Hama Fun 70 BT User manual

”Fun 70 BT”
Sele
D
GB
Operating Instructions
Bedienungsanleitung
00
004315

2
1
3

Controls and Displays
A
1. USB charging port
B
2. Status LED,
ON/OFF switch =activates Bluetooth
remote release; takes aphoto, video
or triggers continuous shooting,
Remote release
3. Smartphone bracket
Thank you for choosing aHama product.
Take your time and read the following
instructions and information completely.
Please keep these instructions in asafe
place for futurereference. If you sell
the device, please pass these operating
instructions on to the new owner.
1. Explanation of Warning Symbols
and Notes
Warning
This symbol is used to indicate safety
instructions or to draw your attention
to specichazards and risks.
Note
This symbol is used to indicate
additional information or important
notes.
2. Package Contents
•SeleFun 70 BT
•USB charging cable
•These operating instructions
3. Safety Notes
•Protect the product from dirt, moisture
and overheating, and only use it in a
dry environment.
•Donot usethe product in areaswherethe
use of electronic devicesisnot permitted.
•Donot use the product in moist
environments and avoid splashes.
•Donot drop the product and do not
expose it to any major shocks.
•Dispose of packaging material
immediately according to locally
applicable regulations.
•Since the battery is integrated and
cannot be removed, you will need to
dispose of the product as awhole.
Do this in compliance with the legal
requirements.
2
GOperating Instructions

•Donot open the device or continue to
operate it if it becomes damaged.
•Donot modify the product in any way.
Doing so voids the warranty.
4. System Requirements
The SeleFun 70 BT supports Bluetooth-
capable terminaldevicessuch as smartphones
and tablet PCs thatuse the iOS 5orAndroid
3.0 (ornewer) operating systems.
Note
•Note that some terminal devices
may not support this product.
•Please refer to the operating
instructions for the device you
areusing.
5. Getting Started
Warning –Battery
•Use only asuitable charger when
charging the battery.Follow the
charger’soperating instructions!
•Donot overcharge the product or
allow the battery to completely
discharge.
•Avoid storing, charging or using
batteries in extreme temperatures.
•When stored over along period of
time, batteries should be charged
regularly (at least every three
months).
•The product is equipped with abuilt-in
battery.
•Charge the battery fully beforeusing
the device for the rst time.
•Tocharge the battery,use the included
USB charging cable to connect the
MicroUSB charging port on the
product (1) to aUSB charger or the USB
port of your notebook/computer (must
be switched on).
•The status LED (2) illuminates redwhile
the battery is charging and switches
off once the battery is fully charged.
If the battery is dead, the status LED
(2) goes out.
Warning –Charging
•Asarule, do not charge devices or
USB connections that aredefective
and do not try to repair them yourself.
3

6. Operation
Note
•The functions described in this
section areonly available for
Bluetooth-capable terminal devices.
•Note that the max. range of
Bluetooth without any obstacles
such as walls, people, etc. is
10 metres.
6.1. Bluetooth connection
Note -Pairing
•Make surethat your Bluetooth-
capable terminal device is on and
Bluetooth is activated.
•Make surethat your Bluetooth-
capable terminal device is visible for
other Bluetooth devices.
•For moreinformation, please refer
to the operating instructions of your
terminal device.
•Press and hold the ON/OFF switch for
about 3seconds.
•The status LED (2) begins to ash
blue. This means the Bluetooth remote
release is searching for aBluetooth
connection.
•This means the Bluetooth remote
release is searching for aBluetooth
connection.
•Open the Bluetooth settings on your
terminal device and wait until
hama SeleFun appears in the list of
Bluetooth devices found.
•Select hama SeleFun and wait until
hama SeleFun is listed as connected
in the Bluetooth settings on your
terminal device. The status LED (2)
glows blue.
Note -automatic connection
and possible problems
After the devices have been paired
once, the connection is then
established automatically.Ifthe
Bluetooth connection is not established
automatically,check the following:
4

•Check the Bluetooth settings of your
terminal device to see whether hama
SeleFun is connected. If it is not,
repeat the steps described above.
•Check whether obstacles are
impairing the range. If so, move the
devices closer together.
•Low battery charge can impair the
connection. Fully charge the battery
if necessary.
•Only one Bluetooth device can be
connected at atime. If thereisan
active connection to another
•device, deactivate this connection
and try again.
6.2. Remote release function
•Once you have established the
Bluetooth connection, open the camera
function on your terminal device and
select the desired camera(front or rear
camera), if applicable.
•Mount the smartphone in the bracket
(3) and ensurethat it is secure.
•Extend the SeleFun 70 BT telescopic
pole to the desired length.
•Press the release button (2) to
trigger the selected function (sele,
photo, video).
7. Care and Maintenance
Only clean this product with aslightly
damp, lint-free cloth and do not use
aggressive cleaning agents. Make sure
that water does not get into the product.
8. Warranty Disclaimer
Hama GmbH &Co. KG assumes no liability
and provides no warranty for damage
resulting from improper installation/
mounting, improper use of the product
or from failuretoobserve the operating
instructions and/or safety notes.
9. Service und Support
Please contact Hama Product Consulting
if you have any questions about this
product.
Hotline: [phone] (German/
English)
Further support information can be
found here:
www.hama.com
5

