Gram KF 2330-00 N User manual

KF 2330-00 N
KF 2330-00 N X
EN User guide
DA Betjeningsvejledning
SV Bruksanvisning
NO Bruksanvisning
FI Käyttöohjeet
NL Gebruiksaanwijzing

WARNING!
In order to ensure a normal operation of your fridge/freezing appliance, which uses a completely environmentally
friendly refrigerant the R600a (Flammable only under certain conditions) you must observe the following rules:
Do not hinder the free circulation of the air around the appliance.
Do not use mechanical devices in order to accelerate the defrosting, other than the ones recommended by the
manufacturer.
Do not destroy the refrigerating circuit.
Do not use electric appliances inside the food keeping compartment, other than those that might have been
recommended by the manufacturer.
ADVARSEL!
For at sikre en normal funktion af køle-/fryseskabet, der anvender et komplet miljøvenligt kølemiddel, R 600a (Kun
brændbar under særlige forhold), skal du overholde følgende regler:
Undlad at hindre den frie luftcirkulation rundt om apparatet.
Der må ikke anvendes mekanisk udstyr, ud over det af producenten anbefalede, til at fremskynde
afrimningsprocessen.
Undgå at beskadige kølekredsløbet.
Undlad at bruge elektrisk udstyr inde i rummet, hvor der opbevares mad, ud over de steder, som producenten evt.
har anbefalet.
VARNING!
För att säkerställa normal användning av kyl- och frysskåpet, som utnyttjar helt miljöanpassade kylmedlet R600a
(Endast antändbart under vissa förhållanden) måste du iaktta följande regler:
Hindra inte fri luftcirkulation runt kyl- och frysskåpet.
Använd inga mekaniska enheter för att påskynda avfrostningen, förutom det som rekommenderas av tillverkaren.
Skada inte kylningskretsen.
Använd inga elektriska enheter inuti matsignalsfacket, utöver det som rekommenderas av tillverkaren.
ADVARSEL!
For å sikre normal drift av kombiskapet, som bruker en fullstendig miljøvennlig kjølevæske – R600a (Kun antennelig
under bestemte forhold), må du overholde følgende regler:
Ikke blokker den frie luftsirkulasjonen rundt apparatet.
Ikke bruk mekanisk utstyr for å akselerere avisingsprosessen annet enn slikt utstyr som produsenten anbefaler.
Pass på så du ikke ødelegger kjølekretsen.
Ikke bruk elektriske apparater inne i de delene av skapet der du lagrer mat, såfremt de ikke er av en slik type som
produsenten anbefaler.
VAROITUS!
Laitteen kylmäaineena on ympäristöystävällinen R600a (syttyvää vain tietyissä olosuhteissa). Jotta laite toimisi
normaalisti, on noudatettava seuraavia ohjeita:
Älä estä ilman vapaata kiertoa laitteen ympäri.
Älä käytä mekaanisia välineitä sulatuksen nopeuttamiseen, paitsi sellaisia, joita valmistaja suosittelee.
Älä vahingoita jäähdytyspiiriä.
Älä käytä ruokalokeroiden sisällä sähkölaitteita, jollei valmistaja niin suosittele.
WAARSCHUWING!
U dient de volgende regels in acht te nemen om de normale werking van uw diepvriesapparaat, die de volledig
milieuvriendelijke koelvloeistof R600a gebruikt, te verzekeren:
De vrije luchtcirculatie rond het toestel niet belemmeren.
Geen andere mechanische toestellen gebruiken om het ontdooien te versnellen dan de toestellen die door de
fabrikant worden aangeraden.
Het koelcircuit niet kapot maken.
Geen andere elektrische toestellen in de bewaarlade voor etenswaren gebruiken dan de toestellen die eventueel
door de fabrikant worden aangeraden.

