Grizzly G5912Z User manual

COPYRIGHT © MARCH, 2017 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#BL18759 PRINTED IN TAIWAN
The following changes were recently made to this machine since the owner's manual was printed:
• Added an additional spindle enclosure guard.
• Changed spindle cartridge support fasteners.
Aside from this information, all other content in the owner's manual applies and MUST be read and under-
stood for your own safety. IMPORTANT: Keep this update with the owner's manual for future reference.
For questions or help, contact our Tech Support at [phone] or [email protected].
READ THIS FIRST
For questions or help with this product contact Tech Support at [phone] or [e-mail]
Model G5912Z/G7214Z/G8621
***IMPORTANT UPDATE***
For Machines Mfd. Since 1/17
and Owner's Manual Printed 2001
7
103
104
8
92
168
168
169
170
52
52
New Parts
REF PART # DESCRIPTION
7 P5912Z007 HEX NUT 3/8-16
8 P5912Z008 LOCK WASHER 3/8
52 P5912Z052 FLAT WASHER 1/4
103 P5912Z103 SET SCREW 3/8-16 X 1
104 P5912Z104 SET SCREW 3/8-16 X 1/2
168 P5912Z168 KNOB BOLT 1/4-20 X 1/2
169 P5912Z169 FRONT GUARD EXTENSION PLATE
170 P5912Z170 FRONT SPINDLE ENCLOSURE GUARD
New Inventory
Inventory Qty
A. Front Spindle Enclosure Guard .................. 1
B. Front Guard Extension Plate ...................... 1
C. V-Belt A28 (G8621) .................................... 1
D. Knob Bolts 1⁄4"-20 x 1⁄2" ............................... 4
E. Flat Washers 1⁄4" ......................................... 4
F. Knob Bolts 3⁄8"-16 x 1" (G5912Z, G7214Z) . 2
F. Knob Bolts 3⁄8"-16 x 1" (G8621) .................. 4
AC
D E
F
B

-2- G5912Z–G8621 Update (Mfd. Since 1/17)
Attaching Spindle Enclosure Guard
Before attaching the spindle enclosure guard,
follow instructions in the Owner's Manual for
installing the cutter guard and attaching the safety
guard (for G5912Z/G7214Z,see Pages 18–19;
for G8621, see Pages 14–15).
To attach spindle enclosure guard:
1. Attach front guard extension plate to thread-
ed holes on front of safety guard with (2) 1⁄4"-
20 x 1⁄2" knob bolts and (2) 1⁄4" flat washers
(see Figure 1).
2. Attach front spindle enclosure guard to exten-
sion plate with (2) 1⁄4"-20 x 1⁄2" knob bolts and
(2) 1⁄4" flat washers, (see Figure 1).
Spindle Enclosure Guard Positioning
The spindle enclosure guard protects the user
from exposure to the cutter and chips thrown by
it. To minimize the risk of injury, the spindle enclo-
sure guard must be adjusted so it encloses as
much of the spindle area as possible, while still
allowing the workpiece to pass through the cut.
Typically this means the front guard is positioned
to just clear the top of the workpiece.
To position the spindle enclosure guard, loosen
the top knob bolts and slide the extension plate in
or out, then loosen the front knob bolts and raise
or lower the spindle enclosure guard as needed.
Tighten the knob bolts to secure the setting.
All guards MUST be
installed on your shaper
before operating it.
Shapers can quickly cause
serious injury if some kind
of guard is not used. To
reduce your risk of injury,
read and follow the entire
Owner's Manual carefully
and do additional research
on shop made guards and
safety jigs.
Figure 1. Front guard extension plate and
spindle enclosure guard attached to safety
guard.
1⁄4"-20 x 1⁄2"
Knob Bolt
Safety Guard
Front Guard Extension
Plate
1⁄4" Flat Washer
Front Spindle Enclosure
Guard

