Graco Therm-O-Flow 25C994 User manual

3A5186B
EN
Instructions - Parts
Communications
Gateway Module
Therm-O-Flow®Installation Kit
For use with Therm-O-Flow 20 and 200 systems to provide fieldbus communication
capabilities. For professional use only.
Kit No. 25C994
Important Safety Instructions
Read all warnings and instructions in this
manual and in all related manuals. Save all
instructions.

Related Manuals
23A5186B
Contents
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Mounting the CGM . . . . . . . . . . . . . . . . . . . . . . . 3
Connecting the CAN Cables . . . . . . . . . . . . . . . . 3
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Gateway Screens . . . . . . . . . . . . . . . . . . . . . . . . 5
EtherNet/IP Fieldbus Screens . . . . . . . . . . . . . . . 5
DeviceNet Fieldbus Screen . . . . . . . . . . . . . . . . 5
PROFIBUS Fieldbus Screen . . . . . . . . . . . . . . . . 6
PROFINET Fieldbus Screens . . . . . . . . . . . . . . . 6
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Software Update Procedure . . . . . . . . . . . . . . . . 8
Available Internal Data . . . . . . . . . . . . . . . . . . . . . . 9
Automation Inputs (Signals from the Therm-O-Flow
to the PLC) . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Automation Outputs (Signals from the PLC to the
Therm-O-Flow) . . . . . . . . . . . . . . . . . . . . . . 11
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Kit No. 25C994 . . . . . . . . . . . . . . . . . . . . . . . . . 12
Appendix A - I/O Signal Descriptions . . . . . . . . . 13
Heat Zone States . . . . . . . . . . . . . . . . . . . . . . . 13
Status Indication Bit Tables . . . . . . . . . . . . . . . 13
System Control Bits . . . . . . . . . . . . . . . . . . . . . 14
Temperature Setpoint Zone Designation Table 16
Appendix B - Data Exchange Interface . . . . . . . . 17
Data Exchange Interface Pointer Designation Tabl
18
Appendix C - Error/Event Tables . . . . . . . . . . . . . 22
Related Manuals
Models
The following kit includes the Communications Gateway
Module (CGM) parts and software that are required for
Therm-O-Flow 20 or Therm-O-Flow 200 machines using
a CGM. This kit enables the Therm-O-Flow machines to
connect to a fieldbus device.
Kit 25C994 is used with the following CGM models,
each of which includes all of the remaining parts neces-
sary to install the CGM. See Communications Gateway
Module Instructions - Parts, manual 312864, for repair
parts for these assemblies.
Overview
The Communications Gateway Module (CGM) provides
a control link between the Therm-O-Flow (TOF) system
and a selected fieldbus. The control link provides the
means for remote monitoring and control by external
automation systems.
The data available to the fieldbus from the CGM
depends on the amount of channels installed on the
Therm-O-Flow system. A data map is available on a
token provided in this kit.
See Available Internal Data on page 9for a list of inter-
nal data from the Therm-O-Flow system that can be
viewed or modified by the fieldbus device.
NOTE: The following system network configuration files
are available at www.graco.com.
• EDS file: DeviceNet or Ethernet/IP fieldbus net-
works
Manual Description
312864 Communications Gateway Module
Instructions - Parts
334130 Therm-O-Flow 200 Instructions - Parts
334129 Therm-O-Flow 20 Instructions - Parts
406987 GCA CAN Cables, Reference
Part No. Description
25C994 Thermo-O-Flow CGM Installation Kit
Part No. Fieldbus
CGMEP0 EtherNet/IP
CGMDN0 DeviceNet
CGMPB0 PROFIBUS
CGMPN0 PROFINET

Installation
3A5186B 3
Installation
NOTE: Turn off the main power switch on the
Therm-O-Flow before starting. See the Therm-O-Flow
manuals referenced in Related Manuals on page 2for
information about turning off the power.
To install the CGM, you will need to drill mounting holes
on the Therm-O-Flow below the electrical control panel
in a location where the CAN cables can be connected to
the CGM. See Figure 1 for the recommended location.
The center of the CGM should be 4 inches from the bot-
tom of the electrical control panel and 8 inches from
each side. Refer to the following mounting dimensions
when drilling the holes for the CGM.
NOTE: Mount the CGM with the CAN cable connectors
on the left side to make it easier to connect the cables.
Mounting the CGM
1. Drill the mounting holes.
2. Remove the access cover from the CGM (D).
Loosen the two screws (C) and remove the CGM
(A) from the base (B).
3. With the CAN connectors on the left side, mount the
base (B) in the mounting holes using the four
screws supplied in this kit. See Parts on page 12.
4. Mount the CGM (A) on the base (B) with the two
screws (C) that were removed in step 2.
5. Reattach the access cover (D).
Connecting the CAN Cables
1. Disconnect the ADM’s CAN cable from the ADM
and from the splitter on the back of the
Therm-O-Flow’s electrical control panel.
2. Connect one end of the 1.5 m (4.9 ft) CAN cable
included in this kit to the ADM. Run the cable down
and through the opening underneath the electrical
control box as shown in Figure 3.
FIG. 1: Mounting Location
Recommended
Location for
Mounting Holes
3.25 in.
(82.6 mm)
2.75 in.
(69.9 mm)
#10-32 UNF
(M5 x 0.8)
CAN Cable Connectors
FIG. 2: Removing the CGM Access Cover
D
A
C
B

