Gratz Pilates LADDER BARREL User manual

LADDER BARREL
Assembly Instructions

attention !
Gratz Pilates is not
responsible for any
damage to the ladder
barrel and equipment
that may happen by
person performing
installation improperly.
assembling your ladder barrel
These instructions will show you how to
assemble and set up your ladder barrel.
Please make sure you have all the items out
of the box listed below and you will need the
items listed on the following page to complete
assembly.
what comes in the box
A. (1) Ladder
B. (1) Barrel
C. (1) Top pole ( with (2) rubber ends )
D. (2) Screws
E. (4) Black knobs
?

E.
A.
D.
C. B.

what you will need
A. (1) scissors
B. (1) phillips screwdriver
C. (1) 1/2” wrench or adjustable wrench
A. (1) scissors
B. (1) phillips screwdriver
C. (1) 1/2” wrench or adjustable wrench

you will need
scissors
important:
if there is anything missing
or damaged from your box
please let us know right away
so that a remedy can be made
step 1 remove contents from box
- place box on side
- use scissors to carefully cut ties
- open box
- three packed bundles should be in box
with everything shown on page 1 & 2

step 2 place top pole on ladder
- locate top pole
- take rubber end off one side of pole
- insert pole through top two holes of
the ladder
- align the holes of the top pole with
the holes of the ladder
- locate (2) screws attached to the pole
- use phillips screwdriver to carefully
tighten the two screws to fix the top
pole to the ladder
- put the rubber end back on the
side of the top pole
you will need
phillips screwdriver

step 3 put black knobs on barrel
- locate the (4) black knobs
- use 1/2” or adjustable wrench to loosen
and remove the four nuts at the bottom of
the barrel
- twist on the (4) black knobs to the bottom
of the barrel where you removed the nuts
- adjust the distance of the ladder from the
barrel by loosening the (4) black knobs and
evenly sliding the barrel away from the ladder
Note: works best if you kneel behind the barrel
while moving it away from the ladder
- once the barrel is in the proper position
tighten (4) black knobs until secure
you will need
1/2” wrench

step 4 prep for use
- prior to using make sure ladder is
preferred distance away from the
barrel and all the black knobs are
fully tightened
- enjoy your Gratz Ladder Barrel
