GPI M-150S-EM User manual

06/16 Rev. - 922124-01
TABLE OF CONTENTS
General Information....................................................2
Safety Instructions......................................................2
Installation ..................................................................2
Operation....................................................................4
Maintenance...............................................................4
Repair.........................................................................4
Troubleshooting..........................................................8
Specications .............................................................9
Illustrated Parts List..................................................10
Parts and Service .....................................................11
Great Plains Industries, Inc. is a member of
the Petroleum Equipment Institute.
To the owner...
Congratulations on receiving your GPI fuel pump. We are pleased
to provide you with a system designed to give you maximum
reliability and efciency.
Your fuel pump is designed, tested, and approved for use with
gasoline blends, diesel fuel blends and kerosene. Please take
all due precautions when handling these ammable liquids. Your
safety is important to us.
Also, to assure the longest possible service life, it is important that
you follow the operation and maintenance procedures outlined in
this manual. We are proud to provide you with a quality product
and dedicated support. Together with your conscientious use,
we are sure that you will obtain years of safe, dependable service.
Victor Lukic, President
Great Plains Industries, Inc.
M-150S-EM & M-150S-EA FUEL PUMP
OWNER’S MANUAL
DO NOT RETURN THIS
PRODUCT TO THE STORE!
Please contact
Great Plains Industries, Inc.
before returning any product.
If you are missing parts, or
experience problems with
your installation, contact our
Customer Support
Department. We will be
happy to assist you.
800-835-0113,
316-686-7361
or
email: [email protected]
Check out the Great Plains Industries, Inc. YouTube
channel to see Installation and Troubleshooting videos
for the M-150S Fuel Transfer Pump.

Rev. - 922124-01
2
GENERAL INFORMATION
The purpose of this manual is to assist you in installing, op-
erating and maintaining your GPI M-150S 12-volt DC pump,
with manual or automatic nozzle.
An automatic bypass valve prevents pressure build up
when the pump is on with the nozzle closed. To avoid
damage, do not run the pump more than 10 minutes with
the nozzle closed.
The duty cycle of this pump is 30 minutes ON and 30 minutes
OFF. Allow the pump to cool for 30 minutes.
This pump is designed for use only with gasoline (up to 15%
alcohol blends such as E15), diesel fuel (up to 20% biodiesel
blends such as B20) and kerosene. Do not use this pump
for dispensing any uids other than those for which it was
designed. To do so may damage pump components and will
void the warranty.
This pump is designed to operate on a typical DC automotive
electrical system. The pump is designed to operate with the
appropriate DC voltage at the motor leads and the ratings
are determined at this voltage. Performance may vary due
to length of power cord, battery condition or output from the
vehicle charging system that will affect system voltage.
Do not leave the system running without uids. “Dry running”
can damage the pump.
Do not pump the tank completely dry, as contaminants from
the bottom of the tank may enter the pump.
SAFETY INSTRUCTIONS
The following safety alert symbols are used in this
manual. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER
DANGER indicates a haz-
ardous situation which, if not
avoided, will result in serious
injury or death.
WARNING WARNING indicates a haz-
ardous situation which, if
not avoided, could result in
serious injury or death.
CAUTION CAUTION indicates a haz-
ardous situation which, if not
avoided, may result in minor
or moderate injury.
It is your responsibility to:
• know and follow applicable national, state, and local safe-
ty codes pertaining to installing and operating electrical
equipment for use with ammable liquids.
• know and follow all safety precautions when handling
petroleum fuels.
• ensure that all equipment operators have access to
adequate instructions concerning safe operating and
maintenance procedures.
Observe all safety precautions concerning safe handling of
petroleum fuels.
To ensure safe operation, all fuel transfer systems must be
properly grounded. Proper grounding means a continuous
metal-to-metal contact from one component to the next,
including tank, bung, pump, meter, lter, hose and nozzle.
Care should be taken to ensure proper grounding during initial
installation and after any service or repair procedures. For your
safety, please take a moment to review the warnings below.
To prevent physical injury, observe precautions against re or
explosion when dispensing fuel. Do not operate the system
in the presence of any source of ignition including running
or hot engines, lighted cigarettes, or gas or electric heaters.
Observe precautions against electrical shock when operating
the system. Serious or fatal shock can result from operating
electrical equipment in damp or wet locations.
