Graco Reactor 2 E-30 Use and care manual

Repair-Parts
Reactor 2 E-30 and E-XP2
Proportioning System 333024A
EN
Electric, Heated, Plural Component Proportioning System. For spraying polyurethane foam and
polyurea coatings. For professional use only. Not approved for use in explosive atmospheres or
hazardous locations.
Important Safety Instructions. Read all warnings and instructions in
this manual. Save these instructions.
PROVEN QUALITY. LEADING TECHNOLOGY.

Contents
Warnings ........................................................... 3
Important Isocyanate Information......................... 7
Models............................................................... 9
Approvals........................................................... 11
Accessories........................................................ 11
Supplied Manuals ............................................... 12
Related Manuals ................................................ 12
Troubleshooting.................................................. 13
Troubleshoot Errors ..................................... 13
Pressure Relief Procedure .................................. 42
Shutdown........................................................... 43
Flushing............................................................. 45
Repair................................................................ 46
Before Beginning Repair............................... 46
Flush Inlet Strainer Screen ........................... 46
Change Pump Lubricant............................... 47
Remove Pump............................................. 48
Install Pump ................................................ 49
Repair Drive Housing ................................... 50
Repair Electric Motor.................................... 53
Repair Circuit Breaker Module ...................... 54
Replace Fluid Inlet Sensor............................ 55
Replace Pressure Transducers..................... 55
Replace Fans .............................................. 56
Repair Primary Heater.................................. 59
Repair Heated Hose..................................... 63
Repair Fluid Temperature Sensor
(FTS) ............................................. 64
Replace Power Supply ................................. 67
Replace Surge Protector .............................. 67
Replace Advanced Display Module
(ADM)............................................ 67
Replace Motor Control Module (MCM)........... 68
Replace Temperature Control Module
(TCM) ............................................ 68
Parts.................................................................. 69
Electrical Schematics.......................................... 89
Performance Charts............................................ 92
Technical Specifications...................................... 95
Graco Extended Warranty for Reactor® 2
Components ......................................... 97
2333024A

Warnings
Warnings
The following warnings are for the setup, use, grounding, maintenance and repair of this equipment. The
exclamation point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific
risks. When these symbols appear in the body of this manual refer back to these Warnings. Product-specific
hazard symbols and warnings not covered in this section may appear throughout the body of this manual
where applicable.
WARNING
ELECTRIC SHOCK HAZARD
This equipment must be grounded. Improper grounding, setup, or usage of the system can
cause electric shock.
• Turn off and disconnect power at main switch before disconnecting any cables and before
servicing or installing equipment.
• Connect only to grounded power source.
• All electrical wiring must be done by a qualified electrician and comply with all local codes
and regulations.
• Do not expose to rain. Store indoors.
TOXIC FLUID OR FUMES
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin,
inhaled, or swallowed.
• Read MSDSs to know the specific hazards of the fluids you are using.
•Storeh
azardous fluid in approved containers, and dispose of it according to applicable
guidelines.
• Always wear chemically impermeable gloves when spraying, dispensing, or cleaning
equipment.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury,
including eye injury, hearing loss, inhalation of toxic fumes, and burns. This protective
equipment includes but is not limited to:
•Prot
ective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent
manufacturer.
333024A 3

Warnings
WARNING
SKIN INJECTION HAZARD
High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin. This may
look like just a cut, but it is a serious injury that can result in amputation.Get immediate surgical
treatment.
•Donotsprayw
ithout tip guard and trigger guard installed.
• Engage trigger lock when not spraying.
• Do not point gun at anyone or at any part of the body.
• Do not put your hand over the spray tip.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow the Pressure Relief Procedure when you stop spraying and before cleaning, checking,
or servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses and couplings daily. Replace worn or damaged parts immediately.
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help
prevent fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and
plastic drop cloths (potential static arc).
• Keep work area free of debris, including solvent, rags and gasoline.
•Donotp
lug or unplug power cords, or turn power or light switches on or off when flammable
fumes are present.
• Ground all equipment in the work area. See Grounding instructions.
• Use only grounded hoses.
•Holdgu
n firmly to side of grounded pail when triggering into pail. Do not use pail liners unless
they are antistatic or conductive.
•Stop operation immediately if static sparking occurs or you feel a shock.Do not use
equipment until you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
THERMAL EXPANSION HAZARD
Fluids subjected to heat in confined spaces, including hoses, can create a rapid rise in pressure
due to the thermal expansion. Over-pressurization can result in equipment rupture and serious
injury.
• Open a valve to relieve the fluid expansion during heating.
• Replace hoses proactively at regular intervals based on your operating conditions.
4333024A

