Graco 17B484 Instruction Manual

332156E
EN
Operation
GH™ Series Big Rig Sprayers
Use with Architectural Coatings, Paints, Roof Coatings and Below Grade Coatings. Not
approved for use in explosive atmospheres or hazardous (classified) locations. For
professional use only.
Related Manuals:
Model Description Maximum Working Pressure
16U277 / 16U277V GH1017es Bare / Vanguard 1000 psi (6.9 MPa, 69 bar)
16U278 / 16U278V GH2570es Bare / Vanguard 2500 psi (17.2 MPa, 172 bar)
16U279 / 16U279V GH733es Bare / Vanguard 4000 psi (27.6 MPa, 276 bar)
16U280 / 16U280V GH5040es Bare / Vanguard 5000 psi (34.5 MPa, 345 bar)
16U285 / 16U285V GH933es Bare / Vanguard 7250 psi (50.0 MPa, 500 bar)
16U281 / 16U281V GH933 Bare / Vanguard 7250 psi (50.0 MPa, 500 bar)
17B484 / 17B484V GH933es Bare / Vanguard 7250 psi (50.0 MPa, 500 bar)
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
311254
312145
332157
332158
308043
311825
311762
ti20726a

2 332156E
Contents
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Component Identification . . . . . . . . . . . . . . . . . . . . 5
Lift Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Pressure Relief Procedure . . . . . . . . . . . . . . . . . . . 7
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
SwitchTip and Guard Assembly . . . . . . . . . . . . 11
Clearing Tip Clogs . . . . . . . . . . . . . . . . . . . . . . . 11
Spraying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cleanup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Additional EAC Information . . . . . . . . . . . . . . . . . 22
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 23

Warnings
332156E 3
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When
these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific
hazard symbols and warnings not covered in this section may appear throughout the body of this manual where
applicable.
WARNINGWARNINGWARNING
WARNING
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. Paint or solvent
flowing through the equipment can cause static sparking. To help prevent fire and explosion:
• Use equipment only in well-ventilated area.
• Do not fill fuel tank while engine is running or hot; shut off engine and let it cool. Fuel is flammable and
can ignite or explode if spilled on hot surface.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop
cloths (potential static sparking).
• Ground all equipment in the work area. See Grounding instructions.
• Never spray or flush solvent at high pressure.
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes
are present.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail. Do not use pail liners unless they are
anti-static or conductive.
•Stop operation immediately if static sparking occurs or you feel a shock. Do not use equipment until
you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
SKIN INJECTION HAZARD
High-pressure spray is able to inject toxins into the body and cause serious bodily injury. In the event
that injection occurs, get immediate surgical treatment.
• Do not aim the gun at, or spray any person or animal.
• Keep hands and other body parts away from the discharge. For example, do not try to stop leaks
with any part of the body.
• Always use the nozzle tip guard. Do not spray without nozzle tip guard in place.
• Use Graco nozzle tips.
• Use caution when cleaning and changing nozzle tips. In the case where the nozzle tip clogs while
spraying, follow the Pressure Relief Procedure for turning off the unit and relieving the pressure
before removing the nozzle tip to clean.
• Do not leave the unit energized or under pressure while unattended. When the unit is not in use, turn
off the unit and follow the Pressure Relief Procedure for turning off the unit.
• Check hoses and parts for signs of damage. Replace any damaged hoses or parts.
• This system is capable of producing 7250 psi (50.0 MPa, 500 bar). Use Graco replacement parts or
accessories that are rated a minimum of 7250 psi (50.0 MPa, 500 bar).
• Always engage the trigger lock when not spraying. Verify the trigger lock is functioning properly.
• Verify that all connections are secure before operating the unit.
• Know how to stop the unit and bleed pressure quickly. Be thoroughly familiar with the controls.

