Grundig Sonoclock 790 DCF User manual

CLOCK RADIO
Sonoclock 790 DCF
IT ES
DE EN FR
RU

3
___________________________________________________________
SNOOZE
MIN/VOL-
HOUR/VOL+
SET
SLEEP
-TUNING+
U
RESET
AL 2
AL 1
TIME ZONE
/ WEC

4
___________________________________________________________
DEUTSCH 05 -15
ENGLISH 16 - 26
FRANÇAIS 27 - 37
ITALIANO 38 - 48
РУССКИЙ 49 - 59
ESPAÑOL 60 - 70

16 ENGLISH
7 Note, prolonged listen-
ing at loud volumes with
the earphones can dam-
age your hearing.
7
Do not expose the back-up bat-
tery to extreme heat, caused for
example by direct sunlight, heat-
ers or fire.
7
Never open the device casing.
No warranty claims are accepted
for damage caused by incorrect
handling.
7
The type plate is located on the
bottom of the device.
SAFETY AND SET-UP ____________________________
7
This device is designed for the
playback of audio signals. Any
other use is expressly prohibited.
7
Protect the device from moisture
(water drops or splashes). Do not
place any vessels such as vases on
the device. These may be knocked
over and spill fluid on the electri-
cal components, thus presenting a
safety risk.
7
Do not place any naked flames
such as candles on the device.
7
Make sure the device is adequate-
ly ventilated. Do not cover the
ventilation slots with newspapers,
table cloths, curtains, etc.
7
When deciding where to place
the device, please note that furni-
ture surfaces are covered by vari-
ous types of varnish and plastic,
most of which contain chemical
additives. These additives can cor-
rode the device supports, leaving
residues on the furniture surfaces
which can be difficult or impossi-
ble to remove.
7
Do not use any cleaning agent,
as this may damage the casing.
Clean the device with a clean,
moist leather cloth.

ENGLISH 17
U
Headphone jack, to connect head-
phones or earphones with a jack
plug (ø 3.5 mm).
RESET
Resets the device.
Controls on the right side
SLEEP
Activates the sleep time setting.
SET
Activates the time setting;
activates the day of the week
setting;
displays the alarm times.
HOUR/VOL+
To set the hour;
press briefly: changes the hours
forward in steps;
press longer: changes the hours
forward continuously.
In radio mode: increases the
volume.
MIN/VOL-
To set the minutes;
press briefly: changes the min-
utes forward in steps;
press longer: changes the min-
utes forward continuously.
In radio mode: decreases the
volume.
OVERVIEW ______________________________________
See the figure on page 3.
Controls on the top
SNOOZE
Interrupts the alarm function;
displays the day of the week;
displays the remaining snooze
time.
Switches the radio on and off;
ends the alarm for this day;
deactivates the sleep timer.
Controls on the left side
AL 1
For alarm time 1: selects the alarm
with a signal tone or radio;
activates and deactivates the
alarm.
AL 2
For alarm time 2: selects the alarm
with a signal tone or radio;
activates and deactivates the
alarm.
TIME ZONE/ WEC
Activates the alarm interruption for
the weekend;
activates the time zone setting.
- TUNING +
Dial for tuning to radio stations.

18 ENGLISH
Displays
•
Automatically adjusts the brightness
of the display to the brightness of
the surroundings.
AL 1
Displays that the alarm is activated with
a signal tone or radio for alarm
time 1.
WEC
Displays that the alarm interruption
for the weekend is activated.
10:00
Displays the time, the alarm times,
the sleep timer time.
AL 2
Displays that the alarm is activated
with a signal tone or radio for
alarm time 2.
Displays that the DCF time synchro-
nisation is active;
flashes during the synchronisa-
tion.
•
Mode indicator for the radio.
FM 88 108 MHz
Frequency display.
OVERVIEW ______________________________________
Controls on the back
Ü
Power cord.
Wire antenna for FM reception.
DCF 77- Antenna.
Controls on the bottom
BACKUP
Battery compartment for the 9V
back-up battery.

ENGLISH 19
Inserting the back-up
battery
During mains operation, the back-up
battery ensures that stored settings
are not lost in the case of a power
failure or when the device is briefly
disconnected from the mains.
1 Open the battery compartment lid
by pressing on the arrow and pus-
hing down the lid.
2 When inserting the battery (9 V,
6LF 22), observe the polarity mar-
ked on the base of the battery com-
partment.
Note:
7 Remove the back-up battery
when it is flat or when you know
that the device will not be used
for a long period of time.
Environmental note:
7 Batteries, including those which
do not contain heavy metal,
should not be disposed of
with household waste. Always
dispose of used batteries in
accordance with local environ-
mental regulations.
POWER SUPPLY ________________________________
Mains operation
Check that the mains voltage on
the type plate (on the bottom of the
device) corresponds to your local
mains supply. If this is not the case,
contact your specialist dealer.
1 Plug the mains cable into the so-
cket (230V~, 50/60 Hz).
Caution:
7 The device is connected to the
mains with the power plug. To
fully disconnect the device from
the mains, pull out the plug.
7 The mains plug is used to dis-
connect the device. It shall
remain readily operable and
should not be obstructed during
intended use.