Installation
43A5186B
3. Connect the CAN cable that you removed from the
ADM to the available splitter connection on the back
of the electrical control panel. Run that cable
through the same opening as the other CAN cable.
4. Connect the two cables to the CGM connectors.
Either cable can be connected to either connector.
5. Attach the two ferrite suppressors included in the kit
to the ends of the two cables closest to the CGM.
6. Use the adhesive cable tie included in the kit to
attach the CAN cables to the back of the control
box.
7. Connect the Ethernet, DeviceNet, or PROFIBUS
cable to the CGM as applicable. Connect the other
end of the cable to the fieldbus device.
8. Perform the Install or Update Data Map procedure
in Communications Gateway Module Instructions -
Parts, manual 312864.
9. See the Available Internal Data on page 9for
details on the fieldbus pinout setup.
10. Perform Setup on page 5to configure the fieldbus.
FIG. 3: CAN Cable Connection
FIG. 4: CGM Connectors
CAN Cable from ADM
CAN Cable
from Splitter
Opening Leading to CGM
CAN Connector 1
CAN Connector 2
FIG. 5: Connecting the Fieldbus
Fieldbus Connection

Setup
3A5186B 5
Setup
Gateway Screens
Use the Gateway screens on the ADM to configure the
fieldbus. These screens are shown only if a CGM is cor-
rectly installed in your system. See Installation on page
3.
1. With the system on and enabled, press on the
ADM to access the Setup screens.
2. Use the ADM’s arrow keys to navigate to the main
Gateway screen.
EtherNet/IP Fieldbus Screens
NOTE: These screens are shown only if you have an
EtherNet/IP fieldbus CGM installed.
Screen 1
Press the key to access this screen. Use the arrow
keys to navigate to each field and the keypad to set the
IP address, DHCP settings, subnet mask, gateway, and
DNS information.
Screen 2
Use the down arrow key on the ADM to navigate to
screen 2. This screen displays the hardware revision,
system serial number, and data map identification infor-
mation.
DeviceNet Fieldbus Screen
NOTE: This screen is shown only if you have a Devi-
ceNet fieldbus CGM installed.
Press the key to access this screen. You can set
the device address and baud rate. You can also view
the hardware revision, system serial number, and data
map identification information.
NOTICE
To prevent damage to soft key buttons on the ADM, do
not press the buttons with sharp objects such as pens,
plastic cards, or fingernails.

Setup
63A5186B
PROFIBUS Fieldbus Screen
NOTE: These screens are shown only if you have a
PROFIBUS fieldbus CGM installed.
Screen 1
Press the key to access this screen. Use the arrow
keys to navigate to each field and the keypad to set the
device address, install date, location tag, function tag,
and description.
Screen 2
Use the down arrow key on the ADM to navigate to
screen 2. This screen displays the hardware revision,
system serial number, and data map identification infor-
mation.
PROFINET Fieldbus Screens
NOTE: These screens are shown only if you have a
PROFINET fieldbus CGM installed.
Screen 1
Press the key to access this screen. Use the arrow
keys to navigate to each field and the keypad to set the
IP address, DHCP settings, subnet mask, gateway, and
DNS information.
Screen 2
Use the down arrow key on the ADM to navigate to
screen 2. Press the key to access this screen. You
can set the station name, install date, location tag, func-
tion tag, and description.

Setup
3A5186B 7
Screen 3
Use the down arrow key on the ADM to navigate to
screen 3. This screen displays the hardware revision,
system serial number, and data map identification infor-
mation.

