Grizzly G0526 User manual

COPYRIGHT © OCTOBER 2003 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#5503 PRINTED IN TAIWAN
ONLINE MANUAL DISCLAIMER
THE INFORMATION IN THIS MANUAL REPRESENTS THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE
CONFIGURATION CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE, THIS
MANUAL MAY NOT EXACTLY DEPICT YOUR MACHINE . CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT DIFFERENCES. PRE-
VIOUS VERSIONS ARE NOT AVAILABLE ONLINE.
6" JOINTER
MODEL G0526
INSTRUCTION MANUAL

WARNING
Some dust created by power sanding, sawing, grind-
ing, drilling, and other construction activities contains
chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and
other masonry products.
• Arsenic and chromium from chemically treated
lumber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to fil-
ter out microscopic particles.

Table Of Contents
SECTION 1: SAFETY........................................................................................................................3
Safety Instructions For Power Tools ..........................................................................................3
Additional Safety Instructions For Jointers ................................................................................5
SECTION 2: INTRODUCTION ..........................................................................................................6
Commentary................................................................................................................................6
SECTION 3: CIRCUIT REQUIREMENTS ........................................................................................7
Circuit Breaker ............................................................................................................................7
Amperage Draw ..........................................................................................................................7
Plug-Type....................................................................................................................................7
Rewiring To 220V ......................................................................................................................8
Grounding ..................................................................................................................................8
Circuit Capacity ..........................................................................................................................8
Extension Cords..........................................................................................................................8
SECTION 4: MACHINE FEATURES ................................................................................................9
External Features........................................................................................................................9
Common Terms & Definitions ..................................................................................................10
SECTION 5: SET UP ......................................................................................................................11
About This Section....................................................................................................................11
Parts Inventory..........................................................................................................................11
Unpacking ................................................................................................................................11
Hardware Recognition Chart ....................................................................................................14
Clean Up ..................................................................................................................................15
Site Considerations ..................................................................................................................15
Beginning Assembly..................................................................................................................16
Jointer To Stand........................................................................................................................16
V-Belt ........................................................................................................................................17
Dust Port ..................................................................................................................................18
Fence ........................................................................................................................................18
Cutterhead Guard ....................................................................................................................19
V-Belt Guard ............................................................................................................................19
Handwheels ..............................................................................................................................20
Pedestal Switch ........................................................................................................................20
Start Up ....................................................................................................................................21
Recommended Adjustments ....................................................................................................21
SECTION 6: OPERATIONS ............................................................................................................22
General ....................................................................................................................................22
Stock Inspection ......................................................................................................................22
Squaring Stock..........................................................................................................................23
Surface Planing ........................................................................................................................24
Edge Jointing ............................................................................................................................25
Bevel Cutting ............................................................................................................................26
Rabbet Cutting ..........................................................................................................................27
SECTION 7: MAINTENANCE ........................................................................................................28
Maintenance Safety ..................................................................................................................28
General ....................................................................................................................................28
Table ........................................................................................................................................28
V-Belts ......................................................................................................................................29
Lubrication ................................................................................................................................29
Carbide Cutters ........................................................................................................................29
Maintenance Log ......................................................................................................................30

SECTION 8: SERVICE ADJUSTMENTS ........................................................................................31
About Service............................................................................................................................31
Outfeed Table Height................................................................................................................31
Depth-Of-Cut Scale ..................................................................................................................32
Fence Stops..............................................................................................................................32
Carbide Cutters ........................................................................................................................34
Adjusting Gibs ..........................................................................................................................34
SECTION 9: REFERENCE INFO ....................................................................................................35
General ....................................................................................................................................35
Aftermarket Accessories ..........................................................................................................35
G0526 Machine Data Sheet......................................................................................................36
G0526 Parts Breakdown ..........................................................................................................37
Troubleshooting Guide..............................................................................................................43
G0526 Wiring Diagram ............................................................................................................45
Warranty & Returns ..................................................................................................................46