EN
Index
Safety first /1
Electrical requirements /2
Transportation instructions /2
Installation instructions /2
Getting to know your appliance /3
Suggested arrangement of food in the appliance /3
Temperature control and adjustment /3
Before operating /4
Storing frozen food /4
Freezing fresh food /4
Making ice cubes /4
Defrosting /4
How to reposition the doors /5
Replacing the interior light bulb /5
Cleaning and care /6
Do’s and Don’ts /6
Energy consumption /7
Information concerning the noise /7
Troubleshooting /8
Technical data /8
Vigtige sikkerhedsanvisninger /9
Krav til el-installationen /10
Transportvejledning /10
Installationsvejledning /10
Dus med dit apparat /11
Forslag til placering af madvarer i apparatet /11
Temperaturkontrol og –regulering /11
Før ibrugtagning /12
Opbevaring af frostvarer /12
Frysning af friske madvarer /12
Fremstilling af isterninger /12
Afrimning /12
Således sættes døren på plads /13
Udskiftning af den indvendige pære /13
Rengøring og vedligeholdelse /14
Husk at, og Undlad at /14
Energiklasse /15
Information om støj /15
Fejlfinding /16
Tekniske data /16
Säkerheten först /17
Krav för elanslutning/18
Transportinstruktioner /18
Installationsinstruktioner /18
Lär känna din enhet/19
Förslag på placering av maten i enheten/19
Temperaturkontroll och justering/19
Före användning/20
Förvaring av fryst mat/20
Infrysning av färsk mat/20
Göra isbitar/20
Avfrostning/20
Så här omplaceras dörren /21
Byte av innerbelysningens glödlampa /21
Rengöring och vård /22
Viktig
a saker att göra och inte göra/22
Energiförbrukning /23
Information rörande buller /23
Felsökning /24
Tekniska data /24
DA
Register
SV
Index
NO
Indeks
Sikkerheten først/25
Krav til det elektriske anlegget/26
Transportanvisninger/26
Installasjonsanvisninger/26
Bli kjent med apparatet/27
Forslag til plassering av matvarer i kjøleskapet/27
Temperaturkontroll og justering/27
Før bruk/28
Lagring av frosne matvarer/28
Frysing av ferske matvarer/28
Lag isbiter/28
Opptining/28
Slik reposisjonerer du dørene /29
Utskifting av lyspæren inne i skapet/29
Rengjøring og stell/30
Ting du må gjøre og ting du ikke må gjøre/30
Energiforbruk/31
Informasjon vedrørende støy/31
Feilsøking/32
Tekniske data /32
Turvallisuus ensin /33
Sähkötekniset vaatimukset /34
Kuljetusohjeet /34
Asennusohjeet /34
Laitteen osat /35
Ehdotus ruokien sijoittamisesta laitteeseen /35
Lämpötilan ohjaus ja säätö /35
Ennen käyttöä /36
Pakastetun ruuan säilyttäminen /36
Tuoreen ruuan pakastaminen /36
Jääpalojen teko /36
Sulattaminen /36
Oven uudelleensijoittaminen /37
Sisälampun vaihtaminen /37
Puhdistus ja huolto /38
Tee ja älä tee /38
Energiankulutus /39
Tietoja käyttöäänistä /39
Vianetsintä /40
Tekniset tiedot /40
Veiligheid eerst /
41
Elektriciteitsvereisten /42
Transportinstructies /42
Installatie-instructies /42
Uw apparaat leren kennen /43
Suggesties voor rangschikking van etenswaren in het
apparaat /43
Temperatuurmeting en -regeling /43
Vóór ingebruikstelling /
44
Bewaren van bevroren etenswaren /44
Verse etenswaren invriezen /4
4
IJsblokjes maken /44
Ontdooien /44
Hoe de deuren om te zetten /45
Het binnenlichtje vervangen /45
Schoonmaak en onderhoud /46
Wel en niet doen /46
Energieverbruik /47
Informatie omtrent het geluid /47
Probleemoplossing /48
Technische gegevens /48
FI
Hakemisto
NL
Inhoud

1

2
3
4
8
5
7
6
9
1
1
10

1
2

Congratulations on your new GRAM fridge/freezer.
Safety first!
Do not connect your appliance to the electricity supply
until all packing and transit protectors have been
removed.
• Leave to stand for at least 4 hours before switching on
to allow the compressor oil to settle if transported
horizontally.
• If you are discarding an old appliance with a lock or a
latch fitted to the door, ensure that it is left in a safe
condition to prevent the entrapment of children.
• This appliance must only be used for its intended
purpose.
• Do not dispose of the appliance on a fire. Your
appliance contains non CFC substances in the
insulation which are flammable. We suggest that you
contact your local authority for information on disposal
and available facilities.
• We do not recommend the use of this appliance in an
unheated, cold room (e.g. garage, conservatory, annex,
shed, out-house etc.).
To obtain the best possible performance and problem-
free operation from your appliance it is very important to
read the user guide carefully. Failure to observe the
user guide may reduce your right to free service during
the guarantee period.
Please keep the user guide in a safe place for easy
reference.
EN User guide
1
This appliance is not intended for people with reduced physical, sensory or mental
capabilities or lack of experience and knowledge unless they have been supervised or
instructed in the use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.

EN User guide
Electrical requirements
Before inserting the plug into the socket make
sure that the voltage and the frequency shown
in the rating plate inside the appliance
corresponds to your electricity supply.
We recommend that this appliance is
connected to the mains supply via a suitably
switched and fused socket in a readily
accessible position.
The plug has to be accessible after installation
in order to allow disconnection of the
appliance from the supply.
Warning! This appliance must be earthed.
Repairs to the electrical equipment may only
be made by authorised technicians. If the
power cable is damaged, the manufacturer or
GRAM service must replace it in order to
avoid danger.
ATTENTION!
This appliance operates with R600a which is
an environmental friendly but flammable gas.
During the transportation and fixing of the
product, care must be taken not to damage
the cooling system. If the cooling system is
damaged and there is a gas leakage from the
system, keep the product away from open
flame sources and ventilate the room for a
while.
WARNING - Do not use electrical devices or
other means to accelerate the defrosting
process, others than those recommended by
the manufacturer.
WARNING - Do not damage the refrigerant
circuit.
Transportation instructions
1. The appliance should only be transported in
an upright position. Packaging must be intact
during transportation.
2. If the appliance has been positioned
horizontally during transportation, it must not
be operated for at least 12 hours to allow the
system to settle.
3. Failure to comply with the above
instructions could result in damage to the
appliance for which the manufacturer will not
be held liable.
4. The appliance must be protected against
rain, moisture and other atmospheric
influences.
Important!
• Avoid touching the bottom of the condenser
metal wires at the back of the appliance while
cleaning or carrying the appliance as you may
receive injuries to your fingers and hands.
• Do not attempt to sit or stand on top of your
appliance as it is not designed for such use.
You could be injured or damage the
appliance.
• Make sure that the mains cable is not caught
under the appliance during and after moving it
as this could damage the cable.
• Do not allow children to play with the
appliance or tamper with the controls.
Installation instructions
1. Do not keep your appliance in a room
where the temperature is likely to fall below
+10 ºC (50 ºF).
2. Do not place the appliance near cookers or
radiators or in direct sunlight, as this will
cause extra strain on the appliance's
functions. If installed next to a heat source or,
maintain the following minimum side
clearances:
30 mm from cookers
300 mm from radiators
3. Make sure that sufficient room is provided
around the appliance to ensure free air
circulation (Fig. 2).
• Place the spacer on the back of your
appliance to set the distance between the
appliance and the wall (Fig. 3).
4. The appliance should be positioned on a level
surface. The two front legs can be adjusted as
required.To ensure that your appliance is
standing upright adjust the two front legs by
turning them either clockwise or anti-clockwise,
until firm contact is secured with the floor.
Correct adjustment of the legs prevents
excessive vibration and noise (Fig. 4).
5. Refer to the "Cleaning and Care" section to
prepare your appliance for use.
6. If you want to place two products side by
side, e.g. a refrigerator and a freezer, as a side
by side solution you have to use a decoration kit
which contains a small mat and a decoration
part. The mat is mounted on the side of one of
2