-37-
Model G5912Z/G7214Z (Mfd. Since 03/13)
Cabinet

-38- Model G5912Z/G7214Z (Mfd. Since 03/13)
Cabinet Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P5912Z001 SET SCREW 5/16-18 X 5/8 18 P5912Z018 TERMINAL BOX ASSY
2 P5912Z002 TABLE 18A P5912Z018A TERMINAL BOX W/O BUSBAR
3 P5912Z003 INSERT (SMALL) INNER 19 P5912Z019 STRAIN RELIEF M14.5 TYPE-6 ST
4 P5912Z004 INSERT (MID) 21 P5912Z021 STRAIN RELIEF
5 P5912Z005 INSERT (BIG) 22B P5912Z022B ELECTRICAL BOX ASSY (G5912Z)
6 P5912Z006 STAND ASSY 22B-1 P5912Z022B-1 CONTACTOR (G5912Z)
6-1 P5912Z006-1 DEGREE SCALE 22B-1 P7214Z022B-1 CONTACTOR (G7214Z)
7 P5912Z007 HEX NUT 3/8-16 22B-2 P5912Z022B-2 OVERLOAD RELAY (G5912Z)
8 P5912Z008 LOCK WASHER 3/8 22B-2 P7214Z022B-2 OVERLOAD RELAY (G7214Z)
9 P5912Z009 FLAT WASHER 3/8 22V2 P7214Z022V2 SWITCH BOX ASSEMBLY V2.10.09 (G7214Z)
10 P5912Z010 TABLE BRACE (R) 23 P5912Z023 TABLE BRACE (L)
11 P5912Z011 HEX NUT 10-24 24 P5912Z024 MITER GAUGE
12 P5912Z012 PHLP HD SCR 1/4-20 X 5/8 128 P5912Z128 RESET SWITCH
13 P5912Z013 REMOVABLE DUST DOOR 129 P5912Z129 POWER INDICATOR LIGHT ZD-10 RED
14 P5912Z014 HEX BOLT 3/8-16 X 1-1/4 156A P7214Z156A 440V CONVERSION KIT (G7214Z)
15 P5912Z015 HEX BOLT 3/8-16 X 3/4 156A-1 P7214Z156A-1 440V MAG CONTACTOR (G7214Z)
16 P5912Z016 MOTOR COVER 156A-2 P7214Z156A-2 440V THERMAL PROTECTOR (G7214Z)
17 P5912Z017 PHLP HD SCR 10-24 X 3/4 156A-3 P7214Z156A-3 440V LIGHT BULB (G7214Z)

-39-
Model G5912Z/G7214Z (Mfd. Since 03/13)
Spindle
42A
42B
37-1
43A
44A 44B
45A 45B
46A 46B
36A 36B
40A
41A

-40- Model G5912Z/G7214Z (Mfd. Since 03/13)
Spindle Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
28 P5912Z028 LOCK BOLT 3/8-11 42B P5912Z042B COLLAR 3/4" X 1/4"
29 P5912Z029 TAPER LOCK NUT 43 P5912Z043 COLLAR 1-1/4" X 3/8" (1PC)
30 P5912Z030 BALL BEARING 6008ZZ 43A P5912Z043A COLLAR 1" X 3/8"
31 P5912Z031 EXT RETAINING RING 40MM 44 P5912Z044 COLLAR 1-1/4" X 1/2" (2PC)
33 P5912Z033 PULLEY SPINDLE 44A P5912Z044A COLLAR 1" X 1/2"
36 P5912Z036 SPINDLE 1-1/4 44B P5912Z044B COLLAR 3/4" X 1/2"
36A P5912Z036A SPINDLE 3/4" 45 P5912Z045 COLLAR 1-1/4" X 3/4" (2PC)
36B P5912Z036B SPINDLE 1" 45A P5912Z045A COLLAR 1" X 3/4" (2PC)
37-1 P5912Z037-1 PULLEY AND QUILL ASSEMBLY 45B P5912Z045B COLLAR 3/4" X 3/4" (2PC)
37A P5912Z037A SPINDLE CARTRIDGE ASSY V2.0 46 P5912Z046 COLLAR 1-1/4" X 1" (2PC)
38 P5912Z038 KEY 7 X 7 X 40 46A P5912Z046A COLLAR 1" X 1" (2PC)
39A P5912Z039A QUILL 7-3/4" LONG V2.01.02 46B P5912Z046B COLLAR 3/4" X 1" (2PC)
40 P5912Z040 HEX NUT 3/4-16 LH (FOR 1" AND 1-1/4" SPINDLES) 161 P5912Z161 EXT RETAINING RING 50MM
40A P5912Z040A HEX NUT 5/8-18 LH (FOR 3/4" SPINDLE) 162 P5912Z162 CAP SCREW M4-.7 X 10
41 P5912Z041 HEX NUT 1-14 (FOR 1" AND 1-1/4" SPINDLES) 163 P5912Z163 OUTER DUST COVER
41A P5912Z041A HEX NUT 3/4-16 (FOR 3/4" SPINDLE) 164 P5912Z164 INNER DUST COVER
42 P5912Z042 COLLAR 1-1/4" X 1/4" (1PC) 165 P5912Z165 WAVY WASHER
42A P5912Z042A COLLAR 1" X 1/4" 166 P5912Z166 WAVY WASHER

