Grillo MD22 N User manual

02466-16
MD22 N
OPERATOR'S MANUAL
MANUALE DELL'OPERATORE
MANUEL D'UTILISATION
BEDIENUNGSANLEITUNG
MANUAL DE INSTRUCCIONES

SUMMARY
Safety rules
Informations and warnings
Instructions :
Warnings 6
Identification and servicing 8
Technical specifications 9
Instructions for use 9
Maintenance and lubrication
Pictures 62
EC Declaration of Conformity
INDICE
Norme antinfortunistiche
Etichette e avvertenze
Istruzioni :
Avvertenze 7
Identificazione e assistenza 8
Caratteristiche tecniche 9
Istruzioni d’uso 20
Manutenzione e lubrificazione 22
Figure 62
Certificato di Conformità CE
INDEX
Règles de sécurité
Étiquettes et mise en garde
Instructions :
Mises en garde 27
Identification et assistance 29
Caractéristiques techniques 30
Mode d’emploi 30
Maintenance et lubrification 33
Illustrations 62
Certificat de Conformité CE
INHALTSÜBERSICHT
Sicherheitsvorschriften
Etiketten und Warnungen
Anleitung:
Sicherheitsrelevante Hinweise 39
Identifikation der Maschine und Kundendienst 4
Technische Daten 42
Inbetriebnahme der Maschine 42
Wartung und Schmierung 45
Abbildungsverzeichnis 62
EG-Konformitätserklärung
ÍNDICE
Normas de seguridad
Etiquetas y advertencias
Instrucciones:
Advertencias 5
Identificación y asistencia 53
Características técnicas 53
Puesta en servicio de la máquina 54
Mantenimiento y lubricación 57
Ìndice de ilustraciones 62
Certificado de conformidad CE - Niveles de ruido y vibración
-
i
-

SAFETY SYMBOLS - SIMBOLOGIA PER LA SICUREZZA - SYMBOLOGIE POUR LA SECURITE – SICHERHEITSSYMBOLE-
SIMBOLOGÍA DE SEGURIDAD
OPEN MANUAL- means that ou must read the operator's manual ver carefull .
MANUALE APERTO - significa che dovete leggere attentamente il manuale di uso e manutenzione.
MANUEL OUVERT – signifie qu'il faut lire avec attention le présent manuel.
OFFENES HANDBUCH – bedeutet, dass Sie die Gebrauchs- und Wartungsanleitung aufmerksam durchlesen müssen.
MANUAL ABIERTO – es decir que ha que leer mu atentamente el manual del operador.
CAUTION! - means that ou have to pa particular attention to the operation ou have to carr out, in particular if there is the
indication “DANGER”.
ATTENZIONE! - significa che dovete porre particolare attenzione all’operazione che dovete effettuare, in particolare se vi è anche
l’indicazione di “Pericolo”.
ATTENTION! - signifie qu'il faut faire particulière attention dans l'opération que vous allez faire, en particulier s'il a aussi
l'indication “DANGER”.
VORSICHT! - bedeutet, dass Sie besondere Aufmerksamkeit beim Durchführen des Vorgangs haben müssen, insbesondere wenn
auch der Hinweis “GEFAHR” aufgeführt ist.
ATENCIÓN! - es decir que ha que poner ma or atención en la operación a ejecutar si, en particular cuando ha también la
indicación “Peligro”.
INTERDICTION, YOU MUST NOT DO THAT! - means that it is absolutel forbidden to carr out the operations reported under this
s mbol because the could lead to mortal danger.
DIVIETO, NON FARE! - significa che non dovete assolutamente fare le operazioni riportate sotto questo simbolo, potrebbe
comportare un pericolo mortale.
INTERDICTION, NE PAS FAIRE! - signifie qu'il est absolument interdit d' effectuer les opérations reportées sous cette indication,
car elles pourraient conduire au danger de mort.
VERBOT, strengstens untersagt! - bedeutet, dass der Vorgang unter diesem S mbol absolut nicht durchgeführt werden darf, da er
zur einer lebensgefährlichen Situation führen könnte.
PROHIBICIÓN, NO LO HAGAN! - es decir que no ha que hacer absolutamente las operaciones bajo este símbolo, podría
comportar un peligro mortal.
NOTE, ou have to pa particular attention to the note put next to this s mbol
NOTA, dovete porre particolare attenzione alla nota posta accanto a questo simbolo.
NOTE, il faut faire attention particulière à la note mise à côté de ce s mbole.
ANMERKUNG, besondere Aufmerksamkeit muss auf die Anmerkungen neben diesem S mbol gelenkt werden.
NOTA, ha que poner atención particular en la nota puesta a lado de este símbolo.
You must not repair nor lubricate the machine with moving parts or with the engine put on.
Non riparare o lubrificare la macchina con organi in movimento o motore acceso
Ne pas réparer ou lubrifier la machine avec des parties en mouvement ou à moteur en marche.
Niemals bei bewegenden Objekten oder bei laufendem Motor Reparationen oder Einschmierungen durchführen.
No reparar ni lubrificar la máquina con órganos en movimiento o motor en marcha.
You must not smoke, light matches or lift flames, trigger frames nor cause sparks.
Vietato fumare, accendere fiammiferi o fiamme, lasciare fiamme libere o creare scintille.
Il est interdit de fumer, allumer des allumettes ou du feu, laisser des flammes libres ou de causer des étincelles.
Es ist untersagt zu Rauchen, Streichhölzer oder Feuer anzuzünden, Flammen auslösen oder Funken verursachen.
Prohibido fumar, encender cerillas o fuego, dejar llamas o crear chispas.
Use personal protective equipment.
Utilizzare mezzi di protezione individuali.
Utilisez l'équipement de protection individuelle.
Individuelle Schutzausrüstung benutzen.
Utilizar dispositivos de protección individual.

