Hans Grohe Ecostat Square 15714 7 Series Manual

ZH 用户手册/组装说明 2
EN Instructions for use / assembly instructions 4
Lesezeichen
中文 2
English 4
Ecostat S
15758007
Ecostat E
15708007
2
Ecostat Square
15714XX7
2

2
中文
安全技巧
装配时为避免挤压和切割受伤,必须戴上手套.
本产品只允许作为洗浴,卫生和洁身之用.
不得让儿童和肢体,精神和/或意识有障碍的成
人在不受监管的情况下使用淋浴系统.受酒精或
毒品影响的人员不得使用淋浴系统.
冷热水管间过大的压力差必须予以平衡.
安装提示
• 安装前必须检查产品是否受到运输损害.安装后
将不认可运输损害或表面损伤.
• 管道和阀门必须根据通用标准进行安装,冲洗和
检查.
• 请遵守当地国家现行的安装规定.
技术参数
工作压强: 最大1MPa
推荐工作压强:0,1-0,5MPa
测试压强:1,6MPa
(1MPa=10bar=147PSI)
热水温度: 最大60°C
热力消毒:70°C/4分钟
该产品专为饮用水设计!
符号说明
请勿使用含有乙酸的硅胶!
安全功能 (参见第页8)
恒温阀芯的安全功能可以预先设定所希望的最高出
水温度,例如最高温度为42°C
调节 (参见第页8)
安装完成后必须检查调温器的出水温度.如在取水
处测量所得的温度与调温器上设定的温度有偏差,
那么必须进行调整.
保养 (参见第页10)
• 单向阀必须在符合国家或当地的法律的情况下
按照EN806-5定期检查(至少一年一次).
• 为了保证恒温器的稳定运转,请务必定期从最热
到最冷转动调温器.
大小 (参见第页16)
流量示意图 (参见第页17)
 时的流速
出水口1
出水口2
备用零件 (参见第页18)
XX=颜色代码
00=镀铬
14=BrushedBronze
25=BrushedGold-Optic
34=BrushedBlackChrome
67=MattBlack
70=镀铬
99=MattWhite
选装附件 (参见第页19)
 不在供货范围内
• 加长25mm#13595000
• 加长件22mm(墙壁不够深时)#13593XX0,
#13597000,#15597000
• 调平装置1°#95521000
清洗 (参见第页14)
操作 (参见第页13)
+

3
中文
安装 (参见第页6)
问题 原因 补救
龙头出水量小 - 水压不足 - 检查总水压
- 调压器过滤网脏污 - 清洁龙头前面和恒温阀芯的过滤
网.
- 花洒滤网有垃圾堵塞
- 花洒过滤器元件有垃圾堵塞
- 清洗花洒和软管间的过滤网
- 清洗花洒和软管间的过滤密封件
串水,在龙头关闭的状态下,热水
被强迫流入冷水管路,或者相反.
- 单向阀有垃圾堵塞或漏水 - 清洗单向阀,如有必要则更换新
的
龙头出水温度和温度设定的不符 - 恒温阀芯未被调节 - 调节恒温器
- 热水温度过低 - 将热水温度从42ºC升高到60ºC
水温无法调节 - 恒温阀芯表面结垢 - 更换-恒温阀芯
- 对于新的安装:基体连接不正确(
可能是:右冷,左热)或者安装时
旋转180º
- 安装功能块时,旋转180º
安全停止按钮不工作 - 弹簧损坏
- 按钮僵化
- 清洁弹簧和/或按钮,并视需要更
换
阀门不灵活 - 阀芯损坏 - 更换阀芯
分流器泄漏 - 密封位置上的脏物或沉积物 - 清洁阀座或更换分流器

