ShowerTablet Select 400
24340XX7
ShowerTablet Select 400
24360XX7

2
中文
安装 (参见第页4)
安全技巧
装配时为避免挤压和切割受伤，必须戴上手套。
本产品只允许作为洗浴、卫生和洁身之用。
不得让儿童和肢体、精神和/或意识有障碍的成人在不受监管的情况下
使用淋浴系统。受酒精或毒品影响的人员不得使用淋浴系统。
该产品不得作扶柄使用。必须安装单独的扶柄。
冷热水管间过大的压力差必须予以平衡。
安装提示
• 安装前必须检查产品是否受到运输损害。安装后将不认可运输损害或
表面损伤。
• 管道和阀门必须根据通用标准进行安装、冲洗和检查。
• 请遵守当地国家现行的安装规定。
• 由有资格的专业人员进行产品安装时请注意：在所有加固区域中，加
固表面是否平整(无突出的接缝或瓷砖)，墙体结构是否适合产品安装
且未显露出任何缺点。
• 本产品并非设计来与蒸气浴连接使用！
• 恒温龙头连接连续流热水器:如果要连接手持花洒，必须去掉它的水
流控制器。
技术参数
工作压强： 最大1MPa
推荐工作压强： 0,1-0,5MPa
测试压强： 1,6MPa
(1MPa=10bar=147PSI)
热水温度： 最大60°C
中心距离： 150±12mm
连接管线G1/2: 左热右冷
热力消毒:70°C/4分钟
• 自动防止回流
• 该产品专为饮用水设计！
符号说明
请勿使用含有乙酸的硅胶！
安全功能 (参见第页5)
恒温阀芯的安全功能可以预先设定所希望的最高出水温度，例如最高温度
为42℃
调节 (参见第页4)
安装完成后必须检查调温器的出水温度。如在取水处测量所得的温度与调
温器上设定的温度有偏差，那么必须进行调整。
保养 (参见第页6)
• 单向阀必须在符合国家或当地的法律的情况下按照EN806-5定期检查(
至少一年一次)。
• 为了保证恒温器的稳定运转，请务必定期从最热到最冷转动调温器。
大小 (参见第页8)
流量示意图 (参见第页8)
手持花洒
浴缸出水口
备用零件 (参见第页9)
XX=颜色代码
00=镀铬
67=MattBlack
70=MattWhite
清洗 (参见第页10)
操作 (参见第页7)
问题 原因 补救
龙头出水量小 - 水压不足 - 检查总水压
- 调压器过滤网脏污 - 清洁龙头前面和恒温阀芯的过滤网。
- 花洒滤网有垃圾堵塞 - 清洗花洒和软管间的过滤网
串水，在龙头关闭的状态下，热水被强迫流入冷
水管路，或者相反。
- 单向阀有垃圾堵塞或漏水 - 清洗单向阀，如有必要则更换新的
龙头出水温度和温度设定的不符 - 恒温阀芯未被调节 - 调节恒温器
- 热水温度过低 - 将热水温度从42ºC升高到47ºC
水温无法调节 - 恒温阀芯表面结垢 - 更换-恒温阀芯
安全停止按钮不工作 - 弹簧损坏
- 按钮僵化
- 清洁弹簧和/或按钮，并视需要更换
使用恒温龙头后，燃气热水器不工作 - 过滤网有垃圾堵塞 - 清洗过滤网/更换过滤网
- 单向阀装反 - 正确安装单向阀
- 手持花洒的流量限制器没有去除 - 去除流量限制器
花洒或龙头出水嘴滴水 - 在阀体上有灰尘或水垢，阀芯损坏 - 更换关闭部件