Maintenance
83A5186B
Maintenance
Software Update Procedure
When software is updated on the ADM, the software is
then automatically updated on the CGM and all other
connected Graco Control Architecture components.
1. At the ADM, turn the power switch to Off.
2. Remove the ADM from the bracket.
3. Use a hex key to remove the token access panel.
4. Insert and press the software upgrade token firmly
into the slot.
5. Turn the power switch to On.
6. The Graco Splash screen is displayed until commu-
nication with other modules is established.
7. Wait for the update to complete. An approximate
time to completion displays below the progress bar.
8. When the update is completed successfully, press
the key.
9. Remove the token and replace the token access
panel.
NOTE: The software version history for each system
can be viewed in the technical support section at
www.graco.com.
FIG. 6: Token Location
NOTICE
A status is shown while software is updating to indi-
cate progress. To prevent corrupting the software
load, do not remove the token until the status screen
disappears.

Available Internal Data
3A5186B 9
Available Internal Data
See Appendix A - I/O Signal Descriptions on page 13 for additional details regarding each input/output. Unless
stated otherwise:
• Values are subject to the same maximum and minimum restrictions of the ADM.
• Some of the temperature data may have slight rounding errors compared to temperatures displayed on the ADM.
• On some controlling devices, the byte order may need to be reversed (byte order within instance, least significant
-> most significant.
Automation Inputs (Signals from the Therm-O-Flow to the PLC)
Instance
Number
Input Byte
Index(es) Description Units
1 0 -1 Pump Actual Temperature, Primary °C/°F
2 2 - 3 Platen Actual Temperature, Primary °C/°F
3 4 - 5 Zone #1 Actual Temperature, Primary °C/°F
4 6 - 7 Zone #2 Actual Temperature, Primary °C/°F
5 8 - 9 Zone #3 Actual Temperature, Primary °C/°F
6 10 - 11 Zone #4 Actual Temperature, Primary °C/°F
7 12 - 13 Zone #5 Actual Temperature, Primary °C/°F
8 14 - 15 Zone #6 Actual Temperature, Primary °C/°F
9 16 - 17 Zone #7 Actual Temperature, Primary °C/°F
10 18 - 19 Zone #8 Actual Temperature, Primary °C/°F
11 20 - 21 Zone #9 Actual Temperature, Primary °C/°F
12 22 - 23 Zone #10 Actual Temperature, Primary °C/°F
13 24 - 25 Zone #11 Actual Temperature, Primary °C/°F
14 26 - 27 Zone #12 Actual Temperature, Primary °C/°F
15 28 - 29 Pump Setpoint Temperature Indication, Primary/Secondary °C/°F
16 30 - 31 Platen Setpoint Temperature Indication, Primary/Secondary °C/°F
17 32 - 33 Zone #1 Setpoint Temperature Indication, Primary/Secondary °C/°F
18 34 - 35 Zone #2 Setpoint Temperature Indication, Primary/Secondary °C/°F
19 36 - 37 Zone #3 Setpoint Temperature Indication, Primary/Secondary °C/°F
20 38 - 39 Zone #4 Setpoint Temperature Indication, Primary/Secondary °C/°F
21 40 - 41 Zone #5 Setpoint Temperature Indication, Primary/Secondary °C/°F
22 42 - 43 Zone #6 Setpoint Temperature Indication, Primary/Secondary °C/°F
23 44 - 45 Zone #7 Setpoint Temperature Indication, Primary/Secondary °C/°F
24 46 - 47 Zone #8 Setpoint Temperature Indication, Primary/Secondary °C/°F
25 48 - 49 Zone #9 Setpoint Temperature Indication, Primary/Secondary °C/°F
26 50 - 51 Zone #10 Setpoint Temperature Indication, Primary/Secondary °C/°F
27 52 - 53 Zone #11 Setpoint Temperature Indication, Primary/Secondary °C/°F
28 54 - 55 Zone #12 Setpoint Temperature Indication, Primary/Secondary °C/°F
29 56 - 57 Pump, Platen, Zones 1 – 3 States, Primary 
30 58 - 59 Zones 4 – 8 States, Primary 
31 60 - 61 Zones 9 – 12 States, Primary 
32* 62 - 63 Pump Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
33* 64 - 65 Platen Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
34* 66 - 67 Zone #1 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
35* 68 - 69 Zone #2 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
36* 70 - 71 Zone #3 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
37* 72 - 73 Zone #4 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F

