HAMPTON BAY OSCW-24M BK User manual

Item #1005 425 416
Model #OSCW-24M BK
USE AND CARE GUIDE
24 INCH BLACK OUTDOOR WALL MOUNT FAN
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and condence you have placed in Hampton Bay through the purchase of this light kit. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

2
Table of Contents ................................................................ 2
Safety Information............................................................... 2
Warranty ............................................................................... 2
Safety Information
Table of Contents
Warranty
CAUTION: Read and follow all instructions before operating
fan. Do not use if any part is damaged or missing.
We warrant the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime
after the date of purchase by the original purchaser. We also warrant that all other fan parts, excluding any glass or acrylic blades, to be free from
defects in workmanship and material at the time of shipment from the factory for a period of two years after the date of purchase by the original
purchaser. We agree to correct such defects without charge or at our option replace with a comparable or superior model if the product is returned.
To obtain warranty service, you must present a copy of the receipt as proof of purchase. All costs of removing and reinstalling the product are your
responsibility. Damage to any part such as by accident, misuse, improper installa-tion or by affixing any accessories, is not covered by this warranty.
Because of varying climatic conditions this warranty does not cover any changes in brass finish, including rusting, pitting, corroding, tarnishing or
peeling. Brass finishes of this type give their longest useful life when protected from varying weather conditions. A certain amount of “wobble” is
normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other
express warranty. We hereby disclaim any and all warranties, including but not limited to those of merchantability and fitness for a particular
purpose to the extent permitted by law. The duration of any implied warranty which cannot be disclaimed is limited to the time period as specified
in the express warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above limitation may not apply to you. The
retailer shall not be liable for incidental, consequential, or special damages arising out of or in connection with product use or performance except
as may otherwise be accorded by law. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion or
limitation may not apply to you. This warranty gives specific legal rights, and you may also have other rights which vary from state to state. This
warranty supersedes all prior warranties. Shipping costs for any return of product as part of a claim on the warranty must be paid by the customer.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
READ AND SAVE THESE INSTRUCTIONS.
WARNING: To reduce the risk of re or electrical shock, DO
NOT use this fan with any solid state speed control device.
This appliance has a 3-prong grounded plug that must
be inserted into a matching outlet. To reduce the risk of
electrical shock, this grounding plug must not be cut off.
Where a two-prong wall outlet is encountered, it must be
replaced: contact a qualied electrician. DO NOT attempt to
defeat this safety feature. Use your fan only with adequate
wiring that is up to code. Connect to properly grounded
outlets only.
Pre-Installation .................................................................... 3
Assembly.............................................................................. 4
WARNING: Unplug from electrical supply source before
cleaning. After servicing, any safety device (including
grills and blades) must be reinstalled or remounted as
previously installed.
NOTE: Installation of this equipment should be performed
by a qualied person. We do not warrant any damage or
injuries as a result of improper installation.
□Always unplug unit for cleaning.
□Always unplug unit when not in use.
□Do not place foreign objects through guard into the blade.
□Do not operate without fan guards properly locked.
□Do not use this fan with an extension cord.
□Do not place fan or any parts near an open ame, cooking or
other heating appliance.
□Do not operate this unit with a damaged cord or plug,
especially when this unit has been malfunctioned, dropped or
damaged.
NOTE: This fan is suitable for wet location. Suitable for use
in wet locations when installed in a GFCI Protected
Branch Circuit.

3HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Installation
Part Description Quantity
A Fan motor 1
B Mounting pipe 1
C Wall mounting bracket 1
PACKAGE CONTENTS
TOOLS REQUIRED
HARDWARE INCLUDED
Part Description Quantity
AA Knob 1
BB Hexagonal screw 1
CC Hexagonal threaded screw 1
DD Flat washer 1
EE Spring washer 1
Part Description Quantity
FF Hexagonal nut 1
GG Screw 4
HH Flat washer 4
II Left ange 1
JJ Right ange 1
C
B
A
D
E
F
Part Description Quantity
D Front grill 1
E Blade 1
F Rear grill 1
Phillips
screwdriver
Flat head
screwdriver
Step
ladder
Square xed
socket wrench
Wrench
AA BB CC DD EE
FF GG HH II JJ

4
Assembly Instructions
Installing the wall mounting bracket to wall
□Determine the approximate position of where you want the fan to
be located on the wall. Then, locate the stud in the wall. Position
the wall mounting bracket (C) on wood stud or wood post and
mark the location of the four holes using a pencil or a marker (not
included).
□Use 3/32-in. drill bit (not included) to drill pilot holes at marked
locations. Then, install wall mounting bracket (C) to the wall using
the wood screws (GG) and washers (HH).
CAUTION: If you are going to attach the fan assembly (A) to
a wood stud or wood post, the stud or wood post must be
wide enough and thick enough to sustain the wall mounting
bracket (C) and the weight of the fan assembly (A).
WARNING: To reduce the risk of the fan falling, use all
four mounting holes in the wall mounting bracket (C)
when installing.
WARNING: It is very important that you use the proper
hardware when installing the wall mounting bracket (C)
as this will support the fan assembly (A).
1
7 feet
minimum
HH
C
GG
Attaching anges to fan motor
□Remove all the screws, spring washers and at washers,then install the left ange (II) and right ange (JJ) accordingly.
2
A
II JJ
Flat
washers
(4)
Spring
washers
(4)
Screws
(4)

5HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Wall mount bracket / Motor assembly
□Remove the hexagonal screw (BB), spring washer (EE) and
nut (FF) from the motor (A).
□Align the holes on the pipe (B) with the holes in the motor
ange on the motor assembly.
□Insert the hexagonal screw (BB) and replace the washers (EE)
and nut (FF) removed in step 1.
□Adjust the tilt to the desired position and tighten the pivot
knob (AA) to set the angle.
□Tighten the position bolt and nut.
CAUTION: Be sure to secure the knobs.
Assembly Instructions (continued)
Installing the mounting pipe and
base assembly
□Put one end of the pipe (B) into the slot in the base of the mounting
bracket (C).
□Carefully insert the position knob and tighten it to hold the pipe (B).
C
B
A
B
AA
BB
DD
EE
FF
CC
3
4

6
Front grill assembly
Assembly Instructions (continued)
6
□Hang the front grill (D) on the top rib of the rear grill (F) by utilizing
the hook.
□Snap the front grill into the rear grill to secure.
D F
Rear grill and blade assembly
□Remove the four nuts, spring washers and at washers from
the bolts around the motor shaft.
□Carefully slide the rear grill (F) over the bolts.
□Secure with the at washers, spring washers and nuts
removed in Step 1.
□Carefully slide the blade assembly (E) over the shaft and align
the inner hex head driver provided with the slot on the shaft
of the motor (A).
□Tighten the blade assembly (E) with the screws using a
Philips-head screwdriver (not provided).
5A
F
nut
spring
washer
at
washer
E
F
A

7HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Adjust airow upward or downward
□Loosen (but do not remove) the adjustment knob by turning it
counterclockwise.
□Tilt the head of the fan to the desired angle.
□Retighten adjustemnt knob once desired angle is set.
Operating Instructions
Speed control
□Pull gently on chain to change the setting on the speed control to
the desired setting; low, medium or high.
Cleaning
□Use soft damp cloth then wipe with dry cloth. Do not use harmful cleaners. Do not bend the blades.
Oscillating control
□Pull the oscillating knob down to enable the oscillating feature.
Push the knob back up to disable the feature. Adjustment knob
(tilts fan head up or down)
Pull chain
(speed control)
Oscillating knob
(oscillating control)

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
Net weight: 38.59 lbs (17.5 kgs)
Gross weight: X.XX lbs (X.X kgs) PENDING
Cubic Feet: 5.07 ft3
