Grizzly G0637hep User manual

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

(FOR MODELS MANUFACTURED SINCE 01/15) #BB17217 PRINTED IN TAIWAN

The Model G0637HEP is the same machine as the Model G0637 except for the dual-filtration HEPA filter

system and the collector mounting brackets. Except for the differences noted in this insert, all other content

in the Model G0637 owner's manual applies to this machine.

: To reduce the risk of serious injury, you MUST read and understand this insert—and

the entire Model G0637 manual—BEFORE assembling, installing, or operating this machine!

If you have any further questions about this manual insert or the differences between the Model G0637HEP

and the Model G0637, contact our Technical Support at (570) 546-9663 or email [email protected].

MODEL G0637HEP

71⁄2HP DUAL-FILTRATION HEPA

CYCLONE DUST COLLECTOR

MANUAL INSERT

(For owner's manual revised August, 2017)

V1.11.17

-2- Model G0442HEP/G0601HEP (Mfd. Since 01/15)Model G0637HEP (Mfd. Since 01/15)

The information contained herein is deemed accurate as of 11/23/2017 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 3

Model G0637HEP

MACHINE DATA

SHEET

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G0637HEP 7‐1/2 HP 3‐PHASE DUAL‐FILTRATION

HEPA CYCLONE DUST COLLECTOR

Product Dimensions:

Weight.............................................................................................................................................................. 939 lbs.

Width (side-to-side) x Depth (front-to-back) x Height...................................................... 96-1/4 x 52-1/2 x 139-1/2 in.

Footprint (Length x Width)............................................................................................................... 96-1/4 x 52-1/2 in.

Shipping Dimensions:

Carton #1

Type................................................................................................................................................ Wood Crate

Content................................................................................................................................................. Machine

Weight.................................................................................................................................................... 824 lbs.

Length x Width x Height............................................................................................................. 90 x 39 x 43 in.

Carton #2

Type........................................................................................................................................... Cardboard Box

Content............................................................................................................................ HEPA Cartridge Filter

Weight.................................................................................................................................................... 119 lbs.

Length x Width x Height............................................................................................................. 53 x 27 x 35 in.

Carton #3

Type........................................................................................................................................... Cardboard Box

Content....................................................................................... HEPA Cartridge Filter and HEPA Stand Legs

Weight.................................................................................................................................................... 119 lbs.

Length x Width x Height............................................................................................................. 53 x 27 x 35 in.

Carton #4

Type........................................................................................................................................... Cardboard Box

Content.................................................................................. Filter Outlet Connector and HEPA Filter Adapter

Weight...................................................................................................................................................... 77 lbs.

Length x Width x Height............................................................................................................. 38 x 19 x 22 in.

Electrical:

Power Requirement..................................................................................................... 220V or 440V, 3-Phase, 60 Hz

Prewired Voltage.................................................................................................................................................. 220V

Full-Load Current Rating.................................................................................................. 25A at 220V, 12.5A at 440V

Minimum Circuit Size.......................................................................................................... 50A at 220V, 20A at 440V

Connection Type........................................................................................... Permanent (Hardwire to Shutoff Switch)

Switch Type......................................................................... Remote Control Magnetic Switch w/Overload Protection

Voltage Conversion Kit.............................................................................................................. P0637119V2 for 440V

Recommended Phase Converter....................................................................................................................... G5845

Motors:

Main

Horsepower............................................................................................................................................. 7.5 HP

Phase.................................................................................................................................................... 3-Phase

Amps.................................................................................................................................................. 25A/12.5A

Speed................................................................................................................................................ 3450 RPM

Type........................................................................................................................... TEFC Induction (Class F)

Power Transfer ............................................................................................................................... Direct Drive

Bearings..................................................................................................... Shielded & Permanently Lubricated

Model G0637HEP (Mfd. Since 01/15) -3-

The information contained herein is deemed accurate as of 11/23/2017 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 3

Model G0637HEP

Main Specifications:

Operation

Dust Collector Type.......................................................................................................... Two-Stage (Cyclone)

Approved Dust Types................................................................................................................................ Wood

Filter Type.......................................................................................................................... Cartridge and HEPA

Airflow Performance..................................................................................................... 3468 CFM @ 4.3 in. SP

Max Static Pressure (at 0 CFM)........................................................................................................... 14.73 in.

Main Inlet Size........................................................................................................................................... 10 in.

Inlet Adapter Included.................................................................................................................................... No

Machine Collection Capacity At One Time....................................................................................................... 4

Maximum Material Collection Capacity................................................................................................. 20 cu. ft.

Filtration Rating................................................................................................................ 99.97% @ 0.3 Micron

Filter Surface Area.............................................................................................................................. 261 sq. ft.

Bag Information

Number of Lower Bags..................................................................................................................................... 2

Lower Bag Diameter.......................................................................................................................... 22-7/16 in.

Lower Bag Length............................................................................................................................... 26-3/4 in.