Warnings
4 332156E
MOVING PARTS HAZARD
Moving parts can pinch, cut or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Pressurized equipment can start without warning. Before checking, moving, or servicing equipment,
follow the Pressure Relief Procedure and disconnect all power sources.
SUCTION HAZARD
Powerful suction could cause serious injury.
• Never place hands near the pump fluid inlet when pump is operating or pressurized.
CARBON MONOXIDE HAZARD
Exhaust contains poisonous carbon monoxide, which is colorless and odorless. Breathing carbon
monoxide can cause death.
• Do not operate in an enclosed area.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read MSDSs to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
BATTERY SAFETY
The battery may leak, explode, cause burns, or cause an explosion if mishandled.
• Only use the battery type specified for use with the equipment. See Technical Data.
• Battery maintenance must only be performed or supervised by personnel knowledgeable of
batteries and the required precautions. Keep unauthorized personnel away from battery.
• Do not dispose of battery in fire. The battery is capable of exploding.
• Follow local ordinances and/or regulations for disposal.
• Do not open or mutilate the battery. Released electrolyte has been known to be harmful to the skin
and eyes and to be toxic.
• Remove watches, rings, or other metal objects.
• Only use tools with insulated handles. Do not lay tools or metal parts on top of battery.
BURN HAZARD
Equipment surfaces and fluids that are heated can become very hot during operation. To avoid severe
burns:
• Do not touch hot fluid or equipment.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. This protective equipment includes but is
not limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.
CALIFORNIA PROPOSITION 65
The engine exhaust from this product contains a chemical known to the State of California to cause
cancer, birth defects or other reproductive harm.
This product contains a chemical known to the State of California to cause cancer, birth defects or other
reproductive harm. Wash hands after handling.
WARNINGWARNINGWARNING
WARNING

Component Identification
332156E 5
Component Identification
1 Engine Controls
2 Ignition
3 Engine ON/OFF Switch (Pull-Start units)
4 Lift Location
5 Suction Tube Holder
6 Pressure Control
7 Lock Ring
8 Serial Number ID Label
9 Hydraulic Pump Valve
10 Hydraulic Oil Fill
11 Pressure Bleed Valve, T handle
12 Trigger Lock

Lift Instructions
6 332156E
Lift Instructions
1. When lifting sprayer, balance weight evenly across
two straps/chains as shown.
2. Wrap each strap/chain securely around frame
where indicated on frame label as shown.
3. Be sure straps/chains used for lifting are rated to
support weight of sprayer: 500 lbs (227 kg).
4. Do not lift unit with only one strap secured across
pump. This could put stress on frame and damage
pump.
To avoid injury, always use designated Lift Locations
when lifting the unit. When lifting the unit, only use
ANSI approved slings and equipment rated for a
minimum of 500 lb (227 kg). Always use ANSI
approved equipment for securing the unit to
transporting equipment.
ti7840a
ti7855a
ti7838a

Pressure Relief Procedure
332156E 7
Pressure Relief Procedure
Follow the Pressure Relief Procedure whenever
you see this symbol.
1. Set pump valve OFF.
2. Turn engine OFF.
3. Loosen Lock Ring. Turn pressure control to lowest
setting. Trigger gun into pail to relieve pressure.
4. Rotate handle counter-clockwise to open prime
valve.
Grounding
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury
from pressurized fluid, such as skin injection,
splashing fluid and moving parts, follow the Pressure
Relief Procedure when you stop spraying and before
cleaning, checking, or servicing the equipment.
ti7108a
ti7111b
Ground sprayer with grounding clamp to earth ground.
ti7120b ti21061a

