Haier HL26K1 - K-Series - 26" LCD TV User manual

Please READ this manual carefully before
operating your TV, and retain it for future
reference.
TFT-LCD TV
OWNER S MANUAL'
MODEL :S
HL26R1
HL32R1
HL42XR1
HL26K1
HL32K1
HL32XK1
HL42XK1
HL32P1
R

2 TV LCD-TFT
Warning
RISK ELECTRIC SHOCK
DO NOT OPEN
CAUTION
!
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
!
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the
risk of electric shock, do not perform any servicing other than that contained in the operating instructions
unless you are qualified to do so.
Important Safety Instructions
1) Read theseinstructions.
2) Keep theseinstructions.
3) Heed allwarnings.
4) Follow allinstructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do notblock any ventilationopenings. Install inaccordance with themanufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produceheat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of theobsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where theyexit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold withthe apparatus. Whena cart isused, use cautionwhen moving thecart/
Apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged
in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15)The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases,
shall be placedon the apparatus.
16)The mains plug or appliance inlet is used as the disconnect device, remain it readily operable during the
apparatus normal use.
Class I apparatus shall be connected to a mains socket outlet with a protective earthing connection.

Owner s Manual 3
Safety Instructions
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rule. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, use and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However there is no
guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encourage to
try to correct the interference by one or more of the following measures:
*Reorient or relocate the receiving antenna.
*Increase the separation between the equipment and receiver.
*Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
*Consult the dealer or an experienced radio/TV technician for help.
This device compiles with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may be not cause harmful interference.
(2) this device must accept any interference received, including interference that may cause undesired
operation.
FCC CAUTION:
To assure continued compliance and possible undesirable interference, the provided ferrite cores must be
used when connecting this LCD display to video equipment; and maintain at least 40cm spacing to other
peripheral device.
CANADIAN NOTICE:
This Class B digital apparatus compiles with Canadian ICES-003.
FCC STATEMENT
Energy Star compliant( )
By being Energy Star compliant you are assured that your Haier model is helping the environment by using less
energy while saving you money. ENERGY STAR is a joint program of the U.S. Environmental Protection Agency and
the U.S. Department of Energy promoting energy efficiency.
models - HL26R1, HL32R1, HL26K1, HL32K1, HL32XK1,HL32P1

SAVE THESE INSTRUCTIONS
Thank you for purchasing the Haier product. This easy-to-use manual will guide you in getting the best use of your
product. Remember torecord the modeland serial number. They are on labelin back ofthe unit.
Model number
serial number
Date of purchase
Staple your receipt to your manual. You will need it to obtain warranty service.
4 TV LCD-TFT
Safety Instructions