G0526 6" Jointer -3-
5. KEEP CHILDREN AND VISITORS
AWAY. All children and visitors should be
kept at a safe distance from work area.
6. MAKE WORKSHOP CHILD PROOF with
padlocks, master switches, or by removing
starter keys.
7. NEVER FORCE TOOL. It will do the job
better and safer at the rate for which it was
designed.
8. USE RIGHT TOOL. DO NOT force tool or
attachment to do a job for which it was not
designed.
1. KEEP GUARDS IN PLACE and in working
order.
2. REMOVE ADJUSTING KEYS AND
WRENCHES. Form a habit of checking to
see that keys and adjusting wrenches are
removed from tool before turning on.
3. KEEP WORK AREA CLEAN. Cluttered
areas and benches invite accidents.
4. NEVER USE IN DANGEROUS ENVIRON-
MENT. DO NOT use power tools in damp
or wet locations, or where any flammable
or noxious fumes may exist. Keep work
area well lighted.
For Your Own Safety Read Instruction
Manual Before Operating This Equipment
Indicates an imminently hazardous situation which, if not avoided,
WILL result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
COULD result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
MAY result in minor or moderate injury. It may also be used to alert
against unsafe practices.
This symbol is used to alert the user to useful information about
proper operation of the equipment.
The purpose of safety symbols is to attract your attention to possible hazardous conditions.
This manual uses a series of symbols and signal words which are intended to convey the level
of importance of the safety messages. The progression of symbols is described below.
Remember that safety messages by themselves do not eliminate danger and are not a substi-
tute for proper accident prevention measures.
NOTICE
Safety Instructions For Power Tools
SECTION 1: SAFETY

-4- G0526 6" Jointer
9. USE PROPER EXTENSION CORD. Make
sure your extension cord is in good condi-
tion. Conductor size should be in accor-
dance with the chart below. The amperage
rating should be listed on the motor or tool
nameplate. An undersized cord will cause
a drop in line voltage resulting in loss of
power and overheating. Your extension
cord must also contain a ground wire and
plug pin. Always repair or replace exten-
sion cords if they become damaged.
Minimum Gauge for Extension Cords
10. WEAR PROPER APPAREL. DO NOT
wear loose clothing, gloves, neckties,
rings, bracelets, or other jewelry which may
get caught in moving parts. Non-slip
footwear is recommended. Wear protective
hair covering to contain long hair.
11. ALWAYS USE SAFETY GLASSES. Also
use face or dust mask if cutting operation is
dusty. Everyday eyeglasses only have impact
resistant lenses, they are NOT safety glasses.
12. SECURE WORK. Use clamps or a vise to hold
work when practical. It’s safer than using your
hand and frees both hands to operate tool.
13. DO NOT OVER-REACH. Keep proper
footing and balance at all times.
14. MAINTAIN TOOLS WITH CARE. Keep
tools sharp and clean for best and safest
performance. Follow instructions for lubri-
cating and changing accessories.
LENGTH
AMP RATING 25ft 50ft 100ft
0-6 16 16 16
7-10 16 16 14
11-12 16 16 14
13-16 14 12 12
17-20 12 12 10
21-30 10 10 No
Safety Instructions For Power Tools
15. USE RECOMMENDED ACCESSORIES.
Consult the owner’s manual for recom-
mended accessories. The use of improper
accessories may cause risk of injury.
16. REDUCE THE RISK OF UNINTENTION-
AL STARTING. On machines with magnet-
ic contact starting switches there is a risk of
starting if the machine is bumped or jarred.
Always disconnect from power source
before adjusting or servicing. Make sure
switch is in OFF position before reconnecting.
17. CHECK DAMAGED PARTS. Before fur-
ther use of the tool, a guard or other part
that is damaged should be carefully
checked to determine that it will operate
properly and perform its intended function.
Check for alignment of moving parts, bind-
ing of moving parts, breakage of parts,
mounting, and any other conditions that
may affect its operation. A guard or other
part that is damaged should be properly
repaired or replaced.
18. NEVER LEAVE TOOL RUNNING UNAT-
TENDED. TURN POWER OFF. DO NOT
leave tool until it comes to a complete stop.
19. NEVER OPERATE A MACHINE WHEN
TIRED, OR UNDER THE INFLUENCE OF
DRUGS OR ALCOHOL. Full mental alert-
ness is required at all times when running a
machine.
20. NEVER ALLOW UNSUPERVISED OR
UNTRAINED PERSONNEL TO OPER-
ATE THE MACHINE. Make sure any
instructions you give in regards to machine
operation are approved, correct, safe, and
clearly understood.
21. IF AT ANY TIME YOU ARE EXPERIENC-
ING DIFFICULTIES performing the intend-
ed operation, stop using the machine! Then
contact our service department or ask a
qualified expert how the operation should
be performed.

