FH-400 New Holland T8 - T4A & B Std. Axle
w/ STD PST & CVT Series
Undercarriage Installation Instructions
Caution:
• Always use precaution when working around any equipment.
• Always wear safety glasses.
• Follow tractor manufacturer’s safety guidelines when installing this product.
Read all instructions prior to installation.
Remove front 3-point or weights and weight bracket from front of tractor if necessary.
Install 2 - 1” x 6” bolts (PN: 16-17271) and 2 - 1” nuts (PN: 70-20599) on the end of the undercarriage. Turn the 1”
bolts in for installation. The bolts will be adjusted after the push pole is installed. See the attached diagram for proper
installation of the bolts and nuts.
Position the undercarriage (U/C) under the tractor and center with the frame of the tractor.
Lift the U/C until the holes on the tractor line up with the holes on the U/C.
At the front of the tractor, use 8 - 20mm x 70mm bolts (PN: 16-1876) with a 3/4” SAE at washer (PN: 57-20757) on
each bolt to attach the U/C to the front of the tractor. Tighten nger tight. See the attached diagram for any clarication.
Modications are needed to reattach the pads on the side of the tractor frame where the side rails are attached. Refer
to the attached diagram for further information.
Use 10 - 20mm x 70mm bolts (PN: 16-1876) with a 3/4” at washer (PN: 57-20747) on each bolt in the holes of the left
and right rail (PN: 44-14980-R,L) to attach the rails to the tractor frame.
If there is a ground boss where the rails are attached to the tractor, use the 20mm x 120mm bolt (PN: 16-2489) with a
3/4” washer (PN: 57-20747) along with the ground boss instead of a 20mm x 70mm bolt.
Attach the left and right rails to the rear of the undercarriage with 2 - 1” bolts (PN: 16-20560), 4 - 1” heavy duty at
washers (PN: 57-20819), and 2 - 1” nuts (PN: 70-20599) for each side.
Once all bolts are installed, torque the front 20mm bolts to 432 ft-lbs., the 20mm bolts on the side rails to 432 ft-lbs., and
the 1” bolts attaching the side rails to the U/C to 903 ft-lbs.
Position the push pole (PN: 17-14930) under the tractor. See the attached diagram for the correct orientation of the
push pole.
Slide the push pole onto the rod at the rear of the undercarriage. Lift the rear of the push pole up to the drawbar bracket.
Screw in a 1” x 3” bolt (PN: 16-20562) on each side of the push pole all the way till they are tight and are resting on the
top of the drawbar bracket.
Push the push pole back tight against the drawbar bracket.
Unscrew the two 1” x 6” bolts at the front of the push pole until they are tight against the push pole. Torque the 1” bolts
to 90-95 ft-lbs.
Tighten the nuts up tight against the push pole. Use the nuts to lock the bolts in place.
After rst 8 hours of use, re-torque all bolts.
Check all fasteners regularly to ensure proper operation of equipment.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
1PN: 63-19060-INS Date: 12-10-2015