EN User guide
the products to create a space between the
products. The decoration part is placed between
the products to hide the gap between the
products (Fig 2). The decoration kit is not a part
of the product but can be delivered as an
accessory.
Getting to know your appliance
(Fig. 1)
1 - Thermostat control and interior light
2 -
Removable glass shelves
3 - Water collector
4 -
Glass shelf
5 - Vegetable drawer
6 - Ice cube tray support & ice cube tray
7 - Compartment for fast freezing
8 - Compartments for keeping frozen food
9 - Adjustable front legs
10 - Door shelves
11 - Bottle shelf
12 - Freezer fan
Suggested arrangement of the food
in the appliance
Guidelines for obtaining optimum storage:
1. The fridge compartment is for the short-
term storage of fresh food and drinks.
2. The freezer compartment is
rated and suitable for the freezing and
storage of pre-frozen food.
The recommendation for storage as
stated on the food packaging should be
observed at all times.
3. Dairy products should be stored in the
coldest places in the fridge compartment.
4. Cooked dishes should be stored in airtight
containers.
5. Fresh wrapped produce can be kept on
the shelves
. Fresh fruit and vegetables should
be stored in the vegetable drawers.
6. Bottles can be kept in the door shelves or
on the bottle shelf.
7. To store fresh meat, wrap it in polythene
bags and place it in the coldest place in the
fridge compartment. Don’t let meat juice from
fresh meat come into contact with other types
of food. For safety, only store fresh meat for
two to three days.
8. For maximum efficiency the removable
shelves should not be covered with paper or other
materials to allow free circulation of cool air.
9. Do not keep vegetable oil on the door
shelves. Keep the food packed, wrapped or
covered. Leftover canned food should not be
stored in the can.
10. To take out the drawers from the freezer
compartment please proceed as in Fig. 9.
Temperature control and adjustment
Operating temperatures are controlled by the
thermostat control (Fig. 5) located on the
ceiling of the fridge compartment. Settings
may be made from MIN., 1 ... 6, MAX., MAX
which is the coldest position. When the
appliance is switched on for the first time, the
thermostat control should be adjusted so that
after 24 hours, the average fridge temperature
is no higher than +5°C (+41°F). We
recommend you to set the thermostat control
half way between the MIN. and the MAX.
position and monitor to obtain the desired
temperature i. e. towards MAX. you will obtain
a colder fridge temperature and vice versa.
Some sections of the fridge may be cooler or
warmer (such as the vegetable drawers and
the top part of the cabinet) which is quite
normal.
The normal storage temperature of the freezer
should be -18°C (0°F). Lower temperatures
may be obtained by adjusting the thermostat
control towards the MAX. position.
We recommend that you check the
temperature with an accurate thermometer to
ensure that the storage compartments are
kept to the desired temperature.
Remember to
read off the thermometer very quickly as the
temperature on the thermometer will rise very
rapidly after you remove it from the freezer.
Please remember that each time the door is
opened cold air escapes and the internal
temperature rises. Therefore never leave the
door open and ensure that it is closed
immediately after food is put in or removed.
3