Setup
8 332156E
Setup
1. Connect appropriate Graco high-pressure hose to
sprayer. Tighten securely.
NOTE: Remove second gun port plug for multiple
guns and repeat steps 1 - 4.
2. Connect other end of hose to gun and tighten fit-
tings securely.
3. Remove tip guard.
4. Install clean inlet strainer.
5. Fill throat packing nut with TSL to prevent prema-
ture packing wear. Do this each time you spray and
store.
6. Check engine oil level. Add SAE 10W-30 (summer)
or 5W-20 (winter), if necessary.
7. Fill fuel tank.
8. Check hydraulic oil level, Component ID, page 5.
Add only Graco Hydraulic Oil, ISO 46 169236 (5
gallon/18.9 liter) or 207428 (1 gallon/3.8 liter).
Hydraulic tank capacity is approximately 4.0 gallons
(15.14 liters).
9. Verify all hose/fitting connections are tight.
10. Attach sprayer grounding clamp to earth ground to
prevent static charge build-up that may result in fire.
ti7112b
ti7130b
ti7122b
ti5239a
Approximate
Fill Level
ti5240a
(cold)
ti5241a
ti5242a
Safe Range (cold)
ti5243a
ti20971a
ti7525a

Startup
332156E 9
Startup
1. Place suction tube and drain tube in grounded metal
pail partially filled with flushing fluid. Attach ground
wire to pail and to ground wire to earth ground.
2. Rotate handle counter-clockwise to open prime
valve.
3. Loosen lock nut and turn pressure control counter-
clockwise to lowest pressure.
4. Set pump valve OFF.
5. Start engine.
a. Move fuel valve to open.
b. Move choke to closed.
c. Set throttle to fast.
d. For electric start models: Rotate key to start.
For pull-start models: Set engine switch to
ON. Pull starter rope or turn ignition key.
Hydraulic system and engine may become very hot
during operation and could burn skin if touched.
Flammable materials spilled on hot, bare motor could
cause fire or explosion. Have belt guard in place
during operation to reduce risk of pinching or loss of
fingers.
ti7120b
ti21061a
ti7111b
ti7108a

Startup
10 332156E
e. After engine starts, move choke to open.
f. Set throttle to desired setting.
6. Set pump valve ON (hydraulic motor is now active).
7. Increase pressure enough to start hydraulic motor
stroking and allow fluid to circulate for 15 seconds;
turn pressure down.
8. Close prime valve by rotating handle clockwise.
9. Take spray gun trigger safety OFF.
10. Hold gun against grounded metal flushing pail.
Trigger gun and increase fluid pressure slowly
until pump runs smoothly.
11. Inspect fittings for leaks. Do not stop leaks with your
hand or a rag! If leaks occur, turn sprayer OFF
immediately. Relieve pressure, page 7. Tighten
leaky fittings. Repeat Startup, steps 1 - 5. If no
leaks, continue to trigger gun until system is
thoroughly flushed. Proceed to step 6.
12. Place siphon tube in paint pail.
13. Trigger gun again into flushing fluid pail until paint
appears. Assemble tip and guard, page 11.
ti7108a
ti7110c
ti7129b ti21060a
ti5403a
ti21143a
ti20730a ti7110c
ti7125a
ti20730a

Startup
332156E 11
SwitchTip and Guard Assembly
1. Insert SwitchTip. Insert seat and OneSeal.
NOTE: Before screwing tip and guard assembly on
gun, perform Pressure Relief Procedure, page 7,
and be sure gun trigger safety is ON.
2. Screw assembly onto gun. Hand tighten.
Clearing Tip Clogs
1. Release trigger, put trigger safety ON. Rotate
SwitchTip. Take trigger safety OFF and trigger
gun to clear the clog.
2. Put trigger safety ON, return SwitchTip to original
position, take trigger safety OFF and continue
spraying.
3. If you suspect the spray tip or hose is clogged or
that pressure has not been fully relieved after follow-
ing the steps above, VERY SLOWLY loosen tip
guard retaining nut or hose end coupling to relieve
pressure gradually, then loosen completely. Clear
hose or tip obstruction.
ti5257ba
ti21142a
ti5402a
ti20728a