3
English
Assembly (see page 4)
Safety Notes
Gloves should be worn during installation to prevent crushing and cutting
injuries.
The product may only be used for bathing, hygienic and body cleaning
purposes.
Children as well as adults with physical, mental and/or sensoric impairments
must not use this product without proper supervision. Persons under the
influence of alcohol or drugs are prohibited from using this product.
The product may not be used as a holding handle. A separate handle must be
installed.
The hot and cold supplies must be of equal pressures.
Installation Instructions
• Prior to installation, inspect the product for transport damages. After it has been
installed, no transport or surface damage will be honoured.
• The pipes and the fixture must be installed, flushed and tested as per the
applicable standards.
• The plumbing codes applicable in the respective countries must be observed.
• During installation of the product by qualified trained personnel, make sure that
the entire fastening surface is even and smooth (no protruding seams or tile
offset), that the finish of the wall is suitable to apply the product and has no
weak points.
• The product is not designed to be used with steam baths!
• Thermostatic mixer in conjunction with combination boilers: If fitting a hand
shower remove the water limiter from the shower.
Technical Data
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,1 - 0,5 MPa
Test pressure: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
Hot water temperature: max. 60°C
Centre distance: 150±12 mm
Connections G 1/2: cold right - hot left
Thermal disinfection: 70°C / 4 min
• Safety against backflow
• The product is exclusively designed for drinking water!
Symbol description
Do not use silicone containing acetic acid!
Safety Function (see page 5)
The desired maximum temperature for example max. 42º C can be pre-set thanks
to the safety function.
Adjustment (see page 4)
After the installation, the output temperature of the thermostat must be checked. A
correction is necessary if the temperature measured at the output differs from the
temperature set on the thermostat.
Maintenance (see page 6)
• The check valves must be checked regularly according to EN 806-5 in
accordance with national or regional regulations (at least once a year).
• To guarantee the smooth running of the thermostat, it is necessary from time to
time to turn the thermostat from total hot to total cold.
Dimensions (see page 8)
Flow diagram (see page 8)
 Hand shower
 Bath Spout
Spare parts (see page 9)
XX = Colors
00 = Chrome Plated
67 = Matt Black
70 = Matt White
Cleaning (see page 10)
Operation (see page 7)
Fault Cause Remedy
Insufficient water - Supply pressure inadequate - Check water pressure (If a pump has been installed
check to see if the pump is working).
- Regulator filter dirty - Clean filter in front of the mixer and on the MTC-ther-
mo cartridge
- Shower filter seal dirty - Clean filter seal between shower and hose
Crossflow, hot water being forced into cold water
pipe, or vice versa, when mixer is closed
- Backflow preventers dirty or leaking - Clean backflow preventers, exchange if necessary
Spout temperature does not correspond with
temperature set
- Thermostat has not been adjusted - Adjust thermostat
- Hot water temperature too low - Increase hot water temperature to 42 ºC to 47 ºC
Temperature regulation not possible - thermo cartridge calcified - Exchange thermo cartridge
Safety stop button not operating - Spring defective
- Button calcified
- Clean spring and/or button, exchange if necessary
Instantaneous heater didn't work with thermostat - Filters are dirty - Clean the filter / exchange filter
- check valve hasn't moved back - Exchange check valves
- Flow limiter in handshower isn’t removed - Remove flow limiter
Shower or spout dripping - Dirt or sedimentation on valve seat, shut-off unit
damaged
- Exchange shut-off unit

4
1.
2.
Silicone
X
X
X 38
1. 2.
X + 38 mm
12
3
1 2
SW 3 mm
(3 Nm)
78
SW 27 mm
3
1.
2.
Armaturenfett
Grease
䀵滑油
37- 38
mm
41.
2.
SW 3 mm
65a
5b
6
7
Montage /Justierung Safety Function

5
SW 3 mm
1.
2.
for example 42°C
z. B. 42°C
SW 3 mm
(1 Nm)
1
4
7
11
3
5
8
2
6
9
10
Safety Function

6
3 .
2.
2.
1.
SW 3 mm SW 22 mm
1.
2.
SW 3 mm
(3 Nm)
1 2
4
1.
3.
SW 22 mm
(4 Nm)
3
红色/Red
Wartung / Bedienung Bedienung