Available Internal Data
10 3A5186B
* Data instances (setback mode setpoint temperatures) are NOT provided for the PROFIBUS and PROFINET versions of the map since the
field protocols do not support that large of a map size. For PROFIBUS or PROFINET, you should use the data exchange interface to obtain
setback setpoint information.
** For the PROFIBUS or PROFINET versions of the map, 14 should be subtracted from the instance number and 28 should be subtracted for the
input byte count so that the PROFIBUS and PROFINET versions have 56 input instances containing 116 input bytes total.
Zone states are packed in groups of three bits, where each zone state equates to the following. Each zone is packed from bit 0, bit 3, bit 6, bit
9, and bit 12 corresponding to the order presented in the description. 000 - zone is not installed, 001 - zone is off, 010 - zone is in warm up
state, 011 - zone is in heat soak state, 100 - zone at temperature, 101 - zone in setback mode.
Temperature units match units of the ADM. Values are in tenths of a degree (for example, a value of 4005 corresponds to 400.5 °F). Setpoint
temperatures are either for the primary or secondary unit, depending on the system selected by the PLC in the System Control Word.
† See Appendix C - Error/Event Tables on page 22.
See the Status Indication Bit Tables on page 13.
See Appendix B - Data Exchange Interface on page 17.
‡ System Mode/State: 0 = System Off, 1 = Inactive, 2 = Warm Up, 3 = Heat Soak, 4 = Ready (at temperature, heat soak done, pump off), 5 =
Active (at ready and pump ON), 6 = Setback Mode.
Instance
Number
Input Byte
Index(es) Description Units
38* 74 - 75 Zone #5 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
39* 76 - 77 Zone #6 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
40* 78 - 79 Zone #7 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
41* 80 - 81 Zone #8 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
42* 82 - 83 Zone #9 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
43* 84 - 85 Zone #10 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
44* 86 - 87 Zone #11 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
45* 88 - 89 Zone #12 Setback Setpoint Temperature Indication, Primary/Secondary °C/°F
46** 90 - 91 Pump Actual Temperature, Secondary °C/°F
47** 92 - 93 Platen Actual Temperature, Secondary °C/°F
48** 94 - 95 Zone #1 Actual Temperature, Secondary °C/°F
49** 96 - 97 Zone #2 Actual Temperature, Secondary °C/°F
50** 98 - 99 Zone #3 Actual Temperature, Secondary °C/°F
51** 100 - 101 Zone #4 Actual Temperature, Secondary °C/°F
52** 102 - 103 Zone #5 Actual Temperature, Secondary °C/°F
53** 104 - 105 Zone #6 Actual Temperature, Secondary °C/°F
54** 106 - 107 Zone #7 Actual Temperature, Secondary °C/°F
55** 108 - 109 Zone #8 Actual Temperature, Secondary °C/°F
56** 110 - 111 Zone #9 Actual Temperature, Secondary °C/°F
57** 112 - 113 Zone #10 Actual Temperature, Secondary °C/°F
58** 114 - 115 Zone #11 Actual Temperature, Secondary °C/°F
59** 116 - 117 Zone #12 Actual Temperature, Secondary °C/°F
60** 118 - 119 Pump, Platen, Zones 1 – 3 States, Secondary 
61** 120 - 121 Zones 4 – 8 States, Secondary 
62** 122 - 123 Zones 9 – 12 States, Secondary 
63** 124 - 127 Error / Event Code(s) Present †
64** 128 - 131 Error / Event Code(s) Needing Acknowledged †
65** 132 - 133 Status Word 1 Indication Bits 
66** 134 - 135 Status Word 2 Indication Bits 
67** 136 - 137 Data Exchange Interface Pointer Last Serviced 
68** 138 - 141 Data Exchange Interface Input Value 
69** 142 System Mode/State, Primary ‡
70** 143 System Mode/State, Secondary ‡

Available Internal Data
3A5186B 11
Automation Outputs (Signals from the PLC to the Therm-O-Flow)
* Set this byte to one of the following: 0 = Do Nothing, 1 = Turns ON the System (same as pressing the key), 2-255 = Shuts Down the
System (same as pressing the key).
** Used to set the temperature setpoints to tenths of a degree (for example, 3005 = 300.5) in the selected units of measurement (°C or °F). See
the Temperature Setpoint Zone Designation Table on page 16.
See System Control Bits on page 14.
† See the Appendix C - Error/Event Tables on page 22
See Appendix B - Data Exchange Interface on page 17.
Instance
Number
Output
Bytes Description Units
1 0 System Activate/Stop *
2 1 Setpoint Zone Designation **
3 2 - 3 Setpoint Temperature for Selected Zone °C/°F**
4 4 - 5 System Control Bits 
5 6 - 9 Error/Event Number Acknowledged †
6 10 - 11 Data Exchange Interface Pointer Output Designation 
7 12 - 15 Data Exchange Interface Output Value 