Warnings
WARNING
PRESSURIZED ALUMINUM PARTS HAZARD
Use of fluids that are incompatible with aluminum in pressurized equipment can cause serious
chemical reaction and equipment rupture. Failure to follow this warning can result in death,
serious injury, or property damage.
• Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon
solvents or fluids containing such solvents.
• Many other fluids may contain chemicals that can react with aluminum. Contact your material
supplier for compatibility.
PLASTIC PARTS CLEANING SOLVENT HAZARD
Many solvents can degrade plastic parts and cause them to fail, which could cause serious
injury or property damage.
• Use only compatible water-based solvents to clean plastic structural or pressure-containing
parts.
•SeeTechnical Data in this and all other equipment instruction manuals. Read fluid and
solvent manufacturer’s MSDSs and recommendations.
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated
system component. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data
in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete
information about your material, request MSDS from distributor or retailer.
• Do not leave the work area while equipment is energized or under pressure.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals
and create safety hazards.
• Make sure all equipment is rated and approved for the environment in which youareusingit.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
•Com
ply with all applicable safety regulations.
333024A 5

Warnings
WARNING
MOVING PARTS HAZARD
Moving parts can pinch, cut or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Pressurized equipment can start without warning. Before checking, moving, or servicing
equipment, follow the Pressure Relief Procedure and disconnect all power sources.
BURN HAZARD
Equipment surfaces and fluid that is heated can become very hot during operation. To avoid
severe burns:
• Do not touch hot fluid or equipment.
6333024A

Important Isocyanate Information
Important Isocyanate Information
Isocyanates (ISO) are catalysts used in two component materials.
Isocyanate Conditions
Spraying or dispensing materials containing
isocyanates creates potentially harmful mists,
vapors, and atomized particulates.
Read material manufacturer’s warnings and
material MSDS to know specific hazards and
precautions related to isocyanates.
Prevent inhalation of isocyanate mists, vapors,
and atomized particulates by providing sufficient
ventilation in the work area. If sufficient ventilation
is not available, a supplied-air respirator is required
for everyone in the work area.
To prevent contact with isocyanates, appropriate
personal protective equipment, including
chemically impermeable gloves, boots, aprons,
and goggles, is also required for everyone in the
work area.
Material Self-Ignition
Some materials may become self-igniting if applied
too thick. Read material manufacturer’s warnings
and material MSDS.
Keep Components A and B Separate
Cross-contamination can result in cured
material in fluid lines which could cause serious
injury or damage equipment. To prevent
cross-contamination:
•Never interchange component A and component
B wetted parts.
• Never use solvent on one side if it has been
contaminated from the other side.
Moisture Sensitivity of Isocyanates
Exposure to moisture (such as humidity) will cause
ISO to partially cure; forming small, hard, abrasive
crystals, which become suspended in the fluid.
Eventually a film will form on the surface and the ISO
will begin to gel, increasing in viscosity
NOTICE
Partially cured ISO will reduce performance and
the life of all wetted parts.
• Always use a sealed container with a desiccant
dryer in the vent, or a nitrogen atmosphere.
Never store ISO in an open container.
• Keep the ISO pump wet cup or reservoir (if
installed) filled with appropriate lubricant. The
lubricant creates a barrier between the ISO and
the atmosphere.
• Use only moisture-proof hoses compatible with
ISO.
• Never use reclaimed solvents, which may
contain moisture. Always keep solvent
containers closed when not in use.
• Always lubricate threaded parts with an
appropriate lubricant when reassembling.
333024A 7

Important Isocyanate Information
Foam Resins with 245 fa Blowing
Agents
Some foam blowing agents will froth at temperatures
above 90°F (33°C) when not under pressure,
especially if agitated. To reduce frothing, minimize
preheating in a circulation system.
Changing Materials
NOTICE
Changing the material types used in your
equipment requires special attention to avoid
equipment damage and downtime.
• When changing materials, flush the equipment
multiple times to ensure it is thoroughly clean.
• Always clean the fluid inlet strainers after
flushing.
•Checkwith
your material manufacturer for
chemical compatibility.
• When changing between epoxies and urethanes
or polyureas, disassemble and clean all fluid
components and change hoses. Epoxies often
have amines on the B (hardener) side. Polyureas
often have amines on the B (resin) side.
8333024A

