100 Purposeanduse
101 Manufacturer
V. Guldmann A/S.
Graham Bells Vej 21-23A
DK - 8200 Aarhus N
Tlf. [phone]
Fax. [phone]
102 Purposeanduseofmobilelifter
Purpose
The Guldmann mobile lifter is a carefully designed, all-round lifter which
covers the needs of hospitals, nursing homes, institutions and private homes.
It can be used indoor whenever elderly and handicapped people have to be
lifted or moved. The lifter is equipped with Guldmann’s lifting hanger or with
another suitable hanger. It should be used at an approximate maximum of
walking speed. Accessories consist of Guldmann’s lifting slings in various
sizes and models.
Requirements
When a lifter is used in an institution or in the home care service, the
assumption is that it will be operated by qualied staff.
Use slings with 4-6 lifting straps designed for tting on Guldmann’s lifting
hanger as shown in the manual.
Liftingtoandfromasittingposition
When lifting from e.g. a wheelchair, move the lifter towards the person to be
lifted. Lifting boom and lifting hanger should be level with the chest and posi-
tioned above the middle of the thigh.
Position lifting hanger parallel to the user’s shoulders. Now t the lifting sling
to the lifting hanger. For instructions on how to t the sling, see the section
entitled “Fitting the lifting sling”.
Liftingtoandfromalyingpositioninbed
Position lifting boom and lifting hanger right over the bed. Now pull the lifter
back until the lifting boom and lifting hanger are positioned above the centre
of the person to be lifted. The lifting hanger and lifting boom should be paral-
lel with the person’s shoulders. Now t the lifting sling to the lifting hanger.
For instructions on how to t the sling, see section entitled “Fitting the lifting
sling”.
Workingwiththemobilelifter
To obtain a correct working posture when moving the lifter, the carer should
always, by placing one leg in front of the other, push the lifter in a forward
motion thus utilizing his/her body weight.

4
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01 © Guldmann GB/US-1688/12/2011 • # 553658_4.01
Turning the lifter should be carried out by two persons, otherwise, stand
alongside the lter and push on the side of the mast thereby minimising the
centre of rotation. It is a good idea to make the heaviest point of the lifter the
centre of rotation. If there is limited space, you can use your foot to push on
the chassis of the lifter in the direction you wish to turn.
Fittingtheliftingsling
Hook the top set of straps (from the back) to the hooks facing the user. Hook
the lower set of straps (from the legs) to the hooks facing away from the user.
Important!
Be careful when applying the lifting sling. Check that the straps have been
pulled completely through the rubber safety catch and into place in the lifting
hanger’s hooks before starting lifting the user.
Fromachair,wheelchairorothersittingpositions
Place lifting sling behind user’s back e.g. between the back of the chair and
the user’s back.
The centre band of the lifting sling should follow the user’s spine. As for the
slings type Active the strap showing the size of the sling should be opposite
the spine. Bring the leg straps along the outer thigh and then under the thigh
between the back of the knee and the hip.
Now cross the leg straps in front of the user.
All four straps are now ready to be mounted onto the lifting hanger.
Lyingpositioninbed,onamattressorontheoor
Turn the user on his side. Place the high back sling so that its upper edge is
ush with the top of the user’s head. Put the sling on the user so that the cen-
tre band follows the spine. Turn the user on his back and pull the sling out.
Bring the leg straps under the thigh and cross them over.
All four straps are now ready to be mounted onto the lifting hanger.
If in doubt about how to use the sling, please contact your supplier.
Guldmann cannot be held responsible for any faults or accidents that may
occur due to incorrect positioning of the lifting hanger, or for reasons of inade-
quate attention paid by helpers or the user.

5
© Guldmann GB/US-1688/12/2011 • # 553658_4.01 © Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
103 Important/warning
• Read the user manual fully before using the lifter.
• Do not exceed the max. load.
• Use the lifter to lift persons only.
• Use the lifter on an even and level surface only.
• Only use a lifting hanger approved for use with the lifter.
• Don’t lift/turn the lifting hanger in vertical direction during the mounting of the
straps of the sling.
• Do not use the lifter where there is a risk of considerable amounts of water
continuously coming into direct contact with the lifter.
• When adjusting the legs of the lifter make sure that no persons stand close to
the legs due to the risk of being jammed.
• Do not run the lifter into persons or objects.
• Exchange of lifting motor/actuator according to the manufacturer’s instruc-
tions. See section 5.04, point 2
• In case of damage, do not use the lifter until authorised by qualied service
staff or the Guldmann service team.
104 Unpackingandpreparationofthelifter
Visualcheckoflifter
Should the packaging be damaged on
receipt, each part of the lifter must be
carefully examined for visible defects
or deciencies. In case of suspected
damage, do not use the lifter until
authorised by qualied service
staff or the Guldmann Service
Team.
Partslist:
• Push handle
• Upper part/mast
• Hand control
• Chassis
• User manual
• Charger
• 1 x Allen key M5