Take special care not to touch hot parts of the engine.
Prestate particolare attenzione a non entrare in contatto con parti surriscaldate del motore.
Veiller tout particulièrement à ne pas toucher des éléments surchauffés du moteur.
Achtung – keine heißen Motorteile berühren!
No tocar partes recalentadas del motor.
Tome muito cuidado para não entrar em contacto com as partes aquecidas do motor
Engine exhaust fumes can cause sickness or death. If it is necessary to run an engine in an
enclosed area use an exhaust pipe extension to remove the fumes. Always try to work in a
well ventilated area.
I gas di scarico possono causare malanni o morte. e è necessario mettere in moto un
motore in uno spazio chiuso, usare una prolunga tubo di scarico per far uscire il fumo.
Lavorare in una zona ben ventilata.
L’exhalation des gaz d’échappement peut être cause d’intoxication ou de mort. S’il est
vraiment nécessaire d’allumer le moteur à l’intérieur appliquer au tuyau d’échappement un
autre tuyau extensible pour permettre la sortie des gaz. Il est toujours mieux de travailler en
plein air.
Auspuffgase können Übelkeit oder Tod verursachen. Wenn es notwendig ist, einen Motor in
einem geschlossenen Raum laufen zu lassen, benützen ie eine Verlängerung, um das
Auspuffgas abzuleiten. Versuchen ie immer in einem gut belüfteten Raum zu arbeiten.
Los gases de escape pueden provocar enfermedades o muerte. De tener que poner en
marcha un motor en un espacio cerrado usar una prolongación del tubo de escape para que
salga el humo. Trabajar en una zona bien ventilada.
Os gases de escape podem causar danos ou morte. Caso seja necessário fazer com que o
motor funcione num espaço fechado, utilize uma extensão para o tubo de escape que os
fumos sejam expulso para o exterior. Trabalhe numa área bem ventilada.
Caution! Never touch moving pulleys or belts. They can be very dangerous. Never do
maintenance with engine running.
Attenzione! Non toccare mai pulegge o cinghie in movimento, creano gravi danni alla
persona. Non fare manutenzione col motore in moto.
Attention! Ne jamais toucher ni poulies ni courroies en mouvement elles peuvent provoquer
des accidents aux personnes. Ne pas faire l’entretien quand le moteur est en marche.
Vorsicht! Nie laufende Riemenscheiben oder Treibriemen anfassen, da es gefährlich ist. Nie
bei laufendem Motor Instandhaltung machen.
¡Atención! No tocar jamás poleas o correas en movimiento porque pueden crear graves
daños a la persona. No efectuar el mantenimiento con el motor en marcha.
Atenção! Nunca toque nas polias ou correias em movimento devido ao alto risco de
ferimentos. Nunca faça a manutenção da máquina com o motor ligado.
A burst which separates the tyre from the rim parts can cause serious injury or death.
La separazione fra pneumatico e cerchione, causata dall’esplosione del pneumatico, può
provocare serie ferite o addirittura la morte.
La séparation entre le pneu et la jante provoquée par l’explosion d’une roue peut causer des
dommages blessures ou la mort.
Die Trennung der Räder von den Felgen durch Explosion kann schwere Verletzungen oder
den Tod verursachen.
La separación entre el neumático y la llanta producida por la explosión del neumático puede
provocar graves herida e incluso la muerte.
A separação entre o pneumático e o aro, provocada pela explosão do pneumático, pode
causar graves ferimentos ou até mesmo a morte.