Inspect external pump wiring regularly to make sure it is
correctly attached to the battery. To avoid electrical shock,
use extra care when connecting the pump to power.
Avoid prolonged skin contact with petroleum fuels. Use
protective goggles, gloves and aprons in case of splashing
or spills. Change saturated clothing and wash skin promptly
with soap and water.
Observe precautions against electrical shock when servicing
the pump. Always disconnect power before repairing or
servicing. Never apply electrical power to the system when
any of the coverplates are removed.
If using solvent to clean pump components or tank, observe
the solvent manufacturer’s recommendations for safe use
and disposal.
INSTALLATION
This pump is designed to self-prime with dry gears. Expect
suction lift as follows:
Manual Nozzle: 5.5 feet (1.7 m) with diesel
6.7 feet (2.1 m) with gasoline
Automatic Nozzle: 4.8 feet (1.5 m) with diesel
5.8 feet (1.8 m) with gasoline
If you require a greater initial prime height, coat the gears
with uid by removing the plug on the top of the pump and
pour a small quantity of motor oil into the gear cavity. Replace
the plug and try again. A foot valve with pressure relief may
be needed to maintain prime.
Make sure all threaded fuel connections are wrapped with
three to four turns of thread tape or a pipe thread sealant
approved for use with petroleum fuels.
Install Bung Adapter and Suction Pipe
• Tighten the bung adapter snugly into the fuel tank.
• Place the union ring gasket into the inlet tting on the
bottom of the pump.
• Thread the suction pipe into the inlet tting and tighten
until snug.

Rev. - 922124-01
3
Install Pump on Tank
• Clean the tank interior of all dirt and foreign material.
• Extend the suction pipe to its full length and insert into
the tank opening. (Figure 1)
FIGURE 1
The suction pipe
will adjust to the
length needed to
rest on the tank
bottom.
• Place the pump on the bung adapter and tighten the union
ring securely with a pipe wrench. Make sure the union
ring is not cross-threaded.
• To prevent pressure buildup and possible fuel leaks
through the nozzle, make sure the tank is vented. A vent
cap rated at 3 psi or less is recommended.
Connect to a Power Source
Please consult the Owner’s Manual for your vehicle
before proceeding.
NOTE: Model M-150S should be connected to a 12-
volt DC power source. Do not attempt installation on
a 24-volt or 115-volt system.
WARNING: Do not attempt to power the pump from
vehicle wiring smaller than 12 gauge, such as the
cigarette lighter wire, as these thin wires could
overheat and cause a re.
NOTE: This pump is pre-wired for installation in
CLASS I, DIVISION 2 locations such as portable fuel
tanks, trailers, etc. Connection to a battery will de-
pend upon the application.
WARNING: If pump is to be installed in
a CLASS I, DIVISION I location please
contact GPI for the appropriate product.
Verify switch is in OFF position, then route the electri-
cal wires to the source of the vehicle power system.
Be sure to support the wires as necessary and protect
them from sharp edges, heat or anything that could
damage the wires.
Step 1
If the power cord provided is too long cut to desired
length. Carefully strip 3 to 4 inches (7.5 to 10 cm) of
outer insulation from end of power cord. DO NOT CUT
INNER WIRES. Next, strip ¼ inch (0.6 cm) of insulation
from the black and red power cord wires.
Step 2
For a negative ground system, rst disconnect the
vehicle’s ground wire, and then wire as follows: Insert
one end of the fuse (J) into the wire connector (H) and
crimp. Insert the red power cord wire into the other
end of the wire connector and crimp. Make sure the
fuse is positioned outside of hazardous areas and as
close to the battery as possible. Make a solid electrical
connection to the grounded side of the battery with the
remaining black wire. Connecting directly to the battery
terminal or the end of the battery cable is recommend-
ed.
Step 3
For temporary wiring: Connect the red and black pow-
er cords to alligator clamps (not included) (Figure 6).
Figure 6
Step 4
For permanent wiring:
Connect the red and black power cords to terminal
post rings (not included) (Figure 7).
Figure 7
Step 5
Check all connections to make sure they are connect-
ed per instructions and all electrical codes. The instal-
lation is now complete.
Carefully route the power cord to the battery, protecting the
power cord from hot surfaces, sharp edges or anything that
could damage the power cord, resulting in a short circuit.