4
English
Safety Notes
Gloves should be worn during installation to prevent
crushing and cutting injuries.
The product may only be used for bathing, hygienic
and body cleaning purposes.
Children as well as adults with physical, mental and/
or sensoric impairments must not use this product
without proper supervision. Persons under the
influence of alcohol or drugs are prohibited from
using this product.
The hot and cold supplies must be of equal pressures.
Installation Instructions
• Prior to installation, inspect the product for transport
damages. After it has been installed, no transport or
surface damage will be honoured.
• The pipes and the fixture must be installed, flushed
and tested as per the applicable standards.
• The plumbing codes applicable in the respective
countries must be observed.
Technical Data
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,1 - 0,5 MPa
Test pressure: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
Hot water temperature: max. 60°C
Thermal disinfection: 70°C / 4 min
The product is exclusively designed for drinking water!
Symbol description
Do not use silicone containing acetic acid!
Safety Function (see page 8)
The desired maximum temperature for example max.
42º C can be pre-set thanks to the safety function.
Adjustment (see page 8)
After the installation, the output temperature of the
thermostat must be checked. A correction is necessary if
the temperature measured at the output differs from the
temperature set on the thermostat.
Maintenance (see page 10)
• The check valves must be checked regularly accord-
ing to EN 806-5 in accordance with national or
regional regulations (at least once a year).
• To guarantee the smooth running of the thermostat, it
is necessary from time to time to turn the thermostat
from total hot to total cold.
Dimensions (see page 16)
Flow diagram (see page 17)
free flow
 Outlet 1
 Outlet 2
Spare parts (see page 18)
XX = Colors
00 = Chrome Plated
14 = Brushed Bronze
25 = Brushed Gold-Optic
34 = Brushed Black Chrome
67 = Matt Black
70 = Chrome Plated
99 = Matt White
Special accessories (see page 19)
order as an extra
• extension 25 mm #13595000
• Extension Set 22 mm (when wall is not deep
enough)#13593XX0, #13597000,
#15597000
• levelling set 1° #95521000
Cleaning (see page 14)
Operation (see page 13)
+

5
English
Assembly (see page 6)
Fault Cause Remedy
Insufficient water - Supply pressure inadequate - Check water pressure (If a pump has
been installed check to see if the
pump is working).
- Regulator filter dirty - Clean filter in front of the mixer and
on the MTC-thermo cartridge
- Shower filter seal dirty
- filter insert shower dirty
- Clean filter seal between shower
and hose
- Clean filter insert between shower
and hose
Crossflow, hot water being forced into
cold water pipe, or vice versa, when
mixer is closed
- Backflow preventers dirty or leaking - Clean backflow preventers,
exchange if necessary
Spout temperature does not
correspond with temperature set
- Thermostat has not been adjusted - Adjust thermostat
- Hot water temperature too low - Increase hot water temperature to
42 ºC to 60 ºC
Temperature regulation not possible - thermo cartridge calcified - Exchange thermo cartridge
- For new installations: basic body
incorrectly connected (should be:
cold right, hot left) or installed with
180º rotation
- Install function block turned through
180º
Safety stop button not operating - Spring defective
- Button calcified
- Clean spring and/or button,
exchange if necessary
Valve stiff - Cartridge defective - Exchange cartridge
Diverter leaking - Dirt or sedimentation on valve seat. - Clean valve seat or exchange
diverter

6
2.
3.
1. SW 5 mm
SW 4 mm
(5 Nm)
3
1
2
5
X + 11
2.
1.
4
X
1 - 2 mm
01800187
1
Montage

7
6 7
40
°C
2
9
2
10
2.
40
°C
2
11a
1.
40
°C
2
11b
15708007 15758007
15714XX7
(0,1 Nm)
2
8
SW 3 mm
(1,5 Nm)
1.
2.
Armaturenfett
Grease
䀵滑油
Armaturenfett
Grease
䀵滑油
Montage

8
1 2 3
例如 42° C
for example 42° C
2
3.
2.
SW 3 mm
2.
1.
2
1
3
2
4
1.
Justierung / Safety Function

9
2
2
2
7 8
SW 3 mm
(1 Nm)
2
9a
2.
1.
5 6
1.
2.
40
°C
2
9b
15708007 15758007
15714XX7
Safety Function

10
2
3 4
5
SW 4 mm
2
2
2.
1.
21
SW 3 mm
6
Wartung

11
(0,1 Nm)
8
11 12
SW 4 mm
(5 Nm)
1. 2.
7
SW 27 mm
910
SW 27 mm
(8 Nm)
红色 / red
Wartung

12
2
2
15
40
°C
2
16
2.
1.
13
40
°C
2
14
SW 3 mm
(1,5 Nm)
Armaturenfett
Grease
䀵滑油
Armaturenfett
Grease
䀵滑油
Wartung

13
2
2
>40° C
2
1.
2.
2
关 / close
开 / open
热 / hot 冷 / cold
Bedienung

14
, , , , ,
,
.
,
.
, :
•
.
• , ,
,
.
• .
• .
• ,
, .
• .
• ,
.
• .
• ,
. ,
.
• ,
( ).
• , .
, , , , , ,
.
: .
,
.
.

