Grundig HS 8030 User manual

trplpt
esende
cs el
fr sv
it
nl
WET & DRY
HAIR STYLER
Straight & Curls
HS 8030

2
_________________________________________________________
B C D E
F I
G H
A

3
_________________________________________________________
DEUTSCH 04-16
SVENSKA 50-60
ESPAÑOL 28-38
PORTUGUÊS 72-82
ČESKY 105-115
ENGLISH 17-27
NEDERLANDS 61-71
TÜRKÇE 94-104
FRANÇAIS 39-49
POLSKI 83-93
ΕΛΛΗΝΙΚΑ 116-126
ITALIANO 127-137

ENGLISH 17
SAFETY_______________________________
Please note the following instructions
when using the appliance:
7 The appliance is designed for do-
mestic use only.
7 Never use the appliance in the
bath, shower or over a wash
basin filled with water; nor should
it be operated with wet hands.
7 Do not immerse the appliance in
water or let it come into contact
with water, even during cleaning.
7 If the appliance is used in the
bathroom, it is essential that you
unplug it after use, as any water
close to the appliance can still
pose a hazard, even if the appli-
ance is switched off.
7 If not already in use, installing
a residual current-operated
protective device (RCD) is
recommended for additional
protection with a rated residual
operating current not exceed-
ing 30 mA in the electrical cir-
cuit of your bathroom. Ask your
plumber for advice.
7 Never cover the appliance, for
example with a towel.
7 The appliance can become
very hot. Never leave your hair
between the ceramic plates for
more than a few seconds.
7 The outer surface of the appli-
ance may get hot when used
for long periods. In this case do
not touch with your hands and
allow it to cool.
7 Do not allow the hot styling
plates to come into contact with
your face, neck or head.
7 Unplug the appliance after use.
Do not disconnect the plug by
pulling on the cord. Place the
appliance on a heat resistant
surface and allow it to cool.
7 Never use the appliance if it or
the power cord is visibly dam-
aged.
7 If the power cord is damaged,
it must be replaced by the
manufacturer, a service centre
or a similarly qualified person
to avoid any danger of electri-
cal shock.
7 Keep the appliance out of the
reach of children.

18 ENGLISH
SAFETY_______________________________
7 The appliance should not be
used by the following people,
including children: those with
limited physical, sensory or
mental capabilities and also
those with a lack of experience
and knowledge. This does not
apply to the latter if they were
instructed in the use of the ap-
pliance or if they use it under
the supervision of a person
responsible for their safety.
Children should always be su-
pervised to ensure that they do
not play with the appliance.
7 Never open the appliance
under any circumstance. No
warranty claims are accepted
for damage caused by im-
proper handling.
7 Check if the mains voltage on
the type plate (on the handle
of the appliance) corresponds
to your local mains supply.
The only way to disconnect the
appliance from the mains is to
unplug it.
7 Never wrap the power cord
around the appliance.
7 Never use the appliance in or
near to combustible, inflam-
mable places and materials
and furniture. Do not let the
appliance come into contact
with or become covered by
inflammable materials e.g. cur-
tains, textiles, walls, etc. Please
make sure that the appliance
is always kept a safe distance
away from flammable materials
and furniture.
7 Do not use paper, cardboard,
plastic under the appliance.

ENGLISH 19
ATAGLANCE________________________
Dear Customer,
Congratulations on the purchase of
your HS 8030 Wet & Dry Hairstyler.
Read the following user notes care-
fully to ensure full enjoyment of your
quality Grundig product for many
years to come.
The high-quality and professional
styling appliances in the new product
range fulfill the highest standards for
salon results at home.
A responsible approach!
GRUNDIG focusses
on contractually
agreed social work-
ing conditions with
fair wages for both
internal employees
and suppliers. We also attach
great importance to the efficient
use of raw materials with continu-
ous waste reduction of several
tonnes of plastic every year. Fur-
thermore, all our accessories are
available for at least 5 years.
For a future worth living.
For a good reason. Grundig.
Special Features
7 Diamond blond shine activator: the
exclusive coating on the plates en-
sures natural shine, sensational vol-
ume, shimmering light reflections
and lively radiance especially for
blond, lightened and fine hair.
7 Care and protection with its gentle
ceramic coating with tourmaline
and nano silver - for hydrated hair
with more shine, bounce and care:
– Ceramic ensures constantly
high temperature and even
heat distribution. The heat is
distributed evenly to ensure hair
is fully protected.
– Tourmaline generates
negative ions in a natural
way, pre vents frizz, static
charging and preserves
the natural moisture of the
hair.
– Nano silver inhibits bac-
teria build-up, constantly
protecting and maintaining
the surface of the plates
- for healthy hair and hygi-
enic styling plates.