EN User guide
Before operating
Final Check
Before you start using the appliance check
that:
1. The front legs have been adjusted for
perfect levelling.
2. The interior is dry and that air can circulate
freely at the back of the appliance.
3. The interior is clean as recommended
under the "Cleaning and care" section.
4. The plug has been inserted into the wall
socket and the electricity is switched on.
When the door is open the interior light will be
switched on.
And note that:
5. You will hear a noise as the compressor
starts. The liquid and gases sealed within the
refrigeration system may also make some
noise, whether the compressor is running or
not. This is quite normal.
6. The top of the cabinet may be slightly
currugated which is quite normal due to the
manufacturing process used; it is not a
defect.
7. We recommend setting the thermostat
control midway and monitor the temperature
to ensure that the appliance maintains the
desired storage temperatures (see the
"Temperature Control and Adjustment"
section).
8. Do not load the appliance immediately after
it is switched on. Wait until the correct storage
temperature has been reached. We
recommend checking the temperature with an
accurate thermometer (see the "Temperature
Control and Adjustment" section).
Storing frozen food
Your freezer is suitable for the long-term
storage of commercially frozen food and also
can be used to freeze and store fresh food.
If there is an electrical cut, do not open the
door. Frozen food should not be affect
ed if the
electrical cut lasts for less than 18 hrs. If the
electrical cut is longer, then the food should
be checked and either eaten immediately or
cooked and then re-frozen.
Freezing fresh food
Please observe the following instructions to
obtain the best results.
Do not freeze too large a quantity at any one
time. The quality of the food is best preserved
when it is frozen right through to the core as
quickly as possible.
Do not exceed the freezing capacity of your
appliance in 24 h.
Placing warm food in the freezer compartment
causes the compressor
to operate continously
until the food is frozen solid. This can
temporarily lead to excessive cooling of the
refrigeration compartment.
When freezing fresh food, keep the
thermostat control at the medium position.
Small quantities of food up to 1/2 kg (1 lb) can
be frozen without adjusting the thermostat
control.
Making ice cubes
Fill the ice cube tray 3/4 with water and place
it in the freezer. Loosen frozen trays with a
spoon handle or a similar instrument; never
use sharp-edged objects such as knives or
forks.
Defrosting
A) Fridge compartment
The fridge compartment defrosts
automatically. The defrost water runs to the
drain tube via a collection container at the
back of the appliance (Fig. 6).
During defrosting, water droplets may form at
the back of the fridge compartment where a
concealed evaporator is located. Some
droplets may remain on the liner and refreeze
when defrosting is completed. Do not use
pointed or sharp-edged objects such as
knives or forks to remove the droplets which
have refrozen.
If, at any time, the thawed water is not drained
from the collection channel, check that no
food particles have blocked the drain tube.
4

EN User guide
The drain tube can be cleared with a cotton
bud or a similar instrument.
Check that the tube is permanently placed with
its end in the collecting tray on the compressor
to prevent the water spilling on the electric
installation or on the floor (Fig. 7).
B) Freezer compartment
As this appliance is supplied with the NO
FROST feature it means that the defrosting is
completely automatic. No intervention from
your side is requiered. The water is collected
on the compressor tray. Due to the heat of the
compressor the water is evaporated.
Never use hairdryers, electrical heaters or
other such electrical appliances for defrosting.
Sponge off the defrost water collected at the
bottom of the freezer compartment. After
defrosting, dry the interior thoroughly (Fig. 8).
Insert the plug into the socket and switch on
the electricity supply.
Warning!
The fan inside the freezer compartment
circulates cold air. Never insert any object
through the guard. Do not allow children to
play with the freezer fan.
Never store products that contain inflammable
propellant gas such as dispensers, spray
cans
etc. or explosive substances.
Don’t cover the shelves with any protective
materials, which may obstruct air circulation.
Do not allow children to play with the
appliance or the controls.
Do not obstruct the freezer fan guard to
ensure that you obtain the best possible
performance from your appliance
(Fig. 10).
Warning!
Your appliance is fitted with a circulating fan
which is essential for the performance of the
freezer. Please ensure that the fan is not
blocked (stopped) or impaired by food or
packaging. Blocking (stopping) or impairing
the fan can result in an increase of the internal
freezer temperature (Thawing).
How to reposition the doors
Proceed in numerical order (Fig. 12).
5
Replacing the interior light bulb
(Fig. 11)
In case the light bulb is not working it is easy
to replace. First make sure that the
fridge/freezer is disconnected from the power
supply by removing the plug. Take a flat
screwdriver and place it ca
refully without force
into the left gap between the lamp cover and
the internal cabinet. Then press the handle of
the screwdriver carefully to the left until you
notice that the left pin of the cover is
disengaged. Repeat this procedure on the
gap on the right, but now press the handle of
the screwdriver carefully to the right. If both
sides are loosened the cover can be removed
easily.
Ensure that the bulb is screwed securely in
the bulb holder. Plug the appliance into the
power supply. If the light is still not working,
replace the E14 screw-cap type 15 Watt
(Max) bulb with a bulb from your local
electrical store and then fit it. Carefully
dispose of the burnt-out light bulb
immediately.
When you have changed the light bulb please
fix the cover again in its former position. Take
care that the cover closes correctly.