Spraying
12 332156E
Spraying
1. Set pump valve ON.
2. Increase pressure enough to start hydraulic motor
stroking and allow fluid to circulate for 15 seconds;
turn pressure down.
3. Turn spray gun trigger safety OFF.
4. Adjust pressure to desired setting. Begin spraying.
5. Rotate Lock Ring clockwise to set pressure.
ti7108a
ti7110c
ti5403a
ti21143a
ti7110c ti21062a
ti20968a

Cleanup
332156E 13
Cleanup
1. Perform Pressure Relief Procedure, page 7.
2. Remove guard and SwitchTip.
3. GH933 units only: Unscrew bowl, remove filter.
Assemble without filter.
4. Clean filter, guard and SwitchTip in flushing fluid.
5. Remove siphon tube set from paint and place in
flushing fluid. Use water for water base paint and
mineral spirits for oil base paint.
6. Turn engine ON and start engine.
7. Set pump valve ON. Rotate handle clockwise to
close prime valve.
8. Hold gun against paint pail. Take trigger safety OFF.
Turn pressure control up until motor begins to drive
pump.
9. Trigger gun until flushing fluid appears.
10. Move gun to flushing pail, hold gun against pail, trig-
ger gun to thoroughly flush system. Release trigger
and put trigger safety ON.
11. Rotate handle counter-clockwise to open prime
valve and allow flushing fluid to circulate for
approximately 20 seconds to clean drain tube.
ti7122b
ti20969a
ti5268a
ti7121b
ti21060a
ti7129b
ti7108a
ti20730a ti7110c
ti20730a
ti7120b ti21061a

Cleanup
14 332156E
12. Raise siphon tube above flushing fluid and run
sprayer for 15 to 30 seconds to drain fluid.
13. Turn pump valve OFF. Turn engine OFF.
Caution: If flushing with water, do not leave water in
sprayer. Flush again with mineral spirits, oil or Pump
Armor and leave this protective coating in the sprayer to
help prevent freezing or corrosion and increase sprayer
life.
14. Rotate handle clockwise to close prime valve. Trig-
ger gun into flushing pail to purge fluid from hose.
15. Rotate handle counter-clockwise to open prime
valve.
16. If pump includes filter, install filter into filter bowl.
Make sure plastic center tube is tightened securely.
Hand tighten filter bowl. Hand tighten gun handle.
17. Clean tip, guard and gasket with a soft bristle brush
to prevent part failure due to dried materials.
Assemble parts and attach loosely onto gun. Wipe
sprayer, hose and gun with a rag soaked in water or
mineral spirits.
ti20729a
ti7108a
Pump Armor
ti2895a
ti21060a
ti7129b
ti20730a
ti21061a
ti7120b
ti20790a
ti5276a
Artfile #: ti5276a
Description: GH 200 230 300 330 OPERATION 233940 248559-64
Scale: -
Artist: J. Iverson

Troubleshooting
332156E 15
Troubleshooting
PROBLEM CAUSE SOLUTION
Gas engine pulls hard (will not start). Hydraulic pressure is too high. Turn hydraulic pressure knob
counterclockwise to lowest setting.
Gas engine does not start. Switch OFF, low oil, no gasoline, or
dead battery.
Consult engine manual, supplied.
Replace battery if necessary.
Gas engine doesn't work properly. Faulty engine. Consult engine manual, supplied.
Gas engine operates, but
displacement pump doesn't operate.
Pump valve is OFF. Set pump valve ON.
Pressure setting too low. Increase pressure.
Displacement pump outlet filter
(if used) is dirty or clogged.
Clean the filter.
Tip or tip filter (if used) is clogged. Remove tip and/or filter and clean.
Hydraulic fluid too low. Shut off sprayer. Add fluid*
Belt worn, broken or off. Replace. See manual 332157.
Hydraulic pump worn or damaged. Bring sprayer to Graco distributor for
repair.
Dried paint seized paint pump rod. Service pump. See manuals 308043,
311825, 311762.
Hydraulic motor not shifting. Set pump valve OFF. Turn pressure
down. Turn engine OFF. Pry rod up
or down until hydraulic motor shifts.
See manual 332157.
Displacement pump operates, but
output is low on upstroke.
Piston ball check not seating
properly.
Service piston ball check.
See manual 308043, 311825,
311762.
Piston packings worn or damaged. Replace packings. See manuals
308043, 311825, 311762.
Displacement pump operates but
output is low on downstroke and/or
on both strokes.
Piston packings worn or damaged. Tighten packing nut or replace
packings. See manuals 308043,
311825, 311762.
Intake valve ball check not seating
properly.
Service intake valve ball check.
See manuals 308043, 311825,
311762.
Suction tube air leak. Repair or replace suction tube.
Paint leaks and runs over side of
wetcup.
Loose wet-cup. Tighten wet-cup enough to stop
leakage.
Throat packings worn or damaged. Replace packings.
See manuals 308043, 311825,
311762.
Excessive leakage around hydraulic
motor piston rod wiper.
Piston rod seal worn or damaged. Replace these parts.
See manuals 308043, 311825,
311762.