20 ENGLISH
The installed microprocessor of the
radio-controlled clock processes the
received time telegrams and controls
the quartz clock fully automatically.
After the clock is first activated, the
DCF synchronisation is performed
immediately and subsequently every
day at 2 am and 3 am. Depending
on the point of reception, synchroni-
sation can take several minutes. Dur-
ing this process, the » « display
flashes, if the signal is strong enough,
in a 1 second rhythm of the received
time telegram. After synchronization
has taken place, the » « display
begins to light up. If the » « dis-
play disappear, the synchronization
was not successful.
In addition to the advantages of the
time precision and the exact, to-the-
second wake-up and alarm signal,
your radio clock sets itself fully auto-
matically from winter time to summer
time.
SETTINGS ________________________________________
Radio-controlled clock
With your built-in radio-controlled
clock, you are in possession of an
absolutely precise alarm and meet-
ing clock which is automatically set
to the radio-transmitted time signals of
the most precise clock in the world:
the atomic clock of the Physikalisch-
Technischen Bundesanstalt (PTB – the
German national metrology institute).
This clock is so precise that in 1 mil-
lion years a deviation of 1 second
can be expected.
Your radio-controlled alarm clock
receives “time telegrams” via long
wave 77.5 kHz from the time signal
transmitter DCF 77, located in Main-
flingen (24 km south-east of Frank-
furt/Main). This time signal transmitter
has a range of 1500 km.
The device receives the station
DCF 77 free of charge via the con-
nected DCF 77 antenna everywhere,
where a sufficient long wave recep-
tion is possible with a good portable
radio. In many cases, your radio
clock receives the time telegrams
from a considerable distance from
the station; however, the local recep-
tion quality plays a significant role
here.

ENGLISH 21
Setting time and day of the
week
If the device has been switched on
for the first time – if no time signal
has been received – »0:00« appears
in the display as a sign that the time
has to be set. The same applies after
a power failure or if the device has
been disconnected from the mains
supply and no back-up battery has
been inserted.
1 Press »SET«.
– Display: »:« flashes.
2 Press »HOUR/VOL+« briefly to
set the hours step-by-step or hold
down to run through the hours
continuously.
3 Press »MIN/VOL-« briefly to set
the minutes step-by-step or hold
down to run through the minutes
continuously.
Notes:
7 When the minute display chang-
es from »59« to »00«, this does
not affect the hour display.
7 The device saves the set time
automatically after 10 seconds.
4 To set the day of the week, press
»TIME ZONE/WEC« and »SET«
at the same time.
– Display: for example, the day of
the week »1« = Monday.
SETTINGS ________________________________________
5 Set the day of the week (»1« =
Monday, »2«, »3«, »4«, »5«, »6«
or »7« = Sunday) using »HOUR/
VOL+« or »MIN/VOL-«.
– The device saves the selected
day of the week automatically
after 5 seconds.
Note:
7 Display the selected day of the
week and press »SNOOZE«
longer than 3 seconds and hold
it pressed.
Setting the time zone
If you use the device outside of the
Central European Time Zone (CET),
you can correct the time by +/– 2
hours.
1 Press »TIME ZONE/WEC« keep
pressed for approximately 2 se-
conds.
– Display: »00«, »:« flashes.
2 Set the time zone with »HOUR/
VOL+« or »MIN/VOL-« (Scale:
»00«, »01«, »02«, »-02« and »-01«).
– Display: e.g. »02«.

22 ENGLISH
Note:
7 If a back-up battery has not been
inserted, the time is automatically
reset by DCF time synchronisa-
tion as long as the DCF recep-
tion is strong enough. Alarm time
and time zone synchronisation
are each reset to the values
»00:00« and »00«. Please note
that, in this case, you may be
wakened at the wrong time.
Setting alarm time 1
1 Press »SET« twice.
– Display: the last alarm time set,
»AL 1 « and »:« flash al-
ternately.
2 Press »HOUR/VOL+« briefly to
set the hours step-by-step or hold
down to run through the hours
continuously.
3 Press »MIN/VOL-« briefly to set
the minutes step-by-step or hold
down to run through the minutes
continuously.
– The device saves the set alarm
time automatically after 10 se-
conds.
– Display: »AL 1 « lights up,
this means the alarm is activa-
ted.
– The device wakes you up at the
set time with the alarm signal of
your choice.
SETTINGS ________________________________________
Setting alarm time 2
1 Press »SET« three times.
– Display: the last alarm time set,
»AL 2 « and »:« flash alter-
nately.
2 Press »HOUR/VOL+« briefly to
set the hours step-by-step or hold
down to run through the hours
continuously.
3 Press »MIN/VOL-« briefly to set
the minutes step-by-step or hold
down to run through the minutes
continuously.
– The device saves the set alarm
time automatically after 10 se-
conds.
– Display: »AL 2 « lights up,
this means the alarm is activa-
ted.
– The device wakes you up at the
set time with the alarm signal of
your choice.