7
> 40 °C
Bedienung

8
74
103
412
95
206
349
150±12
50
G1/2
12°
G1/2
21 - 26
115
161
183
46
150±12
412
74
G 1/2
95
206
147
46
G1/2
21 - 26
115
bar
4,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
5,50,55
6,00,60
036912 15 18 21 24 27 30
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/min
Q = l/sec
bar
4,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
5,50,55
6,00,60
036912 15 18 21 24 27 30
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/min
Q = l/sec
ShowerTablet Select 400
24340XX7
ShowerTablet Select 400
24340XX7
ShowerTablet Select 400
24360XX7
ShowerTablet Select 400
24360XX7
1
2
Maße / Durchflussdiagramm Serviceteile

9
95772000
95772000
98371000
(29x3)
98371000
(29x3)
98199000
(17x2)
98199000
(17x2)
96429000
96429000
95773000
95773000
98372000
(M6x16)
98372000
(M6x16)
9293400X
95758000
95758000
98368000
(M28x1,5)
98368000
(M28x1,5)
98140000
(20x1) 92340000
98367XX0
98367XX0
98282007
98282007
92136000
98913000
94405XX0
94404000
94403XX0
92136000
98140000
(20x1) 92340000
ShowerTablet Select 400
24340XX7
ShowerTablet Select 400
24360XX7
94405XX0
94404000
94403XX0
98913000
Serviceteile

10
English
Cleaning Recommendation for Hansgrohe Products
Today, modern sanitary and kitchen tapware, showers, accessories, washstands,
tubs and radiators consist of very different materials to comply with the needs of the
market with regard to design and functionality.
To avoid damage and reclamations, it is necessary to consider cer
tain criteria when
cleaning.
With regard to caring for the Hansgrohe products, the fol-
lowing must in principle be heeded:
• Only use cleaning material which is explicitly provided for this type of applica-
tion.
• Never use cleaning materials, which contain hydrochloric acid, formic acid,
chlorine pale lye or acetic acid, as they cause considerable damage.
• Phosphorus acidic cleaners are only conditionally applicable.
• Mixing cleaning agents is not permitted, generally.
• Never use cleaning materials or appliances with an abrasive effect, such as
unsuitable cleaning powders, sponge pads or micro fibre cloths.
• The instructions of the cleaning agent manufacturers have to be followed
absolutely.
• Cleaning has to be carried out with a specified cleaner dosage, contact time,
object-related and adapted to the needs.
• The building up of calcifications has to be removed by cleaning regulary.
• When using spray cleaners, spray the cleaning solution onto a soft cloth or
sponge, never directly onto the Hansgrohe products, as the atomised spray
could enter openings and gaps in the Hansgrohe products and cause damage.
• After cleaning rinse thoroughly with clean water to remove any cleaner residue.
• The use of steam cleaners is not permitted. The high temperatures can damage
the products.
Important
Residues of toiletries such as liquid soaps, shampoos and shower gels, hair dyes,
perfumes, aftershave and nail varnish can also cause damage.
Here too: Carefully rinse with water after use to remove residues.
Likewise, do not store any cleaning agents or chemicals under the products, for
example in a vanity unit, as the vapours may damage the products.
The damage of already damaged surfaces will deteriorate under the effect of the
cleansers.
Components with damaged surfaces must be exchanged,
otherwise there could be an injury danger.
Damage caused by improper treatment will not be covered by our guarantee.
Warranty
Hansgrohe guarantees to the consumer that this product is free of production faults.
If evertheless any defect is detected within 5 years from date of purchase, Hans-
grohe will remedy this defect free of charge. You will find the conditions and details
of this guarantee at www.hansgrohe-int.com/guarantee. Please contact your
contracting party to claim your rights under this guarantee. This guarantee does not
affect the customer‘s rights under the respective national legislation.
QuickClean
The QuickClean cleaning function only needs a small manual rub over to remove
the lime scale from the spray channels.
•
•
•
•
•
•
•
•
•
•
•
Hansgr
ohe
Hansgrohe
w
ww.hansgrohe-int.com/guarantee
Q
uickClean
QuickClean
QUICK
CLEAN
Reinigung

11

12
