Grizzl-E Extreme Edition Installation and operating instructions

User Manual & Installation Guide
™
EV charger
GRIZZL E
EXTREME EDITION

2
Grizzl-E Extreme
Edition Manual

3
IMPORTANT SAFETY INSTRUCTIONS
This document contains instructions and warnings that must be followed when installing
and using the GRIZZL-E Extreme Edition Electric Vehicle Supply Equipment (EVSE). Before
installing or using the EVSE, read this document including any WARNING and CAUTION
symbols.
Warning: risk of personal injury
Warning: risk of electric shock
Warning: risk of fire
Caution: risk of damage to equipment
The symbols used have the following meaning:
Grizzl-E Home EV Charging Station – Extreme Edition
The Grizzl-E Extreme Edition is a simple, powerful, heavy-duty and portable electric vehicle
charging station made in Canada and built to withstand the harshest conditions.
Grizzl-E Extreme Edition comes exclusively with a Premium 24ft cable which remains flexible
in cold temperatures. Internal design and components of the charger have been selected to
provide maximum operational life of the device and be able to withstand the elements.
Grizzl-E provides up to 10 KW of power to your vehicle. Physical switches inside can be set to
provide 16 Amps, 24 Amps, 32Amps or 40 Amps adjustable maximum current.
• This document provides instructions for the charging station and should not be used for
any other product. Before installation or use of this product, review this manual carefully
and consult with a licensed contractor, licensed electrician, or trained installation expert to
ensure compliance with local building codes and safety standards.
• Consult a licensed electrician to ensure that you can safely install and use this product.
• Ensure that the materials used, and the installation procedures, follow local building codes
and safety standards.
• The information provided in this manual in no way exempts the user of responsibility to
follow all applicable codes or safety standards.

4
Repair and Maintenance Clause
• All United Chargers products do not require routine maintenance however, periodic
inspections should be conducted to ensure that all parts remain in good working order
and no damage exists.
• Do not attempt to open, disassemble, repair, tamper with, or modify any components of
the products. Contact United Chargers for any repairs.
• Read all the instructions before using this product.
• Children should not use this device.
• Do not put fingers into the EV connector.
• Do not touch live electrical parts.
• Do not use this product if the flexible power cord or EV cable is ragged, has broken
insulation, or any other signs of damage.
• Do not use this product if the enclosure or the EV connector is broken, cracked, open,
or shows any other indication of damage.
• Improper connection of the equipment grounding conductor can result in a risk of electric
shock. Check with a licensed electrician if you are in doubt as to whether the product is
properly connected and grounded.
OVERALL WARNINGS & CAUTIONS
Basic precautions should always be followed when using electrical products,
including the following:
WARNING: This equipment is intended only for charging vehicles
that do not require ventilation during charging. Please refer to your
vehicle’s owner’s manual to determine ventilation requirements.

5
FCC Declaration of Conformity
This charging station complies with part 15 of the FCC Rules. Changes or modifications the
charging station not expressly approved by the manufacturer could void FCC compliance.
Operation is subject to the following two conditions:
1. This charging station may not cause harmful interference
2. This device must accept any interference received, including interference that may cause
undesired operation.
CAUTION: The service wiring in this section are specific to North
America only. Before installing the Charging Station, identify the
type of utility service connection onsite. If unsure about the type of
connection available at the service panel, contact your utility service
provider.