Canister Information

Number of Canister Filters................................................................................................................................ 2

Canister Filter Diameter................................................................................................................... 19-11/16 in.

Canister Filter Length.......................................................................................................................... 47-1/4 in.

Collection Drum Size......................................................................................................................... 55 Gallons

Impeller Information

Impeller Type...................................................................................................................................... Radial Fin

Impeller Size.............................................................................................................................................. 18 in.

Impeller Blade Thickness.......................................................................................................................... 3/8 in.

Construction

Lower Bag...................................................................................................................................... Clear Plastic

Canister............................................................................................................................ Spun Bond Polyester

Frame....................................................................................................................... Steel Sheet Metal (13 ga.)

Impeller....................................................................................................................................................... Steel

Paint Type/Finish....................................................................................................................... Powder Coated

Blower Housing......................................................................................................................... 11-Gauge Steel

Body.......................................................................................................................................... 16-Gauge Steel

Collection Drum.......................................................................................................................................... Steel

Other Specifications:

Country of Origin .............................................................................................................................................. Taiwan

Warranty ........................................................................................................................................................... 1 Year

Approximate Assembly & Setup Time ............................................................................................................. 4 Hours

Serial Number Location .................................................................................................................................. ID Label

Sound Rating ............................................................................................................................................. 78 – 80 dB

ISO 9001 Factory .................................................................................................................................................. Yes

Certified by a Nationally Recognized Testing Laboratory (NRTL) ......................................................................... Yes

-4- Model G0442HEP/G0601HEP (Mfd. Since 01/15)Model G0637HEP (Mfd. Since 01/15)

Inventory

After all the parts have been removed from the

boxes, you should have the following items:

Inventory: (Figures 1–5) Qty

A. Upper Stand Braces ................................... 4

B. Upper Stand Legs ...................................... 4

C. Filter Adapter .............................................. 2

D. Control Box Bracket ................................... 1

E. Lower Stand Legs ...................................... 4

F. HEPA Support Leg (3 Pieces) ................... 1

G. Lower Stand Braces ................................... 4

H. Cyclone Mounting Brackets ....................... 4

Figure 2. Model G0637HEP inventory I–N.

Figure 3. Model G0637HEP inventory O–W.

O. Blower Housing with Motor ........................ 1

P. Control Box ................................................. 1

Q. Remote Control .......................................... 1

R. Collection Drum Lid Latches ...................... 6

S. Casters 2" ................................................... 8

T. Collection Drum Lids .................................. 2

U. Upper Collection Drum Cylinders ............... 2

V. Collection Drum Clamps ............................ 2

W. Lower Collection Drum Cylinders ............... 2

NOTICE

If you cannot find an item on this list, care-

fully check around/inside the machine and

packaging materials. Often, these items get

lost in packaging materials while unpack-

ing or they are pre-installed at the factory.

The following is a list of items shipped with your

machine. Before beginning setup, lay these items

out and inventory them.

If any non-proprietary parts are missing (e.g. a

nut or a washer), we will gladly replace them; or

for the sake of expediency, replacements can be

obtained at your local hardware store.

I. Outlet Port .................................................. 1

J. Intake Cylinder Intake Cylinder .................. 1

K Cyclone Funnel (Small )..............................1

L. Intake Barrel ............................................... 1

M. Funnel Port ................................................. 1

N. Cyclone Funnel (Large) .............................. 1

Figure 1. Model G0637HEP inventory A–H.

Model G0637HEP (Mfd. Since 01/15) -5-

AA. Gaskets (not shown):

— Intake Cylinder 3 x 6 x 1800mm ............ 1

— Outlet Port 3 x 6 x 1100 ........................ 1

— Cyclone Funnel (Large) ......................... 1

— Intake Barrel 3 x 6 x 2500mm ............... 1

— Cyclone Funnel (Small)

3 x 6 x 2200mm ..................................... 1

— Funnel Port 3 x 6 x 735mm ................... 1

— Drum Lid PVC Rubber Seals ................. 2

— Foam Tape 3 x 6 x 300mm ................... 1

AB. Duct Clamps 9" (not shown) ...................... 4

AC. Collection Bags (not shown):

— Collection Drums 640 x 1200mm ........ 12

— Canister Filters 570 x 600mm ............... 2

AD. Hardware (not shown):