Prevent battery explosions: keep sparks lighted matches and open flames away from the top
of the battery. Battery gas can explode.
Per prevenire l’esplosione della batteria, tenete scintille, fiammiferi accesi e fiamme lontani
dalla stessa. Il gas della batteria può esplodere.
Prévenir l’explosion de la batterie: tenir les étincelles les allumettes et le feu loin de la
batterie. Le gaz de la batterie peut exploser.
Vorbeugung der Batterie-Explosion. Entfernen ie Funken, Zündhölzer und Flammen von
der Batterie. Das Batteriegas kann explodieren.
Para prevenir la explosión de la batería mantener chispas cerillas encendidas y llamas lejos
de la misma. El gas de la batería puede explotar.
Para prevenir explosão da bateria ter centelhas, fósforos acendido e chamas longe da
mesma. O gás da bateria poderia explodir.
Handle fuel with care it is highly flammable: Do not refuel machine while smoking when
machine is near an open flame or sparks or when the engine is running. Stop the engine.
Maneggiare il carburante con cura, è altamente infiammabile; non fate rifornimento mentre
fumate, o vicino a fiamme o scintille, o quando il motore è acceso.
Manier avec soin le carburant car c’est très inflammable. Ne pas remplir le réservoir si vous
êtes en train de fumer ou pendant que la machine est près du feu ou d’étincelles ou encore
pendant que la machine travaille. Arrêter le moteur.
Treibstoff vorsichtig handhaben, da er sehr entzündbar ist: beim Tanken nicht rauchen.
Nicht tanken, wenn die Maschine in der Nähe von Flammen oder Funken ist oder wenn der
Motor läuft. Immer den Motor abschalten.
Manejar el combustible con cuidado porque es sumamente inflamable; no repostar mientras
se fuma o cerca de llamas o chispas o cuando el motor está encendido.
Manuseie o carburante com cuidado, pois este è altamente inflamável; não fume durante o
abastecimento da máquina ou enquanto o motor estiver ligado, não o aproximado de chama
ou de faíscas.
Rotating blades are dangerous. Protect children and prevent accidents.
Le lame in movimento sono pericolose. Proteggete i bambini e prevenite gli incidenti.
Les lames en rotation sont dangereuses. Protéger les enfants et prévenir les accidents.
Arbeitende Messer sind gefährlich, Kinder schützen und Unfälle vorbeugen.
Las cuchillas en movimiento son peligrosas proteger a los niños y prevenir los accidentes.
As facas em movimento são perigosas. Proteger as crianças e prevenir acidentes.
Sulphuric acid in battery electrolyte is poisonous. It is strong enough to burn skin eat holes
in clothing and cause blindness if it gets in contact with the eyes.
L’acido solforico della batteria è velenoso. È in grado di causare bruciature alla pelle, bucare
vestiti e causare cecità se arriva negli occhi.
L’acide sulfurique de la batterie est toxique. Il peut causer des brûlures à la peau
endommager les vêtements et peut aussi causer cécité.
äure der Batterie ist giftig. ie kann die Haut verbrennen, Löcher in die Kleidung machen
und Blindheit verursachen.
El ácido sulfúreo de la batería es venenoso puede provocar quemaduras en la piel agujar la
ropa y provocar ceguera si llega a los ojos.
O acido sulfúrico e tóxico. Pode ser causa de queimadura da pele, furar roupa e provocar
cegueira, no caso chegarem em contacto com os olhos.
Avoid tipping. Do not drive where machine could slip or tip. Stay alert for holes and other
hidden objects.
Evitate le scivolate. Non guidate dove la macchina potrebbe scivolare o inclinarsi. Attenzione
a buche o ad oggetti nascosti.
Éviter les pentes. Ne pas conduire la machine où elle pourrait glisser ou se renverser. Faire
attention aux trous ou à tout autre obstacle caché.
Nicht dort fahren wo die Maschine rutschen könnte. Vorsicht bei Löchern oder versteckten
Gegenständen.
Evitar patinazos. No conducir donde la máquina pueda patinar o inclinarse. Cuidado con los
baches o con objetos escondidos.
Evitar deslizamentos. Não dirija em lugares onde a maquina poderia deslizar. Ter cuidado a
buracos e objetos escondidos.

DANGER! Machine roll-over: Do not use this machine on slopes greater than 17° (30%).
PERICOLO! Ribaltamento della macchina. Non usare questa macchina su pendii superiori ai
17° (30%).
DANGER! Renversement de la machine. Ne pas utiliser cette machine sur des pentes
supérieures à 17° (30%).
GEFAHR! Umstürzen der Maschine. Die Maschine nicht an Hängen mit einer Neigung über 17°
(30%) einsetzen.
¡PELIGRO! Volcado de la máquina. No utilizar esta máquina en pendientes superiores a 17°
(30%).
PERIGO! Revirado da máquina. Não use essa máquina em inclinações além de 17° (30%).
WARNING! SHARP PARTS. Keep hands and feet away. Do not operate the mower over
gravel or foreign bodies which may be sucked up and ejected by the blades generating a
danger. Keep people away. Remove the key and read the instruction manual before
attempting to carry out any maintenance or repairs to the machine.
ATTENZIONE! ORGANO TAGLIENTE. Tenere lontano mani e piedi. Non lavorare col
rasaerba sopra alla ghiaia o corpi estranei che possono essere aspirati e centrifugati dalle
lame risultando molto pericolosi, tenere lontano le persone. Togliere la chiave e leggere le
istruzioni prima di effettuare qualsiasi operazione di manutenzione e riparazione.
ATTENTION! ORGANE TRANCHANT. Éloigner les mains et les pieds. Ne pas utiliser la
tondeuse sur le gravier ou sur des corps qui peuvent être aspirés et centrifugés par les
lames et devenir très dangereux. Les personnes doivent se trouver à une certaine distance.
Enlever la clé et lire les instructions avant toute opération de maintenance et de réparation.
ACHTUNG! CHARFE KLINGEN. Hände und Füße fernhalten. Beim Mähen nicht über
chotter, teine oder andere Fremdkörper fahren, da diese durch die Drehbewegung der
Messer angesaugt und weggeschleudert werden können (Verletzungsgefahr). Nicht in der
Nähe von anderen Personen mähen. Vor jedem Wartungs- bzw. Reparatureingriff den
tartschlüssel abziehen und die Gebrauchsanleitung durchlesen.
¡PELIGRO! ÓRGANO CORTANTE. Mantener alejados los pies y las manos. No limpiar la
herramienta con el motor en marcha. ¡Peligro! Expulsión de objetos: mantener alejadas a las
personas. Atención: quitar la llave y leer las instrucciones antes de efectuar cualquier
operación de mantenimiento o reparación.
ATENÇÃO! Órgão cortante. Ficar longe com pés e mãos. Não trabalhar com a máquina
sobre cascalho ou objetos que podem ser aspirados e centrifugados gerando perigo,
manter-se longe das pessoas. Tirar a chave de ignição e ler as instruções antes de efetuar
qualquer operação de reparo ou serviço.