6
Product Features
GRIZZL-E™ Extreme Edition Electric Vehicle Charging Station (EVSE)
• J1772 AC Level 2 (208-240 VAC), 40A Continuous Rated (9.6 kW)
• Adjustable Maximum Current Output (40A, 32A, 24A, 16A) to Support Multiple Circuit
Ratings (50A, 40A, 30A, 20A)
• Extreme Duty, Rigid & Compact Design
• Robust and heavy-duty aluminum cast case; airtight enclosure for indoor or outdoor use
• No user interface required with EVSE, simply Plug-in to your EV to initiate charging
• EasyEvPlug™ Holster and Tesla EasyEVPlug™ Holster with cable Management System
• Plug-in Configuration for easy portability
• Wall Mount with security features (including single stud mount), Pedestal, Bollard/Pole
(Single & Dual Port) available from United Chargers
• Coupler Lock with Keys
• UL certified.
Adjustable Maximum Current Output to Support Multiple Circuit Ratings
The GRIZZL-E™ Extreme Edition Electric Charging Station features the ability to adjust
the maximum charging station current output to allow the use of a 50A, 40A, 30A, or 20A
Dedicated Circuit as follows:
50A Circuit Rating: To support 40A (9.6kW) Maximum Charging Station Output
40A Circuit Rating: To support 32A (7.68kW) Maximum Charging Station Output
30A Circuit Rating: To support 24A (5.76kW) Maximum Charging Station Output
20A Circuit Rating: To support 16A (3.84kW) Maximum Charging Station Output
The Default Factory Setting is 40A (9.6kW). To change the maximum current output, refer to
Chapter 3.1 Adjust Maximum Current Output on page 12. If you are unsure of the circuit
ratings in your home consult a licenced electrician.
Self-Monitoring and Recovery | Power Outage Recovery
When a charging session is interrupted due to a temporary error condition, the charging
station will automatically restart charging when the cause of the temporary error condition
returns to normal. Refer to Chapter 8.3 Self-Monitoring and Recovery (Auto Restart) on page
23 for more information.
Security and Tamper Feature
In addition to the security pin that secures the GRIZZL-E ™ charging station to the wall mount
bracket, the GRIZZL-E Extreme Edition also includes a coupler lock and key with a length of
90mm and diameter of 7mm.

7
Product Specifications
United Chargers GRIZZL-E™ Electric Vehicle Charging Station (EVSE)
Description Specifications
Model Number
Connector / EVSE
Level
Max Output
Rating
Alternate
Adjustable Output
Ratings
Charge Cable
Length
Electrical Circuit
/ Input Power
Requirements
Input Power
Connection
Charging Station
Color
Installation Rating
Operational Ratings
GR1-1424PCC
SAE J1772; AC Level 2
40A; 9.6 kW Maximum Output – For use with 50A Circuit Rating
32A; 7.68 kW Maximum Output – For use with 40A Circuit Rating
24A; 5.76 kW Maximum Output – For use with 30A Circuit Rating
16A; 3.84 kW Maximum Output – For use with 20A Circuit Rating
24 ft. (7.2m)
Circuit Requirement: Dedicated Single Phase 208-240VAC, 50/60 Hz.
Branch Breaker: Double pole.
Circuit Conductors: Line 1, Line 2, Earth / Ground.
Standard: Plug-in NEMA 14-50 Plug.
Plug is removable for Hardwire Connection.
Camo Style Design
NEMA 4, Indoor/Outdoor Rated
Temperature: -22⁰F to 122⁰F (-30⁰C to 50⁰C); Humidity: 95% RH non-
condensing
Mounting Wall or Pedestal Installation
Overall Dimensions
Display & Indicators
EVSE: 10.25 x 6.25 x 3.75 inches (26.0 x 16.0 x 9.3 cm)
LED Charge Status Indicators (Power/Ready, Charging, Fault)
Cable Management
Standards &
Compliance
Holster and Tesla Holster with cable management
UL certified