— Hex Bolts 3⁄8"-16 x 3⁄4" ........................... 69

— Hex Bolts 3⁄8"-16 x 1"............................ 38

— Hex Bolts 3⁄8"-16 x 11⁄4" ........................... 8

— Hex Bolts 5⁄16"-18 x 3⁄4" ......................... 22

— Hex Bolts 5⁄16"-18 x 1" .......................... 16

— Hex Bolts 5⁄16"-18 x 11⁄4" ....................... 27

— Phillips Head Screws #10-24 x 3⁄8" ...... 24

— Fender Washers 5⁄16" .............................. 8

— Flat Washers 3⁄8" ................................ 242

— Flat Washers 5⁄16" ................................. 92

— Lock Washers 3⁄8" ................................... 8

— Hex Nuts 3⁄8"-16 ................................... 11

— Hex Nuts 5⁄16"-18 .................................. 27

— Hex Nuts #10-24 .................................. 24

— Lock Nuts 3⁄8"-16 ................................ 108

— Rubber Flange Gasket .......................... 1

— Outlet Flange Gaskets ........................... 4

— Barrel Gaskets 700mm .......................... 2

— Barrel Gasket 460mm ............................ 1

— Flange Gasket 9" ................................... 1

— Foam Tape Rolls 5 x 50mm .................. 2

Figure 5. Model G0637HEP Inventory AE–AL

AE. Vacuum Hose Clamps 1

1⁄4" ........................ 4

AF. Vacuum Hoses 1

1⁄4" x 79" .......................... 2

AG. Vacuum Manifold ........................................ 1

AH. Vacuum Hose Clamps 2" ........................... 2

AI. Vacuum Hose 2" x 39" ............................... 1

AJ. Collection Drum Vacuum Rings ................. 2

AK. Cyclone Vacuum Port ................................ 1

AL. Vacuum Hose Clips .................................... 2

Figure 4. Model G0637HEP Inventory X–Z.

X. Flexible Ducts 9" x 251⁄2" ............................ 2

Y. HEPA Canister Filter Assemblies ............... 2

Z. Canister Filter Bag Clamps ........................ 2

-6- Model G0442HEP/G0601HEP (Mfd. Since 01/15)Model G0637HEP (Mfd. Since 01/15)

The HEPA cyclones are assembled largely the

same way as the regular cyclones, but with the

HEPA filter components being installed in place of

the regular canister filter assembly. To assemble

your HEPA cyclone, open the Assembly section

in the Owner's Manual and follow those steps only

when specified below.

Assembly

To assemble the G0637HEP:

1. Follow Steps 1–33 in the Assembly section,

beginning on Page 21 of the owner's manual.

In Step 13, replace original brackets (shown

in Figure 24 of the owner's manual) with

brackets provided (see Figure 1).

Figure 7. Dust collector assembled with provided

brackets and outlet gasket.

Brackets

Provided

Outlet

Gasket

2. Follow assembly instruction Steps 14–27 in

owner's manual.

3. Position outlet gasket around opening on

blower housing (see Figure 7), then attach

outlet to blower housing (see Figure 8) using

(10) 3⁄8" x 1" hex bolts, (20) 3⁄8" flat washers,

and (10) 3⁄8" nuts.

4. Assemble all three HEPA support leg

components (see Figure 9) using (8) 3⁄8" x

1" hex bolts, (16) 3⁄8" flat washers, and (8) 3⁄8"

nuts. Then thread adjustable foot completely

into bottom of support leg.

Figure 8. Blower housing and outlet attached.

Blower

Housing

Outlet

x10

Figure 9. Assembled HEPA support leg

(comprised of three parts).

To ensure the integrity of the HEPA filtration

system and prevent fine dust from leaking

out before it reaches the filters, we strongly

recommend using a general-purpose sili-

cone sealant on all mating surfaces dur-

ing the assembly process. For those com-

ponents assembled with a rubber gasket

between them, apply the sealant evenly on

both sides of the gasket before assembly.

Install Adjustable

Foot Here

Model G0637HEP (Mfd. Since 01/15) -7-

8. Slip plastic collection bag around opening

under canister filter, and secure with metal

bag clamp (see Figure 13).

Figure 13. Installing collection bag under filter.

Bag Clamp

Plastic

Collection

Bag

9. Double-check that all nuts and bolts are

tightened. Congratulations, assembly is com-

plete.

Figure 14. G0637HEP filter system completely

installed.

7. Attach square rubber gaskets to outlet (see

Figure 12), then secure filter adapter assem-

bly using (8) 3⁄8" x 1" hex bolts, (16) 3⁄8" flat

washers, and (8) 3⁄8" nuts.

6. Attach square rubber gaskets to filter housing

(see Figure 11), then secure filter adapter

assembly using (8) 5⁄16" x 1" hex bolts and (8)

5⁄16" flat washers.

Figure 11. Filter components assembled.

Filter Housing

Rubber

Gasket

Filter Adapter

5. Attach HEPA support leg assembly to outlet

(see Figure 10) using (4) 3⁄8" x 1" hex bolts,

(8) 3⁄8" flat washers, and (4) 3⁄8" nuts. Then

adjust foot until it touches floor.

Figure 10. HEPA support leg attached to outlet.

Outlet

HEPA

Support Leg

Figure 12. Attaching filter assembly to outlet.