G0526 6" Jointer -5-
No list of safety guidelines can be complete.
Every shop environment is different. Always
consider safety first, as it applies to your
individual working conditions. Use this and
other machinery with caution and respect.
Failure to do so could result in serious per-
sonal injury, damage to equipment, or poor
work results.
Like all machines there is danger associated
with the Model G0526. Accidents are fre-
quently caused by lack of familiarity or fail-
ure to pay attention. Use this machine with
respect and caution to lessen the possibility
of operator injury. If normal safety precau-
tions are overlooked or ignored, serious
personal injury may occur.
Additional Safety Instructions For Jointers
1. JOINTING SAFETY BEGINS with your
lumber. Inspect your stock carefully before
you feed it over the cutterhead. If you have
any doubts about the stability or structural
integrity of your stock, DO NOT JOINT IT!
2. MAINTAIN PROPER RELATIONSHIPS of
infeed and outfeed table surfaces and cut-
terhead knife path.
3. ALWAYS USE A PUSH PADDLE when
jointing. Never place your hands directly
over the cutterhead.
4. SUPPORT THE WORKPIECE adequately
at all times during operation, and maintain
control over the work at all times.
5. WHEN JOINTING, DO NOT stand directly
at the end of either table. Position yourself
just to the side of the infeed table to protect
yourself from possible kickbacks.
6. NEVER MAKE JOINTING CUTS deeper
than 1⁄8".
7. NEVER JOINT A BOARD that has loose
knots. All defects should be cut out of the
board before it is planed or jointed.
8. NEVER JOINT end grain.
9. JOINT WITH THE GRAIN. Jointing against
the grain is dangerous and could produce
chatter or excessive chip out , which could
lead to loss of control over the workpiece.
10. WITH THE EXCEPTION OF RABBETING,
all operations must be performed with the
guard in place. After rabbeting, be sure to
replace the guard.
11. NEVER BACK THE WORK toward the
infeed table. If a cut must be interrupted, lift
the workpiece clear of the cutterhead.
12. HABITS — GOOD AND BAD — are hard
to break. Develop good habits in your shop
and safety will become second-nature to
you.
13. “KICKBACK” is when the workpiece is
thrown off the jointer table by the force of
the cutterhead. Always use push paddles
and safety glasses to reduce the likelihood
of injury from “kickback.” If you do not
understand what kickback is, or how it
occurs, DO NOT operate this machine.
14. PROLONGED EXPOSURE TO WOOD
DUST IS KNOWN TO CAUSE CANCER IN
HUMANS. Always wear an OSHA-
approved respirator when working in an
environment that could contain wood dust.

-6- G0526 6" Jointer
We are proud to offer the Model G0526 6"
Jointer. This machine is part of a growing Grizzly
family of fine woodworking machinery. When
used according to the guidelines set forth in this
manual, you can expect years of trouble-free,
enjoyable operation and proof of Grizzly’s com-
mitment to customer satisfaction.
We are pleased to provide this manual with the
Model G0526. It was written to guide you through
assembly, review safety considerations, and
cover general operating procedures. It represents
our effort to produce the best documentation pos-
sible. If you have any comments regarding this
manual, please write to us at the address below:
Grizzly Industrial, Inc.
C/O Technical Documentation
P.O. Box 2069
Bellingham, WA 98227-2069
Most importantly, we stand behind our machines.
If you have any service questions or parts
requests, please call or write us at the location
listed below.
Grizzly Industrial, Inc.
1203 Lycoming Mall Circle
Muncy, PA 17756
Phone: [phone]
Fax: [phone]
E-Mail: [email protected]
Web Site: http://www.grizzly.com
The specifications, drawings, and photographs
illustrated in this manual represent the Model
G0526 as supplied when the manual was pre-
pared. However, owing to Grizzly’s policy of con-
tinuous improvement, changes may be made at
any time with no obligation on the part of Grizzly.
For your convenience, we always keep current
Grizzly manuals available on our website at
www.grizzly.com. Any updates to your machine
will be reflected in these manuals as soon as they
are complete. Visit our site often to check for the
latest updates to this manual!
Lack of familiarity with
this manual could
cause serious person-
al injury. Become
familiar with the con-
tents of this manual,
including all the safety
warnings.
Commentary
SECTION 2: INTRODUCTION

