c
fAC, r:**Hz
IAC,max:***
Sr:VA****
S
max: ** VA **
PV Input
PAC,r : W****
Galvanically Isolate d HF Transforme r, IP67 , Protectiv e Clas s I
OV C DCII/ACIII
UAC,r ***: Va.c.
S/ N
Indicator status Descriptions
Slow blinking green = Equipment on and in the standby mode.
Fast blinking green = equipment starting and in the self-check
mode.
Steady green = The four PV inputs are available, and the invert-
er is feeding power to the grid properly.
Blinking green and red = Not all PV inputs are available, but the
inverter is still feeding power to the grid.
The four blinks represent the status of four inputs PV1, PV2, PV3
and PV4 respectively. Red blinks indicating abnormal PV input,
green blinks indicating normal PV input.
Example: As shown on the left, PV1 is abnormal and PV2, PV3
and PV4 are normally working.
Single blinking red = Utility grid loss.
Double blinking red = Utility grid fault.
Steady red = Equipment fault.
Fast blinking green and red = Updating software.

11
04 Check and Storage
评审文档
User Manual V1.0-2023-07-30
4 Check and Storage
4.1 Check Before Receiving
4.2 Deliverables
Check the following items before receiving the product.
Check the outer packing box for damage, such as holes, cracks, deformation, and other signs of
equipment damage. Do not unpack the package and contact the supplier as soon as possible if
any damage is found.
Check the inverter model. If the inverter model is not what you requested, do not unpack the
product and contact the supplier.
Check the deliverables for correct model, complete contents, and intact appearance. Contact the
supplier as soon as possible if any damage is found.
NOTICE
• Connect the PV cables using the PV connectors in correct model. The manufacturer shall
not be liable for the damage if other connectors are used.
• The actual number of accessories may dier.
Inverter x8 T shape AC
connector x8
Sealing plug of
the T shape AC
connector x4
Uninstall tool of
the T shape AC
connector x4
Dust cover of
the T shape AC
connector x2
Documents x1

12
04 Check and Storage
评审文档
User Manual V1.0-2023-07-30
4.3 Storage
If the equipment is not to be installed or used immediately, please ensure that the storage
environment meets the following requirements:
1. Do not unpack the outer package or throw the desiccant away.
2. Store the equipment in a clean place. Make sure the temperature and humidity are
appropriate and no condensation.
3. The height and direction of the stacking inverters should follow the instructions on the
packing box.
4. The inverters must be stacked with caution to prevent them from falling.
5. If the inverter has been long term stored, it should be checked by professionals before being
put into use.

13
05 Installation
评审文档
User Manual V1.0-2023-07-30
5 Installation
5.1 Installation Requirements
1. Do not install the equipment in a place near ammable, explosive, or corrosive materials.
2. Install the equipment on a surface that is solid enough to bear the inverter weight.
3. Install the equipment in a well-ventilated place to ensure good dissipation. Also, the
installation space should be large enough for operations.
4. The equipment with a high ingress protection rating can be installed outdoors. The
temperature and humidity at the installation site should be within the appropriate range.
5. Install the equipment in a sheltered place to avoid direct sunlight, rain, and snow.
6. Do not install the equipment in a place that is easy to touch, especially within children’s
reach. High temperature exists when the equipment is working. Do not touch the surface to
avoid burning.
7. Install the equipment at a height that is convenient for operation and maintenance, electrical
connections, and checking indicators and labels.
8. Install the product away from electromagnetic interference. Install the equipment away
from electromagnetic interference. If there are radio stations or wireless communication
equipment below 30 MHz near the installation location, install the equipment as follows:
• Add a multi-turn winding ferrite core at the DC input line or AC output line of the inverter,
or add a low-pass EMI lter.
• Install the inverter at least 30m far away from the wireless equipment.
Installation Environment Requirements
≥200mm
≥200mm
≥200mm
≥200mm
≥20mm
≥100mm
No touch during
operation.
ALT: 2000m

14
05 Installation
评审文档
User Manual V1.0-2023-07-30
0%~100%RH
IP67
Mounting Support Requirements
• Install the inverter on the PV racking.
• The mounting support shall be nonammable and reproof.
• Ensure the PV racking is solid enough to bear the inverter weight.
• Do not install the product on the support with poor sound insulation to avoid the noise
generated by the working product, which may annoy the residents nearby.
Installation Angle Requirements
Mounting the inverter tilt with the angle of the PV module.

15
05 Installation
评审文档
User Manual V1.0-2023-07-30
The following tools are recommended when installing the equipment. Use
other auxiliary tools on site if necessary.
Installation Tool Requirements
Goggles Safety shoes Safety gloves Dust mask
Diagonal pliers
Marker Level Heat shrink tube Rubber hammer Vacuum cleaner
Torque wrench
Cable tie
Multimeter
Wire stripper Hammer drill Heat gun
5.2 Inverter Installation
5.2.1 Moving the Inverter
CAUTION
Move the inverter to the site before installation. Follow the instructions below to avoid
personal injury or equipment damage.
1. Consider the weight of the equipment before moving it. Assign enough personnel to move
the equipment to avoid personal injury.
2. Wear safety gloves to avoid personal injury.
3. Keep balance to avoid falling down when moving the equipment.
4. Do not bump or hit the antenna. Otherwise, the antenna may be damaged.
5. Instead of lifting the cables directly, it is recommended to hold the handle of the inverter to
prevent potential damage to the cables.
M8/M4

16
05 Installation
评审文档
User Manual V1.0-2023-07-30
5.2.2 Installing the Inverter NOTICE
• Plan the installation positions of the inverters and PV modules before installation.
• Install the inverter on the rail. Prepare aluminum clamps to x the installation screws when
the holes on the rail are not suitable for installing the inverter.
• Wear goggles and a dust mask to prevent the dust from being inhaled or contacting eyes
when drilling holes.
• M8 screws should be prepared by customers. Prepare the screws, especially the screw
length, in accordance with the dimension of the rail and thickness of the inverter handle
(8mm).
Step 1 Fix the M8 screws on the rail and reserve a certain length for hanging the inverter.
Step 2 Hang the inverter on the screws
Step 3: Push the handle gently to secure the inverter.
Step 4 Tighten the screws. Ensure that the inverter is xed properly and securely.
3
12
M8
8.5-9.5N·m
4
157mm