6
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01 © Guldmann GB/US-1688/12/2011 • # 553658_4.01
105 Assemblinglifterbeforeuse
Assemblingmast/chassis–electrical
Loosen screw tted to mast. Position mast in base. When mast is in as far as
it will go, tighten screw using an M5 Allen key. To dismantle, remove screw to
pull mast out of base. Retighten screw in mast.
Mountingofconnectorsformotorsandhandcontrol
Fit connectors for width adjustment motor and hand control in the mast.
Fittingactuator
Fasten the actuator using the attached bushing and screw with nut.
Tighten screw and nut and put on the nut protector.
Batteries
The batteries supplied with the lifter are not fully charged on delivery. Before
use, therefore, the lifter must be charged up. A full charge, which takes about
8 hours, is recommended.

7
© Guldmann GB/US-1688/12/2011 • # 553658_4.01 © Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
Liftinghanger
The lifting hanger can be mounted on the mobile lifter without the use of any
tools.
1. Hold the lifting hanger in the right hand
and press the yellow button using the
thumb as shown. The slot on the lifting
hanger’s top cover must face up. (g. 1).
2. Insert the lifting hanger in the slot on the
side of the lifting hanger’s top cover.
(g. 2).
3. Check that the yellow button has returned
to its locked position by checking that it is
ush with the cover of the lifting hanger
and that the strap attachment can rotate
freely. (g. 3).
Fig1
Fig3
Fig2

8
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01 © Guldmann GB/US-1688/12/2011 • # 553658_4.01
200 DescriptionofFunctions
201 Pictograms/labels
Labelonmastoflifter
Labelsinadditiontothatshown:
• Max. load

9
© Guldmann GB/US-1688/12/2011 • # 553658_4.01 © Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
Exampleofaserialnumberlabel
Part no. xxxxxx
Prod. date yyyy-mm-dd
Serial no. xx x x x
IP32 Lifter
IP44 Handcontrol
Duty Cycle max: 10% 2 min/18 min
Barcode 128C
www.guldmann.com
Mobile Lifter GL5
Warninglabel
PRIOR TO USE PLEASE READ INSTRUCTIONS
FOR PRECAUTIONARY STATEMENTS AND
DIRECTIONS FOR INSTALLATION AND USE.
Labelforcharginginput
24V. DC
CE-marking
Type B in accordance with EN 60601-1
Read instructions before use
Please don’t throw away with household rubbish, but recycle the product

10
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01
© Guldmann GB/US-1688/12/2011 • # 553658_4.01 © Guldmann GB/US-1688/12/2011 • # 553658_4.01
202 OperatingGL5mobilelifter
Handcontrolandindicatorlamp
• The lifter switches on automatically when pressing the
hand control, and the green indicator lamp will light up
when lifter is switched on (see illustration in “Rechar-
ging” section).
• The lifter will switch off automatically approx. 1 min.
after use.
NB: If the emergency stop function has been acti-
vated, press the hand control twice.
Adjustmentofchassis/widthadjustment
• On GL5 mobile lifter the width adjustment of the chassis is operated via the
hand control.
• Use max. width setting when lifting to/from wide chairs, or as necessary when
lifting to/from bed, toilet and oor.
Useofbrakes
• The back castors are tted with brakes. Apply the brake by pushing the brake
pedal into the vertical position.
• To release the brake, push the brake pedal into the horizontal position.
• Do not apply brakes when lifting or lowering.
• Always apply brakes when parking.
203 Safetyfunctions
Only use the emergency stop and emergency lowering functions in emer-
gencies. Should it be necessary to apply the emergency/safety functions, the
supplier must be contacted prior to using the lifter again.
Activatingtheemergencystopfunction
Should the lifter not respond to the functions selected
on the hand control when it is in motion, press
emergency stop.
When the emergency stop function is applied, the
lifter ceases to function.
Switch the lifter on again by turning the emergency stop button in the direc-
tion of the arrow until it springs up. Press twice on the hand control and the
lifter is ready for operation.
Activatingtheemergencyloweringfunction
Should the lifter not lower
- press emergency lowering.
Continuous pressure on the red button “emergency
lowering” ensures that the lifting boom is lowered even
though the emergency stop is activated.
ma x
205 kg/450 lbs
ma x
205 kg/450 lbs