Rubber

Gasket

Filter Adapter

Filter Assembly

-8- Model G0442HEP/G0601HEP (Mfd. Since 01/15)Model G0637HEP (Mfd. Since 01/15)

Main

1-1

1-2

1-3

1-4

205

201 201

201

225

226

223

222

228

55 57

69 70 71

270

100

101

102

103

104

105

106

107

108 109

109

110

111

115

135

137

138

139

140

141

142

143

144

145

146

147

148

149

150

153

154

155

156

157

143

232A

148

102

115

107

110

1-7 1-8

119

158

G0637HEP 440V

119-1 119-2

119-3

119-4

119-5

119-6

3-3

3-4

3-1 3-2

3-5

G0637HEP 220V

201

224

202

229

230

230-1

230-5

230-6

230-2

229-1 208

208

204

207

230-4 230-3

231

203

117

206

112

113

114

116

117

118

227

Model G0637HEP (Mfd. Since 01/15) -9-

Main Parts List

REF PART # DESCRIPTION REF PART # DESCRIPTION

1 P0637HEP001 MOTOR 7-1/2HP 220V/440V 3-PH 68 P0637HEP068 FLAT WASHER 5/16

1-1 P0637HEP001-1 MOTOR JUNCTION BOX 69 P0637HEP069 HEX NUT 5/16-18

1-2 P0637HEP001-2 MOTOR JUNCTION BLOCK 70 P0637HEP070 HOSE CLAMP 9"

1-3 P0637HEP001-3 MOTOR FAN COVER 71 P0637HEP071 FLEXIBLE DUCT 9 X 25-1/2"

