Guardian Fall Protection 10947 User manual

Product Name: G-Link SRL
Instruction Manual
Part #: 10947; 10993; 10994; 10995; 10996; 10997; 10998
Do not throw away these instructions!
Read and understand these instructions before using equipment!
Introduction 1
Applicable Safety Standards 1
Worker Classifications 1
Safety Information 6
Product Specific Applications 2
Limitations 2-3
Components and Specifications 3
Maintenance, Cleaning, and Storage 4
Inspection 5
Installation and Use 4
Inspection Log 5
Labels 7

Introduction
Thank you for purchasing a Guardian Fall
Protection G-Link SRL. This manual must be
read and understood in its entirety, and
used as part of an employee training
program as required by OSHA or any
applicable state agency.
This and any other included instructions
must be made available to the user of the
equipment. The user must understand how
to safely and effectively use the G-Link SRL,
and all fall safety equipment used in
combination with the G-Link SRL.
User Information
Date of First Use:
Serial #:
Trainer:
User:
Applicable Safety Standards
When used according to instruction specifications, this product meets or exceeds all applicable OSHA 1926
Subpart M, OSHA 1910, ANSI Z359.14-2014, and ANSI A10.32-2012 standards for fall protection. Applicable
standards and regulations depend on the type of work being done, and also might include state-specific
regulations. Consult regulatory agencies for more information on fall protection systems and associated
components.
Worker Classifications
!
CAUTION
Understand the following definitions of those who
work near or who may be exposed to fall hazards.
Qualified Person: A person with an accredited degree or certification, and with extensive experience or
sufficient professional standing, who is considered proficient in planning and reviewing the conformity of fall
protection and rescue systems.
Competent Person: A highly trained and experienced person who is ASSIGNED BY THE EMPLOYER to be
responsible for all elements of a fall safety program, including, but not limited to, its regulation, management,
and application. A person who is proficient in identifying existing and predictable fall hazards, and who has
the authority to stop work in order to eliminate hazards.
Authorized Person: A person who is assigned by their employer to work around or be subject to potential or
existing fall hazards.
It is the responsibility of a Qualified or Competent person to supervise the job site and ensure all
applicable safety regulations are complied with.
Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
1

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
2
Product Specific Applications
Personal Fall Arrest: G-Link SRL may be used to support a MAXIMUM 1 Personal Fall Arrest System
(PFAS) for use in Fall Arrest applications. Structure must withstand loads applied in the directions
permitted by the system of at least 5,000 lbs. No free fall is permitted. Applicable D-ring: Dorsal.
Restraint: G-Link SRL may be used in Restraint applications. Restraint systems prevent workers
from reaching the leading edge of a fall hazard. Always account for fully deployed length of
lanyard/SRL. Structure must withstand loads applied in the directions permitted by the system of
at least 1,000 lbs. No free fall is permitted. Restraint systems may only be used on surfaces with
slopes up to 4/12 (vertical/horizontal). Applicable D-rings: Dorsal, Chest, Side, Shoulder.
!
WARNING
Use of equipment in unintended applications may result in serious
injury or death. Maximum 1 attachment per connection point.
For all applications: worker weight capacity range
(including all clothing, tools, and equipment) is 130-310 lbs.*
* Maximum capacity may be increased to 420 lbs. if used in combination
with Guardian Shock Absorber Extension (part # 01205).
Limitations
Fall Clearance: There must be
sufficient clearance below the
anchorage connector to arrest
a fall before the user strikes
the ground or an obstruction.
When calculating fall clearance,
account for a MINIMUM 3’
safety factor, deceleration
distance, user height, length
of lanyard/SRL, harness stretch,
and all other applicable factors.
Diagram shown is an example
fall clearance calculation ONLY.
Swing Falls: Prior to installation
or use, make considerations for
eliminating or minimizing all
swing fall hazards. Swing falls
occur when the anchor is not
directly above the location
where a fall occurs. Always
work as close to in line with
the anchor point as possible.
Swing falls significantly increase
the likelihood of serious injury
or death in the event of a fall.
Fall clearance calculation shown based on standing worker falling
directly in-line with anchor point. Always consider potential swing fall
and other hazards when calculating fall clearance.
*Eliminate Swing Fall whenever possible!
If Swing Fall exists, always account
for additional fall clearance.