Introduction
Owner s Manual 5
Contents
War ni ng . . . . . . . . .. .. .. .. .. .. . . . . . . . . . . . . . . . . . . . . . .
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...........
Connection Options . . . . . . . . . . . . . . . . . . . . . .........
Remote control ............. . .. . .. . ........... . ..........
Installation
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . ........
Antenna Connection .. . .. . .. . ...........................
Connecting a VCR. . . . . . . . . . . . . . . . . . . . . ...........
External A/VSource Setup .. . ... . .. . ..................
Connecting a DVD player . . . . . ...... . . . . . . . . . . . . .
Connecting a DTV(digitalTV) ..............................
Connecting digital audiooutput . .. . . . . . . . . . . . . . .
Connecting a computer. . . . . . . . . . . . . . . . . . . . . . . .
Monitor Out Setup. . . . . . . . . . . . . . . . . . . . .. .. .. .. .. .. .
HDMI and DVI input. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cable sample......................................................
Connecting Headphones .. . .. . .. . .. . .. . .. . ......
Power source................ .. . .. . .. . .. . .. . .. . .. . .
Removing the tablestand and installing a
wall mount bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation
Switching On/Off the TV set . . . . . ... . . . . .. . .. . ....
Choose the MenuLanguage . .. . .........................
Choose the inputsource......................................
Channel Menu
Channel Scan............... .. . .. . .. . .. . .. . .. . .. . ..
Channel Skip....... . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Channel Label....... . . . . . . . . . . . . . . . . . . . . . . . . . . .
Select the desired program. . . . . . . . . . . . . . . . . . . . .
Select the desired sound. . . . . . . . . . . . . . . . . . .. . . .
Mute. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Video Menu
How to selectpicture mode..................................
How to customizeyour own picturestatus .............
Set. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ....PC
2
3
6
7
8
9
9
10
11
11
12
12
13
14
14
15
16
16
17
18
18
18
19
19
19
20
20
20
21
21
22
Audio Menu
How to selectaudio mode.....................................
How to customizeyour own audiostatus ...............
SAP Broadcasts Setup.........................................
Function Menu
Menu Language...................................................
OSD Timeout.......................................................
OSD Transparency...............................................
Screen Mode.......................................................
Blue Screen.........................................................
DPMS.................................................................
Time zone setting.................................................
Date /Time setting................................................
Sleep Timersetting..............................................
DTV Caption Style................................................
Lock Menu
Parental Control ratingand categories...................
Lock setup...........................................................
Other Functions
Brief Info. . . . . . . . . . . . . . . . . . . . . . . . . . . . . ............
Using the Guide. . . . . . . . . . . . . . . . . . . . . . . ............
Quick program view..............................................
CC (Closed CaptionDisplay) . .. . .. . .. . .. . .... .. .
USB Input............................................................
Universal Remote Control
Setting up yourremote control ..............................
Remote Control Codes........................................
Maintenance . . ...... . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Specification . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty ............................................................
23
23
23
24
24
24
24
25
25
25
25
26
26
27
28
30
30
31
31
32
34
36
42
43
44
45

This is asimplified representation of the TV front panel, side panel control buttons and side inputs.
Introduction
6 TV LCD-TFT
Controls
1.MENU: Menu display.
2.INPUT: Press to the input source mode.
3.VOL +/-: Press to adjust the volume. In the MENU screen, these buttonsserve as left/rightbuttons.
4.CH +/- : Press to scan through channels. To scan quickly through channels, press and hold down
either +/- . In the MENU screen, these buttonsserve as up/downbuttons.
5.POWER: Press toturn on andoff the TV.
6.
7.Av2 AUDIOIN: Connect the audioL/R cables fromthe video signalsource to thesejacks.
8.AV2 VIDEO IN: Connects the compositevideo cable froman external signalsource to thisjack.
9.Headphone jack : Headphone audio output terminal.
10.HDMI IN: Connect a
11. Remote Sensor Receives signals from the remote control.
Do not put anything near the sensor ,
Press to access the on-screen menu display
access Press repeatedly tochange the source to the one you want to
watch. In the MENU screen, the INPUT button serves as the ENTER button.
USB input: Connecta USB flashdrive to viewJPEG images or listen to MP3 songs.
IR
which may block the remote control signal.
HDMI device toreceive digital audio and uncompressed digital video signals.
HL26K1/HL32K1/
HL32XK1/HL42XK1
HL32P1
HL26R1/HL32R1/
HL42XR1
L - AUDIO - R
L - AUDIO - R
HDMI4 INHDMI3 IN USB
VIDEO2 IN
VIDEO
VIDEO
MENU INPUT VOL+ VOL- CH+ CH- POWER MENU INPUT VOL+ VOL- CH+ CH- POWERMENU INPUT VOL+ VOL- CH+ CH- POWER
TV Side panel controls and connections