8

9
INSTRUCTIONS Manual
United Chargers GRIZZL-E ™ Electric Vehicle Charging Station (EVSE)
Contents
1. Introduction and Unpacking ..........................................................................................10
2. Installation Planning and Service Wiring: .....................................................................11
2.1 Electrical Source Requirements ...................................................................................... 11
2.2 Grounding Instructions .................................................................................................... 11
3. Adjustable Maximum Current Output to Support Multiple Circuit Ratings..............12
3.1 Adjust Maximum Current Output.................................................................................... 12
4. Calibrating the GRIZZL-E Unit (Optional) .......................................................................15
5. Installation ........................................................................................................................16
5.1 Tools & Parts Required for Installation .......................................................................... 16
5.2 Install the Charging Station ............................................................................................. 17
5.3 Install Holster ..................................................................................................................... 19
6. Input Wiring Connection (Optional Hardwire Connection) .........................................20
7. Charging Status Indicators and Buzzers ........................................................................22
8. Operation ..........................................................................................................................23
8.1 Connect and Charge ......................................................................................................... 23
8.2 Stop Charging .................................................................................................................... 23
8.3 Self-Monitoring and Recovery (Auto Restart) ............................................................... 23
9. General Product Care and Use Information .................................................................24
10. Warranty .........................................................................................................................25

10
1. Introduction and Unpacking
The following items are included in the Grizzl-e Extreme Edition Package:
Charging Station with input and
output cable (x1)
Philips-head
screw (x8)
Robertson
Head Screws
(x2)
Holster (x1)
Mounting Bracket (x1)
Socket cap
screw
(x4)
Security Pin
(x1)
EXTREME EDITION
Anchor
(x8)
1
2
3
Coupler Lock and 2
Keys
Tesla Holster (x1)
This user manual applies to the GRIZZL-E ™ EVSE for Plug-in Hybrid Electric Vehicles (PHEVs)
and Electric Vehicles (EVs).

11
WARNING: Disconnect the power supply to the charging station
before installing, adjusting, or repairing the charging. Failure to do so
may result in physical injury or damage to the power supply system
and the charging station.
2. Installation Planning and Service Wiring:
• Prior to mounting, locate an available electrical source that can support the following
Input Requirements for the Charging Station Per local Electrical Safety Code requirements:
»40A Maximum Output Setting (Default Factory Setting): a DEDICATED CIRCUIT rated
for 50A; 208-240 VAC, 50-60 Hz, Single Phase must be used.
»32A Maximum Output Setting (Optional Setting): a DEDICATED CIRCUIT rated for 40A;
208-240 VAC, 50-60 Hz, Single Phase must be used.
»24A Maximum Output Setting (Optional Setting): a DEDICATED CIRCUIT rated for 30A;
208-240 VAC, 50-60 Hz, Single Phase must be used.
»16A Maximum Output Setting (Optional Setting): a DEDICATED CIRCUIT rated for 20A;
208-240 VAC, 50-60 Hz, Single Phase must be used.
• A Double Pole Circuit Breaker of the circuit rating must be used.
• The Charging Unit has a built in GFCI protection; do not provide any additional GFCI
protection upstream of the charging unit.
• The Charging Stations can connect a Standard NEMA 6-50 or 14-50 Receptacle or the unit
can be hardwired
2.2 Grounding Instructions
The charging station must be implemented equipment grounding through a permanent
wiring system or an equipment grounding conductor. Use a cable with a dedicated grounding
conductor connected to the equipment ground terminal block.
CAUTION: To reduce the risk of fire, connect only to a circuit
provided with the minimum branch circuit overcurrent protection
requirements in accordance with the National Electrical Code ANSI/
NFPA 7- and the Canadian Electrical Safety Code, Part 1, C22.1. If
you are unsure if your circuit meets these requirements consult a
licensed electrician.
2.1 Electrical Source Requirements