-41-
Model G5912Z/G7214Z (Mfd. Since 03/13)
Motor
80-2
80-1 80-3
80-7
80-6
80-4
G5912Z G7214Z
80-5
80-8
80-9
80-5 80-10
80-2
80-1 80-3
102
39A

-42- Model G5912Z/G7214Z (Mfd. Since 03/13)
Motor Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
7 P5912Z007 HEX NUT 3/8-16 72 P5912Z072 KEY 7 X 7 X 50
8 P5912Z008 LOCK WASHER 3/8 73 P5912Z073 MOTOR PULLEY
9 P5912Z009 FLAT WASHER 3/8 74 P5912Z074 HEX BOLT 3/8-16 X 1-1/2
14 P5912Z014 HEX BOLT 3/8-16 X 1-1/4 75 P5912Z075 FLAT WASHER 5/16
15 P5912Z015 HEX BOLT 3/8-16 X 3/4 76 P5912Z076 LOCK WASHER 5/16
39A P5912Z039A QUILL 7-3/4" LONG V2.01.02 77 P5912Z077 CAP SCREW 5/16-18 X 1
50 P5912Z050 HEX BOLT 1/4-20 X 5/8 78 P5912Z078 COMPRESSION SPRING 3.4 X 20.3
51 P5912Z051 LOCK WASHER 1/4 79 P5912Z079 KEY 3/8 X 3/4 X 1
52 P5912Z052 FLAT WASHER 1/4 81 P5912Z081 SHAFT
53 P5912Z053 LOCK KNOB 82 P5912Z082 FLAT WASHER 1/2
54 P5912Z054 BAR LOCK 83 P5912Z083 MOTOR BASE
55 P5912Z055 HEX NUT 5/16-18 84 P5912Z084 KNOB
56 P5912Z056 HEX BOLT 5/16-18 X 1 85 P5912Z085 LOCK WASHER 1/2
57 P5912Z057 SCREW LOCK 86 P5912Z086 HEX BOLT 1/2-20 X 1
58 P5912Z058 WASHER GEAR 87 P5912Z087 POINTER
59 P5912Z059 GEAR 88 P5912Z088 PHLP HD SCR 10-24 X 3/8
60 P5912Z060 COLLAR 89 P5912Z089 HEX BOLT 5/16-18 X 3/4
61 P5912Z061 KEY 4 X 4 X 16 90 P5912Z090 SHAFT GUIDE
62 P5912Z062 BASE GEAR SHAFT 91 P5912Z091 PLATE
63 P5912Z063 SHAFT GEAR 92 P5912Z092 MOTOR PLATE
64 P5912Z064 BASE SPINDLE 93 P5912Z093 SHAFT GEAR
65 P5912Z065 FLAT WASHER 1/2 94 P5912Z094 BASE GEAR SHAFT
66 P5912Z066 LOCK NUT 1/2"-12 95 P5912Z095 METAL HANDWHEEL
67 P5912Z067 CAP SCREW 3/8-16 X 1-1/4 96 P5912Z096 HANDLE
68 P5912Z068 SCREW 3/8-16 X 1-1/4 97 P5912Z097 HEX BOLT 1/4-20 X 1-1/4
69 P5912Z069 COLLAR 98 P5912Z098 HEX NUT 1/4-20
70 P5912Z070 V-BELT A30 102 P5912Z102 SET SCREW 10-32 X 3/16
71 P5912Z071 V-BELT A28
80 P5912Z080 MOTOR 5HP 220V 1-PH 80 P7214Z080 MOTOR 7.5HP 220V 3-PH
80-1 P5912Z080-1 MOTOR FAN COVER 80-1 P7214Z080-1 MOTOR FAN COVER
80-2 P5912Z080-2 MOTOR FAN 80-2 P7214Z080-2 MOTOR FAN
80-3 P5912Z080-3 CAPACITOR COVER 80-3 P7214Z080-3 MOTOR JUNCTION BOX
80-4 P5912Z080-4 MOTOR JUNCTION BOX
80-5 P5912Z080-5 CENT SWITCH 1/2-3450
80-6 P5912Z080-6 CONTACT PLT-TUNGSTEN 5HP
80-7 P5912Z080-7 S CAPACITOR 400M 125V 1-3/4 X 3-3/8