A 25 amp fuse is provided to protect the power cord and motor.
Install fuse in the red wire of the power cord as close as pos-
sible to the battery. Connect the red wire of the fuse to the
positive (ungrounded) side of battery. Connect black wire to
the negative (grounded) side of battery.
Failure to follow these instructions could result in death, serious
injury or loss of equipment due to short circuit, re or explosion.
WARNING
If the pump is to be installed in a Hazardous (Classied) loca-
tion, it must be installed by a licensed electrician and conform
to National Fire Protection Association (NFPA) codes 30 and 70.
You as the owner, are responsible for seeing that the installation
and operation of your pump complies with NFPA codes as well
as any applicable state and local codes. Rigid conduit must be
used to install wiring. Note that the lead wires are factory-sealed
isolating the motor from the junction box.
Failure to follow these wiring instructions may result in death or
serious injury from shock, re or explosion.
DANGER
Install Hose and Nozzle
After sealing threads, tighten the hose into the pump outlet

Rev. - 922124-01
4
and the nozzle on the hose. The nozzle can be placed in
the nozzle holder only when the pump is off.
ALWAYS FOLLOW SAFETY PRECAUTIONS WHEN
OPERATING THIS EQUIPMENT. REVIEW THE SAFETY
INSTRUCTIONS.
OPERATION
Before each use, repair leaks around seals or connections.
Make sure hoses are in good condition and connections
are tight. Make sure the work area is dry. MAKE SURE
THE PUMP IS PROPERLY GROUNDED. Repair any
corroded or damaged wiring before use. Ensure the tank
contains enough fuel. Make sure the fuel is not contam-
inated with debris.
To Dispense Fuel
This pump is designed to self-prime with dry gears. Expect
suction lift as follows:
Manual Nozzle: 5.5 ft. (1.7 m) with diesel
6.7 ft. (2.1 m) with gasoline
Automatic Nozzle: 4.8 ft. (1.5 m) with diesel
5.8 ft. (1.8 m) with gasoline
If you require a greater initial prime height, coat the gears
with uid by removing the plug on the top of the pump
and pour a small quantity of motor oil into the gear cavity.
Replace the plug and try again. A foot valve with pressure
relief may be needed to maintain prime.
Turn on the pump by removing the nozzle from the holder
and pushing up the switch lever. Insert the nozzle into the
receiving tank and squeeze the handle to start fuel ow.
When done, release the nozzle handle, turn the pump
off, and return the nozzle to its holder.
This pump is designed to be self-priming. If fuel is not
delivered within 15 to 20 seconds, turn the pump off and
refer to priming information in the Troubleshooting Section.
An automatic bypass valve prevents pressure build up when the
pump is on with the nozzle closed. To avoid pump damage, do
not run the pump more than 10 minutes with the nozzle closed.
Motor Protector
The pump contains a motor protector that provides added
protection against motor damage. It must be reset manually.
If the motor protector trips, reset by turning the switch OFF. Let
the pump cool then turn ON again. If the motor protector trips
again, see the Troubleshooting Section of this manual.
MAINTENANCE
This pump is designed for minimum maintenance. Motor
bearings are sealed and require no lubrication. Inspect
the pump and components regularly for fuel leaks and
make sure the hose and power cord are in good condi-
tion. Keep the pump exterior clean to help identify leaks.
Do not use this pump for water, chemicals or herbicides.
Dispensing any uid other than those listed in this manual
will damage the pump. Use of the pump with unauthorized
uids will void the warranty.
To Clean or Replace Strainer
Turn the pump off and disconnect from power. Remove
the strainer coverplate. Remove the inlet strainer and
inspect for damage or clogs. Clean the strainer with a
soft-bristled brush and solvent. If the strainer is very
dirty, compressed air may be used. If damaged, replace
the strainer.
Place the strainer in the cavity. Clean the coverplate
and O-ring. Coat the O-ring lightly with grease. Ensure
the coverplate O-ring is properly seated and tighten the
strainer coverplate.
SPECIFICATIONS
Applications for
EZ-8
Low viscosity petroleum fuels:
Gasoline (up to 15% alcohol blends
such as E15)
Diesel fuel (up to 20% biodiesel
blends such as B20)
Kerosene
Designed for permanent mounting
on vented storage tanks
Pump housing Lightweight, corrosion-resistant,
cast aluminum body.