EN User guide
Cleaning and care
1. We recommend that you switch off the
appliance at the socket outlet and pull out the
mains plug before cleaning.
2. Never use any sharp instruments or
abrasive substances, soap, household
cleaner, detergent or wax polish for cleaning.
3. Use luke warm water to clean the cabinet
of the appliance and wipe it dry.
4. Use a damp cloth wrung out in a solution of
one teaspoon of sodium bicarbonate to one pint
of water to clean the interior and wipe it dry.
5. Make sure that no water enters the
thermostat control box..
6. If the appliance is not going to be used for
a long period of time, switch it off, remove all
food, clean it and leave the door ajar.
7. We recommend that you polish the metal
parts of the product (i.e. door exterior, cabinet
sides) with a silicone wax (car polish) to
protect the high quality paint finish.
8. Any dust that gathers on the condenser,
located at the back of the appliance, should
be removed once a year with a vacuum
cleaner.
9. Check the door seals regularly to ensure
that they are clean and free from food
particles.
10. Never:
• Clean the
appliance with unsuitable material;
such as petroleum based products.
• Subject it to high temperatures in any way.
• Scour, rub etc., with abrasive material.
11. To remove a door tray, remove all the
contents and then simply push the door tray
upwards from the base.
12. Make sure that the special plastic
container at the back of the appliance which
collects the thawed water is clean at all times.
If you want to remove the tray to clean it,
follow the instructions below:
• Switch off the socket and pull out the mains
plug.
• To remove the water collector tray pull and
turn (left-right).
• Clean and wipe it dry.
• Reassemble the tray by reversing the
sequence and operations.
13. To remove a drawer, pull it as far as
possible, tilt it upwards and then pull it out
completely.
6
Do’s and Don’ts
Do clean your appliance regularly (See
"Defrosting")
Do keep food for as short a time as possible
and adhere to "Best Before" and "Use
by" etc. dates.
Do defrost food in the fridge compartment.
Don’t store bananas in your fridge
compartment.
Don’t cover the shelves with any protective
materials which may obstruct air
circulation.
Don’t store poisonous or any dangerous
substances in your appliance. It has
been designed for the storage of
edible foodstuffs only.
Don’t leave the door open for long periods,
as this will make the appliance more
costly to run and cause excessive ice
formation.
Don’t use sharp edged objects such as
knives or forks to remove the ice.
Don’t put liquid-filled bottles or sealed cans
containing carbonated liquids into the
freezer, as they may burst.
Don’t exceed the maximum freezing loads
when freezing fresh food.
Don’t give children ice-cream and water
ices direct from the freezer. The low
temperature may cause 'freezer
burns' on lips.
Don’t freeze fizzy drinks.
Don’t try to keep frozen food which has
thawed; it should be eaten within 24
hours or cooked and refrozen.
Don’t remove items from the freezer with
wet hands.

Information concerning the noise
and the vibrations which might
appear during the operation of the
appliance
1. The operation noise can increase during
the operation.
- In order to keep the temperatures at the
adjusted level, the compressor of the
appliance starts periodically. The noise
produced by the compressor becomes
stronger when it starts and a click can be
heard when it stops.
- The performance and operation features of
the appliance can change according to in the
surrounding environment. They must be
considered as normal.
2. Noises like liquids flowing or as being
sprayed
- These noises are caused by the flow of the
refrigerant in the circuit of the appliance and
comply with the operation principle of the
appliance.
3. Other vibrations and noises.
- The level of noise and vibrations can be
caused by the type and the condition of the
floor on which the appliance is placed. Make
sure that the floor does not have significant
level distortions or if it can yield to the weight
of the appliance (it is flexible).
- Another source of noise and vibrations is
represented by the objects placed on the
appliance. These objects must be removed
from the appliance.
- The bottles and the vessels placed in the
refrigerator touching each other. In such
cases move the bottles and the vessels so
that there is a small distance between them.
EN User guide
7
Energy Consumption
Maximum frozen food storage volume is
achieved without using the middle drawer and
the upper shelf cover provided in the freezer
compartment. The energy consumption of
your appliance is based on the freezer
compartment being fully loaded without using
the middle drawer and upper shelf cover.
Practical advice concerning the reduction
of the electricity consumption
Make sure that the appliance is located in
well-ventilated areas, far from any heat source
(cooker, radiator etc.). At the same time, the
appliance should be kept away from sunlight.
Make sure that the purchased
refrigerated/frozen food is placed in the
appliance as soon as possible, especially
during summertime. It is recommended to use
thermal insulated bags to transport the food.
We advise you to place frozen food in a
vessel in the refrigerator compartment when
the food has to thaw. In this way you avoid
that the water resulting from the thawing leaks
into the refrigerator compartment.We
recommend you to start the thawing at least
24 hours before the use of the frozen food.
Do not leave the door of the appliance open
more than necessary and make sure to close
it properly after use.

Technical data
Brand GRAM
Model KF 2330-00 N & KF 2330-00 N X
Appliance type No frost Refrigerator-Freezer Type I
Gross volume (litre) 321
Net volume (litre) 294
Freezer net volume (litre) 90
Refrigerator net volume 204
Freeze capacity (kg/24 h) 5
Energy class (1) A+
Power consumption (kWh/year) (2) 297
Safety during electricity cut (hours) 18
Noise dB(A) 40
Environmentally friendly refrigerating agent R600a
(1) Energy class : A++ .......D (A++ = economical . . . D = less economical)
(2) The real power consumption depends on using conditions and appliance location.
EN User guide
8
• That the temperature control has been set
correctly.
• That the new plug is wired correctly, if you
have changed the fitted, moulded plug.
If the appliance is still not operating at all after
above checks, contact the GRAM service.
Please ensure that above checks have been
done, as a charge will be made if no fault is
found.
Troubleshooting
If the appliance does not operate when
switched on then check:
• That the plug is inserted properly in the
socket and that the power supply is on. (To
check the power supply in the socket, plug
in another appliance).
• Whether the fuse has blown, the circuit
breaker has tripped or whether the main
distribution switch has been turned off.
The symbol on the product or on packaging indicates that this product must not be
treated as household waste. Instead it has to be handed over to the place of collection for
the recycling of electrical and electronic equipment. By ensuring the correct removal of this
product, you help preventing the potential negative consequences for the environment and
human health, which could be caused by the inappropriate waste handling of this product.
For more detailed information about recycling of this product, please contact your local
government offices, your household waste disposal service or the shop where you
purchased the product.