ENGLISH 23
Note:
7 If no other button is pressed, the
device switches back automati-
cally to the current time after
10 seconds.
Alarm with radio station
1 Press » « to switch on the device.
2 Select the radio station using the
»-TUNING+« dial.
3 Adjust the alarm volume by pressing
»HOUR/VOL+« or »MIN/VOL-«.
4 Set the radio station you want as
an alarm signal (» «), and press
»AL1« or »AL 2« twice.
– Display: the corresponding LED
»AL 1 « or »AL 2 «
lights up.
5 Press » « to switch off the device.
– The device wakes you up at the
set time with the radio station
(alarm duration is 59 minutes).
Alarm with signal tone
1 Press » « to switch off the device.
2 Set the signal tone alarm signal
(» «), and press »AL 1« or »AL 2«
once.
– The device wakes you up at
the set time with the signal tone
(alarm duration is 59 minutes).
OPERATION _____________________________________
Switching on and off
1 Press » « to switch on the device
from standby mode.
2 Press » « to switch the device to
standby mode.
Radio mode
For the best possible FM (VHF) re-
ception, it is sufficient to align the
wire antenna accordingly.
Tuning to radio stations
1 Select the radio station using the
»-TUNING+« dial.
Adjusting the volume
1 Adjust the volume by pressing
»HOUR/VOL+« or »MIN/VOL-«.
Alarm mode
The device has a dynamic alarm tone
that starts at a low volume and reach-
es its maximum volume within 30 to
45 seconds.
Viewing the alarm time
1 Press »SET« twice (for alarm time
1) or three times (for alarm time 2).
– Display: the last set alarm time
1 or 2, the LED »AL 1 « or
»AL 2 « flashes.

24 ENGLISH
Interrupting the alarm
1 Press »SNOOZE« while the
alarm is sounding.
– The alarm signal (radio station
or signal tone) stops.
– The alarm goes on again at
9 minute intervals (alarm dura-
tion is 59 minutes).
Cancelling the alarm for the
day
1 Press » « while the alarm is
sounding.
– The alarm signal (radio station
or signal tone) stops, the alarm
remains at the set time for the
next day.
Deactivating and activating
alarm standby
1 To deactivate the alarm, press
»AL 1« or »AL 2« repeatedly until
the LED »AL 1 « or »AL 2 «
disappears.
– The set alarm time is saved.
2 To activate the alarm with »AL 1«
or »AL 2« switch to » « or » «.
– Display: the LED »AL 1 « or
»AL 2 « lights up.
OPERATION _____________________________________
Activating the alarm interrup-
tion for the weekend
1 Press »TIME ZONE/WEC«.
– Display: the LED »WEC« lights up.
– The alarm function is deactivat-
ed at the weekend.
2 Press »TIME ZONE/WEC« again.
– Display: the LED »WEC« disap-
pears.
– The alarm function is activated
at the weekend.

ENGLISH 25
Deactivating the sleep timer
1 To deactivate the sleep timer ear-
ly, press » «.
– The device switches to stand-by.
Note:
7 The device realize the switch-off
time and offer this time for the
next using like a preselection.
Timer mode
The device has a sleep timer, which
switches it off in radio mode at a pre-
set time. The switch-off time can be set
to between 1 minute and 1 hour and
59 minutes and then stays saved.
Activating the sleep timer
1 Press »SLEEP« to switch on the
device.
– Display: the switch-off time
»0:59« (for 59 minutes).
– You will hear the selected radio
station.
2 Set the selected switch-off time
with »HOUR/VOL+« or »MIN/
VOL-« step-by-step (press briefly)
or continuously (hold down).
– After the selected switch-off time
has elapsed, the device switch-
es off automatically.
3 Display the remaining switch-off
time with »SLEEP«.
OPERATION _____________________________________

26 ENGLISH
Technical data
This device is noise-sup-
pressed according to the
applicable EU directives.
This product fulfils the European direc-
tives 2004/108/EC, 2006/95/EC ,
2009/125/EC and 2011/65/EU.
The declaration of conformity can be
downloaded at
www.grundig.com/downloads/doc.
Power supply:
230 V, 50/60 Hz
Max. power consumption:
< 3,5 W (operation),
< 1 W (standby)
Output:
400 mW
Frequency bands:
FM 87.5 ...108.0 MHz
Dimensions:
W x H x L 95 x 150 x 75 mm
Weight: 565 g
Technical and design modifications
reserved.
INFORMATION _________________________________
Environmental note
This product has been man-
ufactured with high quality
parts and materials which
can be reused and are suit-
able for recycling.
Therefore, do not dispose the prod-
uct and battery with normal domes-
tic waste at the end of its service life.
Take it to a collection point for the
recycling of electrical and electronic
equipment.
This is indicated by this symbol on
the product, in the operating manual
and on the packaging.
Please consult your local authorities
to learn the nearest collection point.
Help protect the environment by re-
cycling used products.

Grundig Intermedia GmbH
Beuthener Strasse 41
90471 Nürnberg
www.grundig.com
72011 410 3500 13/08