20 ENGLISH
ATAGLANCE________________________
7 Floating bottom plate for even
pressure on hair and straightening
or curling without damaging it.
7 Extra long (11 cm), 2.5 cm wide,
styling plates for efficient styling,
specifically for long hair.
7 Wet & Dry function dries and
styles the hair gently in one go.
7 Memory function of the last
used temperature.
7 Fast electronic heating to
100 ºC within 30 seconds.
7 The Grundig Wet & Dry Hair-
styler can be used for fashion-
able and flexible styling, for
a smooth, sleek look, shaped
ends as well as soft cascading
waves or curls.
7 43W output gives you profes-
sional styling results at home.
Controls
See the figure on page 2.
A Extra long ceramic coated
plates with tourmaline and nano
silver
B Steam vents
C Liquid crystal display (LCD)
D Handle
E Swivel cord (3 m)
F Heat setting button »+«
G Heat setting button »-«
H On/Off button
I Plate lock

ENGLISH 21
OPERATION_________________________
Hair structure and
temperature settings
Hair structure
The appliance allows you to make
individual temperature settings.
Depending on the hair structure, we
recommend the following settings:
7 For fine, porous, coloured,
bleached hair: 140 °C to
160 °C.
7 For normal hair: 170 °C to
180 °C.
7 For strong, resistant, thick hair:
190 °C to 220 °C.
Memory function
7 The appliance automatically heats
up to the temperature level last
used after being switched on.
Turbo heating
7 By pressing the heat setting button
»+« F (TURBO) for two seconds,
the appliance immediately heats
up to the highest temperature
level (220 °C).
Temperature setting
The temperature can be set using the
heat setting buttons »+« F or »–«
G, with 9 levels ranging from
140 °C to 220 °C.
1 Switch the appliance on by press-
ing the On/Off button H for 2
seconds.
– The LCD C lights up in blue.
2 Press the heat setting buttons »+«
F or »–« G to set the tempera-
ture. Heat setting button »–« to
reduce the temperature in 10 °C
increments, »+« to increase the
temperature in 10 °C increments.
Notes
7 When the appliance reaches the
set temperature, a signal sounds
meaning that is is ready to use.
7 The appliance reaches a tem-
perature of 100 °C in only 30
seconds.

22 ENGLISH
OPERATION_________________________
“Locking” the temperature
setting
1 Switch the appliance on by press-
ing the On/Off button H for 2
seconds.
– The LCD C lights up in blue.
2 Press the heat setting buttons »+«
F or »–« G to set the tempera-
ture.
3 The set temperature level is locked
automatically after 5 seconds and
the temperature cannot be altered
during use.
– In the display, the »D« symbol
appears next to the tempera-
ture.
4 To “unlock” the temperature,
press the heat setting button »–«
(LOCK) for a few seconds.
– In the display, the »D« symbol
disappears.
5 After unlocking the temperature,
a new temperature level can be
selected or the appliance can be
switched off using the On/Off
button H.
Styling options
The special temperature settings
make this appliance suitable for all
types of hair, wet or dry.
Using your hair styler, you can:
7 Straighten hair,
7 Shape the ends (inwards and
outwards),
7 Style soft-cascading waves and
curls.
You can style / straighten your hair
when it is dry, damp or towel-dry.
Wet hair dries while it is being styled
/ straightened.
For a special styling guide on how
to use a classic straightener model
for straightening and also curling
hair, please visit: www.grundig.de/
stylingguide!
Straightening hair
Caution
7 The housing of the appliance be-
comes very hot near the heating
plates. Do not touch the housing
near the heating plates.

ENGLISH 23
OPERATION_________________________
7 Place the appliance on a solid,
flat, heat resistant surface. Do not
place the appliance on any soft
or uneven surfaces such as car-
pets, rugs or bedding and never
cover.
Note
7 Release the plate lock I if neces-
sary.
1 Plug the power cord E into the
wall socket.
2 Switch the appliance on by press-
ing the On/Off button H for 2
seconds.
– The LCD C lights up in blue.
3 Press the heat setting buttons »+«
F or »–« G to set the tempera-
ture. Heat setting button »–« to
reduce the temperature in 10 °C
increments, »+« to increase the
temperature in 10 °C increments.
Notes
7 Select the lowest temperature set-
ting the first time you use it. There
are 9 temperature levels avail-
able (140 °C = min., 220 °C = max.).
7 When the appliance reaches
the set temperature, a signal
sounds meaning that is is ready
to use.
7 When set accordingly, the
temperature level reaches the
maximum temperature of
220 °C after 60 seconds.
Hold the appliance in your
hand while it heats up.
4 Comb or brush out a section
of your hair about 3 cm wide,
starting at the neck.
5 Place the section of hair be-
tween the plates A as close to
the hair line as you can, and
then close them.
Caution
7 Do not touch the plates as they
are very hot.
6 Hold the appliance in position
until the hair is heated.
– This takes a few seconds at the
most.
7 Guide the plates in a careful,
smooth movement away from the
head to the end of the section of
hair. Avoid making kinks in it.
Notes
7 Repeat the procedure section by
section.
7 If you have thick hair, you might
have to repeat this procedure on
the same section several times.