G0526 6" Jointer -7-
The Model G0526 features a 110V/220V motor
that is prewired at 110V.
Amperage Draw
110V (prewired) .................................... 18 Amps
220V ...................................................... 9 Amps
Use the following guidelines when choosing a cir-
cuit breaker (circuit breakers rated any higher are
not adequate to protect the circuit):
Circuit Breaker
110V (prewired) ..........................20 Amp, 1 Pole
220V ..........................................10 Amp, 2 Pole
Figure 1b. NEMA 6-15 plug and receptacle.
Figure 1a. NEMA 5-15 plug and receptacle.
The cord set enclosed is equipped with a NEMA
5-15 plug (Figure 1a).
If the jointer is rewired to operate on a 220V
power source, the plug must be replaced with a
NEMA 6-15 plug (Figure 1b).
Plug-TypeAmperage Draw
Circuit Breaker
SECTION 3: CIRCUIT REQUIREMENTS

-8- G0526 6" Jointer
Electrocution or a fire
can result if the machine
is not grounded correct-
ly. Make sure all electri-
cal circuits are ground-
ed. DO NOT use the
machine if it is not
grounded.
Because of the high amperage draw from this
machine, we do not recommend the use of exten-
sion cords. Instead, position your equipment near
installed wiring to eliminate the need for exten-
sion cords.
NOTICE
The wire on the power cord with green or
green and yellow striped insulation is the
grounding conductor.
In the event of an electrical short, grounding
reduces the risk of electric shock by providing a
path of least resistance to disperse electric cur-
rent. This tool is equipped with a power cord that
has an equipment-grounding prong. The outlet
must be properly installed and grounded in accor-
dance with all local codes and ordinances.
The Model G0526 can be rewired to operate on a
220V power source; however, the MA-15
Magnetic Overload Switch (18-26A) must be
replaced with an MA-9 Magnetic Overload Switch
(8-12A). To order the MA-9, call our customer
service number at [phone] and purchase
part # P0526349.
The motor must also be rewired to handle the
220V power source. The correct wiring configura-
tion can be found on the inside of the motor wire
cover, as well as on page 48.
This procedure takes moderate electrical skill and
the rewiring job should be inspected by a licensed
electrician before turning the machine ON.
Extension CordsCircuit Capacity
Grounding
Rewiring To 220V
Always check to see if the wires in your circuit are
capable of handling the amperage draw from
your machine, as well as any other machines that
could be operating on the same circuit. If you are
unsure, consult a qualified electrician.
If the circuit breaker trips or the fuse blows regu-
larly, your machine may be operating on a circuit
that is close to its amperage draw capacity.
However, if an unusual amperage draw does not
exist and a power failure still occurs, contact a
qualified electrician.

G0526 6" Jointer -9-
Figure 2. External features.
External Features
SECTION 4: MACHINE FEATURES
Dust Port
Outfeed Table
Fence
Fence Lock Handle
Pedestal
Switch
Cutterhead
Guard
Fence Tilt
Lever
Infeed Table
Outfeed Table
Height Handwheel
Infeed Table
Height Handwheel
Infeed Table
Lock Handle
Outfeed Table
Lock Handle

-10- G0526 6" Jointer
Infeed Table: The infeed table is where the cut-
ting operation begins. When facing the front of
the jointer, it is on the right-hand side. The
wood travels right to left; from the infeed table,
across the cutterhead, and onto the outfeed
table.
Outfeed Table: The outfeed table is where the
cutting operation ends. When facing the front
of the jointer, it is on the left-hand side.
Cutterhead: The cutterhead is the cylindrical
assembly that holds each of the carbide cut-
ters. It spins on a horizontal axis between the
infeed and outfeed table, and is covered by the
cutterhead guard.
Fence: The jointer fence is the adjustable cast
iron surface that the wood stock runs along
when jointing and surface planing. The fence is
adjustable from 45°-90° to the infeed and out-
feed tables.
Adjustment Handwheels: Controls the height of
the infeed and outfeed tables.
Table Lock Handles: The threaded handles that
must be loosened before the height of the
tables can be adjusted. They are then tight-
ened after the height is properly set.
Rabbet Cut: A rabbet cut is a groove cut along
the long edge of the wood stock, usually used
for making simple joints. The cutterhead guard
must be removed for this operation, so great
care is needed for safe operation.
Surface Planing: Surface planing is running the
face of the wood stock over the jointer. This
provides one flat side that is ready to be run
through a dedicated planing machine.
Edge Jointing: Edge jointing is running the long
edge of the wood stock over the jointer. This
provides one flat edge that is ready to be run
against the table saw rip fence or edge glued.
Cutterhead Guard: The metal guard that covers
the cutterhead and automatically moves out of
the way during operation, then automatically
moves back into place after the operation.
Common Terms & Definitions