1
2
3
4
5
6
7
8
9
10
11

LABEL LEGEND – LEGENDA DECALCOMANIE – LEGENDE AUTOCOLLANTS –
AUFKLEBERLEGENDE – LEYENDA ETIQUETAS
ENGLISH ITALIANO FRANÇAIS
1. Cutting height
2. Parking brake
3. Grease plan
4. Differential lock
5. Pedal brake
6. A EN ION, DANGER!
horoughly read the operator's
manual.
7. Noise level
8. DANGER! Machine roll-over: do
not use this machine on slopes
higher than 20° - 36%
9. DANGER! CU ING PAR S: keep
your hands and feet away.
10. hrottle lever min./max.
11. Fast and slow speed
1. Altezza di taglio
2. Freno di parcheggio
3. Punti di lubrificazione
4. Bloccaggio differenziale
5. Freno di servizio
6. A ENZIONE, PERICOLO! Leggere
attentamente il manuale d'istruzioni.
7. Livello sonoro
8. PERICOLO! Ribaltamento della
macchina: non usare questa macchina
su pendii superiori a 20° (36%)
9. PERICOLO, ORGANI AGLIEN I!
enere lontani mani e piedi.
10. Acceleratore min./max.
11. Lenta/veloce
1. Hauteur de coupe
2. Frein de parking
3. Points de graissage
4. Blocage du différentiel
5. Frein à pédale
6. A EN ION, DANGER! Lire
attentivement le manuel de
l'opérateur.
7. Niveau sonore
8. DANGER! La machine peut se
renverser, ne pas la utiliser sur des
pentes majeures de 20° (36%)
9. DANGER, ORGANS
RANCHAN S, tenir loin mains et
pieds.
10. Accélérateur min./max.
12. Lentes/rapides
DEUTSCH ESPAÑOL
1. Schnitthöheneinstellung
2. Feststellbremse
3. Schmierpunkte
4. Differentialsperre ù
5. Betriebsbremse
6. ACH UNG, GEFAHR! Die
Bedienungsanleitung aufmerksam
durchlesen
7. Schallpegel
8. GEFAHR! Die Maschine auf keinen
Fall an Hängen über 20° (36%)
einsetzen, da sie umstürzen könnte
9. GEFAHR, SCHARFE KLINGEN!
Hände und Füße fernhalten
10. Gaszug Min. / Max.
11. Langsam / schnell
1. Altura de corte
2. Freno de aparcamiento
3. Puntos de lubricación
4. Bloqueo del diferencial
5. Freno de servicio
6. A ENCIÓN.Peligro! Leer atentamente
el manual de instrucciones
7. Nivel de ruido
8. PELIGRO! Vuelco de la máquina: no
cortar nunca sobre pendientes de
ángulos superiores a 20°(36%).
9. PELIGRO. ELEMEN OS
COR AN ES!
Mantener alejados las manos y los pies
10. Acelerador min./max.
11. Lenta/Veloz

MD22 N/ Translation of the original instructions
RIDE-ON LAWNMOWER
WITH TWIN-FUNCTION CUTTING DECK
MD22 N
Dear Customer,
Thank you for choosing the Grillo MD22 N. We hope that this new ri e-on mower will meet your
requirements perfectly. To obtain the best possible performance please carefully rea an follow the
instructions given in this manual. This will enable you to obtain first class results from your mower an
will prevent any avoi able expense. Please look after this manual which shoul always be kept with
the machine.
GENERAL DESCRIPTION AND INTENDED USE
The Grillo MD22 N is a ri e-on mower with a ual function cutter eck which is esigne to mow
grass on even groun or slopes, ( epen ing on the severity of the slope)
WARNING! Before start ng the eng ne, read th s manual carefully. The
follow ng warn ngs are very mportant n ensur ng safety!
WARNINGS
Always exercise caution to prevent acci ents. Before using the mower carefully rea the following
instructions. The action of this lawnmower coul cause injury or amage if the equipment is not use
in a careful an controlle way. Rea , un erstan an follow all instructions in this manual to prevent
such acci ents:
1) Rea the instructions carefully before starting the engine.
2) Pay particular attention to the warning an safety labels positione aroun the mower.
3) Make sure other people are thoroughly familiar with these instructions before allowing them to
use the mower.
4) Whilst mowing always wear substantial footwear an long trousers, gloves, boots an protective
glasses.
5) Wear a suitable protective evice such as earplugs. Lou noise can cause impairment or loss of
hearing.
6) Before commencement of mowing, make sure there are neither people, especially chil ren, nor
pets in the mowing area.
7) Use caution when reversing, make sure there are no people or obstacles in the way.
8) Clear the mowing area of any objects that might be thrown. Before mowing i entify potential
obstacles an remove them.
9) After striking a foreign object, inspect the mower for amage an make repairs before restarting
an operating the equipment.
10) Before ismounting the mower, switch off the engine, turn off the PTO, remove the ignition key
an lower the cutting eck to its lowest position.
11) Drive slowly along uneven paths.
12) Machine spee shoul be kept low on slopes.
13) Machine spee shoul be kept low uring tight turns.
14) The operator or user is responsible for acci ents or hazar s occurring to other people or their
property.
15) Replace amage , ba ly worn or missing bla es.
16) Use only accessories an attachments approve by the manufacturer of this machine.
17) Mow only in aylight or in goo artificial light.
18) Store fuel in containers specifically esigne for this purpose.
19) Watch out for traffic when mowing near roa ways.
20) Allow the engine to cool before storing in any enclosure.
21) Do not operate the machine when tire or un er the influence of rugs or alcohol.
22) If fuel is spilt, o not attempt to start the engine but move the machine away from the area of
spillage an avoi creating any source of ignition until any fuel vapours have issipate .
6