Models
Models
Reactor 2 E-30 and E-30 Elite
All elite systems include fluid inlet pressure and temperature sensors, Graco InSite™, and Xtreme-Wrap 50 ft
(15 m) head hose. For part numbers, see Accessories, page 11
Base Model Elite Model
Model E-30, 10 kW E-30, 15 kW Elite, 10 kW Elite, 15kW
Proportioner ★ 272010 272011 272110 272111
Maximum Fluid Working
Pressure psi (MPa, bar)
2000 (14, 140) 2000 (14, 140) 2000 (14, 140) 2000 (14, 140)
Approximate Output per
Cycle (A+B) gal. (liter)
0.0272 (0.1034) 0.0272 (0.1034) 0.0272 (0.1034) 0.0272 (0.1034)
Max Flow Rate lb/min
(kg/min)
30 (13.5) 30 (13.5) 30 (13.5) 30 (13.5)
Total System Load †
(Watts)
17,900 23,000 17,900 23,000
Configurable Voltage
Phase
230
1Ø
230
3Ø∆
380
3ØY
230
1Ø
230
3Ø∆
380
3ØY
230
1Ø
230
3Ø∆
380
3ØY
230
1Ø
230
3Ø∆
380
3ØY
Full Load Peak Current* 78 50 34 100 62 35 78 50 34 100 62 35
Base Machine 272010 272110 272011 272111
Heated Hose
50 ft (15 m)
24K240 (scuff
guard)
24K240 (scuff
guard)
24Y240 (Xtreme-
Wrap)
24Y240 (Xtreme-
Wrap)
Heated Whip Hose
10 ft (3 m)
246050 246050 246050 246050
Fusion AP Package
(Gun Part No.)
AP2010
(246102)
AP2011
(246102)
AP2110
(246102)
AP2111
(246102)
Fusion CS Package
(Gun Part No.)
CS2010
(CS02RD)
CS2011
(CS02RD)
CS2110
(CS02RD)
CS2111
(CS02RD)
Probler P2 Package
(Gun Part No.)
P22010
(GCP2R2)
P22011
(GCP2R2)
P22110
(GCP2R2)
P22111
(GCP2R2)
Graco InSite™✓✓
Fluid Inlet Sensors (2) ✓✓
*Full load amps with all devices operating at
maximum capabilities. Fuse requirements at
various flow rates and mix chamber sizes
may be less.
Total system watts used by system, based on
maximum heated hose length for each unit.
•E–
30 and E–XP2 series: 310 ft (94.5 m)
maximum heated hose length, including
whip hose.
★See Approvals, page 11.
333024A 9

Models
Reactor 2 E-XP2 and E-XP2 Elite
All elite systems include fluid inlet pressure and temperature sensors, Graco InSite™, and Xtreme-Wrap 50 ft
(15 m) head hose. For part numbers, see Accessories, page 11
Base Model Elite Model
Model
E–XP2, 15 kW E–XP2, 15 kW
Proportioner★272012 272112
Maximum Fluid Working
Pressure psi (MPa, bar)
3500 (24.1, 241) 3500 (24.1, 241)
Approximate Output per
Cycle (A+B) gal. (liter)
0.0203 (0.0771) 0.0203 (0.0771)
Max Flow Rate gpm/min
(l/min)
2 (7.6) 2 (7.6)
Total System Load †
(Watts)
23,000 23,000
Configurable Voltage
Phase
230 1Ø 230 3Ø∆ 380 3ØY 230 1Ø 230 3Ø∆ 380 3ØY
Full Load Peak Current
(amps)*
100 62 35 100 62 35
Fusion AP Package
(Gun Part No.)
AP2012
(246101)
AP2112
(246101)
Probler P2 Package
(Gun Part No.)
P22012
(GCP2R1)
P22112
(GCP2R1)
Heated Hose
50 ft (15 m)
24K241
(scuff guard)
24Y241
(Xtreme-Wrap)
Heated Whip Hose
10 ft (3 m)
246050 246050
GracoInSite
™✓
Fluid Inlet Sensors (2) ✓
*Full load amps with all devices operating at
maximum capabilities. Fuse requirements
at various flow rates and mix chamber sizes
may be less.
Total system watts used by system, based on
maximum heated hose length for each unit.
• E–30 and E–XP2 series: 310 ft (94.5 m)
maximum heated hose length, including
whip hose.
★SeeApprovals, page 11.
10 333024A