Tillykke med dit nye GRAM køleskab/fryser.
Vigtige sikkerhedsanvisninger!
Undlad at tilslutte apparatet til strømforsyning før alle
pakke- og transportbeskyttelser er fjernet.
• Lad apparatet står stå i mindst 4 timer før du tænder for
det. Dette sikrer, at kompressorolien kan løbe på plads,
hvis apparatet har været transporteret liggende.
• Hvis du kasserer et brugt apparat, som er udstyret med
dørlås eller smæklås, så vær opmærksom på at efterlade
det sikkert for at forhindre, at børn kan blive spærret inde
i det.
• Dette apparat må kun anvendes til det tilsigtede formål.
• Bortskaf ikke apparatet ved at brænde det. Dit apparat
indeholder CFC-fri stoffer i isoleringen, som er
brandbare. Vi foreslår, at du kontakter kommunen for
information om bortskaffelse og evt. genbrugsstationer.
• Vi anbefaler ikke brug at dette apparat i et uopvarmet,
koldt rum (som f.eks. garage, vinterhave, anneks, skur,
udhus, osv.).
For at få størst mulig nytte af dit apparat og for at sikre en
problemfri funktion, er det meget vigtigt, at du læser
denne brugsvejledning grundigt. Hvis brugsvejledningen
ikke følges, kan det medføre, at retten til gratis service i
garantiperioden reduceres.
Opbevar denne brugsvejledning på et sikkert sted, hvor
den er nem at komme til.
DA Betjeningsvejledning
Dette apparat er ikke beregnet til anvendelse af personer med reducerede fysiske,
følelsesmæssige eller mentale evner, eller mangel på erfaring og viden, medmindre de har
været under opsyn eller har fået instruktion omkring brugen af apparatet af en person, der er
ansvarlig for deres sikkerhed.
Børn skal overvåges for at sikre, at de ikke leger med apparatet.
9

DA Betjeningsvejledning
Krav til el-installationen
Før stikket sluttes til stikkontakten, skal du
kontrollere, at den spænding og frekvens, der
fremgår af typeskiltet inde i apparatet, svarer
til netspændingen hos dig.
Vi anbefaler, at dette apparat tilsluttes til en
lettilgængelig stikkontakt, som er beskyttet
med en passende sikring samt forsynet med
afbryder.
Stikket i netledningen skal være lettilgængelig
efter installationen, så apparatet kan nem
afbrydes fra strømforsyningen.
Advarsel! Dette apparat skal jordforbindes.
Reparationer af det elektriske udstyr må kun
udføres af autoriserede teknikere. Hvis
forbindelseskablet er beskadiget, skal
producenten eller GRAM service erstatte det
for at undgå fare.
BEMÆRK!
Dette apparat bruger R600a, som er en
miljøvenlig, men brændbar gas. Under
transporten og under monteringen af
produktet skal der udvises omhu med ikke at
beskadige kølesystemet. Hvis kølesystemet
beskadiges, og der bliver en gaslækage fra
systemet, skal produktet holdes væk fra åben
ild, og rummet skal luftes ud.
ADVARSEL - Der må ikke anvendes
elektriske genstande eller andre midler, ud
over de af producenten anbefalede, for at
fremskynde afrimningsprocessen.
ADVARSEL - Undgå at beskadige
kølekredsløbet.
Transportvejledning
1. Apparatet bør kun transporteres
opretstående. Emballagen skal være intakt
under transporten.
2. Hvis apparatet har været placeret liggende
under transporten, må det ikke betjenes i
mindst 12 timer for at give systemet tid til at
sætte sig.
3. Hvis ovenstående retningslinier ikke
overholdes, kan det medføre beskadigelse af
apparatet, som ikke er dækket af
producentens garantiforpligtelse.
4. Apparatet skal beskyttes mod regn, fugt og
andre atmosfæriske påvirkninger.
Vigtigt!
• Undgå berøring af den metalliske
kondensator trådføring på bagsiden af
apparatet underrengøring eller flytning, da der
er risiko for skade på fingre eller hænder.
• Undlad at sidde eller stå oven på apparatet,
da det ikke er designet med henblik på dette.
Du kan selv komme til skade eller komme til
at beskadige apparatet.
• Kontrollér at netledningen ikke kommer i
klemme under apparatet under og efter
flytning, da dette kan beskadige ledningen.
• Lad ikke bør børn lege med apparatet eller
pille ved knapperne.
Installationsvejledning
1. Undlad at installere apparatet i rum, hvor
temperaturen kan falde til under +10 ºC.
2. Undlad at placere apparatet tæt ved
komfurer eller radiatorer eller i direkte sollys,
da dette vil medføre en øget belastning af
apparatets funktioner. Hvis apparatet
installeres i nærheden af en varmekilde, skal
følgende minimumsafstande overholdes:
30 mm fra komfur
300 mm fra radiator
3. Kontrollér at der er tilstrækkelig plads
omkring apparatet til at sikre fri luftcirkulation
(Fig. 2).
• Sæt det bageste ventilationslåg til bagsiden
af køleskabet for at justere afstanden mellem
køleskabet og væggen (Fig. 3).
4. Apparatet skal placeres på en plan overflade.
De to forreste fødder kan justeres efter behov.
For at sikre, at apparatet står lodret, skal de to
forreste fødder drejes med eller mod uret, indtil
de er i fast kontakt med gulvet. Ved korrekt
justering af fødderne reduceres vibrationer og
støj (Fig. 4).
5. Se afsnittet "Rengøring og vedligeholdelse"
for at forberede apparatet til brug.
10

