First choice when
quality counts.

308–787
Rev.
A
INSTRUCTIONS
This
manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
Sprayer
Power Cord Installation
For
Sprayer Cords:
239–670
through 239–674,
239–749 and 239–771
WARNING
FIRE
AND EXPLOSION HAZARD
Use of the plug retainer is essential to
reduce the risk of fire or explosion. Acci
-
dental disconnection of the plug can
cause sparks. This can result in serious
injury and property damage. Also read
FIRE OR EXPLOSION HAZARD
in
sprayer manuals.
For detailed instructions and warnings, see sprayer
manuals.

201 239–XXX* CORD,
power
1
202 192–149 RET
AINER, plug
1
203 112–546 SCREW 2
204 114–027 W
ASHER, flat, no. 6
2
205 239–429 PRESSURE CONTROL (220V) 1
239–750 PRESSURE CONTROL (120V) 1
* Select power cord part number from list below:
239–670 CORD, power
(220V for Continental Europe, CEE 7/7)
239–671 CORD, power
(220V for Italy)
239–672 CORD, power
(220V for Denmark)
239–673 CORD, power
(220V for Switzerland)
239–674 CORD, power
(220V–bare end)
239–749 CORD, power
(120V)
239–771 CORD, power
(120V CSA sprayers)
201 202203
204
205
1. Remove
screws (203) and washers (204) from pressure control (205).
2.
Plug power cord (201) into pressure control (205).
3.
Attach plug retainer (202) with screws (203) and washers (204).
GRACO INC. P.O. BOX 1441
MINNEAPOLIS, MN
55440–1441
COPYRIGHT
1997, GRACO INC.
Graco
Inc. is registered to I.S. EN ISO 9001

Graco
W
arranty
Graco
warrants all equipment listed in this manual which is manufactured by Graco and bearing its name to be free from defects in
material
and workmanship on the date of sale by an authorized Graco distributor to the original purchaser for use. With
the exception of
any
special extended or limited warranty published by Graco,
Graco will, for a period of twelve months from the date of sale, repair or
replace
any part of the equipment determined by Graco to be defective. This warranty applies only
when the equipment is installed,
operated
and maintained in accordance with Graco’
s written recommendations.
This
warranty does not cover
, and Graco shall not
be liable for general wear and tear
, or any malfunction, damage or wear caused by
faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or
substitution
of non-Graco component parts. Nor shall Graco be liable for malfunction, damage or wear caused by the incompatibility of
Graco
equipment with structures, accessories, equipment or materials not supplied by Graco,
or the improper design, manufacture,
installation,
operation or maintenance or structures, accessories, equipment or materials not supplied by Graco.
This
warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for
verification
of the claimed defect. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The
equipment
will be returned to the original purchaser transportation prepaid. If inspection of the equipment does not disclose any defect
in
material or workmanship, repairs will be made at a reasonable charge, which charges may include the costs of parts, labor
, and
transportation.
Graco’s
sole obligation and buyer
’
s sole remedy for any breach of warranty shall be as set
forth above. The buyer agrees that no other
remedy (including, but not limited to, incidental or consequential damages for lost profits, lost
sales,
injury to person or property
, or any
other incidental or consequential loss) shall be available. Any action for breach of warranty must be brought within two (2) years
of
the
date
of sale.
GRACO
MAKES NO W
ARRANTY
, AND
DISCLAIMS ALL IMPLIED W
ARRANTIES OF MERCHANT
ABILITY AND FITNESS FOR
A
P
ARTICULAR PURPOSE IN CONNECTION WITH ACCESSORIES, EQUIPMENT
, MA
TERIALS OR COMPONENTS SOLD BUT
NOT MANUFACTURED BY GRACO. These items sold, but not manufactured by Graco (such as electric motors, gas engines,
switches,
hose, etc.), are subject to the warranty
, if any
, of their manufacturer
. Graco will provide purchaser with reasonable assistance
in
making any claim for breach of these warranties.
LIMITATION
OF LIABILITY
In
no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco supplying
equipment
hereunder,
or the furnishing, performance, or use of any products or other goods sold hereto, whether due to a breach of contract,
breach
of warranty
, the negligence of Graco, or otherwise.
FOR
GRACO CANADA CUST
OMERS
The
parties acknowledge that they have required that the present document,
as well as all documents, notices and legal proceedings
entered into, given or instituted pursuant hereto or relating directly or indirectly hereto, be drawn up in English. Les parties
reconnaissent
avoir convenu que la rédaction du présente document sera
en Anglais, ainsi que tous documents, avis et procédures
judiciaires
exécutés, donnés ou intentés à la suite de ou en rapport, directement ou indirectement, avec les procédures concernées.
All
written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
Sales Offices:
Minneapolis, Detroit, Los Angeles
Foreign Offices:
Belgium, Canada, England, Korea, France, Germany
, Hong Kong, Japan
GRACO INC. P.O. BOX 1441
MINNEAPOLIS, MN
55440–1441
PRINTED
IN U.S.A. 308–787 May
1997