MD22 N/ Translation of the original instructions
23) Never mo ify or isassemble the safety evices.
24) Do not change the engine governor settings or over rev the engine.
25) Do not rest heavy loa s on the seat, the starter safety evice coul become isengage .
26) Before servicing or cleaning the mower or any attachment, switch off the engine.
27) Never allow anyone to check the machine whilst you are seate at the controls with the engine
running.
IMPROPER USE TO BE AVOIDED
28) Do not carry passengers.
29) Never allow untraine people or un er-age chil ren to operate the machine: its use is prohibite
to minors un er 16 years ol .
30) Do not operate the mower near rop-offs, itches or embankments. The machine coul su enly
roll over if the tyres lose traction. Use care when mowing on wet grass an on slopes, tyres coul
lose traction an the machine coul consequently roll over.
31) Replace faulty silencers.
FURTHER SAFETY RULES
The above mentione warnings coul not possibly be enough to avoi all risks, if the operator oes
not use the mower as instructe . Therefore, we kin ly ask you to follow these a itional safety rules
outline below:
32) Rotating bla es are highly angerous, keep han s an feet away from the mower eck.
33) Use care when reversing.
34) Do not stop or start su enly when going up or ownhill.
35) A fuel before starting the engine. Never remove the cap of the fuel tank or a fuel whilst the
engine is running or when the engine is hot. Replace all fuel tank an container caps securely.
36) If the fuel tank has to be raine , this shoul be one out oors.
37) Do not operate the lawnmower on gravel which coul be sucke up an rawn into the bla e,
becoming therefore becoming very angerous.
38) If you have chil ren, hi e the ignition key after using the mower.
39) CAUTION: to avoi the risk of fire, keep the engine compartment, exhaust, ischarge outlets,
battery, tank area an fuel pipes free from grass, leaves, irt etc.
40) Never store the equipment with fuel in the tank insi e a buil ing where fumes coul reach an
open flame or spark.
Remove the attachment, turn off the engine an isconnect the spark plugs:
a) before clean ng obstructed po nts.
b) before check ng or repa r ng the lawnmower.
c) when the mach ne h ts a fore gn body (check the mower deck to see f t s damaged and
make repa rs before you operate).
d) f abnormal v brat on occurs, stop and nspect the mach ne. Contact your nearest
author sed serv ce centre f you need help.
7

MD22 N/ Translation of the original instructions
IDENTIFICATION AND SERVICING
The mower MD22 N is equippe with a label
in icating its serial number an is locate on the
mowers steering column.
TECHNICAL ASSISTANCE
This manual provi es instructions for the use an basic maintenance of the mower the operator can
carry out themselves. For operations not escribe in this manual, contact you nearest authorise
Grillo ealer.
SPARE PARTS
Only use original spare parts. These are the only parts that ensure safety an interchangeability.
Always state the machine’s serial number an the co e number of the part to be replace when
or ering spare parts. For engine parts, follow the in ications given in the specific manual.
WARRANTY
The guarantee is given in compliance with the current law. The ealer will give the customer a copy of
the registration car of the mower, which they will print from the Grillo website. For the engine the
guarantee of the relative manufacturer will apply .
RECOMMENDED LIST OF SPARE PARTS TO BE KEPT IN STORE
2 x mowing bla es
2 x bla e screws
2 x bla e screw nuts
1 x set of belts
1 x engine air filter
1 x engine oil filter
1 x throttle cable
2 x fuses
8

MD22 N/ Translation of the original instructions
TECHNICAL SPECIFICATIONS
ENGINE: - B&S INTEK 7220 PROFESSIONAL SERIES OHV 656 cm³ 18HP twin-cylin er petrol.
STARTER: electric with 12V battery.
FUEL TANK: 7 Litres – RESERVE: 1 litre.
GEARBOX: hy rostatic transmission fitte with a ifferential.
DIFFERENTIAL: on the rear wheels via pe al control.
STEERING RADIUS: 48 cm.
CLUTCH: electromagnetic with P.T.O an bla e brake.
SPEED: continuously variable from 0 to 10,5 km/h, reverse spee from 0 to 6 km/h.
WHEELS: front TURF TYRES 15×6.00-6; rear TURF TYRES: 20x 10.00-8.
BRAKES: pe al operate front wheel brakes – emergency an parking brake on the rear wheels via
lever control.
SEAT: high-comfort, sprung an a justable seat, equippe with armrests an roll-bar.
CUTTER DECK: rear ischarge or mulching via a “Quick Shift” lever.
CUTTING SYSTEM: 3 rotating bla es.
CUTTING WIDTH: 110 cm (±43’’).
CUTTING HEIGHT: continuously a justable from 25 to 110 mm (±0.6’’ to 4’’).
APPROX HOURLY CUTTING CAPACITY: 8.500 m2/h (± 2 acres per hour)
STANDARD FEATURE: tow hitch.
ATTACHMENTS: front an rear TURF TYPE TYRES.
WEIGHT: 315 kg (±694 lb)
SIZE: Length: 1940 mm – W dth: 1110 mm – He ght: 980 mm
INSTRUCTIONS FOR USE
1) Check that the machine has not been amage uring transport.
2) Check the engine oil level (fig. 4) an the hy rostatic transmission oil level (fig. 10).
3) Check the tyre pressure: 1 BAR front wheels 15X6.00-6 – 1 BAR rear wheels 20X10.00-8
4) Check the battery voltage (fig. 21), it must be at least 12 Volts. Charge if necessary.
IMPORTANT: During assembly take care not to reverse the polarity of the battery.
5) Fix the steering wheel taking care to insert the key properly an to tighten the bolt correctly
(tightening torque 2 KgF.m [20 Nm]).
6) Fit the roll-bar.
RUNNING IN – CAUTION!!
Change both the engine oil an filter after the first 20 working hours. Check that there are no oil leaks
or loose screws, especially those fixing the bla es an the steering.
BEFORE STARTING THE ENGINE
Before starting the engine, always check that:
– the forwar lever is in the i le position (fig. 3, n. 2);
– the engine oil level is correct (fig. 4);
– the engine cooling intake gri s are clean (fig. 4);
– the air filter is clean (fig. 7.
– the mower eck is clean;
– the hy raulic transmission fins are clean (fig. 6);
9