Back panel connections
Introduction
Owner s Manual 7
Connection Options
2
1
1
YPb Pr LR
L L
R R
VIDEO
VIDEO
S-VIDEO
S-VIDEO
VGA
VGA
VGA AUDIO
VGA AUDIO
AUDIO
AUDIO AUDIO
L
R
DVI AUDIO
DVI AUDIO
AUDIO
AUDIO
2
LR
AUDIO
AUDIO
COMPONENT IN
COMPONENT IN
VIDEO IN
VIDEO IN
1
AV OUT
AV OUT
VGA IN
VGA IN
HDMI IN
ANT IN
ANT IN
OPTICAL OUT
OPTICAL OUT
1. Digital Audio Output:
NOTE: In standby mode, these ports will not work.
2. DVI Audio In:
3. Antenna Input: Connect cable or antenna signals to the TV, either directly or through your cable box.
4. HDMI In:
5.VGA Audio In: Connect the audio L/R cables from a computer to this jack.
6.VGA Video In: Connect a video cable from a computer to this jack.
7. VIDEO In: Connects the video signal from a video device.
8. In: Connect a component video device to these jacks.
9. AUDIO In: Connect the audio L/R cables from the video signal source to these jacks.
10. S-VIDEO In: Connect the S-Video cable from an external signal source to this jacks.
11. COMPONENT AUDIO In: Connect the audio L/R cables from the component video signal source to these jacks.
12. AUDIO In: Connect the audio L/R cables from the S-Video signal source to these jacks.
13. AUDIO Out: Connect the audio L/R cables to
Connect various types of digital audio equipment.
When using a DVI to HDMI adapter, connect the audio signal to these jacks.
Connect a HDMI device to receive digital audio and uncompressed digital video.
your audio equipment.
Component Video

The remote control cannot be operated unless the batteries are properly loaded.
When using the remote control, aim it at the remote sensor on the TV.
Introduction
Universal Remote control
8 TV LCD-TFT
Function introduction 1.POWER
Press to turnon and off the TV.
2.TV DVD SETBOX CABLE VCR
To select one of the system modes in which the remote control
can be used.
3.PICTURE
Press repeatedly tocycle through theavailable picture modes.
4. AUDIO
Press to cyclethrough different sound settings.
5.INPUT
Show the input source.
6.MUTE
Switches the sound on oroff.
7.VOLUME UP/DOWN
Press to adjust the volume.
8.MENU
Press to open the on-screen menu.
9.THUMBSTICK (Up/Down/Left/Right)
Allows you tonavigate the on-screenmenus and adjust
the system settings to your preference.
10.SLEEP button
Press to display the sleep timer option.
11.
12. MTS/SAP
Selects MTS sound: Mono, Stereo, and SAP in Analog
mode. Change the audio language in DTV mode.
13.GUIDE
Press to display the guide when you are watching analog or
digital channels.
14.CCD(closed caption)
Select a closed caption.
15.
17.Number buttons
Press to change a channel.
18. button
Press to select digital channels. For example, to enter
“54-3”, press “54”, “ ” and “3”.
19.RECALL
Press to jump back and forth between two channels.
20.CHANNEL UP/DOWN
21.EXIT
Clears all on-screen displays and returns to TV viewing
from any menu.
22.
23.DISPLAY
24. Functions
/Rewind / Fast /backward /Forward
Stop Play/Pause REC
25.FREEZE
Press once todisplay a frozenimage of thecurrent program,
but audio continues.Press again toreturn to the program.
26.CH.LIST
Open the channellist .
27.FAV.LIST
Press to open the favorite channel list .
28.ARC(Aspect Ratio Control)
Press to change the aspect ratio.
AUD
video
USB: Press to switch input source to USB in.
HDMI:Press to select a device connected to the HDMI input
16.PC:Press to select the computer connected to the VGA input
o scan quickly between the
last two channels,press and holddown either +/-.
ENTER
Accesses the highlighted item in the on-screen menu
Press to displaythe TV status information onthe top ofthe TV
screen.
Press to scanthrough channels. T
USB
Control the USBSystem.
REPEAT Repeat
in TV
in TV
PLAY/PAUSE
REV
REPEAT
GUIDE
MTS/SAP
CCD ARC
FREEZE
ENTER
STOPUSB REC
PREV NEXT
CH.LIST
FAVORITE
TV
STB
INPUT
MUTE
VOL CH
MENU
SLEEP DISPLAY
EXIT
RECALL
PICTURE AUDIO PC HDMI
CABLE VCR AUD
DVD
1
2
3
4
5
6
7
8
9
10
11
18
19
20
21
22
23
24
25
26
27
28
12
13
14
15
16
17

