GPI M-150S User manual

15-18 GPM (57-68 L/min)
12V & 24V (dc)
Fuel Transfer Pump
Models: M-150S, M-180S, M-240S
Product Owner’s Manual EN
922123-01 Rev B
per ECN 5821
12/2020 SAVE THESE INSTRUCTIONS

Please save these instructions for future reference. Read carefully before attempting
to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply
with instructions could result in personal injury and/or property damage.
Please refer to back cover for information regarding this product’s warranty and
other important information.
Thank you for choosing a Great Plains Industries product, and
congratulations on your purchase!
Headquartered in the heartland of the U.S., GPI strives
for integrity, innovation, continuous improvement, and
dependability—values you will immediately recognize when using
our products.
The maintenance policies and procedures outlined in this manual
emphasize our commitment to safety and our dedication to you
as a customer. By working together, we can ensure years of
reliable, quality service.
SAVE FOR YOUR RECORDS
Model #: ___________________
Serial #: ___________________
Purchase Date: _____________
DO NOT RETURN THIS PRODUCT TO THE STORE!
Please contact Great Plains Industries, Inc. before returning any product. If you are
missing parts, or experience problems with your installation, contact our Customer
Support Department. We will be happy to assist you.
Call: 800-835-0113 or 316-686-7361
Email: [email protected]
Website: gpi.net

NOTES

BEFORE YOU BEGIN
Fueling Requirements:
• This fuel pump is designed, tested and approved for use with gasoline
blends (up to E15) diesel fuel blends (up to B20) and kerosene. Pump
only models sold without a hose/nozzle are compatible with aviation
gasoline AVGAS 100LL and kerosene grade Jet A. Please take all due
precautions when handling these flammable liquids.
•Do not use this pump for dispensing any fluids other than those for
which it was designed. To do so may damage the pumps components
and will void the warranty.
Power Source Requirements:
• This manual covers 12 and 24 volt DC electric gear pump
models M-150S, M-180S, and M-240S.
• Models M-150S and M-180S should be connected to a 12-volt
DC power source. Model M-240S should be connected to
a 24-volt power source only.
• Do not attempt connection of any pump to a 115-volt AC or
230-volt AC power source.
Tools Needed:
•Adjustable Wrench, Pipe Wrench, Pliers, Utility Knife,
Wire Crimper/Stripper, and Thread Tape
UNPACKING
Contents (See Figure 1):
• (1) 12-volt or 24-volt DC Fuel Transfer Pump with Spin Collar (Item A),
(1) Fiber Gasket (Item C) and (1) Tank Adapter (Item D); or 12-volt Fuel
Transfer Pump with Direct Mount (Item B) (M-150S-EM only)
• (1) 18 foot (5.5 m) Attached Power Cord with (1) Fuse Assembly (Item E),
(2) Ring Terminals (Item F) and (1) Wire Connector (Item G)
• (1) 12 foot (3.6 m) Dispensing Hose (Item H) (M-150S-AU & -MU, M-180S-
AU & -ML, and M-240S-MU) or (1) 10 foot (3.0 m) Dispensing Hose
(M-150S-EM only)
• (1) 1 inch Female to 3/4 inch Reducer (Item K) - (M-180S-AU &
M-180S-ML)
• (1) 15 inch (38 cm) to 40 inch (101 cm) Adjustable Suction Pipe (Item L)
• (1) Automatic (Item M) - (M-150S-AU and M-180S-AU) or Manual Shut-off
Nozzle (Item N) - (M-150S-EM & -MU, M-180S-ML and M-240S-MU)
• (1) Lockable Nozzle Holder (Item P) - (M-150S-AU & -MU, M-180S-AU & -ML,
and M-240S-MU); or (1) Standard Nozzle Holder (Item Q) (M-150S-EM
only)
tools.eps
box.eps
magnify_2.eps
warning symbol.eps
measure.eps
plug.eps
oil.eps
megaphone.eps
biohaz.eps
Battery_Caution1.eps
Caution.eps
Crush_Caution1.eps
Electrical_Caution.eps
Face_protection.eps
Fall_Hazard.eps
Fall_protection.eps
GearHand_Hazard.eps
Head_protection.eps
Heavy_Hazard.eps
Hot_surface.eps
Recycle.eps
Resp_protection1.eps
Resp_protection2.eps
Temp_Caution1.eps
body_protection.eps
chemical_Caution.eps
ear_protection1.eps
explosive_caution.eps
eye_protection1.eps
foot_protection.eps
hand_protection.eps
tools.eps
box.eps
magnify_2.eps
warning symbol.eps
measure.eps
plug.eps
oil.eps
megaphone.eps
biohaz.eps
Battery_Caution1.eps
Caution.eps
Crush_Caution1.eps
Electrical_Caution.eps
Face_protection.eps
Fall_Hazard.eps
Fall_protection.eps
GearHand_Hazard.eps
Head_protection.eps
Heavy_Hazard.eps
Hot_surface.eps
Recycle.eps
Resp_protection1.eps
Resp_protection2.eps
Temp_Caution1.eps
body_protection.eps
chemical_Caution.eps
ear_protection1.eps
explosive_caution.eps
eye_protection1.eps
foot_protection.eps
hand_protection.eps
tools.eps
box.eps
magnify_2.eps
warning symbol.eps
measure.eps
plug.eps
oil.eps
megaphone.eps
biohaz.eps
Battery_Caution1.eps
Caution.eps
Crush_Caution1.eps
Electrical_Caution.eps
Face_protection.eps
Fall_Hazard.eps
Fall_protection.eps
GearHand_Hazard.eps
Head_protection.eps
Heavy_Hazard.eps
Hot_surface.eps
Recycle.eps
Resp_protection1.eps
Resp_protection2.eps
Temp_Caution1.eps
body_protection.eps
chemical_Caution.eps
ear_protection1.eps
explosive_caution.eps
eye_protection1.eps
foot_protection.eps
hand_protection.eps
MAINTENANCE /
REPAIR TROUBLESHOOTING OPERATION ASSEMBLY /
INSTALLATION
SAFETY /
SPECIFICATIONS GETTING STARTED
GETTING STARTED
1-EN

UNPACKING (CONTINUED)
Contents (Continued):
Inspect:
• After unpacking the unit, inspect carefully for any damage that may
have occurred during transit. Check for loose, missing or damaged
parts. Shipping damage claims must be filed with carrier.
• See General Safety Instructions on page 3, and Cautions and
Warnings as shown.
15” - 25” Telescoping Suction Pipe
25” - 40” Extension Pipe
1Figure
(A) Spin Collar
(B) Direct Mount
(H or J)
Dispensing
Hose
(C) Fiber Gasket
(F) Ring Terminals
(K) Reducer
(E) Fuse
Assembly
(D) Tank
Adapter
(L) Suction Pipe Assembly
(G) Wire
Connector
(M) Automatic
Shut-off Nozzle
(N) Manual
Shut-off Nozzle
(P) Lockable
Nozzle Holder
(Q) Standard
Nozzle Holder
GETTING STARTED SAFETY /
SPECIFICATIONS
ASSEMBLY /
INSTALLATION OPERATIONTROUBLESHOOTING MAINTENANCE /
REPAIR
2-EN