Parts
12 3A5186B
Parts
Kit No. 25C994
Not shown.
NOTE: The CGM is not included in the kit. See Models on page 2for available CGM modules.
FIG. 7: Kit 25C994 Parts
6
7
15
20
13
CGM shown for mounting
purposes only.
Not included in kit.
Ref Part Description Quantity
6 96/0650/99 SCREW, tapping, phillips pan hd 4
7 17T051 TOKEN, gca, map, tof cgm 1
917T053SOFTWARE, gateway, tof, gsd 1
10 17T054SOFTWARE, gateway, tof, eds 1
11 17T055SOFTWARE, gateway, tof, gsdml 1
13 121901 SUPPRESSOR, box snap, ferrite 2
15 16H821 TOKEN, gca, upgrade, adm32 1
19 17T056KIT, sample program 1
20 121002 CABLE, can, female/female 1.5 m 1
21 84/0805/89CABLE, TIE MOUNT, 1 x 1 sq w/adhesive 1

Appendix A - I/O Signal Descriptions
3A5186B 13
Appendix A - I/O Signal Descriptions
This section provides details about the CGM automation input and output signals.
Heat Zone States
The signal is 0 on power up. The following values of this signal correspond to the various heat zone states. Each
zone is bit packed into 3 bits for each zone designation in input instances 29-31 and 60-62 of the map.
Status Indication Bit Tables
The following tables reflect bit-packed data, which corresponds to the status words located at input instances 65 and
66.
Status Word 1 Indication Bits
Number Binary # Heat Zone State
0 000 Zone Not Installed
1 001 OFF
2 010 Warm Up
3 011 Heat Soak State
4 100 At Temperature
5 101 Setback Mode
Bit
Number
Hex
Equivalent Binary Number Description
0 0x0001 0000 0000 0000 0001 System is ON
1 0x0002 0000 0000 0000 0010 Active System is Secondary (B) System
2 0x0004 0000 0000 0000 0100 Heat is Turned ON for Primary (A) System
3 0x0008 0000 0000 0000 1000 Heat is Turned ON for Secondary (B) System
4 0x0010 0000 0000 0001 0000 Setpoint Indications are for Secondary (B) System
5 0x0020 0000 0000 0010 0000 Setback Setpoint Indications are for Secondary (B) System
6 0x0040 0000 0000 0100 0000 Material Tracking is ON or Active
7 0x0080 0000 0000 1000 0000 Pump Priming is Active for Primary (A) System
8 0x0100 0000 0001 0000 0000 Pump Priming is Active for Secondary (B) System
9 0x0200 0000 0010 0000 0000 Pump is ON for Primary (A) System
10 0x0400 0000 0100 0000 0000 Pump is ON for Secondary (B) System
11 0x0800 0000 1000 0000 0000 Setback Mode is Active for Primary (A) System
12 0x1000 0001 0000 0000 0000 Setback Mode is Active for Secondary (B) System
13 0x2000 0010 0000 0000 0000 Data Exchange Interface is Active or in Transition
14-15 ------ ------ Reserved for Future Use

Appendix A - I/O Signal Descriptions
14 3A5186B
Status Word 2 Indication Bits
System Control Bits
The following table reflects the bit variables in output instance 4, which can be set or cleared to control the following
conditions.
1 Same as pressing on the main Run screen.
2 Same as pressing on the main Run screen.
3 Same as pressing on the main Run screen.
4 Same as pressing on the main Run screen.
5 Same as pressing or on the main Run screen.
Bit
Number
Hex
Equivalent Binary Number Description
0 0x0001 0000 0000 0000 0001 Heat Soak Timer Active for Primary (A) System
1 0x0002 0000 0000 0000 0010 Heat Soak Timer Active for Secondary (B) System
2 0x0004 0000 0000 0000 0100 Turn ON Primary System (A), Heat Command Active
3 0x0008 0000 0000 0000 1000 Turn ON Secondary System (B), Heat Command Active
4 0x0010 0000 0000 0001 0000 Prime/Pump on A Command Active
5 0x0020 0000 0000 0010 0000 Prime/Pump on B Command Active
6 0x0040 0000 0000 0100 0000 Setback A Command Active
7 0x0080 0000 0000 1000 0000 Setback B Command Active
8 0x0100 0000 0001 0000 0000 Cross Over Command Active
9 0x0200 0000 0010 0000 0000 PLC Control Active Indication
10 0x0400 0000 0100 0000 0000 Heart Beat Indication for PLC from TOF (See Note 7 in System
Control Bits)
11 0x0800 0000 1000 0000 0000 Error/Event Reported is an Alarm
12-15 ------ ------ Reserved for Future Use
Bit
Number
Hex
Equivalent Binary Number Description Notes
0 0x0001 0000 0000 0000 0001 Turn ON Heat Command for System A Command 1
1 0x0002 0000 0000 0000 0010 Turn ON Head Command for System B Command 1
2 0x0004 0000 0000 0000 0100 Turn ON/Prime Pumps for System A Command 2
3 0x0008 0000 0000 0000 1000 Turn ON/Prime Pumps for System B Command 2
4 0x0010 0000 0000 0001 0000 Setback Command System A 3
5 0x0020 0000 0000 0010 0000 Setback Command System B 3
6 0x0040 0000 0000 0100 0000 Cross Over Command 4
7 0x0080 0000 0000 1000 0000 Pause Material Tracking/Counters Command 5
8 0x0100 0000 0001 0000 0000 Continue Material Tracking Command 5
9 0x0200 0000 0010 0000 0000 Command Setpoint Indications on Map for System B 6
10 0x0400 0000 0100 0000 0000 Command Setback Setpoint Indications for System B 6
11 0x0800 0000 1000 0000 0000 Heart Beat Output to TOF 7
12 0x1000 0001 0000 0000 0000 PLC Control Command 8
13-15 ------ ------ Reserved for Future Use