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
3
Components and Specifications
Compatibility: When making connections with G-Link SRL, eliminate all possibility of roll-out. Roll-out occurs
when interference between a hook and the attachment point causes the hook gate to unintentionally open
and release. All connections must be selected and deemed compatible with G-Link SRL by a Competent Person.
All connector gates must be self-closing and self-locking, and withstand minimum loads of 3,600 lbs. See the
following for examples of compatible/incompatible connections:
Connector
closed and
locked to
D-ring. OK.
Two or more
snap hooks or
carabiners
connected to
each other. NO.
Two connectors
to same
D-ring. NO.
Connector
directly to
horizontal
lifeline. NO.
Connector
to integral
lanyard.
NO.
Connector
directly to
webbing.
NO.
Incompatible
or irregular
application,
which may
increase risk
of roll-out. NO.
Materials: Nylon, stainless steel, and aluminum.
Part # Length Description
10993
10994
6’
11’
G-Link Dual 6’ Retractable System With Aluminum Snap Hooks
G-Link Dual 11’ Retractable System With Aluminum Snap Hooks
10995
10996
10997
11’
6’
11’
G-Link Dual 11’ Retractable System With Steel Rebar Hooks
G-Link Dual 6’ Retractable System With Steel Rebar Hooks
G-Link Dual 11’ Retractable System With Aluminum Rebar Hooks
10998 6’ G-Link Dual 6’ Retractable System With Aluminum Rebar Hooks
n/a G-Link Connector Bracket w/High Strength Carabiner10947

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
4
Maintenance, Cleaning, and Storage
If G-Link SRL fails inspection in any way, immediately remove it from service, and contact Guardian to
inquire about its return or repair.
Cleaning after use is important for maintaining the safety and longevity of G-Link SRL. Remove all dirt,
corrosives, and contaminants from G-Link SRL before and after each use. If G-Link SRL cannot be cleaned
with plain water, use mild soap and water, then rinse and wipe dry. NEVER clean G-Link SRL with corrosive
substances.
When not in use, store equipment where it will not be affected by heat, light, excessive moisture, chemicals,
or other degrading elements.
Installation and Use
G-Link SRL MUST NEVER be used in Leading Edge (LE) applications.
No free fall is allowed.
ALWAYS avoid lifeline contact with sharp or abrasive edges and surfaces.
In Fall Arrest applications, SRL must always be positioned at
or above harness dorsal D-ring AND at or below anchor point.
1. All components of the personal fall arrest system must be selected and deemed compatible with G-Link by
a Competent Person.
2. Ensure structure to which SRL is to be attached, and on which work is to be performed, is free of all
hazards, including, but not limited to, debris, rot, rust, sharp or abrasive edges and surfaces, and hazardous
materials.
3. G-Links are primarily intended for use in mobile applications. Use a compatible carabiner to connect G-Link
Carabiner Connection Point to user harness dorsal D-ring. NEVER attach G-Link snap hooks or rebar hooks to
harness when used in this manner.
4. Attach G-Link snap hook or rebar hook to a compatible anchorage connector. NEVER make connections to
anchorages that will allow harness dorsal D-ring to be positioned above anchor point.
*If using SRL with rebar hook configuration, rebar hooks must ONLY be connected to compatible
structural rebar.
5. Ensure 100% tie-off will be maintained at all times; ALWAYS attach disengaged snap hook or rebar hook to
a compatible anchorage connector prior to unhooking engaged snap hook or rebar hook.
* G-Links configured with snap hooks may also be used in stationary applications, with the Carabiner
Connection Point attached with a compatible carabiner to an anchorage connector at or above the harness
dorsal D-ring. The snap hook of one lifeline leg may then be attached to a harness D-ring compatible with the
application. NEVER attach both lifeline legs to the harness. NEVER attach rebar hooks to the harness at any
time. G-Link for MAXIMUM 1 worker ONLY.