12
3. Adjustable Maximum Current Output to Support Multiple
Circuit Ratings
The GRIZZL-E ™ charging station features the ability to adjust the maximum current output
to support 50A, 40A, 30A, or 20A Dedicated Circuit ratings as follows:
Circuit Rating Maximum Charging Station Output
50A 40A (9.6 kW)
40A 32A (7.68 kW)
30A 24A (5.76 kW)
20A 16A (3.84 kW)
• The Charging Station Default Factory Maximum Current Output Setting is 40A (9.6 kW) for
use with a 50A Circuit Rating.
• To obtain the fastest charging capability of 40A, a 50A Circuit Rating must be used.
• The Circuit must be a DEDICATED CIRCUIT 208-240 VAC, 50-60 Hz, Single Phase.
• Requirements govern that only 80% of the circuit rated load may be utilized, hence the
higher Circuit Ratings Requirement relative to maximum Charging Station output.
To adjust the Maximum Current Output Setting:
1. Place the Charging Station on a flat surface with the front cover facing up.
2. Remove the front cover by removing the 4 screws at each corner of the charging station.
3.1 Adjust Maximum Current Output
Figure 3-1. Four screws to remove the Charging Station Cover.

13
3. With the front cover placed to the side, locate the DIP switch on the charging station circuit
board. The DIP switch is a 3-position switch on the main circuit board, located directly to
the left of the LED.
CAUTION: The LED pipe is attached to the front cover. When the
front cover is removed, place it on a flat surface facing down to avoid
damage to the LED pipe.
Figure 3-2. 3-DIP Switch Position
WARNING: Do not touch live electrical parts. Disconnect the power
supply to the charging station and verify no power is present before
adjusting the DIP Switches. A non-conductive object MUST be used to
adjust the DIP switch settings. Failure to do so may result in physical
injury or damage to the power supply system and the charging station.
UPDOWN DOWN

14
UP UP
UPUPUP
DOWN
DOWN
4. Using a non-conductive object adjust the Maximum Current Output to either 32A, 24A or
16A, using the following combination of DIP switch settings:
Maximum Current Output DIP 3 DIP 2 DIP 1 DIP Switch Setting (Picture)
40A Maximum Current Output
(Factory Default Setting)
32A Maximum Current Output
24A Maximum Current Output
16A Maximum Current Output
UP
UPUP
DOWN DOWN
Figure 3-3
Figure 3--4
Figure 3-5
Figure 3-6
5. Once the DIP Switch Setting is adjusted, reassemble the charging station. Reinstall the top
cover to the charging station using the following torque force to secure the (4) socket cap
screw:
Screw Torque
M6 16 kgf-cm 13.88 lb-in

15
DOWN DOWN
UP
Note:
Calibration should be done before adjusting the charging station’s maximum current output
settings.
Calibration Steps:
1. Remove the front cover by removing the 4 screws at each corner of the charging station.
For more information on how to remove the front cover refer to Chapter 3. Adjustable
Maximum Current Output to Support Multiple Circuit Ratings on page 12.
2. Using a non-conductive object, calibrate the Grizzl-E unit by adjusting the DIP switch
settings as follows:
Calibrate the GFCI Offset
Figure 3-8
4. Calibrating the GRIZZL-E Unit (Optional)
WARNING: Electrical Power MUST remain OFF and DISCONNECTED
before setting or changing the DIP switch. Incorrect connection may
cause electric shock.
3. Close the lid, and re-secure the screws.
4. Power ON the supply unit until the front LED light turns solid red LED. The solid red LED
indicates that the calibration is finished.
5. Once calibration is complete, follow the steps from the user manual to set the maximum
current output. Refer to Chapter 3.1 Adjust Maximum Current Output on page 12.

16
5.1 Tools & Parts Required for Installation
Table 2-1 Tools & parts required for installation
Tool Size Source of Supply Remark
Mounting Bracket
Robertson-Head Screw
(x2)
Phillips-Head Screw
(x8)
Anchors
(x8)
Holster/Tesla Holster™
Socket cap screw
(x4)
Allen key
Philips Screwdriver
255 x148 x 36 mm
#14
#8
#8
58 x 58 x 70 mm
5/16”
PH3
M4
Included with Product
Included with Product
Included with Product
Included with Product
Included with Product
Included with Product
Commercially Available
Commercially Available
For mounting the charging
station to the wall/structure
For installing the Mounting
Bracket to the wall/structure
For installing the
EasyEvPlug™to the wall/
structure
For installing the EasyEvPlug™
to the wall/structure
To store the EV charging Plug
and Cable
For securing the charging
station to the Mounting
Bracket
For Charging Station Cover
Screws
For Holder Installation and
Optional Hardwire Install
Allen key 3/16” Commercially Available For installing the enclosure
plate to the back of the
station body.
5. Installation
Prior to mounting, determine the location of an acceptable mounting support. All charging
station products must be anchored into a mounting support such as a 2” x 4” stud or a solid
concrete wall. DO NOT mount this unit directly to a stucco/drywall/wall board.

