Hanover FCA30332BST User manual

Assembly Instructions
FCA30332BST
Aluminum Sling 4pc Seating Set
Questions, problems, or missing parts?
Before returning to the store, call Customer Service.
1-866-988-3300
8 a.m. - 5 p.m., PST Monday - Friday
Retain this manual for future use.

FCA30332BST
1
Chair Parts & Tools
PART
QTY
PICTURE & DESCRIPTION
PART
QTY
PICTURE & DESCRIPTION
A
2
Right Arm
AA
20
M6X20 Bolt
B
2
Left Arm
BB
4
M6X40 Bolt
C
2
Back Frame
CC
1
Allen Wrench
D
2
Seat Frame
WARNING: To avoid damaging this product,
assemble it on a soft, non-abrasive surface
such as carpet or cardboard.

FCA30332BST
2
Chair Assembly
Step 1:
•Place the right arm (A) on a soft surface.
Line up the bolt holes on the right arm (A)
and seat frame (D). Insert M6x20 bolt (AA).
Loosely tighten using the Allen wrench(CC).
Step 2:
•Place the left arm (B) on a soft surface. Line
up the bolt holes on the seat frame (D) and
left arm (B). Insert M6x20 bolt (AA). Loosely
tighten using the Allen wrench(CC).
Step 3:
•Attach the back frame (C) to the right
arm(A) and left arm (B). Line up the bolt
holes on the back frame (C) and right
arm(A), left arm (B). Insert M6x40 bolt (BB).
•Attach the back frame (C) to the seat
frame (D) . Line up the bolt holes on the
back frame (C) and seat frame (D). Insert
M6x20 bolt (AA).
•Loosely tighten using the Allen
wrench(CC)

FCA30332BST
3
Chair Assembly
Step 4
•Ensure all connections are secure before
use.
•Turn the chair in an upright position.

FCA30332BST
4
Loveseat Parts & Tools
PART
QTY
PICTURE & DESCRIPTION
PART
QTY
PICTURE & DESCRIPTION
A
1
Right Arm
AA
11
M6X20 Bolt
B
1
Left Arm
BB
2
M6X40 Bolt
E
1
Back Frame
cc
1
Allen Wrench
F
1
Seat Frame
WARNING: To avoid damaging this product,
assemble it on a soft, non-abrasive surface
such as carpet or cardboard.

FCA30332BST
5
Loveseat Assembly
Step 1:
•Place the right arm (A) on a soft surface.
Line up the bolt holes on the right arm (A)
and seat frame (F). Insert M6x20 bolt (AA).
Loosely tighten using the Allen wrench(CC).
Step 2:
•Place the left arm (B) on a soft surface. Line
up the bolt holes on the seat frame (F) and
left arm (B). Insert M6x20 bolt (AA). Loosely
tighten using the Allen wrench(CC).
Step 3:
•Attach the back frame (E) to the right arm
(A) and left arm(B). Line up the bolt holes
on the back frame (E) and right arm
(A),left arm(B). Insert M6x40 bolt (BB).
•Attach the back frame (E) to the seat
frame (F) . Line up the bolt holes on the
back frame (E) and seat frame (F). Insert
M6x40 bolt (BB).
•Loosely tighten using the Allen
wrench(CC)

FCA30332BST
6
Loveseat Assembly
Step 4
•Ensure all connections are secure before
use.
•Turn the loveseat in an upright position

FCA30332BST
7
Table Parts & Tools
PART
QTY
PICTURE & DESCRIPTION
PART
QTY
PICTURE & DESCRIPTION
G
1
Table Rim
DD
8
M6*35 Bolt
H
2
Table Leg
CC
1
Allen Wrench
I
1
Glass
WARNING: To avoid damaging this product,
assemble it on a soft, non-abrasive surface
such as carpet or cardboard.

FCA30332BST
8
Table Assembly
Step 1:
•Place the table rim (G) on a soft surface.
Line up the holes on the table legs (H) and
table rim (G). Insert M6x35 bolts (DD).
•Loosely tighten using Allen wrench (CC).
•
Step 2:
•Repeat the same steps for the other table
legs.
Step 3:
•Ensure all connections are secure before
use.
•Turn the table right side up. Place glass (I)
onto the table rim (G).