Performance
Pump rate Up to 15 GPM (57 LPM)
Duty cycle 30 minutes ON, 30 minutes OFF
Suction lift Manual nozzle: Up to 5.5 ft. (1.7m)
Automatic nozzle: Up to 4.8 ft. (1.5m)
Operating
temperature -20F to +125F (-29C to +52C)
Operating
pressure 15 PSI
Electrical
specications
Input: 12-volt DC
Current draw: 18 amp
Motor protection: 20 amp circuit
breaker
Motor: 1900 RPM, UL Listed, CSA
Certied. 1/5 HP (150 watts)
Mechanical
connections
Bung: 2 in. NPT, Inlet: 1 in. NPT,
Outlet: 3/4 in. NPT
Accessories
3/4 in. x 10 ft. (3.0m) Buna-N elec-
trically conductive discharge hose
Standard 3/4 in. manual unleaded
nozzle
Standard 3/4 in. automatic unlead-
ed nozzle
Cord: 18 ft. (5.5m), 12/2 gauge
Fuse: 20 amp
Strain relief grip
Shipping weight
23 lbs. (10.5 kg) with manual
nozzle
24 lbs. (10.8 kg) with automatic
nozzle

Rev. - 922124-01
5
SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION
A. SWITCH FAILS TO
OPERATE MOTOR
1. Motor protector activated. Turn off switch. Allow motor to cool, then turn on switch.
2. Fuse blown. Inspect fuse in fuse holder on power cord. If blown, replace.
3. Switch or electrical connections faulty. Inspect for damaged motor protector, defective wiring or switch, or improper
electrical connections. Replace as necessary.
4. Motor burned out. Inspect and replace as necessary.
B. MOTOR RUNS BUT
DOES NOT PUMP
FLUID
1. Suction pipe clogged, damaged, or
missing.
Remove pump from tank. Inspect suction pipe. Clean or replace, as neces-
sary.
2. Gear coverplate or O-ring damaged Remove and inspect the coverplate and O-ring. Replace, as necessary.
3. Strainer clogged or defective Remove strainer coverplate. Remove and clean strainer. Install again.
4. Bypass poppet O-ring worn, missing
Inspect O-ring using instructions in the Repair Section. Replace, if necessary.
5. Bypass poppet O-ring dirty Remove poppet assembly and clean poppet and cavity.
6. Bypass poppet binding or damaged Using instructions in the Repair Section, remove the bypass poppet, spring,
and O-ring. Clean cavity. Inspect and replace components, as necessary.
7. System air leak
Tighten all pump ttings and connections. Inspect suction pipe for leaks or
damage.
8. System air lock This can occur if external lter, meters, or an off-the-shelf automatic
nozzle is used. To correct, remove the pipe plug in the top outlet port and
ll the gear cavity with fuel. Use of a factory-supplied automatic nozzle is
recommended.
9. Poor connections or low voltage Make sure electrical connections are secure. Also check battery voltage.
10. Fuel level low Fill tank.
11. Motor running backwards due to incor-
rect polarity
Connect red wire to positive (+) ungrounded side of battery. Gear with key
should turn counterclockwise.
C. LOW FLOWRATE
1. Poor connections or low voltage Make sure electrical connections are secure. Also check battery voltage.
2. Strainer partially clogged
Remove the strainer coverplate. Remove and clean the strainer. Install again.
3. Suction pipe clogged or damaged Remove pump from tank. Inspect suction pipe. Clean or replace, as necessary.
4. Fuel tank empty Fill tank.
5. Using off-the-shelf automatic nozzle Factory-supplied automatic nozzle is recommended.
6. System air leak Tighten all pump ttings and connections. Inspect suction pipe for leaks or
damage. Replace, as necessary.
7. Bypass poppet spring weak Using instructions in the Repair Section, remove the bypass poppet and
inspect spring. Replace, if necessary.
D. MOTOR STALLS
WHEN OPERATING
IN BYPASS MODE
1. Motor protector activated Turn off switch. Allow motor to cool, then turn on switch.
2. Gears locked Remove gear coverplate and inspect gears and drive key. Make sure gears
turn freely with the key removed. Replace, if worn.
3. Wiring defective
Use Wiring instructions in the Installation Section to ensure proper connections.