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
5
Inspection
Inspection Log
If equipment fails inspection IMMEDIATELY REMOVE FROM SERVICE.
Date of First Use: __________________.
Product lifetime is indefinite, as long as product passes all inspection requirements. User must inspect
prior to EACH use. Competent Person other than user must complete formal inspection at least every
6 months. Competent Person to inspect and initial.
This inspection log must be specific to one G-Link SRL. Separate inspection logs must be used for
each G-Link SRL. All inspection records must be made visible and available to all users at all times.
KEEP INSTRUCTIONS AVAILABLE FOR REFERENCE. Record Date of First Use.
Prior to EACH use, inspect G-Link SRLs for deficiencies, including, but not limited to, corrosion, deformation,
pits, burrs, rough surfaces, sharp edges, cracking, rust, paint buildup, excessive heating, alteration, broken
stitching, fraying, bird-caging, and missing or illegible labels. Inspect full length of lifeline. IMMEDIATELY
remove G-Link SRL from service if defects or damage are found, or if exposed to forces of fall arrest.
Prior to EACH use, check G-Link SRL lifeline retraction by pulling out a minimum 4’ and allowing it to retract
under light tension; lifeline must retract completely. Pull lifeline sharply to test braking function; brakes must
engage. Check shock pack for signs of deployment and/or fall arrest indicator for signs of activation.
IMMEDIATELY remove from service if G-Link SRL does not function properly, or if any evidence of exposure to
forces of fall arrest exists.
Ensure that applicable work area is free of all damage, including, but not limited to, debris, rot, rust, decay,
cracking, and hazardous materials. Ensure that selected work area will support the application-specific
minimum loads set forth in this instruction manual. Work area MUST be stable.
Every 6 months, a Competent Person other than the user must inspect G-Link SRLs. Competent Person
inspections MUST be recorded in inspection log in instruction manual and on equipment inspection
grid label. The Competent Person must sign their initials in the box corresponding to the month and
year the inspection took place.
During inspection, consider all applications and hazards G-Link SRLs have been subjected to.

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
6
Safety Information
Failure to understand and comply with safety regulations may result in
serious injury or death. Regulations included herein are not all-inclusive,
are for reference only, and are not intended to replace a Competent
Person’s judgment or knowledge of federal or state standards.
!
WARNING
Do not alter equipment. Do not misuse equipment.
Workplace conditions, including, but not limited to, flame, corrosive chemicals, electrical shock, sharp objects,
machinery, abrasive substances, weather conditions, and uneven surfaces, must be assessed by a Competent
Person before fall protection equipment is selected.
The analysis of the workplace must anticipate where workers will be performing their duties, the routes they
will take to reach their work, and the potential and existing fall hazards they may be exposed to. Fall
protection equipment must be chosen by a Competent Person. Selections must account for all potential
hazardous workplace conditions. All fall protection equipment should be purchased new and in an unused
condition.
Fall protection systems must be selected and installed under the supervision of a Competent Person, and used
in a compliant manner. Fall protection systems must be designed in a manner compliant with all federal, state,
and safety regulations. Forces applied to anchors must be calculated by a Competent Person.
Unless explicitly stated otherwise, the maximum allowable free fall distance for lanyards must not exceed 6’.
No free fall allowed for non-LE SRLs. Class A SRLs must arrest falls within 24”; Class B SRLs must arrest falls
within 54”.
Harnesses and connectors selected must be compliant with manufacturer’s instructions, and must be of
compatible size and configuration. Snap hooks, carabiners, and other connectors must be selected and applied
in a compatible fashion. All risk of disengagement must be eliminated. All snap hooks and carabiners must be
self-locking and self-closing, and must never be connected to each other.
A pre-planned rescue procedure in the case of a fall is required. The rescue plan must be project-specific. The
rescue plan must allow for employees to rescue themselves, or provide an alternative means for their prompt
rescue. Store rescue equipment in an easily accessible and clearly marked area.
Training of Authorized Persons to correctly erect, disassemble, inspect, maintain, store, and use equipment
must be provided by a Competent Person. Training must include the ability to recognize fall hazards, minimize
the likelihood of fall hazards, and the correct use of personal fall arrest systems.
NEVER use fall protection equipment of any kind to hang, lift, support, or hoist tools or equipment, unless
explicitly certified for such use.
Equipment subjected to forces of fall arrest must immediately be removed from use.
Age, fitness, and health conditions can seriously affect the worker should a fall occur. Consult a doctor if there
is any reason to doubt a user’s ability to withstand and safely absorb fall arrest forces or perform set-up of
equipment. Pregnant women and minors must not use this equipment.
Physical harm may still occur even if fall safety equipment functions correctly. Sustained post-fall suspension
may result in serious injury or death. Use trauma relief straps to reduce the effects of suspension trauma.