1-4 P0637HEP001-4 MOTOR FAN 72 P0637HEP072 COLLECTION DRUM LID

1-7 P0637HEP001-7 BALL BEARING P6308ZZ 73 P0637HEP073 DRUM SEAL TYPE-R 2.1M

1-8 P0637HEP001-8 BALL BEARING P6306ZZ 77 P0637HEP077 COLLECTION BAG 640 X 1200MM

2 P0637HEP002 MOTOR CORD 10G 4W 300V 78 P0637HEP078 COLLECTION DRUM 25GAL (UPPER)

3 P0637HEP003 MAG SWITCH ASSY 79 P0637HEP079 COLLECTION DRUM 35GAL (LOWER)

3-1 P0637HEP003-1 MAG SWITCH COVER 80 P0637HEP080 DRUM CLAMP

3-2 P0637HEP003-2 POWER SWITCH 81 P0637HEP081 HEX BOLT 5/16-18 X 3

3-3 P0637HEP003-3 CONTACTOR NHD C-35D 220V 82 P0637HEP082 HEX NUT 5/16-18

3-4 P0637HEP003-4 OL RELAY NHD NTH-28 24-28A 83 P0637HEP083 COLLECTION DRUM LID LATCH

3-5 P0637HEP003-5 CIRCUIT BOARD W/TRANSFORMER 84 P0637HEP084 PHLP HD SCR 10-24 X 3/8

4 P0637HEP004 REMOTE CONTROLLER 85 P0637HEP085 HEX NUT 10-24

6 P0637HEP006 MOTOR BASE 86 P0637HEP086 PHLP HD SCR 10-24 X 3/8

7 P0637HEP007 HEX BOLT 3/8-16 X 1-1/2 87 P0637HEP087 HEX NUT 10-24

8 P0637HEP008 FLAT WASHER 3/8 88 P0637HEP088 CASTER 2"

9 P0637HEP009 LOCK WASHER 3/8 89 P0637HEP089 FLAT WASHER 3/8

10 P0637HEP010 HEX NUT 3/8-16 90 P0637HEP090 LOCK WASHER 3/8

11 P0637HEP011 HEX BOLT 1/2-13 X 1-1/2 91 P0637HEP091 HEX NUT 3/8-16

12 P0637HEP012 FENDER WASHER 1/2 93 P0637HEP093 HEX BOLT 3/8-16 X 1-1/4

13 P0637HEP013 LOCK WASHER 1/2 94 P0637HEP094 FLAT WASHER 3/8

14 P0637HEP014 HEX NUT 1/2-13 95 P0637HEP095 LOCK NUT 3/8-16

15 P0637HEP015 IMPELLER 18" 96 P0637HEP096 UPPER STAND BRACE

16 P0637HEP016 FLAT WASHER 1-1/6 97 P0637HEP097 UPPER STAND LEG

17 P0637HEP017 HEX NUT 1-1/16-8 LH 98 P0637HEP098 HEX BOLT 3/8-16 X 3/4

18 P0637HEP018 GASKET 3 X 6 X 1700MM 99 P0637HEP099 FLAT WASHER 3/8

19 P0637HEP019 BLOWER 100 P0637HEP100 LOCK NUT 3/8-16

20 P0637HEP020 FLAT WASHER 5/16 101 P0637HEP101 HEX BOLT 3/8-16 X 3/4

21 P0637HEP021 HEX BOLT 5/16-18 X 3/4 102 P0637HEP102 FLAT WASHER 3/8

45 P0637HEP045 FILTER BAG CLAMP 545MM 103 P0637HEP103 LOCK NUT 3/8-16

46 P0637HEP046 COLLECTION BAG 570 X 600MM 104 P0637HEP104 LOWER STAND BRACE

47 P0637HEP047 INTAKE CYLINDER 105 P0637HEP105 LOWER STAND LEG

48 P0637HEP048 GASKET 3 X 6 X 1800MM 106 P0637HEP106 HEX BOLT 3/8-16 X 3/4

49 P0637HEP049 HEX BOLT 5/16-18 X 3/4 107 P0637HEP107 FLAT WASHER 3/8

50 P0637HEP050 FLAT WASHER 5/16 108 P0637HEP108 LOCK NUT 3/8-16

51 P0637HEP051 INTAKE BARREL 109 P0637HEP109 HEX BOLT 3/8-16 X 3/4

52 P0637HEP052 CYCLONE FUNNEL (LARGE) 110 P0637HEP110 FLAT WASHER 3/8

53 P0637HEP053 RUBBER GASKET 700MM DIA 111 P0637HEP111 LOCK NUT 3/8-16

54 P0637HEP054 HEX BOLT 5/16-18 X 3/4 112 P0637HEP112 CONTROL BOX BRACKET CSA

55 P0637HEP055 FLAT WASHER 5/16 113 P0637HEP113 HEX BOLT 3/8-16 X 3/4

56 P0637HEP056 RUBBER GASKET 700MM DIA 114 P0637HEP114 FLAT WASHER 3/8

57 P0637HEP057 HEX BOLT 5/16-18 X 1-1/4 115 P0637HEP115 HEX NUT 3/8-16

58 P0637HEP058 FLAT WASHER 5/16 116 P0637HEP116 PHLP HD SCR M6-1 X 16

59 P0637HEP059 HEX NUT 5/16-18 117 P0637HEP117 FLAT WASHER 1/4

60 P0637HEP060 RUBBER GASKET 400MM DIA 118 P0637HEP118 HEX NUT M6-1

61 P0637HEP061 CYCLONE FUNNEL (SMALL) 119 P0637HEP119 CONVERSION KIT 440V

62 P0637HEP062 HEX BOLT 5/16-18 X 1-1/4 119-1 P0637HEP119-1 MAGNETIC SWITCH COVER

63 P0637HEP063 FLAT WASHER 5/16 119-2 P0637HEP119-2 POWER SWITCH

64 P0637HEP064 HEX NUT 5/16-18 119-3 P0637HEP119-3 CONTACTOR MSN35-18D

65 P0637HEP065 RUBBER GASKET 9" 119-4 P0637HEP119-4 OL RELAY NHD NTH-15 10–15A

66 P0637HEP066 FUNNEL PORT 119-5 P0637HEP119-5 CIRCUIT BOARD W/TRANSFORMER

67 P0637HEP067 HEX BOLT 5/16-18 X 1-1/4 119-6 P0637HEP119-6 MOTOR CORD 12G 4W 600V

-10- Model G0442HEP/G0601HEP (Mfd. Since 01/15)Model G0637HEP (Mfd. Since 01/15)

Main Parts List Cont.