MD22 N/ Translation of the original instructions
– the bla es are sharp an firmly fastene in place;
– the bolt in the centre of the bla e hub is safely tightene (fig. 8, n. 3)
– the oil in the hy raulic axle reaches the bottom e ge of the steel strap of the tank (fig. 10);
Fill the fuel tank using a funnel with a very fine filter. A just the seat by using the lever (fig. 2, A - B).
PUTTING THE MACHINE INTO SERVICE
STARTING THE ENGINE
– Push the throttle half way in (fig. 3, n. 5)
– If the engine is col , use the choke (fig. 3, n. 6). Turn the ignition key (fig. 1, n. 1).
– Once the engine has starte , turn off the choke an wait a few minutes to allow the engine to warm
up.
IMPORTANT: When travelling with the mower, keep the mower eck at the maximum height setting
(fig. 2, n. 8, pos. 6).
SWITCHING ON THE HEADLIGHT
To switch on the hea light, put the ignition key in the secon position (fig. 15, A). IMPORTANT: use
the hea light only when the engine is running to avoi battery ischarge.
STARTING WORK
– Choose the cutting height by means of the lever (fig. 2, no.8). accelerate the engine to approx half
throttle an engage the cutter bla es via the switch on the ashboar (fig.1, no. 6). Gently operate the
forwar lever (fig. 3, n. 2) an start mowing. To stop, move the forwar lever back into the stop
position. The forwar lever returns back automatically to the stop position when pressing the brake
pe al (fig. 1, n. 4).
– The lever (fig. 3, n. 2) is also use to reverse. When it is move back, the machine moves
backwar s; always operate it gently. When this lever is release , it returns automatically to the neutral
position.
FRONT BRAKE
The front brake (fig. 1, n. 4) must be use only as an emergency brake when riving ownhill to avoi
the slipping of the machine. If use together with the ifferential lock, the machine is much stea ier
particularly on slopes. Un er normal circumstances just use the forwar lever to slow own an
brake. To a just the cables, use the a justing screws (fig. 24). The forwar lever comes back
automatically into its stop position by operating the brake pe al.
PARKING BRAKE
The parking brake is engage by moving upwar s an then locking the lever which is situate un er
the steering wheel (fig. 1, n. 7). To a just the parking brake, use the a justing screw (fig. 24). If the
operator moves the forwar lever when the parking brake is engage , a warning buzzer will soun .
DIFFERENTIAL LOCK
Press the ifferential lock pe al (fig. 1, n. 5) if the rive wheels start to slip. It is also recommen e to
use the ifferential lock when riving ownhill an on slopes to ensure groun a herence of both rear
rive wheels. CAUTION: Do not use the ifferential lock when turning.
HOUR METER
The machine is equippe with an hour meter which has three ifferent functions:
1) It always shows the no. of hours worke , even when the key is not inserte .
2) It isplays the no. of hours to the next engine oil change (OIL CHANGE IN... HS). The first oil
change must be carrie out after the first 20 working hours than every 100 working hours. The
in icator “OIL CHANGE” flashes automatically when it is necessary to change the oil.
3) It isplays the no. of hours to the next lubrication (LUBE IN... HS). Lubrication must be carrie out
every 40 working hours. The in icator “LUBE” flashes automatically when lubrication must be carrie
out.
10

MD22 N/ Translation of the original instructions
By epressing the white button, you can choose the type of function to be isplaye on the hour
meter.
4) To reset the hour meter after the engine oil change or after lubrication procee as follows:
Push the button until the relative alarm will flash (OIL CHANGE IN... HS or LUBE IN... HS). Then keep
the button pushe for 6 secon s until the alarm stops flashing.
TIPS FOR EFFICIENT USE
1) Never strain the engine: when fumes are emitte from the exhaust it means that it is being
straine . Slow own.
2) Do not leave the machine out in the rain.
3) Frequently sharpen the mower bla es: the cut will be better an the engine will not be straine too
much.
4) Check the groun before mowing to make sure that there are no stones, sticks or foreign bo ies.
5) Keep the engine at max.rpm uring mowing, a just the spee accor ing to the height of the grass.
6) Keep the gr ds above the eng ne and the cool ng f ns of the hydraul c motor (f g. 4 – 6)
clean.
CUTTING POSITIONS
To choose the cutting height use the lever (fig. 2, no. 8). The eck can be set in 6 ifferent cutting
positions from 25 to 105 mm. In case of uneven groun , humps or ips, put the mower eck in the
highest cutting position to avoi amage to the bla es.
CUTTING ON SLOPES
Slopes must, wherever possible, be mown in the up/ own irection, paying strict attention when
turning that the wheels uphill, o not strike obstacles (stones, branches, roots, etc.) which might
cause the machine to overturn, or lea to loss of control. Assess the con itions an pay attention if
the groun an grass are amp since the machine might slip. Downhill, set off at low spee an o
not pass over ry or cut grass since the wheels may lose grip. Remember that if you engage the
ifferential lock an possibly the front emergency brake (fig. 1, n. 4) the machine is stea ier.
INTERVENTION OF SAFETY DEVICES
The engine stops when:
– The operator gets up from the seat an the parking brake is not engage .
The engine oes not start if:
– The bla e is engage .
– Nobo y is sitting in the river’s seat an the parking brake is not engage .
– The forwar lever is not in STOP position.
MAINTENANCE AND LUBRICATION
CAUTION!
- D sconnect the plug before perform ng any clean ng, ma ntenance or repa r operat on.
Always wear su table cloth ng and work ng gloves.
- When the mach ne or part of t s l fted to carry out ma ntenance operat ons, always
remember to use su table f x ng tools such as holders and safety locks.
- When carry ng out ma ntenance operat ons and/or when the mach ne s t lted w thout safety
locks or supports, never leave t unguarded n places where nexper enced people and
ch ldren could have easy access to t.
- Protect the env ronment: carefully d spose of used o ls, petrol and any other pollutant
product!
- Effect ve ma ntenance and correct lubr cat on help to keep the mach ne fully eff c ent.
ENGINE
For the lubrication intervals, follow the instructions provi e in the engine manual. Engine o l must be
changed after the f rst 20 work ng hours, and then every 100 hours or every season, together
11