Approvals
Approvals
Intertek approvals apply to proportioners without
hoses.
Proportioner Approvals:
9902471
Conforms to ANSI/UL Std. 499
Certified to CAN/CSA Std. C22.2 No. 88
Note
Heated hoses provided with a system or sold
individually are not approved by Intertek.
Accessories
Kit Number Description
24N449 50 ft (15 m) CAN cable (for remote
display module)
24K207 Fluid Temperature Sensor (FTS)
with RTD
24U174 Remote Display Module Kit
24K337 Light Tower Kit
15V551 ADM Protective Covers (10 pack)
15M483 Remote Display Module Protective
Covers (10 pack)
24M174 Drum Level Sticks
121006 150 ft (45m)CANcable(forremote
display module)
24N365 RTD Test Cables (to aide resistance
measurements)
24U315 Air Manifold Kit (4 outlets)
24U314 Wheel and Handle Kit
24T280Graco InSite Kit
16X521 Graco InSite Extension cable 24.6 ft
(7.5 m)
333024A 11

Supplied Manuals
Supplied Manuals
The following manuals are shipped with the Reactor
2. Refer to these manuals for detailed equipment
information.
Manuals are also available at www.graco.com.
Manual Description
333023 Reactor 2 E-30 and E-XP2
Operation
333091 Reactor 2 E-30 and E-XP2 Startup
Quick Guide
333092 Reactor 2 E-30 and E-XP2
Shutdown Quick Guide
Related Manuals
The following manuals are for accessories used with
the Reactor.
Component Manuals in English:
Manuals are available at www.graco.com.
System Manuals
333023 Reactor 2 E-30 and E-XP2 Operation
Displacement Pump Manual
309577 Electric Reactor Displacement Pump,
Repair-Parts
Feed System Manuals
309572 Heated Hose, Instructions-Parts
309852 Circulation and Return Tube Kit,
Instructions-Parts
309815 Feed Pump Kits, Instructions-Parts
309827 Feed Pump Air Supply Kit,
Instructions-Parts
Spray Gun Manuals
309550 Fusion ™ AP Gun
312666 Fusion ™ CS Gun
313213 Probler®P2 Gun
Accessory Manuals
3A1906 Light Tower Kit, Instructions-Parts
3A1907 Remote Display Module Kit,
Instructions-Parts
332735 Air Manifold Kit, Instructions-Parts
332736 Handle and Wheel Kit,
Instructions-Parts
333276 Graco InSite ™ Kit, Instructions-Parts
12333024A

Troubleshooting
Troubleshooting
Troubleshoot Errors
There are three types of errors that can occur. Errors
are indicated on the display as well as by the light
tower (optional).
Error Description
Alarms A parameter critical to
the process has reached
a level requiring the
system to stop. The
alarm needs to be
addressed immediately.
Deviations A parameter critical
to the process has
reached a level requiring
attention, but not
sufficient enough to
stop the system at this
time.
Advisories A parameter that is
not immediately critical
to the process. The
advisory needs attention
to prevent more serious
issues in the future.
See Error Codes, page 14 for causes and solutions
to each error code.
To troubleshoot the error:
1. Press the soft key for help with the active error.
Note
Press or to return to the
previously displayed screen.
2. The QR code screen will be displayed. Scan
the QR code with your smartphone to be sent
directly to online troubleshooting for the active
error code. Otherwise, manually navigate to
http://help.graco.com and search for the active
error.
3. If no internet connection is available, see
Error Codes, page 14 for causes and solutions
for each error code.
333024A 13

Troubleshooting
Error Codes
Note
When an error occurs be sure to determine the code before resetting it. If you forget which error code
occurred, see the Errors screen to view the last 200 errors, with date, time, and description.
Error Location Type Description Cause Solution
Loose/broken
connection.
Check for loose wire
terminations at MCM motor
connector.
A1NM MCM Low Motor Current
Bad Motor. Disconnect motor output
connector from MCM.
Confirm less than 8 ohms
resistance between each
pair of motor power leads
(M1 to M2, M1 to M3, M2 to
M3). If any readings greater
than 8 ohms, check motor
wiring for damage and/or
loose terminations.
Short circuit in
heater wiring.
Check wiring for touching
wires.
A4DA Heater A High Current A
Bad Heater. Confirm resistance of
heater. Heater resistance
should be 18–21 Ω for
each heater element, 9–12
Ω combined for 10 kW
systems, and 6-8 Ω for
15 kW systems. If out of
tolerance, replace heater
element.
Short circuit in
heater wiring.
Check wiring for touching
wires.
A4DB Heater B High Current B
Bad Heater. Confirm resistance of
heater. Heater resistance
should be 9-12 Ω for 10
kW systems and 6-8 Ω for
15 kW systems. If out of
tolerance, replace heater.
Check continuity of
transformer windings.
Normal readings are about
0.2Ω on both primary and
secondary. If reading is 0Ω
replace transformer.
A4DH Hose High Current Hose Short circuit in
hose wiring.
Check for shorts between
the primary winding and the
support frame or enclosure.
14333024A