ANT IN
ANT IN
ANT IN
Over-the-air TV reception quality will depend onyour antenna type, antenna location and antenna positioning.
External Equipment Connections
Antenna Connection
Multi-family Dwellings/Apartments
(Connect to wallantenna socket)
Wall Antenna
Socket
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Outdoor
Antenna
VHF Antenna
UHF Antenna
Turn clockwise to tighten
RF Coaxial Wire(75 ohm)
Bronze Wire
Be careful notto bend thebronze wire
when connecting the antenna.
Bronze Wire
To improve the picture quality in a poor signal area,
please purchase a signal amplifier and install properly.
If the antenna needs to be split for two TV`s, install a
2-Way Signal Splitter in the connections.
To install theantenna properly pleasecontact a
professional in your area.
Installation
Accessories
Remote control Owner`smanual Alkalinebattery(AAA) 2
Owner s Manual 9
Please READ this manual carefully before
operating your TV,and retain it for future
reference.
TFT-LCD TV
OWNER S MANUAL'
MODEL:S
HL26K
HL32K
HL37K
HL42K
HL47K
R
HL37T
HL52T
PLAY/PAUSE
REV
REPEAT
GUIDE
MTS/SAP
CCD ARC
FREEZE
ENTER
STOPUSB REC
PREV NEXT
CH.LIST
FAVORITE
TV
STB
INPUT
MUTE
VOL CH
MENU
SLEEP DISPLAY
EXIT
RECALL
PICTURE AUDIO PC HDMI
CABLE VCR AUD
DVD

2
1
1
YPb Pr LR
L L
R R
VIDEO
VIDEO
S-VIDEO
S-VIDEO
VGA
VGA AUDIO
VGA AUDIO
AUDIO AUDIO
L
R
DVI AUDIO
DVI AUDIO
AUDIO
AUDIO
2
LR
AUDIO
AUDIO
COMPONENT IN
COMPONENT IN
VIDEO IN
VIDEO IN
1
AV OUT
AV OUT
VGA IN
HDMI IN
HDMI IN
ANT IN
ANT IN
OPTICAL OUT
OPTICAL OUT
Installation
10 TV LCD-TFT
Connecting a VCR
NOTE: All cables shownare not includedwith the TV.
There are several ways to connect your television,
depending on the components you want to connect and
the quality of the signal you want to achieve. The
following are examplesof some different ways toconnect
your TV with different input sources.
External Equipment Connections
Choose Your Connection
Toavoid picture noise(interference), leave an adequate
distance between theVCR and TV.
Connection Option 1
Set VCR output switch to channel 3 or 4 and then tune
the TV to the same channel number.
Connection Option 2
1. Connect theaudio and videocables from the VCR's
output jacks to the TV input jacks, as shown in the figure.
When connecting theTV to VCR, match the jack colors
(Video = yellow, Audio Left = white, and Audio Right = red).
If you connect a S-VIDEO output from VCR to the
S-VIDEO input, the picture quality is improved;
compared to connectinga regular VCR to the Video input.
2. Insert a video tape into the VCR and press PLAY on
the VCR. (Referto the VCRowner`s manual.)
3. Select the input source with using the
INPUT button on the remote control, and
then press /button to select the source,
press ENTER button to confirm.