.
Hansgrohe , .
, Hansgrohe
.
www.hansgrohe-int.com/guarantee.
.
QuickClean
QuickClean, ,
, .
Reinigung

15
English
Cleaning Recommendation for Hans-
grohe Products
T
oday, modern sanitary and kitchen tapware, showers,
accessories, washstands, tubs and radiators consist of
ve
ry different materials to comply with the needs of the
mark
et with regard to design and functionality.
To
avoid damage and reclamations, it is necessary to
consider ce
rtain criteria when cleaning.
Wi
th regard to caring for the Hans-
gro
he products, the following must in
principle be heeded
:
• Only use cleaning material which is explicitly
provided for this type of application.
• Never use cleaning materials, which contain
hydrochloric acid, formic acid, chlorine pale lye or
acetic acid, as they cause considerable damage.
• Phosphorus acidic cleaners are only conditionally
applicable.
• Mixing cleaning agents is not permitted, generally.
• Never use cleaning materials or appliances with an
abrasive effect, such as unsuitable cleaning powders,
sponge pads or micro fibre cloths.
• The instructions of the cleaning agent manufacturers
have to be followed absolutely.
• Cleaning has to be carried out with a specified
cleaner dosage, contact time, object-related and
adapted to the needs.
• The building up of calcifications has to be removed by
cleaning regulary.
• When using spray cleaners, spray the cleaning
solution onto a soft cloth or sponge, never directly
onto the Hansgrohe products, as the atomised spray
could enter openings and gaps in the Hansgrohe
products and cause damage.
• After cleaning rinse thoroughly with clean water to
remove any cleaner residue.
• The use of steam cleaners is not permitted. The high
temperatures can damage the products.
Important
R
esidues of toiletries such as liquid soaps, shampoos and
shower gels, hair dyes, perfumes, aftershave and nail
varnish can also cause damage.
Here too: Carefully rinse with water after use to remove
residues.
Likewise, do not store any cleaning agents or chemicals
under the products, for example in a vanity unit, as the
vapours may damage the products.
The damage of already damaged surfaces will
deteriorate under the effect of the cleansers.
Components with damaged surfaces
must be exchanged, otherwise t
here
could be an injury danger.
Damage caused by improper treatment will not be
covered by our guarantee.
Warranty
Hansgrohe guarantees to the consumer that this product
is free of production faults. If evertheless any defect is
detected within 5 years from date of purchase, Hans-
grohe will remedy this defect free of charge. Y
ou will find
the conditions and details of this guarantee at
www.hansgrohe-int.com/guarantee. Please contact your
contracting party to claim your rights under this
guar
antee. This guarantee does not affect the customer‘s
rights under the respective national legislation.
QuickClean
The QuickClean cleaning function only needs a small
manual rub over to remove the lime scale from the spray
channels.
Reinigung

16
Ø 45 Ø30
74
45/45
33/33
55 - 83
155 / 155
16
74
Ø 150
16
57
52 - 80
Ø30
Ø 45
74
156 / 156
16
57
52 - 80
Ø30
Ø 45
155
15 5
3 3
4 5
33
45
150Ø
44Ø
30Ø
156
44Ø
30Ø
Ecostat S
15758007
Ecostat Square
15714XX7
Ecostat E
15708007
Maße

17
bar
4,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
5,50,55
6,00,60
036912151821242730
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/min
Q = l/sec
Ecostat E
15708007
Ecostat S
15758007
Ecostat Square
15714XX7
2
1
2
Durchflussdiagramm

18
2
2
92273000
98133000
(16x2)
98793000
(Ø 145 mm)
96525000
(M5x20)
SW 4 mm
97350000
92594000
96454000
98471000
(44x4)
95843000
SW 3 mm
92216000
92216XX0
92279000
94073000
Ecostat E
15708007
98282007
98913000
(M34x1,5)
SW 27 mm
98197000
(20x1,5)
98146000
(25x1,5)
92146000
(25x2,5)
95253000
95253XX0
98153000
(30x5)
92280000
95252000
98156000
(36x2)
2
Ecostat S
15758007
95843000
SW 3 mm
95252000
98153000
(30x5)
98471000
(44x4)
92215000
92281000
92283000
98283000
95255000
(SW 27 mm
Ecostat Square
15714XX7
95843000
SW 3 mm
95252000
98153000
(30x5)
98471000
(44x4)
92215XX0
92281XX0
93241XX0
Serviceteile

19
+
Ecostat E
15597000 (22 mm)
Ecostat S
13597000 (22 mm)
Ecostat Square
13593XX0 (22 mm)
98133000
(16x2)
95521000
(1°) 13595000
(25 mm)
Sonderzubehör

Hansgrohe · Auestraße 5 - 9 · D-77761 Schiltach · Telefon [phone] · Telefax +49 (0) 7836/511440
E-Mail: [email protected] · Internet: www.hansgrohe.com
07/2022 9.02439.51