4. Bypass poppet binding or damaged Using instructions in the Repair Section, remove the bypass poppet, spring,
and O-ring. Clean cavity. Inspect components and replace, as necessary.
5. Motor defective Replace motor as described in the Repair Section.
E. SWITCH FAILS TO
OPERATE MOTOR
1. Switch or electrical connections faulty
(Model M-240S)
Inspect for a blown fuse, defective wiring or switch, or improper electrical
connections. Replace or install again, as necessary. Refer to Switch Re-
placement instructions in the Repair Section.
2. Motor burned out Replace motor as described in the Repair Section.
3. Motor protector activated Turn off switch. Allow motor to cool, then turn on switch.
4. Switch or electrical connections faulty
(Models M-150S and M-180S)
Inspect for damaged motor protector, blown fuse, defective wiring or switch,
or improper electrical connections. Replace as needed and re-install.
F. RAPID OVER-
HEATING OF
MOTOR
1. Duty cycle too long Pump operation should not exceed the standard duty cycle of 30 minutes
ON, and 30 minutes OFF. Allow the pump to cool for 30 minutes.
2. Strainer clogged Remove strainer coverplate. Remove and clean strainer. Install again.
3. Suction pipe clogged or damaged
Remove pump from tank. Inspect suction pipe. Clean or replace, as necessary.
4. Gears worn Remove gear coverplate and inspect gears and drive key. Make sure gears
turn freely with key removed. Replace, if necessary.
5. Fuel level low Fill tank.
6. Running too long in bypass mode Limit bypass operation to 10 minutes.
TROUBLESHOOTING

Rev. - 922124-01
6
1
3
20
23
5
21
11
20
19
4
9
14
16
24
10
15
1322
29 6
7
25
12
18
230
27
28
26
8
31
ILLUSTRATED PARTS LIST
Individual Parts
Item
No. Part No. Description Req’d.
1 110155-1 Nozzle, Manual 3/4 in., Unleaded .........................1
2 110382-501 Inlet Fitting.............................................................1
3 110187-2 Hose, 3/4 in. x 3/4 in. x 10 ft. ................................1
4 110195-02 Coverplate, Electrical ............................................1
5 110265-02 Power Cord, 12 ga. x 18 ft......................................1
6 110276-01 Switch Coverplate Assy.........................................1
7 110026-6 Switch Coverplate O-Ring......................................1
8 110285-01 Electrical Coverplate Gasket..................................1
9 110907-1 Gear Kit-Includes 2 Gears & Drive Key or (Kit ) 1
10 110009-501 Inlet Strainer ..........................................................1
11 110010-501 Bypass Poppet........................................................1
12 110017-6 Motor Shaft Key.....................................................1
13 110024-1 Coverplate, Strainer...............................................1
14 901003-70 Gear Coverplate O-Ring .........................................1
15 110026-4 Strainer Coverplate O-Ring....................................1
16 110067-2 Gear Coverplate .....................................................1
17 110131-2 Spring, Bypass Poppet ..........................................1
18 110277-505 Switch Assy, M-150S (Switch, Breaker, Bracket) ..1
19 118017-3 O-Ring.....................................................................1
20 119200-551 Motor, 12-Volt (M-150)...........................................1
21 904001-42 Plug, Pipe, 3/4-14 NPT...........................................1
22 904002-22 Sems Screw ...........................................................4
23 904002-23 Sems Screw, 1/4-20 x 3/4 in..................................3
24 904002-24 Sems Screw ...........................................................4
25 904003-84 Tapping Screw........................................................1
26 11002502 Motor Shaft Seal....................................................1
Individual Parts
Item
No. Part No. Description Req’d.
