Gratz Pilates LADDER BARREL User manual

LADDER BARREL
Assembly Instructions

How to Assemble Your Ladder Barrel
What Comes in the Box
A. Ladder (x1)
B. Barrel (x1)
C. Top pole (x1)
With Rubber Ends (x2)
D. Screws (x2)
E. Black Knobs (x4)
STEP 1 - Remove Contents from Box
Place the long-side box down. Use the
scissors to carefully cut ties and open the
box. Remove the three packed bundles
from the box.
STEP 2 - Place the Top Pole on the Ladder
Locate the top pole. Remove the rubber end off one side of the pole (1). Insert the pole through the
top two holes of the ladder (2). Then align the holes of the top pole with the holes of the ladder by
aligning the two tape (3). Locate the 2 screws attached to the pole and use the Phillips screwdriver
to carefully tighten the two screws to fix the top pole to the ladder. Put the rubber end back (4).
IMPORTANT NOTE:
Gratz Industries is not responsible for any damages to the Ladder Barrel that is caused by improper opening, set up or installation. Please email customercar[email protected] for any inquiries.
What You Will Need:
Phillip
Screwdriver
Scissors 1/2” Wrench
OR Adjustable
Wrench
**DO NOT USE A KNIFE OR BLADE**
**DO NOT STAB**
**DRILL HIGHLY RECOMMENDED** 4
D
*included

How to Assemble Your Ladder Barrel - pg. 2
STEP 3 - Put Black Knobs on Barrel
Locate the 4 black knobs. Use 1/2” or adjustable wrench to loosen and remove the
4 nuts at the bottom of the barrel. Next, twist on the 4 black knobs to the bottom of the
barrel where you removed the nuts. Then adjust the distance of the ladder from the
barrel by loosening the 4 black knobs and evenly sliding the barrel away from the ladder.
STEP 4 - Prep for Use
IMPORTANT NOTE:
Gratz Industries is not responsible for any damages to the Ladder Barrel that is caused by improper opening, set up or installation. Please email customercar[email protected] for any inquiries.
To adjust the barrel:
Move the barrel using the bottom (near the knobs) not the top of the barrel to adjust. Prior to using, make sure the ladder is the
preferred distance away from the barrel and
all the black knobs are fully tightened.
Enjoy your Gratz Ladder Barrel!

Gratz recommends consulting a physician before starting any exercise program. This manual contains important assembly, safety, and
warranty information. Please read carefully before using your new equipment. USER ASSUMES ALL RISKS FOR IMPROPER CARE.
It is impossible to anticipate every potential issue that may arise while using this equipment, so Gratz makes no representation concerning
the safety of this equipment. For inexperienced or first-time users, we recommend this equipment be set up under the supervision of a trained
professional. Contact customer[email protected] or Pilates Pro Maintenance for assistance: [e-mail]
CAUTION Misuse or improper use of this equipment due to failure to read and
comply with all requirements and warnings could result in serious injury.
- USE ONLY PARTS AND ACCESSORIES PROVIDED BY
THE MANUFACTURER. DO NOT USE COMPONENTS
NOT APPROVED BY GRATZ PILATES.
- MAKE CERTAIN THAT THE EQUIPMENT IS OPERATED
ON A LEVEL SURFACE. KEEP AT LEAST 18IN OF SPACE
BETWEEN EQUIPMENT.
- BE SURE THAT ALL PARTS ARE FULLY TIGHTENED
BEFORE BEGINNING ANY EXERCISE.
- INSPECT THAT THE SPRINGS HAVE NO DEFECTS
SUCH AS CRACKS. IMMEDIATELY REQUEST
REPLACEMENT IF YOU SEE ANY DAMAGES.
- CONFIRM THAT NO TEARS ARE PRESENT IN THE VINYL
LEATHER STRAPS OR HANDLES. IMMEDIATELY REQUEST
REPLACEMENT IF NOTICED.
- USERS UNDER 18 SHOULD HAVE ADULT SUPERVISION.
- KEEP ANY LOOSE ITEMS OR CLOTHES CLEAR FROM
MOVING PARTS AT ALL TIME.
- IT IS THE BUYER’S RESPONSIBILITY TO SUPERVISE
OTHER USERS ON THE PROPER CARE AND USE OF THE
EQUIPMENT. GRATZ STRONGLY RECOMMENDS THAT
NEW USERS BE PROPERLY EVALUATED BEFORE USING
GRATZ EQUIPMENT.
WARNING: As with any exercise activity, the use of
equipment involves risk of injury, damage
and/or possibly death.
By choosing to use Gratz equipment, you and/or
your clients/patients/others assume responsibility for
that risk, not the people who sell, distribute and/or
manufacture this equipment.
Visit www.pilates-gratz.com to find complete
warranty, maintenance, and other assembly instructions.
RECOMMENDED USE AND SAFETY