DA Betjeningsvejledning
6. Hvis du ønsker at installere to produkter ved
siden af hinanden, f.eks. et køleskab og en
fryser, anbefaler vi at købe et dekorationsudstyr,
der indeholder en lille måtte og en dekorativ del.
Måtten placeres på siden af det ene produkt for
at skabe et frit rum mellem produkterne. Den
dekorative del placeres mellem de to produkter
for at skjule det frie rum (Fig. 2).
Dekorationsudstyret er ikke en del af produktet,
men kan levers som ekstraudstyr.
Dus med dit apparat
(Fig. 1)
1 - Termostatkontrol og indvendigt lys
2 -
Flytbare glashylder
3 - Vandopsamler
4 -
Glashylde
5 - Grøntsagsskuffe
6 - Støtte til isterningbakke og
isterningbakke
7 - Rum til hurtigfrys
8 - Rum til at opbevare frossen mad
9 - Justerbare forreste ben
10 - Lågehylder
11 - Flaskehylde
12 - Ventilator
Forslag til placering af madvarer i
apparatet
Retningslinier for opnåelse af maksimal
opbevaring:
1. Køleskabsrummet er beregnet til kortvarig
opbevaring af friske mad- og drikkevarer.
2. Fryseafdelingen er forsynet med
og er egnet til frysning og opbevaring af
allerede frosne madvarer.
Anbefalingerne for opbevaring i
frysere, som det fremgår af
levnedsmiddelemballagen, bør altid følges.
3. Mejeriprodukter bør opbevares i det
koldeste sted i køleskabet.
4. Tilberedte retter bør opbevares i
tætsluttende beholdere.
5. Emballerede friskvarer kan opbevares på
hylderne. Friske frugter og grøntsager bør
opbevares i grøntsagsskuffer.
6. Flasker kan opbevares i dørhylder eller på
flaskehylden.
7. Fersk kød emballeres i polyethylenposer og
placeres på den koldeste plads i køleskabet.
Lad ikke kødsaften fra fersk kød at komme i
kontakt med andre madvaretyper. Af
sundhedshensyn bør fersk kød kun
opbevares i to til tre dage.
8. For at sikre maksimal effekt og uhindret
cirkulation af kold luft, bør de flytbare hylder ikke
dækkes med papir ellerandre materialer.
9. Opbevar ikke vegetabilske olier på
dørhylderne. Opbevar madvarer emballeret,
foliepakket eller tildækket. Rester af
konserves bør ikke opbevares i dåsen.
10. For at tage skufferne ud af fryserrummet,
følg vejledningen i Fig. 9.
Temperaturkontrol og -regulering
Driftstemperaturer kontrolleres af
termostatkontrollen (Fig. 5), der er placeret i
loftet af køleskabssektionen. Justeringerne
kan være fra MIN., 1 ... 6, MAKS., hvor maks.
er den koldeste position. Når apparatet
tændes for første gang, bør
termostatkontrollen justeres, således at den
gennemsnitlige temperatur efter 24 timer ikke
overstiger 5 g+5°C. Vi anbefaler, at
termostatkontrollen indstilles halvvejs mellem
MIN. og MAKS., og der kontrolleres, at den
ønskede temperatur opnås, dvs. at du mod
MAKS. får en koldere temperatur og omvendt.
Visse sektioner af køleskabet kan være
koldere og visse varmere (som f.eks.
grøntsagsskuffe og øverst i kabinettet). Dette
er helt normalt.
Den normale opbevaringstemperatur for din
fryser bør være -18 °C. Lavere temperaturer
kan opnås ved at justere termostatkontrollen
mod position MAKS.
Vi anbefaler, at du kontrollerer temperaturen
med et nøjagtigt termometer for at sikre, at
rummene til opbevaring holdes på den
ønskede temperatur. Husk at aflæse
temperaturen med det samme, da
termometerets temperatur vil stige meget
hurtigt, efter du tager det ud af fryseren.
Husk på, at der kommer kold luft ud, hver
gang lågen åbnes, og den indvendige
temperatur stiger. Derfor skal du aldrig
efterlade lågen åben, og du skal sørge for, at
den lukkes straks efter, at der er ilagt eller
fjernet madvarer.
11