Appendix A - I/O Signal Descriptions
3A5186B 15
6 After changing the state of the command XX setpoint indications on the map for the Secondary B system bit, the controlling PLC logic should
monitor the corresponding status indication bit and verify it corresponds to the command bit before monitoring the corresponding setpoint indi-
cation from the Therm-O-Flow.
7 The PLC or controlling logic needs to generate a dynamic signal at approximately a 0.333 Hz (1.5 seconds high, 1.5 seconds low) oscillation
rate. The signal is present to enable detection of a communication failure between the Therm-O-Flow system and the controlling logic. The
TOF system also generates the same rate dynamic signal indication (heart beat indication for PLC from TOF) signal for controlling logic to the
monitor.
8 The PLC Control Command bit needs to be set, and the controlling logic needs to generate a valid heart beat output (described in note 7) to
the Therm-O-Flo system before the TOF will grant the PLC requests or commands. If the heart beat output to TOF becomes a static signal
(always low or high) after an extended period of time while the TOF is in PLC control, the TOF reverts to a safe state, and generates a corre-
sponding alarm. This situation would be similar to an operator pressing the key

Appendix A - I/O Signal Descriptions
16 3A5186B
Temperature Setpoint Zone Designation Table
The following table shows the setpoint designations in
output instance 2 used to command the Therm-O-Flow
temperature zones to the corresponding setpoint. Prior
to writing to instance 2, the PLC needs to write the
desired temperature setpoint (in tenths of a degree for
the selected temperature unit of measure) to output
instance 3 for the selected zone. After the zone desig-
nation has been written, the PLC can monitor the set-
point change by monitoring the correct setpoint
indications: input instances 15-28 or 32-45.
Zone
Designation
Number
Description
0 No Zone Selected
1 Pump Setpoint Temperature, Primary
2 Platen Setpoint Temperature, Primary
3 Zone 1 Setpoint Temperature, Primary
4 Zone 2 Setpoint Temperature, Primary
5 Zone 3 Setpoint Temperature, Primary
6 Zone 4 Setpoint Temperature, Primary
7 Zone 5 Setpoint Temperature, Primary
8 Zone 6 Setpoint Temperature, Primary
9 Zone 7 Setpoint Temperature, Primary
10 Zone 8 Setpoint Temperature, Primary
11 Zone 9 Setpoint Temperature, Primary
12 Zone 10 Setpoint Temperature, Primary
13 Zone 11 Setpoint Temperature, Primary
14 Zone 12 Setpoint Temperature, Primary
15 Pump Setpoint Temperature, Secondary
16 Platen Setpoint Temperature, Secondary
17 Zone 1 Setpoint Temperature, Secondary
18 Zone 2 Setpoint Temperature, Secondary
19 Zone 3 Setpoint Temperature, Secondary
20 Zone 4 Setpoint Temperature, Secondary
21 Zone 5 Setpoint Temperature, Secondary
22 Zone 6 Setpoint Temperature, Secondary
23 Zone 7 Setpoint Temperature, Secondary
24 Zone 8 Setpoint Temperature, Secondary
25 Zone 9 Setpoint Temperature, Secondary
26 Zone 10 Setpoint Temperature, Secondary
27 Zone 11 Setpoint Temperature, Secondary
28 Zone 12 Setpoint Temperature, Secondary
61 Pump Setback Setpoint Temperature, Primary
62 Platen Setback Setpoint Temperature, Primary
63 Zone 1 Setback Setpoint Temperature, Pri-
mary
64 Zone 2 Setback Setpoint Temperature, Pri-
mary
65 Zone 3 Setback Setpoint Temperature, Pri-
mary
66 Zone 4 Setback Setpoint Temperature, Pri-
mary
67 Zone 5 Setback Setpoint Temperature, Pri-
mary
68 Zone 6 Setback Setpoint Temperature, Pri-
mary
69 Zone 7 Setback Setpoint Temperature, Pri-
mary
70 Zone 8 Setback Setpoint Temperature, Pri-
mary
71 Zone 9 Setback Setpoint Temperature, Pri-
mary
72 Zone 10 Setback Setpoint Temperature, Pri-
mary
73 Zone 11 Setback Setpoint Temperature, Pri-
mary
74 Zone 12 Setback Setpoint Temperature, Pri-
mary
75 Pump Setback Setpoint Temperature, Sec-
ondary
76 Platen Setback Setpoint Temperature, Sec-
ondary
77 Zone 1 Setback Setpoint Temperature, Sec-
ondary
78 Zone 2 Setback Setpoint Temperature, Sec-
ondary
79 Zone 3 Setback Setpoint Temperature, Sec-
ondary
80 Zone 4 Setback Setpoint Temperature, Sec-
ondary
81 Zone 5 Setback Setpoint Temperature, Sec-
ondary
82 Zone 6 Setback Setpoint Temperature, Sec-
ondary
83 Zone 7 Setback Setpoint Temperature, Sec-
ondary
84 Zone 8 Setback Setpoint Temperature, Sec-
ondary
85 Zone 9 Setback Setpoint Temperature, Sec-
ondary
86 Zone 10 Setback Setpoint Temperature, Sec-
ondary
87 Zone 11 Setback Setpoint Temperature, Sec-
ondary
88 Zone 12 Setback Setpoint Temperature, Sec-
ondary