27 110360-02 Nozzle Cover...........................................................1
28 904002-517 Strain Relief Sealing Grip ......................................1
29 904002-23 Sems Screw & Washer Assy.................................6
30 904006-86 Tapping Screw........................................................2
31 110241-01 Telescoping Suction Pipe .......................................1
Kits and Accessories
Part No. Description
110500-02 25 Amp Fuse Kit
110524-1 Armature Assy Kit (includes Armature Assy)
110527-1 Battery Clamp Kit (includes 2 Battery Clamps)
110525-1 Brush Card Assy Kit (includes Brush Holder Assy)
110504-1
Fuel Pump Overhaul Kit (includes 2 Gears, Drive Key & O-Rings)
110907-1 Gear Kit (includes 2 Gears & Drive Key)
110526-1 Motor Housing Kit (includes Motor Housing Assy)
110908-1 Poppet Seal Kit (includes Poppet O-Ring)
906001-4 Pre-Vent Vapor Control Cap (3 psi)
110913-2 Spare Key Kit (includes Spare Drive Key)
902007-530 Switch Kit (includes Switch only)
110906-1 Wet Seal Kit (includes O-Rings & Motor Shaft Seal)

Rev. - 922124-01
7
PARTS AND SERVICE
In order to preserve the UL Listing for the motor, do not attempt to
service the motor. For products serviced outside the factory, the UL
nameplate must be defaced to indicate that the equipment may no
longer meet the requirements for UL Listing. This does not apply
to products serviced outside the factory under the UL program for
Rebuilt Motors for Use in Hazardous Locations.
For warranty consideration, parts, or other service information,
please contact your local distributor. If you need further assistance,
contact the GPI Customer Service Department in Wichita, Kansas,
during normal business hours.
A toll free number is provided for your convenience.
1-800-835-0113
To obtain prompt, efcient service, always be prepared with the
following information:
1. The model number of your pump.
2. The serial number or manufacturing date code of your pump.
3. Part descriptions and numbers.
Part information can be obtained from the Illustrated Parts List.
For warranty work, always be prepared with your original sales slip
or other evidence of purchase date.
Please contact GPI before returning any parts. It may be possible
to diagnose the trouble and identify needed parts in a telephone
call. GPI can also inform you of any special requirements you will
need to follow for shipping fuel dispensing equipment.
Do not return the pump or parts without authority from the
Customer Service Department. Due to strict government regu-
lations, GPI cannot accept parts unless they have been drained
and cleaned.
CAUTION
SAVE THESE INSTRUCTIONS

Rev. - 922124-01
06/16
LISTED MOTOR
Limited Warranty Policy
Great Plains Industries, Inc. 5252 E. 36th Street North, Wichita, KS USA 67220-3205, hereby provides a limited warranty against
defects in material and workmanship on all products manufactured by Great Plains Industries, Inc. This product includes a 2 year
warranty from date of purchase as evidenced by the original sales receipt. A 30 month warranty from product date of manufacture
will apply in cases where the original sales receipt is not available. Reference product labeling for the warranty expiration date
based on 30 months from date of manufacture. Manufacturer’s sole obligation under the foregoing warranties will be limited to
either, at Manufacturer’s option, replacing or repairing defective Goods (subject to limitations hereinafter provided) or refunding the
purchase price for such Goods theretofore paid by the Buyer, and Buyer’s exclusive remedy for breach of any such warranties will
be enforcement of such obligations of Manufacturer. The warranty shall extend to the purchaser of this product and to any person
to whom such product is transferred during the warranty period.
This warranty shall not apply if:
A. the product has been altered or modied outside the warrantor’s duly appointed representative;
B. the product has been subjected to neglect, misuse, abuse or damage or has been installed or operated other than in
accordance with the manufacturer’s operating instructions.
To make a claim against this warranty, contact the GPI Customer Service Department at 316-686-7361 or 800-835-0113. Or by mail at:
Great Plains Industries, Inc.
5252 E. 36th St. North
Wichita, KS, USA 67220-3205
GPI will step you through a product troubleshooting process to determine appropriate corrective actions.
GREAT PLAINS INDUSTRIES, INC., EXCLUDES LIABILITY UNDER THIS WARRANTY FOR DIRECT, INDIRECT, INCIDENTAL
AND CONSEQUENTIALDAMAGES INCURRED IN THE USE OR LOSS OF USE OF THEPRODUCT WARRANTED HEREUNDER.
The company herewith expressly disclaims any warranty of merchantability or tness for any particular purpose other than for which
it was designed.
This warranty gives you specic rights and you may also have other rights which vary from U.S. state to U.S. state.
Note: In compliance with MAGNUSON MOSS CONSUMER WARRANTY ACT – Part 702 (governs the resale availability of the war-
ranty terms).
Great Plains Industries, Inc. / 800-835-0113 / GPI.net
© 2016 Great Plains Industries, Inc. All Rights Reserved.