17
5.2 Install the Charging Station
1. Separate the front and back piece of the mounting bracket by pushing down on the
notch.
Figure 5-1. Mounting bracket
2. Attach the front piece of the mounting bracket to the back of the charging station
using the Socket-cap screws. Ensure the top of the mounting bracket is matched with
the top of the charging station.
Back Piece Front Piece
TOP
Figure 5-2 Back of Charging station and
mounting bracket

18
The back piece of the mounting bracket has 3 holes to support attachment to various
surfaces. Use the top two holes to attach the back piece of the mounting bracket to a
wall stud.
Mounting Screw Recommendations:
• For finished walls supported by wood studs, use #14 or M6 tapping screws.
(Included).
• For masonry walls, use M6 mechanical screws. (Commercially available)
• Use following torque force:
Screw Torque
M6
1/4”
50 kgf-cm
50 kgf-cm
43.4 lb-in
43.4 lb-in
3. Secure the back piece of the mounting bracket to the wall or other suitable structure
using the Robertson-head screws.
4. Mount the charger on the wall by securing the front piece of the mounting bracket
to the back piece of the mounting bracket.
5. Secure the charger in place by inserting either the security pin or coupler lock into
the mounting bracket.
Figure 5-4. Security pin
Figure 5-3 Back Piece of
Mounting Bracket

19
6. Plug in the power cord to the NEMA 14-50 Wall Outlet/Receptacle. The NEMA outlet should
be located no less than 20~26” from the ground or as defined by applicable, local electrical
safety codes and standards.
5.3 Install Holster
Figure 5-5. EasyEvPlug™
1. The Holster or Tesla holster can be installed at any location near the charging station.
Once the location is determined hold the flat side of the against the wall with the label
facing up.
2. Secure the holster with the Philips-head screws. Use the anchors if attaching directly into
the drywall.
The EasyEVPlug™ Holster or Tesla EasyEVPlug™ Holster is the new innovative method to
protect your plug and manage your cord. It has the following features:
• No need to aim – flawless plug even in the dark.
• Your EV holster will always be in a convenient location.
• Saves space – special angle for less wall clearance.
• Integrated cable management – holds up to 25 feet of cable.
• Safety – use simple coupler lock to prevent unauthorized use (only on J1772 holster).

20
Figure 6-1. Conduit.
Figure 6-2. Copper terminal, heat shrink tube and copper wire
6. Input Wiring Connection (Optional Hardwire Connection)
1. Choose the appropriate conduit in accordance with all applicable, local and electrical
safety codes and standards.
2. Using the appropriate tool, clamp the wire terminal to the copper wire. For non-insulated
terminals, use heat shrink tube to cover the non-insulated portion of the terminal.
3. Remove the front cover by removing the 4 screws at each corner of the charging station.
For more information on how to remove the front cover refer to Chapter 3.1 Adjust
Maximum Current Output on page 12.
4. With the front cover placed to the side, use Philips screwdriver to release terminal screws
of the or 14-50 Plug cable. Loosen the Strain Relief Fitting for the or 14-50 Plug and
Remove the Plug. Remove the Strain Relief connector.
5. Insert the wire end passing through the conduit and insert them into the input wiring hole.
(Use Red wire for L1, Black wire for L2, Green wire for G). Attach the copper wire on the
corresponding terminal block. Use the following wire and torque force when connecting to
input terminal block.