80-8 P5912Z080-8 R CAPACITOR 50M 250V 1-3/4 X 2-3/4
80-9 P5912Z080-9 REAR MOTOR BEARING
80-10 P5912Z080-10 FRONT MOTOR BEARING
G5912Z 5HP, 1-PH MOTOR G7214Z 71⁄2HP, 3-PH MOTOR
REF PART # DESCRIPTION REF PART # DESCRIPTION
7 P5912Z007 HEX NUT 3/8-16 72 P5912Z072 KEY 7 X 7 X 50
8 P5912Z008 LOCK WASHER 3/8 73 P5912Z073 MOTOR PULLEY
9 P5912Z009 FLAT WASHER 3/8 74 P5912Z074 HEX BOLT 3/8-16 X 1-1/2
14 P5912Z014 HEX BOLT 3/8-16 X 1-1/4 75 P5912Z075 FLAT WASHER 5/16
15 P5912Z015 HEX BOLT 3/8-16 X 3/4 76 P5912Z076 LOCK WASHER 5/16
39A P5912Z039A QUILL 7-3/4" LONG V2.01.02 77 P5912Z077 CAP SCREW 5/16-18 X 1
50 P5912Z050 HEX BOLT 1/4-20 X 5/8 78 P5912Z078 COMPRESSION SPRING 3.4 X 20.3
51 P5912Z051 LOCK WASHER 1/4 79 P5912Z079 KEY 3/8 X 3/4 X 1
52 P5912Z052 FLAT WASHER 1/4 81 P5912Z081 SHAFT
53 P5912Z053 LOCK KNOB 82 P5912Z082 FLAT WASHER 1/2
54 P5912Z054 BAR LOCK 83 P5912Z083 MOTOR BASE
55 P5912Z055 HEX NUT 5/16-18 84 P5912Z084 KNOB
56 P5912Z056 HEX BOLT 5/16-18 X 1 85 P5912Z085 LOCK WASHER 1/2
57 P5912Z057 SCREW LOCK 86 P5912Z086 HEX BOLT 1/2-20 X 1
58 P5912Z058 WASHER GEAR 87 P5912Z087 POINTER
59 P5912Z059 GEAR 88 P5912Z088 PHLP HD SCR 10-24 X 3/8
60 P5912Z060 COLLAR 89 P5912Z089 HEX BOLT 5/16-18 X 3/4
61 P5912Z061 KEY 4 X 4 X 16 90 P5912Z090 SHAFT GUIDE
62 P5912Z062 BASE GEAR SHAFT 91 P5912Z091 PLATE
63 P5912Z063 SHAFT GEAR 92 P5912Z092 MOTOR PLATE
64 P5912Z064 BASE SPINDLE 93 P5912Z093 SHAFT GEAR
65 P5912Z065 FLAT WASHER 1/2 94 P5912Z094 BASE GEAR SHAFT
66 P5912Z066 LOCK NUT 1/2"-12 95 P5912Z095 METAL HANDWHEEL
67 P5912Z067 CAP SCREW 3/8-16 X 1-1/4 96 P5912Z096 HANDLE
68 P5912Z068 SCREW 3/8-16 X 1-1/4 97 P5912Z097 HEX BOLT 1/4-20 X 1-1/4
69 P5912Z069 COLLAR 98 P5912Z098 HEX NUT 1/4-20
70 P5912Z070 V-BELT A30 102 P5912Z102 SET SCREW 10-32 X 3/16
71 P5912Z071 V-BELT A28
80 P5912Z080 MOTOR 5HP 220V 1-PH
80 P7214Z080 MOTOR 7.5HP 220V 3-PH
80-1 P5912Z080-1 MOTOR FAN COVER
80-1 P7214Z080-1 MOTOR FAN COVER
80-2 P5912Z080-2 MOTOR FAN
80-2 P7214Z080-2 MOTOR FAN
80-3 P5912Z080-3 CAPACITOR COVER
80-3 P7214Z080-3 MOTOR JUNCTION BOX
80-4 P5912Z080-4 MOTOR JUNCTION BOX
80-5 P5912Z080-5 CENT SWITCH 1/2-3450
80-6 P5912Z080-6 CONTACT PLT-TUNGSTEN 5HP
80-7 P5912Z080-7 S CAPACITOR 400M 125V 1-3/4 X 3-3/8
80-8 P5912Z080-8 R CAPACITOR 50M 250V 1-3/4 X 2-3/4