Troubleshooting
Error Location Type Description Cause Solution
Short circuit of
motor wiring.
Check wiring tothemotor
to ensure no bare wires are
touching and that no wires
areshortedtoground.
Motor will not
rotate.
Remove pump gear
housings from motor
and check that motor shaft
rotates freely in direction
indicated on motor housing.
Damaged gear
train.
Check pump gear trains
for damage and repair or
replace as necessary.
A4NM MCM High Motor Current
Chemical pump is
stuck.
Repair or replace chemical
pump.
A7DA Heater A Unexpected Current
A
Shorted TCM If error cannot be cleared
or regenerates consistently,
replace module.
A7DB Heater B Unexpected Current
B
ShortedTCM If error cannot be cleared
or regenerates consistently,
replace module.
A7DH Hose Unexpected Current
Hose
Shorted TCM If error cannot be cleared
or regenerates consistently,
replace module.
333024A 15

Troubleshooting
Error Location Type Description Cause Solution
Tripped circuit
breaker.
Visually check circuit
breaker for a tripped
condition.
A8DA Heater A No Current A
Loose/broken
connection.
Check heater wiring for
loose wires.
Tripped circuit
breaker.
Visually check circuit
breaker for a tripped
condition.
A8DB Heater B No Current B
Loose/broken
connection.
Check heater wiring for
loose wires.
Tripped circuit
breaker.
Visually check circuit
breaker for a tripped
condition.
A8DH Hose No Current Hose
Loose/broken
connection.
Check heater wiring for
loose wires.
Module does not
have software.
Insert a system token into
theADMmoduleandcycle
the power. Wait until the
upload is complete before
removing the token.
Dial settowrong
position.
Ensure the MCM dial is set
to the correct position: 2 for
E-30, 3 for E-XP2
No 24 VDC supply
to module.
Green light on each module
should be lit. If green light is
not lit, check to make sure
each CAN cable connection
is tight. Verify the power
supply is outputting 24
VDC. If not, check power
supply wiring. If wiring is
okay, replace the power
supply.
CACM MCM MCM Communica-
tion Error
Loose or broken
CAN cable.
Check the CAN cables
running between GCA
modules and tighten of
needed. If the problem
still persists move each
cable around the connector
and watch the flashing
yellow light on the GCA
modules. If the yellow light
stops flashing, replace the
CAN cable.
16 333024A

Troubleshooting
Error Location Type Description Cause Solution
Module does not
have software.
Insert a system token into
the ADM module and cycle
the power. Wait until the
upload is complete before
removing the token.
No 24 VDC supply
to module.
Green light on each module
should be lit. If green light is
not lit, check to make sure
each CAN cable connection
is tight. Verify the power
supply is outputting 24
VDC. If not, check power
supply wiring. If wiring is
okay, replace the power
supply.
CACT TCM TCM Communication
Error
Loose or broken
CAN cable.
Check the CAN cables
running between GCA
modules and tighten of
needed. If the problem
still persists move each
cable around the connector
and watch the flashing
yellow light on the GCA
modules. If the yellow light
stops flashing, replace the
CAN cable.
Mix chamber too large for
system selected. Use mix
chamber rated for system.
Ensure the system has
chemical and the feed
pumps are operating
correctly.
No material in pumps.
Verify pumps are supplying
chemical. If necessary,
replace or refill drums.
DADX MCM Pump Runaway Flow rate is too
large.
Inlet ball valves are closed.
Open ball valves.
Faulty or missing
cycle switch.
Check wiring between cycle
switch and MCM.
DE0X MCM CycleSwitchError
Missing or out of
place cycle switch
magnet.
Check presence and
position of cycle switch
magnet on output crank
arm.
333024A 17