G0526 6" Jointer -11-
The Model G0526 is shipped from the manufac-
turer in carefully packed boxes. If you discover
the machine is damaged after you have signed
for delivery, please immediately call Customer
Service at [phone] for advice.
Save the containers and all packing materials for
possible inspection by the carrier or its agent.
Otherwise, filing a freight claim can be difficult.
When you are completely satisfied with the con-
dition of your shipment, you should inventory the
parts.
The purpose of this section is to guide you
through the required steps to get your machine
out of its packaging and into operating condition.
Wear safety glasses dur-
ing the entire set up
process!
This machine presents
serious injury hazards
to untrained users. Read
through this entire man-
ual to become familiar
with the controls and
operations before start-
ing the machine!
Unpacking
Parts Inventory
About This Section
SECTION 5: SET UP
A. Push Paddles ............................................2
B. Jointer Stand..............................................1
C. Jointer ........................................................1
D. Fence (Ship Attached To Jointer) ..............1
Figure 3. Loose components.
E. Indexable Cutters ......................................5
F. Flat Hd Torx Screws M6-1.0 x 15 ..............10
G. Torx Bits ....................................................5
H. Torx T-Handle Driver 6mm (Not Shown) ..1
Figure 4. Spiral cutterhead bag contents.
A
B
C
D
G
F
E

-12- G0526 6" Jointer
J. Hex Bolts 3⁄8"-16 x 3⁄4"................................3
K. Lock Washers 3⁄8"......................................3
Figure 5. Jointer mounting hardware
bag contents.
Figure 7. Large hardware bag contents.
Figure 8. Handwheel bag contents.
Figure 6. Pedestal switch hardware
bag contents.
L. Hex Bolts 5⁄16"-18 x 1" ................................4
M. Flat Washers 5⁄16"......................................8
N. Hex Nuts 5⁄16"-18 ........................................4
O. V-Belt Belt Guard ......................................1
P. Hex Bolt 5⁄16"-18 x 21⁄2"................................1
Q. Flat Washer 5⁄16"........................................1
R. V-Belt A-54 ................................................1
S. Fence Support Key W/Pin..........................1
T. Tilt Lever W/Knob ......................................1
U. Lock Handle 1⁄2"-12 x 11⁄4"..........................1
V. Flat Washer 1⁄2"..........................................1
W. Special Nut 1⁄2"-12 ......................................1
X. 3mm Allen Wrench ....................................1
Y. 8 X 10mm Wrench ....................................1
Z. 12 X 14mm Wrench ..................................1
AA. Handwheels ..............................................2
BB. Handwheel Handles..................................2
J
K
L
M
N
Z
Y
X
U
R
VWT
S
O
P
Q
AA
BB

G0526 6" Jointer -13-
Figure 9. Cutterhead guard bag contents. Figure 10. Dust port bag contents.
CC. Cutterhead Guard ....................................1 DD. Phillips Head Screws 1⁄4"-20 x 1⁄2"............4
EE. Flat Washers 1⁄4"......................................4
FF. Dust Port ..................................................1
CC
FF
EE
DD

-14- G0526 6" Jointer
5mm
10mm
15mm
20mm
25mm
30mm
35mm
40mm
45mm
50mm
55mm
60mm
65mm
70mm
75mm
Washer Lock
Washer
Hex
Nut
Wing
Nut
Phillips
Head
Sheet
Metal
Screw
Setscrew
Phillips
Head
Screw
Thumb
Screw Slotted
Screw
Countersunk
Phillips
Head
Screw
Cap
Screw
Carriage
Bolt
Hex
Head
Bolt
Button
Head
Screw
Flange
Bolt