80-9 P5912Z080-9 REAR MOTOR BEARING
80-10 P5912Z080-10 FRONT MOTOR BEARING
REF PART # DESCRIPTION REF PART # DESCRIPTION
7 P5912Z007 HEX NUT 3/8-16 72 P5912Z072 KEY 7 X 7 X 50
8 P5912Z008 LOCK WASHER 3/8 73 P5912Z073 MOTOR PULLEY
9 P5912Z009 FLAT WASHER 3/8 74 P5912Z074 HEX BOLT 3/8-16 X 1-1/2
14 P5912Z014 HEX BOLT 3/8-16 X 1-1/4 75 P5912Z075 FLAT WASHER 5/16
15 P5912Z015 HEX BOLT 3/8-16 X 3/4 76 P5912Z076 LOCK WASHER 5/16
39A P5912Z039A QUILL 7-3/4" LONG V2.01.02 77 P5912Z077 CAP SCREW 5/16-18 X 1
50 P5912Z050 HEX BOLT 1/4-20 X 5/8 78 P5912Z078 COMPRESSION SPRING 3.4 X 20.3
51 P5912Z051 LOCK WASHER 1/4 79 P5912Z079 KEY 3/8 X 3/4 X 1
52 P5912Z052 FLAT WASHER 1/4 81 P5912Z081 SHAFT
53 P5912Z053 LOCK KNOB 82 P5912Z082 FLAT WASHER 1/2
54 P5912Z054 BAR LOCK 83 P5912Z083 MOTOR BASE
55 P5912Z055 HEX NUT 5/16-18 84 P5912Z084 KNOB
56 P5912Z056 HEX BOLT 5/16-18 X 1 85 P5912Z085 LOCK WASHER 1/2
57 P5912Z057 SCREW LOCK 86 P5912Z086 HEX BOLT 1/2-20 X 1
58 P5912Z058 WASHER GEAR 87 P5912Z087 POINTER
59 P5912Z059 GEAR 88 P5912Z088 PHLP HD SCR 10-24 X 3/8
60 P5912Z060 COLLAR 89 P5912Z089 HEX BOLT 5/16-18 X 3/4
61 P5912Z061 KEY 4 X 4 X 16 90 P5912Z090 SHAFT GUIDE
62 P5912Z062 BASE GEAR SHAFT 91 P5912Z091 PLATE
63 P5912Z063 SHAFT GEAR 92 P5912Z092 MOTOR PLATE
64 P5912Z064 BASE SPINDLE 93 P5912Z093 SHAFT GEAR
65 P5912Z065 FLAT WASHER 1/2 94 P5912Z094 BASE GEAR SHAFT
66 P5912Z066 LOCK NUT 1/2"-12 95 P5912Z095 METAL HANDWHEEL
67 P5912Z067 CAP SCREW 3/8-16 X 1-1/4 96 P5912Z096 HANDLE
68 P5912Z068 SCREW 3/8-16 X 1-1/4 97 P5912Z097 HEX BOLT 1/4-20 X 1-1/4
69 P5912Z069 COLLAR 98 P5912Z098 HEX NUT 1/4-20
70 P5912Z070 V-BELT A30 102 P5912Z102 SET SCREW 10-32 X 3/16
71 P5912Z071 V-BELT A28
80 P5912Z080 MOTOR 5HP 220V 1-PH
80 P7214Z080 MOTOR 7.5HP 220V 3-PH
80-1 P5912Z080-1 MOTOR FAN COVER
80-1 P7214Z080-1 MOTOR FAN COVER
80-2 P5912Z080-2 MOTOR FAN
80-2 P7214Z080-2 MOTOR FAN
80-3 P5912Z080-3 CAPACITOR COVER
80-3 P7214Z080-3 MOTOR JUNCTION BOX
80-4 P5912Z080-4 MOTOR JUNCTION BOX
80-5 P5912Z080-5 CENT SWITCH 1/2-3450
80-6 P5912Z080-6 CONTACT PLT-TUNGSTEN 5HP
80-7 P5912Z080-7 S CAPACITOR 400M 125V 1-3/4 X 3-3/8
80-8 P5912Z080-8 R CAPACITOR 50M 250V 1-3/4 X 2-3/4
80-9 P5912Z080-9 REAR MOTOR BEARING
80-10 P5912Z080-10 FRONT MOTOR BEARING