Troubleshooting
16 332156E
Fluid delivery is low. Pressure setting too low Increase pressure, page 4
Displacement pump outlet filter (if
used) is dirty or clogged
Clean filter
Intake line to pump inlet is not tight Tighten intake line
Hydraulic motor is worn or damaged Bring sprayer to Graco distributor
for repair
Large pressure drop in fluid hose. Use larger diameter or shorter hose.
The sprayer overheats Paint buildup on hydraulic
components
Clean
Oil level is low Fill with oil.
Spitting from gun Air in fluid pump or hose Check for loose connections on
siphon assembly, tighten, then
reprime pump
Loose intake suction Tighten
Fluid supply is low or empty Refill supply container
Excessive hydraulic pump noise Low hydraulic fluid level Turn sprayer OFF. Add fluid*
*Check hydraulic fluid level often. Do not allow it to become too low. Use only Graco approved hydraulic fluid, page 8.
PROBLEM CAUSE SOLUTION

Technical Data
332156E 17
Technical Data
GH733ES
US Metric
Sprayer
Hydraulic Pressure 2750 psi 190 bar
Hydraulic Reservoir Capacity 4.0 gallons 15.1 liters
Honda Motor 13 HP 9.7 KW
Vanguard Motor 14 HP 10.4 KW
Maximum Delivery 4.0 gpm 15.1 lpm
Maximum Pressure 4000 psi 276 bar
Maximum Tip Size
• 1 gun .065 in. 1.65 mm
• 2 guns .046 in. 1.16 mm
• 3 guns .037 in. 0.93 mm
• 4 guns .032 in. 0.81 mm
• 5 guns .029 in. 0.71 mm
• 6 guns .026 in. 0.66 mm
Fluid Inlet 1.25 in. npt(m) 3.2 cm npt(f)
Fluid Outlet (with fitting as shipped) 0.75 in. nps(f) swivel 1.9 cm npsm
Fluid Outlet Pump 1.0 in. npt(f) 2.5 cm npt(f)
Dimensions
Weight 434 lb 197 kg
Height 49 in. 124 cm
Width 28 in. 71 cm
Length 43 in. 109 cm
Sounds Levels*
Sound Pressure 91 dB(A)
Sound Power 106 dB(A)
*measured at maximum normal load conditions
Wetted Parts
Displacement Pump steel, nitralloy, tungsten, carbide, PTFE, leather,
polyethylene
Miscellaneous
Graco-Approved Hydraulic Oil
169236 5 gallons 19 liters
207428 1 gallon 3.8 liters