2
1
1
YPb Pr LR
L L
R R
VIDEO
VIDEO
S-VIDEO
S-VIDEO
VGA
VGA
VGA AUDIO
AUDIO
AUDIO
AUDIO
L
R
DVI AUDIO
DVI AUDIO
AUDIO
AUDIO
2
LR
AUDIO
COMPONENT IN
COMPONENT IN
VIDEO IN
VIDEO IN
1
AV OUT
AV OUT
VGA IN
HDMI IN
HDMI IN
ANT IN
ANT IN
OPTICAL OUT
OPTICAL OUT
2
1
1
YPb Pr LR
L L
R R
VIDEO
VIDEO
S-VIDEO
S-VIDEO
VGA
VGA
VGA AUDIO
AUDIO
AUDIO
AUDIO
L
R
DVI AUDIO
DVI AUDIO
AUDIO
AUDIO
2
LR
AUDIO
COMPONENT IN
COMPONENT IN
VIDEO IN
VIDEO IN
1
AV OUT
AV OUT
VGA IN
VGA IN
HDMI IN
HDMI IN
ANT IN
ANT IN
OPTICAL OUT
OPTICAL OUT
How to connect
1. Connect theDVD video outputs(COMPONENT) to
the Y Pb Pr jacks on the TV and connect the DVD audio
outputs to the YPbPr Audio IN jacks onthe TV, as
shown in the figure.
2. If your DVD onlyhas an S-VIDEOoutput jack,
connect this to the S-VIDEO inputon the TV. as shown
in the figure.
Note
If your DVD player does not have component video
output, use S-Video.
How to use
1. Turn on the DVD player, insert a DVD.
2. Use INPUTbutton on the remote control toselect
component mode.
3. Press Play button on external equipment for program
play.
4. Refer to the DVD player's manual for operating
instructions.
External Equipment Connections
How to connect
Connect the audio and video cables from the external
equipment's output jacks to the TV input jacks, as shown
in the figure.
When connecting the TV to external equipment, match the
jack colors (Video = yellow, Audio Left = white, and Audio
Right = red).
How to use
1. Select the input source with using the INPUT button on
the remote control.
2. Press / button to select the desired source.
3. Press button to confirm.
4. Operate thecorresponding external equipment.
ENTER
Video Game Set
Camcorder
Component Input ports
To get better picture quality, connect a DVD player to the
component input ports as shown below.
Installation
Component ports
on the TV
Video output ports
on DVD player
Y Pb Pr
Y Pb Pr
Y B-Y R-Y
Y Cb Cr
Y P P
BR
External A/V Source Setup
Connecting a DVD player
Owner s Manual 11

2
1
1
YPb Pr LR
L L
R R
VIDEO
VIDEO
S-VIDEO
S-VIDEO
VGA
VGA AUDIO
VGA AUDIO
AUDIO
AUDIO
AUDIO
AUDIO
L
R
DVI AUDIO
DVI AUDIO
AUDIO
2
LR
AUDIO
AUDIO
COMPONENT IN
COMPONENT IN
VIDEO IN
VIDEO IN
1
AV OUT
AV OUT
VGA IN
VGA IN
HDMI IN
HDMI IN
ANT IN
ANT IN
OPTICAL OUT
OPTICAL OUT
2
1
1
YPb Pr LR
L L
R R
VIDEO
VIDEO
S-VIDEO
S-VIDEO
VGA
VGA AUDIO
VGA AUDIO
AUDIO
AUDIO
AUDIO
AUDIO
L
R
DVI AUDIO
DVI AUDIO
AUDIO
2
LR
AUDIO
COMPONENT IN
COMPONENT IN
VIDEO IN
VIDEO IN
1
AV OUT
AV OUT
VGA IN
HDMI IN
HDMI IN ANT IN
OPTICAL OUT
OPTICAL OUT
Digital Set-top Box
This TV can receive DigitalOver-the-air/Cable signals without an external digital set-top box. However, if you do receive
Digital signals from a digital set-top box or other digital external device, refer to the figure as shown below.
This TV supports HDCP (High-bandwidth Digital Contents Protection) protocol for Digital Contents (480p,720p,1080i).
How to connect
Use the TV`s COMPONENT , VGA or HDMI
jack for video connections, depending on
your set-top boxconnector. Then, make
the corresponding audioconnections.
How to use
1. Turn on the digital set-top box. (Refer to the
owner`s manual forthe digital set-topbox.)
2. Use INPUT on the remote control to select
COMPONENT , VGA or HDMI source.
Send the TV`s audio to external audio equipment (stereo
system) via theDigital AudioOutput (Optical) port.
How to connect
1. Connect one end of an optical cable to the TV Digital
Audio(Optical) Outputport.
2. Connect the other end of the optical cable to the digital
audio (optical) inputon the audioequipment.
See the external audio equipment instruction manual for
operation.
Note
When connecting withexternal audio equipments,such
as amplifers orspeakers, please turnthe TV speakers off.
Connecting a digital audio output
External Equipment Connections
Connecting a DTV(digital TV)
Installation
Signal
480i
480p
720p
1080i
1080p
COMPONENT HDMI
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
HDMI
12 TV LCD-TFT
Caution: Do not look into the optical output
port. Looking at the laser beam may damage
your vision.
!