-43-
Model G5912Z/G7214Z (Mfd. Since 03/13)
Fence Guard
105AV3
105AV3
119A

-44- Model G5912Z/G7214Z (Mfd. Since 03/13)
REF PART # DESCRIPTION REF PART # DESCRIPTION
119A P5912Z119A COMPLETE FENCE ASSEMBLY 113 P5912Z113 CUTTER GUARD
51 P5912Z051 LOCK WASHER 1/4 114 P5912Z114 SET SCREW 1/4-20 X 1/4
52 P5912Z052 FLAT WASHER 1/4 115 P5912Z115 BRACKET ASSY FENCE RH
55 P5912Z055 HEX NUT 5/16-18 116A P5912Z116A WOOD FENCE (RIGHT)
76 P5912Z076 LOCK WASHER 5/16 116B P5912Z116B WOOD FENCE (LEFT)
82 P5912Z082 FLAT WASHER 1/2 117 P5912Z117 FLAT HD SCR 5/16-18 X 1-1/2
89 P5912Z089 HEX BOLT 5/16-18 X 3/4 118 P5912Z118 HOLD DOWN PLATE
97 P5912Z097 HEX BOLT 1/4-20 X 1-1/4 119 P5912Z119 GUARD/DUST HOOD
98 P5912Z098 HEX NUT 1/4-20 120 P5912Z120 BAR
105AV3 P5912Z105AV3 ADJ HANDLE 3"L 1/2-12 X 1-9/16 V3.03.13 121 P5912Z121 RETAINER (L) 5/8"
106 P5912Z106 BRACKET SCREW GUIDE 122A P5912Z122A KNOB BOLT 3/8-16 X 1 V2.10.02
107 P5912Z107 SCREW GUIDE ASSY 123 P5912Z123 NUT 3/8
107A P5912Z107A HANDWHEEL 124 P5912Z124 RETAINER (S) 1/2"
108 P5912Z108 BALL KNOB 3/8-16 (PLASTIC) 125 P5912Z125 KNOB
109 P5912Z109 SHAFT GUIDE 126 P5912Z126 BRACKET ASSY FENCE LH
110 P5912Z110 BAR 127 P5912Z127 HEX BOLT 1/4-20 X 1-1/2
111 P5912Z111 KNOB 5/16-18 V1 167 P5912Z167 KNOB BOLT 3/8-16 X 1
112 P5912Z112 FLAT WASHER 5/16
Fence Guard Parts List

-45-
Model G5912Z/G7214Z (Mfd. Since 03/13)
Labels & Cosmetics
400
401
403
408
409
410
411
412 413
414
415
416
REF PART # DESCRIPTION REF PART # DESCRIPTION
400 P5912Z400 G5912Z MACHINE ID LABEL 410 P5912Z410 ROTATION DIRECTION LABEL
400 P7214Z400 G7214Z MACHINE ID LABEL 411 P5912Z411 SAFETY GLASSES LABEL
401 P5912Z401 GRIZZLY NAME PLATE 412 P5912Z412 HAND NEAR CUTTER LABEL
402 P5912Z402 PULLEY LABEL 413 P5912Z413 UNPLUG LABEL
403 P5912Z403 SPEED CHANGE LABEL 414 P5912Z414 ELECTRICITY LABEL
408 P5912Z408 READ MANUAL LABEL 415 P5912Z415 LARGE ELECTRICITY LABEL
409 P5912Z409 SCALE LABEL 416 P5912Z416 "GRIZZLY GREEN" TOUCH-UP PAINT
Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes
off or becomes unreadable, the owner of this machine MUST replace it in the original location
before resuming operations. For replacements, contact [phone] or www.grizzly.com.
