Graco ROOMFOR2 User manual

ROOMFOR2™
featuring
Graco PD314829B 4/15

2-A ROOMFOR2™ Use Positions
2-B Parts List
1 WARNING
2 Features
3-A To Open Stroller
3-B Rear Wheels
3-C Front Wheels
3-D Armbar
3-E Child’s Tray
3-F Parent’s Tray
3-G Canopy
3 Assembly
4-A To Secure Child
4-B To Recline Front Seat
4-C Brakes
4-D Swivel Wheels
4-E To Attach Graco® Infant Car Seat
4-F To Fold Stroller
4 Use
5-A Care & Maintenance
5 Cleaning

Failure to follow these warnings and the
assembly instructions could result in serious injury or death.
PLEASE SAVE OWNER’S
MANUAL FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED.
NEVER LEAVE child
unattended. Always keep
child in view while in stroller.
AVOID SERIOUS INJURY from
falling or sliding out. Always use
seat belt. After fastening buck-
les, adjust belts to get a snug fit
around your child.
AVOID FINGER ENTRAPMENT.
Use care when folding and
unfolding the stroller. Be certain
the stroller is fully erected and
latched before allowing your
child near the stroller.
AVOID STRANGULATION.
DO NOT place items with a
string around your child’s
neck, suspend strings from
this product, or attach strings
to toys.
NEVER USE STROLLER ON
STAIRS or escalators. You may
suddenly lose control of the
stroller or your child may fall
out. Also, use extra care when
going up or down a step or
curb.
STROLLER TO BE USED only
at walking speed. Product not
intended for use while jogging,
skating, etc.
USE OF THE front seat, bench
seat or standing platform with a
child weighing more than 50 lbs
(22.7 kg) or taller than 45 in.
(114.3 cm) will cause excessive
wear and stress on the stroller.
TIPPING HAZARD! DO NOT
OVERLOAD BENCH SEAT,
FRONT SEAT OR STANDING
PLATFORM PAST THE
MANUFACTURERS
RECOMMENDED WEIGHT
RATING.
TO PREVENT TIPPING, do not
place more than 3 lbs (1.4 kg)
on the parent’s tray.
TO AVOID BURNS, never put hot
liquids in the parent’s tray.
TO PREVENT A HAZARDOUS,
UNSTABLE CONDITION, never
place purses, shopping bags,
parcels or accessory items on
the handle or canopy.
TO PREVENT A HAZARDOUS,
UNSTABLE CONDITION, do not
place more than 10 lbs
(4.5 kg) in the storage basket.
DO NOT use storage basket as a
child carrier.
NEVER ALLOW YOUR STROLLER
to be used as a toy.
DISCONTINUE USING YOUR
STROLLER should it become
damaged or broken.

USING GRACO®INFANT CAR SEAT WITH
STROLLER:
•ONLY USE A Graco® SnugRide®, SnugRide®
Click Connect™, SnugRide® Classic
Connect™ OR INFANT SAFESEAT™ CAR SEAT
WITH THIS PRODUCT. (Not intended for use with
AUTOBABY, LOGICO S, JUNIORBABY and ASSURA
infant car seats.) Improper use of this stroller with
other manufacturers’ car seats may result in
serious injury or death.
• READ THE MANUAL provided with your Graco car seat before
using it with your stroller.
• Front tray MUST be installed over the armbar in the front location to
use Classic Connect™ car seats.
• Front tray MUST be removed from armbar in the front location to
use Click Connect™ car seats.
• ALWAYS SECURE your child with the car seat harness when using
the car seat in the stroller. If your child is already in the car seat,
check that the child is secured with the harness.
10

WARNING
DO NOT allow child to stand on platform facing backwards. To avoid falling,
child must hold onto stroller frame.
2-A ROOMFOR2™ Use Positions

10
2-B Parts List
All models
On certain models
2X
2X
2X
2X2X
This model may not include some features shown below. Check that you
have all the parts for this model BEFORE assembling your product. If any
parts are missing, call Customer Service.
No tools required.

3-A To Open Stroller
1. Open stroller lock.
Be sure to place stroller on top of a piece of cardboard or some other
protective cover to prevent any damage to floor.
2. Lift handle of stroller up.

3. CHECK that the stroller is
completely latched open every
time you open the stroller and
before continuing with the rest of
the assembly steps.
SNAP!
4. Push the platform down until it
snaps into place.
SNAP!

5. Flip stroller upside down as
shown and make sure all 3
plastic tabs are snapped around
the rear axle.

3-B Rear Wheels
SNAP!
1. Brake levers point toward rear of
stroller.
2. Press down on brake assemblies
until that snap into place.

2X
3. Insert axle rod through axle
opening. Axle key must line up
with key holes.
4. Place wheel on axle.

5. Push straight side of pin through
axle hole. Pin will separate around
the axle. Curved end of pin MUST
face up as shown.
6. Snap hubcap over pin as shown.
Repeat steps 4-6 (Rear Wheels)
on other side.
2X
SNAP!
2X

3-C Front Wheels
2X
SNAP!
1. Attach front wheels to posts as
shown.
2. Check that wheels are securely
attached by pulling on wheel
assemblies.

3-D Armbar
WARNING
Always secure your child with the seat belt. The armbar is not a restraint
device. DO NOT lift the stroller by the armbar. Use care when snapping the
armbar on the stroller with a child in the stroller.
1. To attach armbar to stroller, slide
onto post as shown until button
snaps into opening in arm bar.
SNAP!

2. Rotate arm bar down to close.
3. Pull tab on bottom of arm bar to
open.

3-E Child’s Tray
WARNING
Always secure your child with the seat belt. The tray is not a restraint device.
DO NOT lift the stroller by the child’s tray. Use care when snapping the tray
on the stroller with a child in the stroller.
1. To attach child tray insert.

2. To remove, press in tabs on inside
of child tray and lift away from
child tray bar.

3-F Parent’s Tray
1. Insert tray into slots.
2. Make sure parent tray is snapped
securely onto pegs on each side of
the frame.

3-G Canopy
1. Insert canopy into the canopy
mounts on each side of the
stroller, with the padded edge
facing towards the front as
shown.
2. To adjust.

4-A To Secure Child
WARNING Falling Hazard: Always use the seat belt.
1. To open, press button on buckle
to release the waist straps.
2. To close, slide shoulder strap
connectors to waist straps and
insert into buckle.
5 Point Harness