2
1
1
YPb Pr LR
L L
R R
VIDEO
VIDEO
S-VIDEO
S-VIDEO
VGA
VGA AUDIO
VGA AUDIO
AUDIO
AUDIO AUDIO
L
R
DVI AUDIO
DVI AUDIO
AUDIO
2
LR
AUDIO
AUDIO
COMPONENT IN
COMPONENT IN
VIDEO IN
VIDEO IN
1
AV OUT
AV OUT
VGA IN
VGA IN
HDMI IN
HDMI IN
ANT IN
ANT IN
OPTICAL OUT
OPTICAL OUT
How toconnect
1. To getthe bestpicture quality, adjustthe VGAgraphics card to 1024x768 .
2. Usethe TV`sVGAor DVI(Digital VisualInterface)Audio INport foraudio connections,depending on your computer
connector.
If the graphic card on the computer does not output analog and digital RGB simultaneously, connect only one of
either VGAIN or HDMI IN todisplay the VGAon theTV.
If the graphic cardon the computer doesoutput analogand digitalRGB simultaneously, setthe TVto eitherVGAor
HDMI ; (theother mode isset to Plugand Play automaticallyby theTV.)
3. Then,make thecorresponding audioconnection. Ifusing asound card,adjust the VGA sound as required.
How touse
1. Turnon the computerand theTV.
2. UseINPUT onthe remotecontrol toselect VGAor HDMIsource.
3. Check the image on your TV. There may be noise associated with the resolution, vertical pattern, contrast or
brightness in VGAmode. If noiseis present, changethe VGAmode to anotherresolution, change therefresh rate to
another rate oradjust the brightnessand contrast onthe menu untilthe picture isclear. Ifthe refresh rateof the VGA
graphic cardcan notbe changed,change theVGAgraphic cardor consultthe manufacturerof theVGAgraphic card.
Note
1.Use aDVI cable.
2.Avoid keepinga fixed imageon theTV's screen fora long periodof time.The fixed image may becomepermanently
imprinted onthe screen.
3. Thesynchronization inputform forHorizontal andVerticalfrequencies isseparate.
Resolution
Frame
frequency
(Hz)
VGA
SVGA
XGA
640x480 60Hz
800x600 60Hz
1024x768
60Hz
Mode Resolution
External Equipment Connections
Installation
75Hz
Connecting a computer
Owner s Manual 13
75Hz