6
10. Technical Data
Bluetooth version 3.0 and newer
Bluetooth Class Class 2
Bluetooth Range
max. 10 m
Extension 20,5 -70cm
Battery capacity 55 mAh
Charging time ca. 2h
11. Recycling Information
Note on environmental protection:
After the implementation of
the European Directive
2012/19/EU and 2006/66/EU
in the national legal system,
the following applies: Electric
and electronic devices as well as batteries
must not be disposed of with household
waste. Consumers areobliged by law to
return electrical and electronic devices as
well as batteries at the end of their service
lives to the public collecting points set up
for this purpose or point of sale. Details to
this aredened by the national law of the
respective country.This symbol on the
product, the instruction manual or the
package indicates that aproduct is subject
to these regulations. By recycling, reusing
the materials or other forms of utilising old
devices/batteries, you aremaking an
important contribution to protecting our
environment.
12. Declaration of Conformity
Hereby,Hama GmbH &CoKG
declares that the radio
equipment type [00004315] is
in compliance with Directive 2014/53/EU.
The full text of the EU declaration of
conformity is available at the following
internet address: www.hama.
com/00004315/Downloads.
Frequency band(s)
2.40 –2.48 GHz
Maximum radio-
frequency
power transmitted
0.64 mW

7
Bedienungselemente und Anzeigen
A
1. USB-Ladebuchse
B
2. Status LED,
ON/OFF Schalter= Aktivierung
Bluetooth-Fernauslöser /Foto-/
Video-/ Serienaufnahme,
Auslöser
3. Smartphone Halterung
Vielen Dank, dassSie sichfür einHama
Produkt entschieden haben! Nehmen Siesich
Zeitund lesen Sie diefolgendenAnweisungen
und Hinweise zunächstganzdurch.
BewahrenSie dieseBedienungsanleitung
anschließend an einemsicherenOrt auf,um
bei Bedarf darinnachschlagen zu können.
Sollten Sie dasGerät veräußern,geben Sie
diese Bedienungsanleitung an den neuen
Eigentümer weiter.
1. Erklärung von Warnsymbolen und
Hinweisen
Warnung
Wirdverwendet, um Sicherheitshinweise zu
kennzeichnen oderumAufmerksamkeit auf
besondereGefahren und Risiken zu lenken.
Hinweis
Wirdverwendet, um zusätzlich
Informationen oder wichtige Hinweise
zu kennzeichnen.
2. Packungsinhalt
•SeleFun 70 BT
•USB Ladekabel
•diese Bedienungsanleitung
3. Sicherheitshinweise
•Schützen Sie das Produkt vor Schmutz,
Feuchtigkeit und Überhitzung und
verwenden Sie es nur in trockenen
Umgebungen.
•Benutzen Sie das Produkt nicht in
Bereichen, in denen elektronische
Produkte nicht erlaubt sind.
•Verwenden Sie das Produkt nicht
in einer feuchten Umgebung und
vermeiden Sie Spritzwasser.
•Lassen Sie das Produkt nicht fallen
und setzen Sie es keinen heftigen
Erschütterungen aus.
•Entsorgen Sie das Verpackungsmaterial
sofort gemäß den örtlich gültigen
Entsorgungsvorschriften.
DBedienungsanleitung

8
•Der Akku ist fest eingebaut und kann
nicht entfernt werden, entsorgen Sie
das Produkt als Ganzes gemäß den
gesetzlichen Bestimmungen.
•Öffnen Sie das Produkt nicht und
betreiben Sie es bei Beschädigungen
nicht weiter.
•Nehmen Sie keine Veränderungen
am Produkt vor.Dadurch verlieren sie
jegliche Gewährleistungsansprüche.
4. Systemvoraussetzungen
Die SeleFun 70 BT Bluetooth unterstützt
Bluetooth-fähige Endgeräte wie
Smartphones und Tablet-PCs, auf denen
die Betriebssysteme iOS 5bzw.Android
3.0 oder neuereVersioneninstalliert sind.
Hinweis
•Beachten Sie, dass die
Unterstützung des Produktes von
Ihrem Endgerät abhängig ist.
•Beachten Sie dazu die Bedienungs-
anleitung Ihres verwendeten
Endgerätes.
5. Inbetriebnahme
Warnung –Akku
•Benutzen Siezum Laden nur geeignete
Ladegeräte, beachten Siehierbei
auch die Bedienungsanleitungdes
Ladegerätes!
•Überladenodertiefentladen Siedas
Produktnicht.
•Vermeiden SieLagerung, Ladenund
Benutzen bei extremen Temperaturen.
•Laden Siebei längererLagerung
regelmäßig(mind. vierteljährig) nach.
•Das Produkt verfügt über einen fest
eingebauten Akku.
•Laden Sie den Akku vor dem ersten
Gebrauch zunächst einmal vollständig auf.
•Verbinden Sie zum Laden die
Micro-USB Ladebuchse des Produkts
(1) mithilfe des beiliegenden USB
Ladekabels mit einem USB-Ladegerät
oder einem USB Anschluss Ihres
eingeschalteten Notebooks/Computers.
•Die Status LED (2) leuchtet bei aktivem
Ladevorgang rotund erlischt, sobald
der Akku vollständig geladen ist.
Bei verbrauchtem Akku erlischt die
Status-LED (2).