Appendix B - Data Exchange Interface
3A5186B 17
Appendix B - Data Exchange Interface
The Data Exchange Interface is a bi-directional interface
that enables both transmitting and receiving data
between the Therm-O-Flow system and the controlling
logic (PLC). The interface allows a large amount of data
to exchange between the systems while only occupying
a very small data map to support the exchange. The
interface also allows for future expansion of data without
changing the map structure.
To get or receive data from the supply system, the con-
trolling PLC needs to:
1. Write to the Data Exchange Interface Pointer Output
Designation location on the map (output instance 6)
a value corresponding to the data the PLC wants to
receive.
2. Wait for the Therm-O-Flow to provide the same
Pointer Designation number written in the previous
step at input instance 67 (Data Exchange Interface
Pointer Last Serviced).
3. Read the requested data at input instance 68, Data
Exchange Interface Input Value.
To write or transmit data to the supply system, the con-
trolling PLC needs to:
1. Write the data for the Therm-O-Flow system to the
Data Exchange Interface Output Value location, out-
put instance 7.
2. Write to the Data Exchange Interface Pointer Output
Designation location on the map (output instance 6)
a value corresponding to the data the PLC is going
to transmit to the supply system.
3. The Therm-O-Flow system echoes back to the PLC
the Pointer Designation and the Data Interface
Value after the Therm-O-Flow system processes
the data transmit request to input instances 67 and
68 respectively.
When the controlling logic is exchanging data over this
interface, the Therm-O-Flow system sets the Data
Exchange Interface Active or in Transition status bit
while it processes the request and writes to the Data
Exchange Interface input locations (input instances 67
and 68).
After valid data is present at the input instances, the
Therm-O-Flow system clears the bit. While the bit is set,
the controlling PLC should ignore the interface inputs
until the bit is cleared. After the Therm-O-Flow system
services the request, the designation pointer input
matches the designation pointer output. If the scan rate
of the controlling PLC or control logic is slow enough,
monitoring of the status bit may not be necessary.
NOTE: When changes are made over the Data
Exchange Interface, the Therm-O-Flow system display
screen may not update immediately. It may be neces-
sary to navigate away from the screen, then back to it.

Appendix B - Data Exchange Interface
18 3A5186B
Data Exchange Interface Pointer Designation Tabl
Pointer
Designation
Description Comments Read/
Write
0 Interface Not Active
1 Set Temperature Units Value - Setting
0 - °F
1 - °C
Read
2 Read Temperature Units Write
3 Set Mass Units
Value - Setting (0 - g, 1 - kg, 2 - lb)
Write
4 Read Mass Units Read
5 Set Specific Gravity Specific gravity in thousandths (for instance a SG setting of
1.055 = 1055).
Write
6 Read Specific Gravity Read
7 Set High Temp. Alarm Offset
In whole selected C or F units of measure.
Write
8 Get High Temp. Alarm Offset Read
9 Set High Temp. Deviation Offset Write
10 Get High Temp. Deviation Offset Read
11 Set Low Temp. Alarm Offset Write
12 Get Low Temp. Alarm Offset Read
13 Set Low Temp. Deviation Offset Write
14 Get Low Temp. Deviation Offset Read
15 Set Prime Pump Duration
Prime pump duration setting in second increments
Write
16 Get Prime Pump Duration Read
17 Read System Version
A 32-bit string in the format of 0xXXCCBBAA.
0xCC…Build Version
0xBB…Minor Version
0xAA…Major Version
Read
18 Read System Date
A 32-bit string in the format of 0xXXDDCCBB.
0xDD…Year (0x0D corresponds to 2013)
0xCC…Month (0x0A corresponds to October)
0xBB…Day
Read
19 Read System Time
A 32-bit string in the format of 0xDDHHMMSS.
0xHH…Hours
0xMM…Minutes
0xSS…Seconds
0xDD...Day of week (0x01 corresponds to Monday)
Read
20 Read ADM Version
A 32-bit string in the format of 0xXXMMNNBB
0xMM...Major #
0xNN...Minor #
0xBB...Build #
21 - 90 Reserved for Future Use