When the source device(DVD player or SetTop Box) supports HDMI
How To Connect
1. Connect thesource device toHDMI port of this TV with an HDMI cable(not supplied with this product).
2. No separatedaudio connection isnecessary.
How To Use
If the source device supports Auto HDMI function, the output resolution of the source device will be automatically
set to 1280x720p.
If the source device does not support Auto HDMI, you need to set the output resolution appropriately.
To get the best picture quality, adjust the output resolution of the source device to 1280x720p.
Select HDMI input source in input source option of Select Main source menu.
When the source device(DVD player or Set Top Box) supports DVI
How To Connect
1. Connect thesource device toHDMI port of this TV with a HDMI-to-DVI cable(not supplied with this product).
2. Aseparated audio connectionis necessary.
3. If the source device has an analog audio output connector, connect the source device audio output to DVI Audio
In port locatedon the leftside of HDMIport.
How To Use
If the source device supports Auto DVI function, the output resolution of the source device will be automatically
set to 1280x720p.
If the source device does not support Auto DVI, you need to set the output resolution appropriately.
To get the best picture quality, adjust the output resolution of the source device to 1280x720p.
Press the INPUT button to select HDMI input source in input source option of Select Main source menu.
Installation
HDMI and DVI input
14 TV LCD-TFT
External Equipment Connections

HDMI Cable
(not supplied withthe product)
HDMI to DVI Cable
(not supplied withthe product)
Analog AudioCable
(Stereo to RCA type)
(not supplied withthe product)
Installation
Cable sample
Owner s Manual 15

HDMI4 INHDMI3 IN
TO USE AC POWER SOURCE
Use the AC polarized line cord provided for
operation onAC. Insert theAC cord plug into
a standard polarizedAC outlet.
Note
Never connect the AC line cord plug to other
than the specified voltage. Use the
attached power cord only.
If the polarized AC cord does not fit into a non-
polarized AC outlet, do not attempt to file or cut
the blade. Itis the user`s responsibility to have
an electrician replacethe obsolete outlet.
If you cause a static discharge when touching
the unit and the unit fails to function, simply
unplug the unit from the AC outlet and plug it
back in. The unit should return to normal operation.
Polarized AC Cord Plug
AC Outlet
Wider Hole
and Blade
You can connect a set of headphones to your set if you wish to watch a
TV programme withoutdisturbing the other people in the room.
Connecting Headphones
Note
Prolonged use ofheadphones at ahigh volume
may damage your hearing.
Youwill not receivesound from thespeakers
when you connectheadphones to thesystem.
Plug a setof headphones intothe 3.5mm
mini-jack socket onthe side panelof the set.
Installation
External Equipment Connections
16 TV LCD-TFT
Power source

Installation
Owner s Manual 17
Removing the table stand and installing a
wall mount bracket
Remove 4X M4 screws securing the
stand to the TV, then remove the stand.
Use 4X M6 screws to secure the wall
bracket (not supplied)to the back of your TV.
HL42XK1
HL26R1(4X M4), HL32R1(5X M4 ),
HL42XR1(4X M4), HL26K1(4X M4),
HL32K1(4X M4), HL32XK1(4X M4),
HL32P1(4X M4)
HL26R1(4X M4), HL32R1(4X M4),
HL42XR1(4X M4), HL26K1(4X M4),
HL32K1(4X M4), HL32XK1(4X M4),
HL32P1(4X M4 )

Choose the Menu Language
When you startusing your setfor the first time, you must
select the language which will be used for displaying menus
and indications.
In the manual, the OSD (on screen display) may be
different from your TV`s, because it isjust an example to
help you with the TV operation.
There are several options you might need to set up in order
for your TV to work properly. Read the instructions that
follow.
Initial Setup: Set according to the screen display.
Note
If the TV in power on , the screen show information
according the type of input signal . the information will
disappear. If there is no signal , No Signal will display
on the screen.
1. Choose TV Input and then press MENU button.
2. Press /button to select Function menu.
3. Press ENTER button and then use /button to
select Language.
4. Press button to select language.
English Spanish or French
/
/
1 First, connect power cord correctly.
2 Select the viewing source by using INPUT button on
the remote control.
3 When finished usingthe TV, press POWER button on
the remote control. The TV reverts to standby mode.
4 If you intend to be away on vacation, disconnect the
power plug fromthe wall power outlet.
.
.
.
.
Change the picturesource so youcan watch your TV,
VCR, DVD, Cable, or any other devices that are
connected to yourTV.
1. Press INPUT button to enter the Select Source menu
and then use /button to select the desireditems
(TV, Video1, Video2, S-Video,Component1, Component2,
, HDMI1,HDMI2,HDMI3,HDMI4).
2. Press ENTER button to confirm .
PC
Operation
Select Source
TV
Video1
Video2
S-Video
Component1
Component2
HDMI1
HDMI2
HDMI3
HDMI4
PC
Operation
Switching On/Off the TV set
Choose the Input source
18 TV LCD-TFT
Video
Audio
Channel
Lock
Function
Function
Language English
OSD Timeout Short
OSD Transparency Middle
Screen Mode Normal
Blue Screen On
DPMS On
Time Setup
Closed Caption
Default
Select
/Back
EXIT