REF PART # DESCRIPTION REF PART # DESCRIPTION

135 P0637HEP135 EXT TOOTH WASHER 1/2 204 P0637HEP204 HEX NUT 1/4-20

137 P0637HEP137 DRUM LID HOOK 205 P0637HEP205 OUTLET GASKET 456 X 226MM

138 P0637HEP138 RIVET 4 X 7MM BLIND, STEEL 206 P0637HEP206 HEX BOLT 5/16-18 X 1

139 P0637HEP139 VACUUM HOSE 1-1/4" X 79" 207 P0637HEP207 HEX BOLT 1/4-20 X 3/4

140 P0637HEP140 COLLECTION DRUM VACUUM PORT 208 P0637HEP208 FLAT WASHER 1/4

141 P0637HEP141 FLAT WASHER 5/16 222 P0637HEP222 OUTLET

142 P0637HEP142 HEX BOLT 5/16-18 X 3/4 223 P0637HEP223 FILTER ADAPTER GASKET

143 P0637HEP143 HOSE CLAMP 1-1/4" 224 P0637HEP224 FILTER ADAPTER

144 P0637HEP144 PORT PLUG 1-1/4" 225 P0637HEP225 HEPA SUPPORT LEG (TOP)

145 P0637HEP145 FOAM TAPE 3 X 6 X 300MM 226 P0637HEP226 HEPA SUPPORT LEG (MIDDLE)

146 P0637HEP146 VACUUM HOSE CLIP 2-1/2" 227 P0637HEP227 HEPA SUPPORT LEG (BOTTOM)

147 P0637HEP147 PORT PLUG 2" 228 P0637HEP228 ADJUSTABLE FOOT M16

148 P0637HEP148 HOSE CLAMP 2" 229 P0637HEP229 PULL WIRE RAIL COVER

149 P0637HEP149 VACUUM HOSE 2" X 39" 229-1 P0637HEP229-1 PULL WIRE

150 P0637HEP150 VACUUM MANIFOLD 230 P0637HEP230 HEPA FILTER BODY (RIGHT)

153 P0637HEP153 CYCLONE VACUUM PORT 230-1 P0637HEP230-1 HEPA FILTER OUTER

154 P0637HEP154 FOAM TAPE 3 X 6 X 300MM 230-2 P0637HEP230-2 HEPA FILTER 595 X 595 X 300MM

155 P0637HEP155 HEX BOLT 5/16-18 X 3/4 230-3 P0637HEP230-3 HEPA FILTER BOTTOM PLATE

156 P0637HEP156 FLAT WASHER 5/16 230-4 P0637HEP230-4 HEPA FILTER CAGE 595 X 595

157 P0637HEP157 COLLECTION DRUM VACUUM RING 230-5 P0637HEP230-5 HEPA FILTER 595 X 295 X 300MM

158 P0637HEP158 DRUM LID PVC RUBBER SEAL 2M 230-6 P0637HEP230-6 HEPA FILTER CAGE 595 X 295

201 P0637HEP201 HEX BOLT 3/8-16 X 1 231 P0637HEP231 HEPA FILTER BODY (LEFT)

202 P0637HEP202 TAP SCEW M4 X 12 232A P0637HEP232A HEPA FILTER KIT

203 P0637HEP203 PHLP HD SCR 1/4-20 X 3/4 270 P0637HEP270 COLLECTOR MOUNTING BRACKET

Model G0637HEP (Mfd. Since 01/15) -11-

G0637HEP Labels & Cosmetics

120

121

122

123

133

134

124

126

127

128

129

130

131

132

125

REF PART # DESCRIPTION REF PART # DESCRIPTION

120 P0637HEP120 MACHINE ID LABEL CSA 128 P0637HEP128 EAR PROTECTION LABEL

121 P0637HEP121 GENERAL WARNING LABEL 129 P0637HEP129 MODEL NUMBER LABEL

122 P0637HEP122 RED HANDLE NOTICE LABEL 130 P0637HEP130 GRIZZLY.COM LABEL

123 P0637HEP123 ELECTRICITY LABEL 131 P0637HEP131 CONTROL PANEL LABEL

124 P0637HEP124 DISCONNECT POWER LABEL 132 P0637HEP132 REMOTE CONTROL LABEL

125 P0637HEP125 READ MANUAL LABEL 133 P0637HEP133 GRIZZLY GREEN TOUCH-UP PAINT

126 P0637HEP126 HANDS/OUTLET LABEL 134 P0637HEP134 GRIZZLY PUTTY TOUCH-UP PAINT

127 P0637HEP127 GLASSES/RESPIRATOR DC LABEL

WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE

OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

#TS8762 PRINTED IN TAIWAN

Model G0637 Model G0638

MODELS G0637 & G0638

71⁄2& 10 HP CYCLONE

DUST COLLECTORS

OWNER'S MANUAL

(For models manufactured since 04/12)

V4.01.18

This manual provides critical safety instructions on the proper setup,

operation, maintenance, and service of this machine/tool. Save this

document, refer to it often, and use it to instruct other operators.

Failure to read, understand and follow the instructions in this manual

may result in fire or serious personal injury—including amputation,

electrocution, or death.

The owner of this machine/tool is solely responsible for its safe use.

This responsibility includes but is not limited to proper installation in

a safe environment, personnel training and usage authorization,

proper inspection and maintenance, manual availability and compre-

hension, application of safety devices, cutting/sanding/grinding tool

integrity, and the usage of personal protective equipment.

The manufacturer will not be held liable for injury or property damage

from negligence, improper training, machine modifications or misuse.

Some dust created by power sanding, sawing, grinding, drilling, and

other construction activities contains chemicals known to the State

of California to cause cancer, birth defects or other reproductive

harm. Some examples of these chemicals are:

• Lead from lead-based paints.

• Crystalline silica from bricks, cement and other masonry products.

• Arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies, depending on how often you

do this type of work. To reduce your exposure to these chemicals:

Work in a well ventilated area, and work with approved safety equip-

ment, such as those dust masks that are specially designed to filter

out microscopic particles.

