Graham Field Grafco 8817 Parts list manual

8617-INS-LAB-RevC12 1



Info: The most current version of these instructions can be found online at www.grahamfield.com.

 



 


 


The Grafco 8617 Fiberoptic Otoscope is intended to illuminate the auditory canal for examination.

 
 
 
 

Install the batteries: Unscrew the bottom cap from the battery handle. Insert two AA alkaline batteries into
the battery handle, ensuring that the batteries are congured correctly. Screw the bottom cap onto the
battery handle.

 
 


 


 


 
ON and OFF: Move the battery handle clip ON/OFF switch down to
turn the instrument ON. Move the switch up to turn the instrument OFF.
Magnification lens: The 2.5x lens can be swivelled laterally.
Speculum insertion and removal: The speculum size is marked on its outside. Insertion: position the
selected speculum on the otoscope socket and turn it clockwise until you feel resistance. Removal: turn the
speculum counter-clockwise until it is free of the otoscope socket.

Replacing the bulb: Unscrew the instrument head to remove it from the battery handle. The bulb is in the
bottom section of the instrument head. Remove the bulb from the instrument head carefully with your
thumb and forenger or a suitable tool. Insert the new bulb rmly.
bulb
battery
handle
socket
instrument
head
speculum
8617 FiberOptic Otoscope
bottom
cap
battery
handle
ON/OFF
switch
clip
magnification lens

8617-INS-LAB-RevC12 2
www.grahamfield.com
GF Health Products, Inc. is not responsible for typographical errors. For the most updated and current information on packaging, warranties,
products and specications, including the most current version of these instructions, please visit our website at www.grahameld.com.
Grafco and Graham-Field are registered trademarks of GF Health Products, Inc.
© 2012 GF Health Products, Inc. • 2935 Northeast Parkway, Atlanta, GA 30360 • tel [phone], fax [phone]
Battery use and care: Use two AA alkaline batteries only. If the otoscope will not be used for an extended
period of time, remove the batteries. Dispose of used batteries in accordance with all applicable laws and
regulations.
Cleaning and sterilization: Dampen a clean cloth with a mild detergent and water solution, a solution
of 70% isopropyl alcohol and water solution, or a 10% bleach and water solution. Wring out the cloth to
remove excess uid. Use the cloth to wipe all external surfaces of the otoscope. Ensure that no uid enters
the otoscope. Clean the instrument glass with a cotton swab dipped in isopropyl alcohol. The reusable ear
specula may be sterilized in 134°C saturation steam for a dwell time of ten minutes.
s 

Optical specications Illumination form FiberOptics transmit light
Lens magnication 2.5x
Otoscope port View tympanic membrane using the Fiberoptic Otoscope bulb
Ear specula specications Ear specula diameter 2.5mm, 4mm
Light port specications Light port Yes. An otoscope bulb can be tted to the port.
Electrical specications Bulb model T4954 2.5V, 1.6W
Rated voltage Two AA alkaline batteries (not included)
Operation mode ON time Intermittent; ≤ one minute
OFF time ≥ ve minutes
Electrical safety standard IEC60601-1, IEC60601-1-2
Environmental requirements Use Temperature 50°F — 95°F (10°C — 35°C)
Relative humidity 30% — 75% RH
Atmospheric pressure 10.15 psi — 15.37 psi (70 kPa — 106 kPa)
Shipping and storage Temperature -40°F — 131°F (-40°C — 55°C)
Relative humidity 10% — 90% RH
Atmospheric pressure 7.25 psi — 15.37 psi (50 kPa — 106 kPa)
Replacement parts Specula size 2.5mm (8617-1); Specula size 4.0mm (8617-2); Replacement bulb (8617-3)

GF Health Products, Inc. ("Graham-Field") warrants the Grafco 8617 Fiberoptic Otoscope (not including
specula) for defects in workmanship and materials for a period of one year. If a product is deemed to be
under warranty, GF Health Products, Inc. shall provide, at its option, (1) replacement of any defective part
or product or (2) a credit of the original selling price made to GF Health Products, Inc.’s initial customer.
The warranty does not include any labor charges incurred in replacement part(s) installation or any
associated freight or shipping charges to GF Health Products, Inc.
The warranties contained herein contain all the representations and warranties with respect to the subject
matter of this document, and supersede all prior negotiations, agreements and understandings with respect
thereto. The recipient of this document hereby acknowledges and represents that it has not relied on any
representation, assertion, guarantee, warranty, collateral contract or other assurance, except those set out
in this document.
