Guldmann GLS5 User manual

Operators Check List Before Use
• Makesurethelifterismovingfreelyonitscastors.
• Operatethebrakes(9)tomakesuretheyare
working.
• Lift&lowertheliftingboom(2)bypressingthe
buttonsviathehandcontrol(3)andcontrol
panel(14).
• Checkthelegwidthadjustmentisopeningand
closing,viathehandcontrol(3)andcontrol
panel(14).
• Checktheemergencyloweringbypressingthe
buttononthecontrolbox(16)alsocheckthe
manualfunctionbyturntheredknob(12)inthe
directionofthearrows.
• Checkemergencystopbuttonisworking(4)
–depressandtrythehandset–turnthered
buttoninthedirectionofthearrowstorelease.
• ReleaseKneepadadjustmentknobsx2(11)
thepadshouldmoveup/downandslidein/
out,tightentolock.
• Makesurefootplate(10)issecureandclean.
Charging Options
• Chargeattachedtothelifter(8)-simplywheel
andplug.
• Chargeawayfromthelifter-removebattery
fromdockingstation(6)&charger(8).
Quick Guide - GLS5 Active Lifter
1
4
6
8
9
10
11
15
16
13
14
7
3
12
2
5
5
 1. Slingattachmenthooks
 2. Liftingboom
 3. Handcontrol
 4. Emergencystop
 5. Electroniccontrolbox
 6. Batterydockingstation
 7. Pushhandle
 8. Charger
 9. Rearbrakedcastor
10. Footplate
11. Kneepad&adjustmentknobsx2
12. Emergencyloweringmanual
13. Audioandvisualindicatorfor
lowbattery
14. Controlpanel
15. Visualserviceindicator
16. Emergencyloweringelectrical

V. Guldmann A/S
GrahamBellsVej21-23A,DK-8200AarhusN
Tel.+4587413100,Fax+4587413131
[email protected]
www.guldmann.com
Indicator lamps and audio warning
Status Indicator lamps Audio signals Possible GLS signals
Up Down Leg
spread
Emergency
down
Off-standby Off
AllOK Green x x x x
Lowbattery Yellow x x x x
CriticallylowBattery Red Beepsatbuttonactivation x
Faultonlifter Yellow x x x x
Overload Beepsatbuttonactivation x x
Lifetimeofactuatorwill
exceedin1.000lifts
Yellow x x x x
Lifetimeofactuator
exceeded
Yellowashes Beepsatbuttonactivation x x x x
Scan here for user manual,
etc. concerning use of the
GLS5.
Accessories
Sling attachment hooks
Youhavetheoptiontouseeithertheouterhooks
orinnerhooks.(AriskassessmentMUSTbecar-
riedoutbeforeattemptingalift).
Placetheslingstrapinthehooks,uponlifting
checkthatthestrapmaintainsitsposition.
Lifting sling
Weonlyrecommendusingthedesignedslings
forthe“ActiveLifter.”Theslingmustbechecked
beforeeverylift–(pleaseseeslingusermanualfor
guidance).Labelmustbeintactandreadable.
Daily cleaning and
maintenance
Cleanwithadampclothandordinarydetergent.
Donotusestrongacids,basesoralcoholwhen
cleaning.Seeusermanual.