DA Betjeningsvejledning
Før ibrugtagning
Den sidste kontrol
Inden du begynder at bruge apparatet, bør du
kontrollere at:
1. Fødderne er justeret, så apparatet står
fuldstændig plant.
2. Apparatet er tørt indeni og luften kan
cirkulere frit bag det.
3. Apparatet er rengjort sådan som anbefalet i
afsnittet "Rengøring og vedligeholdelse".
4. Stikket er tilsluttet til stikkontakten, og at
der er tændt for strømmen. Når døren åbnes,
vil det indvendige lys tændes.
Og bemærk at:
5. Der vil kunne høres en lyd, når
kompressoren starter. Kølevæsken og
luftarterne, der findes i kølesystemet, kan
også støje lidt, uanset om kompressoren
kører eller ej. Dette er helt normalt.
6. Oversiden af kabinet
tet kan være let bølget.
Dette er helt normalt og skyldes
produktionsprocessen, det er ikke en defekt.
7. Vi anbefaler, at termostatkontrollen
indstilles til midterpositionen, og at
temperaturen overvåges for at sikre, at
apparatet holder den ønskede
opbevaringstemperatur (se afsnittet
"Temperaturkontrol og –regulering").
8. Fyld ikke apparatet op umiddelbart efter at
have tænde tændt for det. Vent til den
korrekte opbevaringstemperatur er nået. Vi
anbefaler, at temperaturen kontrolleres med
et nøjagtigt termometer (se afsnittet
"Temperaturkontrol og -regulering").
Opbevaring af frostvarer
Din fryser er egnet til langtidsopbevaring af
varer, som købes frosne, og den kan også
anvendes til nedfrysning og opbevaring af
friske madvarer.
Undlad at åbne lågen i
tilfælde af strømudfald.
Frosne madvarer burde ikke tage skade, hvis
strømudfaldet varer mindre end 18 timer. Hvis
strømudfaldet varer længere, bør madvarerne
kontrolleres og enten spises med det samme
eller tilberedes og derefter genindfryses.
Frysning af friske madvarer
Ved at følge disse retningslinier, opnås de
bedste resultater.
Frys ikke for store mængder ad gangen.
Madvarernes kvalitet bevares bedst, hvis de
indfryses komplet og så hurtigt som muligt.
Overskrid ikke apparatets
indfrysningskapacitet pr døgn
Hvis varme madvarer lægges i fryseren, vil
det få kompressoren til at køre uafbrudt, indtil
madvarerne er dybfrosne. Dette kan føre til en
kortvarig forøget nedkøling af kølerummet.
Ved frysning af frisk mad skal
termostatkontrollen holdes på midter-position.
Små mængder mad på op til 1/2 kg kan fryses
uden at justere termostatkontrollen.
Fremstille isterninger
Fyld isterningbakken 3/4 med vand og sæt
den i fryseren. Hvis bakken fryser fast, løsnes
den med skaftet på en ske eller lignende; brug
aldrig skarpe redskaber som f.eks. knive eller
gafler.
Afrimning
A) Køleskabsrum
Køleskabsafdelingen afrimer automatisk.
Afrimningsvandet løber via afløbsslangen til
en opsamlingsbakke bag på apparatet (Fig.
6).
Under afrimning kan der dannes vanddråber
på køleskabets bagvæg, hvor der findes en
skjult fordamper. Det kan ske, at en del af
disse dråber forbliver på bagvæggen hvor de
fryser fast, så snart afrimningen er
tilendebragt. Brug ikke spidse eller skarpe
genstande som knive eller gafler til at fjerne
disse frosne dråber.
Hvis det på et tidspunkt sker, at optøet vand
ikke løber ud af opsamlingskanalen, bør det
kontrolleres, om drænslangen er blevet
tilstoppet af madpartikler.
12

DA Betjeningsvejledning
Drænrøret kan renses med en vatpind eller
lignende.
Kontrollér, at rørets ende hele tiden er i
opsamlingsbakken på kompressoren for at
forhindre, at der spildes vand på de elektriske
installationer eller på gulvet (Fig. 7).
B) Fryserrum
NO FROST afrimningen sker automatisk. Der
kræves ikke noget indgreb fra din side.
Vandet samles på kompressorbakken. Pga.
varmen fra kompressoren fordamper vandet.
Brug aldrig hårtørrer, elektriske varmeovne
eller lignende el-apparater til afrimning.
Afrimningsvandet, som samler sig i bunden af
fryseren, fjernes med en svamp. Efter
afrimningen tørres fryserens indersider
grundigt (Fig. 8). Sæt stikket i stikkontakten
og tænd for strømmen.
Advarsler!
Opbevar aldrig produkter, der indeholder en
brandfarlig drivgas (f.eks. dispensere,
sprayflasker osv. som eller eksplosionsfarlige
produkter.
Lad ikke bør børn lege med apparatet eller
pille ved knapperne.
Tilstop ikke beskyttelsen til fryserventilatoren,
hvis du vil sikre, at du opnår den bedste
mulige effekt af dit apparat
(Fig. 10).
Advarsel!
Dit apparat er udstyret med en
cirkulationsblæser, der er essentiel for
fryserens funktion. Sørg for, at blæseren ikke
er blokeret eller forringet af fødevarer eller
emballage. Blokering eller forringelse af
blæseren kan resultere i en forøgelse af den
indvendige frysertemperatur (Optøning).
Således sættes døre på plads
Fortsæt i numerisk rækkefølge (Fig. 12).
Udskiftning af den indvendige
lyspære
(Fig. 11)
Hvis lyspæren ikke virker, er den nem at
udskifte. Sørg først for, at køleskabet /
fryseren er taget ud af stikkontakten. Tag en
flad skruetrækker og hold den forsigtigt uden
at bruge vold i det venstre hul mellem
lampedækslet og det indvendige kabinet. Tryk
så skruetrækkerens håndtag forsigtigt til
venstre, indtil du ser, at dækslets venstre bolt
frigøres. Gentag denne fremgangsmåde på
det højre hul, men tryk nu skruetrækkerens
håndtag til højre. Når begge sider er løsnet,
kan dækslet nemt tages af.
Kontrollér herefter, at pæren er skruet korrekt
fast i fatningen. Sæt køleskabet ind i
kontakten. Hvis lyset fortsat ikke virker,
udskiftes pæren med en ny 15 W (maks.)
pære med E14 gevind. Reservepærer kan
købes i enhver el-installationsforretning.
Bortskaf forsigtigt den udbrændte pære med
det samme.
Når du har skiftet pæren, sættes dækslet
tilbage til den oprindelig position. Sørg for, at
dækslet lukkes korrekt.
13