Table of Contents

INTRODUCTION............................................... 2

Manual Accuracy ........................................... 2

Contact Info.................................................... 2

Machine Description ...................................... 2

Identification ................................................... 3

Glossary Of Terms ......................................... 4

G0637 Machine Data Sheet .......................... 5

G0638 Machine Data Sheet .......................... 7

SECTION 1: SAFETY....................................... 9

Safety Instructions for Machinery .................. 9

Additional Safety for Dust Collectors ........... 11

SECTION 2: POWER SUPPLY ...................... 12

Availability .................................................. 12

Full-Load Current Rating ........................... 12

Circuit Information ..................................... 12

Circuit Requirements for 220V .................. 12

Circuit Requirements for 440V .................. 12

Connection Type ....................................... 13

Grounding Instructions .............................. 13

Extension Cords ........................................ 13

Phase Converter ........................................ 13

Model G0637 440V Conversion ................ 14

Model G0638 440V Conversion ................ 15

Correcting Phase Polarity .......................... 16

SECTION 3: SETUP ....................................... 17

Needed for Setup ......................................... 17

Unpacking .................................................... 17

Inventory ...................................................... 18

Site Considerations ...................................... 20

Mounting to Shop Floor ............................... 21

Bolting to Concrete Floors ......................... 21

Assembly ..................................................... 21

Power Connection........................................ 31

G0637 Power Connection ......................... 32

G0638 Power Connection ......................... 32

Test Run ...................................................... 33

SECTION 4: DESIGNING THE SYSTEM....... 35

General ........................................................ 35

Duct Material ................................................ 35

Metal Duct ................................................. 36

Flexible Duct .............................................. 36

System Design ............................................. 37

Decide Who Will Design ............................ 37

Sketch Your Shop Layout .......................... 37

Sketch a Basic Duct Layout ...................... 37

Determine Required CFMs ........................ 38

Determining Main Line Duct Size .............. 39

Determining Branch Line Duct Size .......... 39

Planning Drop Downs ................................ 40

Calculating Duct Resistance ..................... 40

Example Materials List .............................. 42

System Grounding ....................................... 43

SECTION 5: ACCESSORIES......................... 44

SECTION 6: OPERATIONS ........................... 46

Operation Safety .......................................... 46

General ........................................................ 46

Remote Control ............................................ 46

SECTION 7: MAINTENANCE......................... 47

Schedule ...................................................... 47

Emptying Drums .......................................... 47

Cleaning Filters ............................................ 47

Rinsing Filter ................................................ 48

Removing/Replacing Filter ........................... 48

SECTION 8: SERVICE ................................... 50

Troubleshooting ........................................... 50

Motor & Electrical ...................................... 50

Dust Collector Operation ........................... 51

SECTION 9: WIRING...................................... 52

Wiring Safety Instructions ............................ 52

G0637 Electrical Components ..................... 53

G0637 Control Box Wiring Diagram ............ 54

G0637 440V Wiring Diagram ....................... 55

G0637 Motor Wiring Diagram ...................... 56

G0638 Electrical Components ..................... 57

G0638 Control Box Wiring Diagram ............ 58

G0638 Motor Wiring Diagram ...................... 59

SECTION 10: PARTS..................................... 60

WARRANTY AND RETURNS ........................ 66

-2- Model G0637/G0638 (Mfd. Since 04/12)

INTRODUCTION

Machine Description

We stand behind our machines! If you have ques-

tions or need help, contact us with the information

below. Before contacting, make sure you get the

serial number

and manufacture date

from the

machine ID label. This will help us help you faster.

Grizzly Technical Support

1815 W. Battlefield

Springfield, MO 65807

Phone: (570) 546-9663

Email: [email protected]

We want your feedback on this manual. What did

you like about it? Where could it be improved?

Please take a few minutes to give us feedback.

Grizzly Documentation Manager

P.O. Box 2069

Bellingham, WA 98227-2069

Email: [email protected]

Contact Info

We are proud to offer this manual with your new

machine! We've made every effort to be exact

with the instructions, specifications, drawings,

and photographs of the machine we used when

writing this manual. However, sometimes we still

make

an occasional mistake.

Also, owing to our policy of continuous improve-

ment, your machine may not exactly match the

manual

If you find this to be the case, and the dif-

ference between the manual and machine leaves

you in doubt,

check our website for the latest

manual update or call technical support for help.

Before calling, find the manufacture date of your

machine by looking at the date stamped into the

machine ID label (see below). This will help us

determine if the manual version you received

matches the manufacture date of your machine.

For your convenience, we

post all available man

uals and

manual updates for free

on our website

www.grizzly.com. Any updates to your

model

machine will be reflected in these documents

as soon as they are complete.

Manufacture Date

of Your Machine

Manual Accuracy

The Model G0637/G0638 is a 2-stage cyclone

wood dust collector capable of collecting dust

from multiple machines running simultaneously.

Cyclonic action separates the heavy dust and

chips from the fine particles and drops them

into the steel collection drum. Any remain-

ing fine dust travels past the impeller and is

trapped by the pleated cartridge filter made

of spun-bond polyester. With the use of the

cable and pulley system on the outside of the

filter assembly, the caked dust is forced down

into the collection bag.

The machine is controlled directly by the

magnetic switch mounted to it or by the IR

remote switch—each control includes timer

options.