Appendix B - Data Exchange Interface
3A5186B 19
Pointer
Designation
Description Comments Read/
Write
91 Read Pump A Resettable Mate-
rial counter In selected mass units, times 10. So, for instance, if in Kg mode,
101 = 10.1 Kg.
read
92 Read Pump B Resettable Mate-
rial counter read
93 Reset Pump A Resettable mate-
rial counter
No Data required for Data Exchange Interface Output Value
location (Same as pressing on the corresponding setup or
run screen).
Write
94 Reset Pump B Resettable mate-
rial counter Write
95 Read Pump A Resettable Cycle
counter In whole pump cycle units of measure.
read
96 Read Pump B Resettable Cycle
counter read
97 Reset Pump A Resettable Cycle
counter
No Data required for Data Exchange Interface Output Value
location (Same as pressing on the corresponding setup or
run screen).
Write
98 Reset Pump B Resettable Cycle
counter Write
99-100 Reserved for Future Use
101 Get Heat Soak Timer A Get Primary or Secondary Heat Soak timer Remaining Count in
Seconds (= 0 if not active)
Read
102 Get Heat Soak Timer B Read
103 -
110 Reserved for Future Use
111 Get CV Percent (5051 = 50.51%) Get Control Variable for Pump, Primary Heat Zone Read
112 Get CV Percent (5051 = 50.51%) Get Control Variable for Platen, Primary Heat Zone Read
113 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 1, Primary Read
114 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 2, Primary Read
115 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 3, Primary Read
116 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 4, Primary Read
117 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 5, Primary Read
118 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 6, Primary Read
119 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 7, Primary Read
120 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 8, Primary Read
121 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 9, Primary Read
122 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 10, Primary Read
123 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 11, Primary Read
124 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 12, Primary Read

Appendix B - Data Exchange Interface
20 3A5186B
Pointer Designation
Description Comments Read/
Write
125 Get CV Percent (5051 = 50.51%) Get Control Variable for Pump, Secondary Heat Zone Read
126 Get CV Percent (5051 = 50.51%) Get Control Variable for Platen, Secondary Heat Zone Read
127 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 1, Secondary Read
128 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 2, Secondary Read
129 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 3, Secondary Read
130 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 4, Secondary Read
131 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 5, Secondary Read
132 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 6, Secondary Read
133 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 7, Secondary Read
134 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 8, Secondary Read
135 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 9, Secondary Read
136 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 10, Secondary Read
137 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 11, Secondary Read
138 Get CV Percent (5051 = 50.51%) Get Control Variable for Heat Zone 12, Secondary Read
139 -
150 Reserved for Future Use
151 Get Pump A Setback Setpoint
Temperature
Provides the selected Primary System Zone Setback Mode set-
point temperature setting to the interface. Temperature Units
match units of the ADM. Values are in tenths of a degree (for
example, a value of 2505 corresponds to 250.5°F). These
pointer designations are typically used for PROFIBUS and
PROFINET applications.
Read
152 Get Platen A Setback Setpoint
Temperature Read
153 Get Zone 1, A Setback Setpoint
Temperature Read
154 Get Zone 2, A Setback Setpoint
Temperature Read
155 Get Zone 3, A Setback Setpoint
Temperature Read
156 Get Zone 4, A Setback Setpoint
Temperature Read
157 Get Zone 5, A Setback Setpoint
Temperature Read
158 Get Zone 6, A Setback Setpoint
Temperature Read
159 Get Zone 7, A Setback Setpoint
Temperature Read
160 Get Zone 8, A Setback Setpoint
Temperature Read
161 Get Zone 9, A Setback Setpoint
Temperature Read
162 Get Zone 10, A Setback Setpoint
Temperature Read
163 Get Zone 11, A Setback Setpoint
Temperature Read
164 Get Zone 12, A Setback Setpoint
Temperature Read