24 ENGLISH
OPERATION_________________________
8 After use, switch the appliance
off by pressing the On/Off but-
ton H for 2 seconds. The LCD
C light turns off. Then unplug
the power cord E.
Notes
7 If the appliance is not used for
a while after it is heated up, it
automatically switches off after 60
minutes.
7 Never leave the appliance un-
attended while it is plugged in.
7 Unplug the power cord after
use.
7 Allow the appliance to cool in
a safe place.
Styling waves or curls
Caution
7 The housing of the appliance be-
comes very hot near the heating
plates. Do not touch the housing
near the heating plates.
7 Place the appliance on a solid,
flat, heat resistant surface. Do
not place the appliance on any
soft or uneven surfaces such as
carpets, rugs or bedding and
never cover.
Note
7 Release the plate lock I if neces-
sary.
1 Plug the power cord E into the
wall socket.
2 Switch the appliance on by press-
ing the On/Off button H for 2
seconds.
– The LCD C lights up in blue.
3 Press the heat setting buttons »+«
F or »–« G to set the tempera-
ture. Heat setting button »–« to
reduce the temperature in 10 °C
increments, »+« to increase the
temperature in 10 °C increments.
Notes
7 Select the lowest temperature set-
ting the first time you use it. There
are 9 temperature levels avail-
able (140 °C = min., 220 °C = max.).
7 When the appliance reaches
the set temperature, a signal
sounds meaning that is is ready
to use.

ENGLISH 25
OPERATION_________________________
7 When set accordingly, the
temperature level reaches a
maximum temperature of
220 °C after 60 seconds.
Hold the appliance in your
hand while it heats up.
4 Comb or brush out a strand of
your hair about 3 cm wide,
starting at the neck.
5 Place the strand of hair be-
tween the plates A as near to
the hair line as you can, and
then close them.
6 Depending on the hair style,
rotate the appliance by 180°
so that the hair wraps around
it at the height of the heating
plates A.
7 While rotating, slowly pull the
appliance towards the ends of
the hair.
– A curl is formed once the ap-
pliance has been pulled down
and over the ends of the hair.
Note
7 Repeat the procedure section by
section.
8 After use, switch the appliance off
by pressing the On/Off button H
for 2 seconds. The LCD C light
turns off. Then unplug the power
cord E.
Notes
7 If the appliance is not used for
a while after it is heated up, it
automatically switches off after 60
minutes.
7 Never leave the appliance un-
attended while it is plugged in.
7 Unplug the power cord after
use.
7 Allow the appliance to cool in
a safe place.

26 ENGLISH
Cleaning and care
1 Turn the appliance off and unplug
the power cord E from the wall
socket.
2 Before cleaning, allow the ap-
pliance to cool completely. The
appliance can become very hot
and may take up to 45 minutes
to cool.
3 Clean the housing and the ce-
ramic plates only with a damp,
soft cloth.
Caution
7 Never put the appliance or power
cord in water or any other liquid.
Do not use any cleaning agents.
Note
7 Before using the appliance after
cleaning, dry all parts carefully
using a dry soft towel.
INFORMATION_____________________
Storage
If you do not plan to use the ap-
pliance for a long period of time,
please store it carefully.
Make sure that it is unplugged, has
completely cooled and is completely
dry.
Lock the heating plates on the appli-
ance using the plate lock I.
Do not wrap the power cord around
the appliance.
Keep it in a cool, dry place.
Make sure that the appliance is kept
out of the reach of children.

ENGLISH 27
INFORMATION_____________________
Environmental note
This product has been manufactured
with high quality parts and materials
which can be reused and are suit-
able for recycling.
Therefore, do not dis-
pose the product with
normal domestic waste
at the end of its service
life. Take it to a collec-
tion point for the recy-
cling of electrical and electronic
equipment. This is indicated by this
symbol on the product, in the operat-
ing manual and on the packaging.
Please consult your local authorities
to learn the nearest collection point.
Help protect the environment by
recycling used products.
Technical data
This product conforms to the Euro-
pean directives 2004/108/EC,
2006/95/EC and 2009/125/EC.
Power supply:
220 - 240 V~, 50 Hz
Power: 43 W
Technical and design modifications
reserved.

www.grundig.com_
72011_906_3500