Troubleshooting
Error Location Type Description Cause Solution
EVCH ADM Manual Hose Mode
Enabled
Manual hose mode
has been enabled
in System Setup
screen.
Install a functioning fluid
temperature sensor (FTS)
on the hose. Manual hose
mode will automatically turn
off.
EAUX ADM USB Busy USB drive has
been inserted to
the ADM.
Do not remove USB drive
until download/upload is
complete.
EVUX ADM USB disabled USB
download/uploads
are disabled.
Enable USB download/up-
loads on the Advanced
Setup screen before insert-
ing a USB drive.
F9DX MCM High Pressure/Flow
Cutback
Mix chamber is
too large for set
pressure.
Reference the pressure
flow curves and select a tip
size that is the correct size
for the set pressure.
H2MA Heater A Low Frequency A Line frequency is
below 45 Hz
Ensure line frequency of
incoming power is between
45 and 65 Hz.
H2MB Heater BLow Frequency B Line frequency is
below 45 Hz
Ensure line frequency of
incoming power is between
45 and 65 Hz.
H2MH Hose Low Frequency Hose Line frequency is
below 45 Hz
Ensure line frequency of
incoming power is between
45 and65Hz.
H3MA Heater A High Frequency A Line frequency is
above 65 Hz
Ensure line frequency of
incoming power is between
45 and 65 Hz.
H3MBHeater B High Frequency B Line frequency is
above 65 Hz
Ensure line frequency of
incoming power is between
45 and 65 Hz.
H3MH Hose High Frequency
Hose
Line frequency is
above65Hz
Ensure line frequency of
incoming power is between
45 and 65 Hz.
Motor will not
rotate.
Remove pump gear
housings from motor
and check that motor shaft
rotates freely in direction
indicated on motor housing.
Damaged gear
train.
Check motor/pump gear
trains for damage and repair
or replace as necessary.
K8NM MCM Locked Rotor Motor
Chemical pump is
stuck.
Repair or replace chemical
pump.
18 333024A

Troubleshooting
Error Location Type Description Cause Solution
L1AX ADM Low Chemical Level
A
Low material level. Refill material and update
drum level on ADM
Maintenance screen.
Alarm can be disabled on
the System Setup screen.
L1BX ADM Low Chemical Level
B
Low material level. Refill material and update
drum level on ADM
Maintenance screen.
Alarm can be disabled on
the System Setup screen.
MMUX USB Maintenance Due -
USB
USB logs have
reached a level
where data loss
will occur if logs are
not downloaded.
InsertaUSBdriveintothe
ADM and download all logs.
Pressure
difference between
A and B material
is greater than the
defined value.
Ensure material flow is
equally restricted on both
material lines.
Pressure
imbalance is
defined too low.
Ensure that the pressure
imbalance value, on the
System Setup screen, is at
an acceptable maximum
pressure to prevent
unnecessary alarms and
abort dispenses.
Out of material. Fill tanks with material
Fluid leaking from
heater inlet rupture
disk.
Check if heater
and PRESSURE
RELIEF/SPRAY valve are
plugged. Clear. Replace
rupture disk. Do not replace
withapipeplug.
P0AX MCM Pressure Imbalance
AHigh
Feed system
defective.
Check feed pump and
hoses for blockage. Check
that feed pumps have
correct air pressure.
333024A 19

Troubleshooting
Error Location Type Description Cause Solution
Pressure
difference between
A and B material
is greater than the
defined value.
Ensure material flow is
equally restrictedonboth
material lines.
Pressure
imbalance is
defined too low.
Ensure that the pressure
imbalance value, on the
System Setup screen, is at
an acceptable maximum
pressure to prevent
unnecessaryalarmsand
abort dispenses.
Out of material. Fill tanks with material
Fluid leaking from
heater inlet rupture
disk.
Check if heater
and PRESSURE
RELIEF/SPRAY valve are
plugged. Clear. Replace
rupture disk. Do not replace
withapipeplug.
P0BX MCM Pressure Imbalance
BHigh
Feed system
defective.
Check feed pump and
hoses for blockage. Check
that feed pumps have
correctairpressure.
Inlet pressure
lower than defined
value.
Ensure that inlet pressure
to the pump is sufficient.
P1FA MCM Low Inlet Pressure A
Value defined too
high.
Ensure that the low
pressure alarm level
defined on the System
Setup screen is acceptable.
Inletpressure
lower than defined
value.
Ensure that inlet pressure
to the pump is sufficient.
P1FB MCM Low Inlet Pressure B
Value defined too
high.
Ensure that the low
pressure alarm level
defined on the System
Setup screen is acceptable.
Inlet pressure
lower than defined
value.
Ensure that inlet pressure
to the pump is sufficient.
P2FA MCMLow Inlet Pressure A
Value defined too
high.
Ensure that the low
pressure alarm level
defined on the System
Setup screen is acceptable.
20 333024A