MD22 N/ Translation of the original instructions
w th the o l f lter (f g. 9 – o l dra n plug > use a counter wrench for the f x ng part). Replace the
engine oil filter (fig. 5, A). The first precaution is to ensure that the engine is correctly service with the
air filter, cooling fins an cylin er hea clean an the oil at the correct level. Check the air filter every
4 hours, or even more often in very usty environments. Check the engine cooling intake gri (fig. 4,
A).
HYDROSTATIC AXLE
Check the oil level in the tank when the engine is col : it must be un er the bottom e ge of the steel
strap of the tank (fig. 10). Regularly clean the hy rostatic transmission cooling fans, every 4 working
hours in summer when con itions are very usty (fig. 6). Replace oil after the first 50 working hours,
then every 200 hours. Use 20W50 engine oil, quantity: 2.5 litres. To replace the oil, follow the
instructions below:
1) remove the two plugs (fig. 6, A-B)
2) remove the oil filter plug (fig. 12) an check the filter
3) unscrew tank cap (fig. 10, B)
4) unscrew the cap marke “Gear Chamber” (fig. 11)
5) a oil in position (fig. 10, B). Replace the cap marke “Gear Chamber” when oil comes out.
6) make sure the oil level in the hy raulic axle reaches the bottom e ge of the steel strap of the
tank (fig. 10, A).
FRONT WHEEL AXLE
Grease the wheel pivot pins every 20 hours. Lubricate the steering joints.
AIR FILTER
Check the air filter every 4 hours, or more frequently if working in a very usty environment (fig. 7).
CHECKING THE BLADES AND CUTTING DECK
A blunt bla e tears the grass, leaving it unattractive. The cutting e ges of both bla es must be
sharpene . To remove a bla e, take hol of it firmly, wearing work gloves, an unscrew the central
bolt clockwise (fig. 8, n. 3). Sharpen both cutting e ges using a me ium-grain grin ing wheel an
check that the bla e is balance by stan ing it on a roun bar inserte in the central hole. When
replacing the bla es always replace also the screw an its belleville washer (fig. 8, n. 3). Once the
bla e has been replace , make sure the screw has been firmly tightene . Fastening torque 60 Nm.
IMPORTANT: Replace amage or ba ly worn bla es, never repair them.
110 cm MOWER DECK ADJUSTMENT
This 110 cm mower eck has a ual-function: mulching an rear ischarge. The operator chooses the
function via a lever (fig. 25). Levelness of the cutter eck is essential in or er to obtain an evenly
mown lawn. Park the mower on a flat surface an check that the tyre pressure is correct. Loosen the
screws of the rear arms (fig. 26) an completely unscrew the screw the nut an jam nut. Check the
height of the cutter eck front an rear both in the lowest an the highest cutting position. If the
mower eck is higher in the rear part than in the front shorten the front arms (fig. 27), while if the
mower eck is higher in the front part the front arms have to be lengthene . When the mower eck is
set at the lowest cutting position, a just the screw with nut an jam nut so that both the front an rear
part of the mower eck are set at the same height (fig. 26 – fig. 27).
To set the bla e at 2,5 cm from the groun , the top e ge of the mower eck housing must be at 125
mm from the groun . To carry out this a justment use the ro of the mower eck arms. Once the
bla e belt has been replace use the a justing nut to put it in tension again (fig. 17). Loosen or screw
the nut so that the centering bush of the spring touches the nut in the point in icate by the re arrow.
BLADE – ENGINE BELT
Carry out all the checks an a justments (fig. 16) after having set the mower eck at the lowest
cutting position. Check the belt tensioner spring (fig. 18). Lubricate the bushes of the cutting eck-
engine belt tensioner (fig. 13).
HYDROSTATIC TRANSMISSION – ENGINE BELTS
These belts are self-a justing an o not require any a justment. Simply check the spring tension.
To replace the belts, release the tension spring (fig. 19).
12

MD22 N/ Translation of the original instructions
BLADE ROTATION
Bla es are engage an isengage via the switch (fig. 1, n. 6). When the bla es are engage the
engine must be running at me ium r.p.m. (see throttle label) an the machine must be outsi e of the
grass to be cut. Never engage the bla es with the engine at maximum r.p.m. The machine is
equippe with an electromagnetic clutch which also brakes the bla e uring isengagement. Bla es
must stop within 5 secon s from their isengagement. If this is not the case, a just the 3 nuts of the
electromagnetic clutch, placing a 0.3 mm feeler gauge un er the brake plate. N.B. Th s operat on
must be carr ed out by an author sed after-sales serv ce center.
REPLACING THE BELT
The movement is transmitte from the engine to the hy raulic transmission an to the bla es by
means of a V-belt. Replace the belt as soon as t shows s gns of wear! Its replacement an
subsequent a justment are fairly complex proce ures an must be carrie out by an authorise
service centre. ALWAYS USE ORIGINAL BELTS!
ADJUSTMENT OF THE DIFFERENTIAL LOCK
The ifferential lock must engage half-way of the pe al stroke (fig. 1, n. 5). To a just the ifferential
lock, use the a justing screws (fig. 16).
TRACTION RELEASE LEVER
The traction release lever is locate in the rear part of the machine (fig. 20). If the machine breaks
own, move the lever to i le position to allow it to be towe or move by han (fig. 20, B). In the
position (A) the machine is in working con ition.
LUBRICATION POINTS
13