Technical Data
18 332156E
GH5040ES
US Metric
Sprayer
Hydraulic Pressure 2750 psi 190 bar
Hydraulic Reservoir Capacity 4.0 gallons 15.1 liters
Honda Motor 13 HP 9.7 KW
Vanguard Motor 14 HP 10.4 KW
Maximum Delivery 3.5 gpm 13.2 lpm
Maximum Pressure 5000 psi 344.7 bar
Maximum Tip Size
• 1 gun .067 in. 1.70 mm
• 2 guns .048 in. 1.22 mm
• 3 guns .039 in. 0.99 mm
• 4 guns .035 in. 0.89 mm
• 5 guns .031 in. 0.79 mm
• 6 guns .028 in. 0.71 mm
Fluid Inlet 1.25 in. npt(m) 3.2 cm npt(f)
Fluid Outlet (with fitting as shipped) 0.75 in. nps(f) swivel 1.9 cm npsm
Fluid Outlet Pump 1.0 in. npt(f) 2.5 cm npt(f)
Dimensions
Weight 438 lb 199 kg
Height 49 in. 124 cm
Width 28 in. 71 cm
Length 43 in. 109 cm
Sounds Levels*
Sound Pressure 91 dB(A)
Sound Power 106 dB(A)
*measured at maximum normal load conditions
Wetted Parts
Displacement Pump steel, nitralloy, tungsten, carbide, PTFE, leather,
polyethylene
Miscellaneous
Graco-Approved Hydraulic Oil
169236 5 gallons 19 liters
207428 1 gallon 3.8 liters

Technical Data
332156E 19
GH1017ES
US Metric
Sprayer
Hydraulic Pressure 2750 psi 190 bar
Hydraulic Reservoir Capacity 4.0 gallons 15.1 liters
Honda Motor 13 HP 9.7 KW
Vanguard Motor 14 HP 10.4 KW
Maximum Delivery 16.5 gpm 62.5 lpm
Maximum Pressure 1000 psi 69 bar
Maximum Tip Size
• 1 gun n/a n/a
• 2 guns n/a n/a
• 3 guns n/a n/a
• 4 guns n/a n/a
• 5 guns n/a n/a
• 6 guns n/a n/a
Fluid Inlet 2 in. npt(f) 5 cm npt(f)
Fluid Outlet (with fitting as shipped) 0.75 in. nps(f) swivel 1.9 cm npsm
Fluid Outlet Pump 1.5 in. npt(f) 3.8 cm npt(f)
Dimensions
Weight 473 lb 215 kg
Height 49 in. 124 cm
Width 28 in. 71 cm
Length 43 in. 109 cm
Sounds Levels*
Sound Pressure 91 dB(A)
Sound Power 106 dB(A)
*measured at maximum normal load conditions
Wetted Parts
Displacement Pump steel, nitralloy, tungsten, carbide, PTFE, leather
Miscellaneous
Graco-Approved Hydraulic Oil
169236 5 gallons 19 liters
207428 1 gallon 3.8 liters

Technical Data
20 332156E
GH2570ES
US Metric
Sprayer
Hydraulic Pressure 2750 psi 190 bar
Hydraulic Reservoir Capacity 4.0 gallons 15.1 liters
Honda Motor 13 HP 9.7 KW
Vanguard Motor 14 HP 10.4 KW
Maximum Delivery 7.0 gpm 26.5 lpm
Maximum Pressure 2500 psi 172.3 bar
Fluid Inlet 2 in. npt(f) 5 cm npt(f)
Fluid Outlet (with fitting as shipped) 0.75 in. nps(f) swivel 1.9 cm npsm
Fluid Outlet Pump 1.5 in. npt(m) 3.8 cm npt(m)
Dimensions
Weight 471 lb 214 kg
Height 49 in. 124 cm
Width 28 in. 71 cm
Length 43 in. 109 cm
Sounds Levels*
Sound Pressure 91 dB(A)
Sound Power 106 dB(A)
*measured at maximum normal load conditions
Wetted Parts
Displacement Pump steel, nitralloy, tungsten, carbide, PTFE, leather
Miscellaneous
Graco-Approved Hydraulic Oil
169236 5 gallons 19 liters
207428 1 gallon 3.8 liters