Guardian Fall Protection 6305 S. 231st St., Kent, WA 98032 phone: [phone] fax: [phone] www.guardianfall.com
785077 (Rev. F)
Labels
G-Link
SRL Attachment SRL Attachment
FALL ARREST
ATTACHMENT.
ONLY USE ANSI
Z359.12-09
CARABINER. 800-466-6385
6305 S. 231st St.
Kent, WA 98032
DO NOT REMOVE LABELS
Part #: 10947; 10993; 10994; 10995; 10996; 10997; 10998
ANSI Z359.1-07,
ANSI A10.32-12
OSHA 1926 Subpart M,
OSHA 1910
90061 (Rev. B)
COMPETENT
PERSON MUST
ENSURE
COMPATIBILITY OF
ALL COMPONENTS.
READ AND FULLY
UNDERSTAND
ALL INSTRUCTIONS
BEFORE USE; FAILURE TO
DO SO MAY RESULT IN SERIOUS INJURY OR DEATH! ATTACH
RETRACTABLES DIRECTLY TO THIS BRACKET. DO NOT USE ANY
COMPONENT BETWEEN THE RETRACTABLE AND THIS BRACKET.
Capacity:
1 person,
130-310 lbs.
(including all
equipment), or up
to 420 lbs.
*see instructions.
Bracket Material:
Zinc-Plated Steel
!
WARNING
WARNING: Manufacturer's
instructions supplied with this
product at time of shipment
must be read prior to use.
Instructions must be followed
for proper use, maintenance, and
inspection. Alterations or misuse of
this product, or failure to follow instructions,
may result in serious injury or death.
NOT REPAIRABLE.
DO NOT REMOVE THIS LABEL.
USE: No free fall is allowed. SRL must always be
positioned at or above harness D-ring. Avoid
lifeline contact with sharp edges. For use by trained
persons only. This device is only for use by
one person as a fall arrester. Ensure
connection to anchorage is secured
properly before use. Not suitable for
horizontal use. May be used as a
component of a PFAS in HLL applications.
Design, installation, and utilization of HLLs
must be supervised by a Qualified Person.
Serial #Part #
Mfg. Date (mo/yr)
_____/_____
Date of First Use
INSPECTION: Prior to each
use, inspect device per user
manual, including locking
function (pull sharply to test),
retraction function, legibility of
labels, evidence of defects,
damage, or missing parts, and
condition of connectors, housing, fasteners, and
lifeline (inspect full length). Inspection by
Competent Person required at least every 6
months. Immediately remove from service if
evidence of shock pack deployment is found.
SPECIFICATIONS:
Average arresting force: 900 lbs.
Max. arresting distance: 54”
Max. capacity: 130 - 310 lbs.
Webbing: 11’ Dyneema, 1" width
Class B SRL
STANDARDS:
OSHA 1910 & OSHA 1926 Subpart M
ANSI Z359.14-2014 & ANSI A10.32-2012
Made in Taiwan
90001 (Rev. F)