Model G0637/G0638 (Mfd. Since 04/12) -3-

Identification

Figure 1. Identification (Model G0637 shown).

Motor

Noise Muffler

Canister Filter

Brush Handle

Canister

Filter Assembly

Vacuum Hoses

Collection Drum

w/Coaster

Control Box

Cyclone Funnel

Inlet Port

Blower Housing

Junction Box

To reduce your risk of

serious injury, read this

entire manual BEFORE

using machine.

-4- Model G0637/G0638 (Mfd. Since 04/12)

The following is a list of common definitions, terms and phrases that relate to dust collection and dust col-

lectors in general. To get the most out of this manual, familiarize yourself with these terms before reading.

Air Suction Capacity: The maximum volume

of air (rated in CFM) that a dust collector can

move, at the inlet, when fully assembled and

not connected to any ducting.

Branch Line: A secondary length of duct that

connects a dust-producing machine to the

Main Line of a permanent dust collection sys-

tem. The minimum recommended Velocity for

branch lines is 4000 FPM.

Collection Bag/Drum: The part of the dust col-

lector that holds the majority of captured dust.

CFM (Cubic Feet per Minute): A measurement

describing the volume of air that moves through

an area in one minute. CFM = Velocity (FPM) x

Cross-Sectional Area of Duct (ft.2).

Cyclone: A type of two-stage dust collector that

uses centrifugal force to remove large dust par-

ticles before they can reach the filter.

Duct (Ducting): Metal/plastic pipe or hose that

connects the dust collector to dust-producing

machines. Typically available in rigid or flexible

options.

Dust Collection System: The entire assembly of

dust collector, duct, and fittings used to capture

dust from machines.

Dust Port/Hood: The part of a dust-producing

machine that connects to dust collection duct.

Filter: The part of the dust collector that prevents

the majority of suctioned dust from returning to

the shop environment. Filters are rated by the

size of fine dust (measured in microns) that can

pass through them.

Fittings (Y's, T's, Elbows, etc.): The various

duct connections that allow the branch and

main lines of a dust collection system to be

routed from the machine to the dust collector.

Duct Grounding: A method of using bare wire

with plastic duct to safely dissipate static elec-

tricity buildup during operation.

Main Line: The primary length of duct that con-

nects the dust collector to the branch lines of

a permanent dust collection system. The mini-

mum recommended Velocity for main lines is

3500 FPM.

Machine CFM Requirement: Indicates the mini-

mum amount of airflow required at the dust port/

hood of a dust-producing machine for adequate

removal of the waste produced. Essentially, the

performance required by the Dust Collection

System after accounting for the drop in CFM

from the static pressure loss of the duct line

between the machine and the dust collector.

Powered Air Filter: An independently operated

machine that removes fine dust suspended in

the air. Typically operated during and after dust-

producing operations as a secondary method

to improve the air quality in a shop.

Single-Stage Collector: A type of dust collector

where all collected chips and dust are expelled

directly into the filter.

Static Pressure: Expressed in units of inches of

water, this describes the difference in pressure

between the air inside and outside the dust col-

lector. It is a measure of the suction created by

the blower.

Two-Stage Collector: A type of dust collector

where large/heavy waste is captured in a sepa-

rate container before the airflow reaches the

filter. Benefits include longer operation times

between filter maintenance or replacement.

Velocity: The speed of airflow movement, mea-

sured in FPM (Feet Per Minute). Velocity =

Volume (CFM) / Cross-Sectional Area of Duct

(ft.2).

Glossary Of Terms

Model G0637/G0638 (Mfd. Since 04/12) -5-

The information contained herein is deemed accurate as of 1/5/2018 and represents our most recent product specifications.

Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 3

Model G0637

MACHINE DATA

SHEET

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901

MODEL G0637 7‐1/2 HP 3‐PHASE CYCLONE DUST

COLLECTOR

Product Dimensions:

Weight.............................................................................................................................................................. 818 lbs.

Width (side-to-side) x Depth (front-to-back) x Height............................................................. 76-3/4 x 60 x 139-3/8 in.

Footprint (Length x Width)............................................................................................................................ 77 x 64 in.

Shipping Dimensions:

Carton #1

Type................................................................................................................................................ Wood Crate

Content................................................................................................................................................. Machine

Weight.................................................................................................................................................... 886 lbs.

Length x Width x Height............................................................................................................. 90 x 39 x 42 in.

Must Ship Upright......................................................................................................................................... Yes

Carton #2

Type........................................................................................................................................... Cardboard Box

Content.................................................................................................................................... Canister Filter #1

Weight...................................................................................................................................................... 57 lbs.

Length x Width x Height............................................................................................................. 57 x 23 x 23 in.

Must Ship Upright.......................................................................................................................................... No

Carton #3

Type.......................................................................................................................................... Cardboard Box

Content.................................................................................................................................... Canister Filter #2
