Guldmann GLS5.1 User manual

13
15
16
14
8
21
5
7
4
3
8
912
10
11
6
3
17
Operators check list before use
• Make sure the lifter is moving freely on its castors.
• Operate the brakes (10) to make sure they are
working.
• Lift & lower the lifting boom (2) via the control
buttons (15) on the hand control (8).
• Check that the base adjustment (16) is opening
and closing, via the hand control (8).
• Check the emergency function by pressing the
buttons (17) on the control box (3). Check the
manual function by turning the knob (7) in the
direction of the arrow.
• Check that the emergency stop button (6) is work-
ing – depress and try hand control – turn in the
direction of the arrow to release.
• Release Knee pad adjustment knobs x 2 (12)
the pad should move up / down and slide in / out,
tighten to lock.
• Make sure footplate (11) is secure and clean.
Charging options
• Charger integrated in control box - plug net cable
into power socket.
• When the power is plugged in, the green LED light
on the control box lights up.
• The green and yellow diode on the control box (3)
illuminates during charging, when fully charged the
yellow diode turns off.
Quick Guide - GLS5.1 Active Lifter
1. Sling attachment
hooks
2. Lifting boom
3. Control box
4. Battery
5. Push handle
6. Emergency stop
7. Emergency lowering
manual
8. Hand control
9. Actuator
10. Rear braked castor
11. Foot plate
12. Knee pad & adjust-
ment knobs x 2
13. Battery indicator
14. Service indicator
15. Lifting boom up/down
16. Base adjustment
17. Emergency function
up/down and base
adjustment

V. Guldmann A/S
Graham Bells Vej 21-23A, DK-8200 Aarhus N
Tel. [phone]
[email protected]
www.guldmann.com
Scan here for user manual,
etc. concerning use of the
GLS5.1.
Accessories
Sling attachment hooks
You have the option to use either the outer hooks or inner
hooks. (A risk assessment MUST be carried out before
attempting a lift).
Place the sling strap in the hooks. Upon lifting make sure
that the strap maintains its position.
Lifting sling
We only recommend using the designed slings for the
“Active Lifter.” The sling must be checked before every lift –
(please see sling user manual for guidance). Label must be
intact and readable.
Daily cleaning and
maintenance
Clean with a damp cloth and ordinary detergent. Do not
use strong acids, bases or alcohol when cleaning. See
user manual.
Indicator lamps and audio warning
Status Indicator lamps Audio signals Possible GLS5.1 signals
Up Down Leg
spread
Emergency
down
Hand control
All OK Green x x x x
Low battery Yellow x x x x
Critically low Battery Yellow Beeps at button activation x x x x
Lifter service Yellow - Is lit
during use and 2
minutes after
x x x x
Over load Yellow - Flashes 3
times + lights up
for 10 seconds
x x
Control box
Charger Green + yellow
Charged Green