MD22 N/ Translation of the original instructions
MAINTENANCE SUMMARY TABLE
PROCEDURE EVERY 8
HOURS
AFTER
20
HOURS
EVERY
50
HOURS
EVERY
100
HOURS
ONCE A
YEAR OR
EVERY 200
HOURS
Engine oil check the level ●
change ● ●
Air filter check ●
replace ٭
Spark plug check/a just ●
replace ●
Check that the engine intake gri is
clean ●
Check that the hy raulic engine
cooling fins are clean ●
Hy rostatic
axle oil
check the level
● ●
replace ● ●
Check that bla es are well-
sharpene an well-fixe ●
Lubricate with grease ● ●
● recommen e proce ure
٭ procedure to be carr ed out f necessary
TROUBLE-SHOOTING
CAUSE REMEDY
Dashboar OFF with key in “AVV.” (ON) pos.
– Battery not supplying power – Check connecting cables
– Recharge battery
– Change the fuse
Dashboar ON, but starter motor oes not turn over with key in “AVV” (ON) pos.
– Battery not supplying enough power – Recharge battery
– Start-up go-ahea not given – Travel lever in stop position
– Disengage bla es
– Sit in the river’s seat
– Check the three safety sensors (seat –
bla es engagement - forwar lever)
14

MD22 N/ Translation of the original instructions
Difficult starting or irregular running of engine
– Carburettor problems – Clean or change the air filter
– A just the carburettor (follow engine manual
instructions)
– Deposits or irt in fuel – Empty the tank an use fresh petrol
– Check an change the petrol filter if
necessary
Starter motor turns over but engine oes not start
– No petrol flow – Check that the choke has been activate (if
engine is col )
– Check petrol level in tank
– Check wiring of carburettor opening control
– Check petrol filter (an change if necessary)
- Check that the vent on the tank cap is not
blocke
– Fault in ignition system – Check that the caps of the sparkplugs are
correctly fastene
– Check that the electro es are clean an at
the correct istance apart.
Drop in engine performance uring cutting
– Spee too high for cutting height – Re uce spee
–Raise cutting eck by a few notches
Uneven cutting
– Cutting eck not parallel to groun – Check tyre pressure
– Level off the eck
– Bla es fault – Check that the bla es are correctly mounte
– Sharpen or change the bla es
– Check the tension of the eck motor belt
Vibrations uring operation
– Bla es unbalance – Balance bla es or replace if amage
Fastenings are loose – Check an fasten the bla e fixing screws as
well as the fixing screws of the engine an
chassis.
15

MD22 N/ Translation of the original instructions
ELECTRICAL SYSTEM
The electrical system is protecte by a fuse which cuts out the entire electrical system if blown. After
f nd ng and repa r ng the fault, replace the fuse with another of the same rating. Never replace the
fuse w th one of a d fferent rat ng. The electrical system fuses are place on the left-han si e of
the steering wheel (fig. 23, B). If problems persist after all the proce ures escribe above have been
carrie out, contact the Authorise After-Sales Service Centre. Never attempt to make ifficult repairs
unless you have the necessary equipment an technical expertise.
IMPORTANT!
– Take care not to reverse the battery polarity.
– Never operate the mower without the battery, since it is equippe with a charge regulator.
– Take care not to cause short-circuits.
THE MACHINE DOES NOT REMAIN IN NEUTRAL
A just the evice by loosening both the right an left counter-nuts (fig. 22, B) an acting on the
central nut (fig. 22, A).
FORWARD LEVER
A just both the forwar an the reverse spee via the screws (fig. 26, A). If the forwar lever comes
back into i le position once it has been engage , a just it through the self-locking nut (fig. 26, B).
END OF WORK
After mowing, isengage the bla es an rive back with the cutter eck in the highest position. To
stop, move the forwar lever to the STOP position (fig. 3, n. 2), set the throttle lever to the minimum
r.p.m, switch off the engine by turning the key (fig. 1, n. 1) an set the mower eck at the lowest
position.
CLEANING
Thoroughly clean the outsi e of the mower after each use.
STORAGE AND PROLONGED PERIODS OF DISUSE
Store the mower in a ry place, away from atmospheric agents, an preferably cover with a sheet. If
the mower is not going to be use for a long perio (over 1 month), isconnect the re battery cable
(fig. 21) an follow the instructions given in the engine manual. Also lubricate all of the articulate
joints. Regularly check that the battery voltage oes not rop below 12 volts. If it oes, recharge the
battery. If the machine is to be out of use for more than 30 ays, rain the fuel from the engine to
prevent sticky eposits from forming in the fuel intake system or in vital parts of carburettor. To protect
the engine, we a vise you to use a preservative a itive for unlea e petrol. A the a itive to the
fuel in the tank or in the fuel container. Run the engine a little to circulate the a itive through the
carburettor. The engine an carburettor can be store for up to 24 months. NB.: If no a itive is use
or the engine is running on petrol which contains alcohol, rain the fuel tank an run the engine until
there is no fuel left.
16