This TV set has two methods to set channels, which are
respectively Channel Scan, Channel Skip.
In this section, how to use the remote control to set
channel is explained. You can also use buttons on the TV to
set channel.
Note
The Channel menu will be only operated in normal TV mode.
Channel menu
Operation
Owner s Manual 19
1. Press MENU button and then use /button to select
Channel menu.
2. Press ENTER button to select Tuner.
3. Press button to selectCable or Antenna mode.
4. Press /button to select Channel Scan.
5. Press ENTER button to start searching.
6. To cancel searching,press EXIT button.
/
/
/
Note
When Antenna is selected, the TV will detect antenna
signals and will search for antenna TV (NTSC and
ATSC) channels available in your local area.
When Cable is selected, the TV will detect cable
company supplied signalsand will searchfor cable TV
(NTSC,QAM modulated) channels available in your
Area.
Channel Scan
Channel Skip
1. Press MENU button and then use /button to select
Channel menu.
2. Press / ENTER button and thenuse /button to
select Channel Skip.
3. Press /button to selecta channel, thenpress ENTER
button to toggle between and .
A skip channel is skipped when using /button to
browse the channels. A skip channel can be watch
by key-in the channel number or select by list.
Default un-scanned analog channels are skip.
Channel with a check icon is a skipped channel.
Status: Antenna
Analog Channels: 19
Digital Channels: 0
64%
Scanning
1
2
3
4
5
5-1
6
7
8
9
10
Analog
Analog
Analog
Analog
Analog
Digital KPIX-DT
Analog
Analog
Analog
Analog
Analog
Video
Video
Video
Video
Audio
Audio
Audio
Audio
Channel
Channel
Channel
Channel
Lock
Lock
Lock
Lock
Function
Function
Function
Function
Channel
Channel Scan
Channel Skip
Channel Label Set
Tuner Antenna
Channel Scan
Channel Skip
Channel Label
Select
/BackScan EXIT
Select
/
/
BackSet EXIT
Cancel
EXIT
ENTER
ENTER
Channel Label
Allows you to name the channel that is selected.
Press /ENTER button to enter the submenu.
Then press /to select Channel Index and Channel
Label and /to select the position of the item that you
want to change,afterward press INPUT to input the
numbers and symbols and ENTER button to confirm.
Channel Index
Channel Label
Select Back
EXIT
1

Operation
20 TV LCD-TFT
1
Also can enter channel number directly,eg:2-0.
.
Note
If skip is ON on one channel, press CH+/- button, the
channel will not appear.
2.
Using CH+/- buttons.
Press CH+ button to select a channel number in
number increasing direction.
Press CH- button to select a channel number in
number decreasing direction.
Select the desired sound
Press VOL-/+ buttons on the remote or the front of the
TV set to adjust the volume level. The range is 0~100.
When the volume buttons are pressed the volume level
is displayed automatically on the TV screen.
Mute
1. Press MUTE button on the remote control and
icon will display on the screen. At this time, the sound
of the TV set isturned off.
2. If you want to recover the sound, press MUTE
button again ordirectly press VOL+ button.
Volume
Select the desired program
