Hatco Insulate Single Built-In Heate
Wells keep hot foo at safe serving
temperatures longer. The fully insulate
construction retains heat better,
istributing it more evenly to keep foo
hot an fresh.
FLEXIBILITY
The Insulate Single Built-In Heate
Wells are available in top or bottom
mount configurations an with or
without a rain . The compact stan ar
control assembly comes in three mounting
choices to accommo ate your steam
table configuration: compact front
mounte with or without a bezel, or back
mounte without a bezel.
Options inclu e a front mounte
recesse control that is angle for easy
rea ability an an Auto-Fill to maintain
proper water levels an insure optimum
serving temperatures.
QUALITY
The following features assure the finest
performance for years to come:
• Fully insulate wells on si es an
bottom ensure better heat retention,
an cooler surroun ing surfaces for
customer safety.
• Faster preheat an recovery for
improve energy efficiency.
• Full size mo els in low, stan ar , an
high watt.
• Separate lighte on/off rocker switch
an temperature ial for easy
operation.
• 50% larger rain with flat screen
simplifies cleaning an hol s pans
level.
• Easy service access to heating
elements an thermostats.
• Mounting kits for combustible
countertops available.
• EZ locking har ware for quick
installation.
• Thicker stainless steel construction
an soli braise joints for urability.
INSULATED SINGLE
BUILT-IN HEATED WELLS
Models HWBLI-FUL, -FULD HWBLIB-FUL, -FULD HWBLIB-FULDA HWBI-FUL, -FULD HWBIB-FUL, -FULD HWBIB-FULDA
HWBHI-FUL, -FULD HWBHIB-FUL, -FULD HWBHIB-FULDA
Mo el HWBI-FULD
with accessory foo pan
Mo el HWBIB-FULD
with accessory foo pan
Model Minimum Width Maximum Width Minimum Depth Maximum Depth Below Counter
HWBI-FUL 12.75" (324 mm) 12.94" (328 mm) 20.75" (528 mm) 20.94" (531 mm) 9.45" (240 mm)
HWBI-FUL
•
14" (356 mm) 14.25" (362 mm) 22" (559 mm) 22.25" (565 mm) 9.45" (240 mm)
HWBIB-FUL▲12.03" (306 mm) 12.03" (306 mm) 20.03" (509 mm) 20.03" (509 mm) 9.45" (240 mm)
HWBIB-FULDA 12.03" (306 mm) 12.03" (306 mm) 20.03" (509 mm) 20.03" (509 mm) 9.45" (240 mm)
Built-in Heate Wells Countertop Cutout Dimensions
•Indicates cutout dimensions or a combustible countertop sur ace.
▲
Must be langed.
METAL SHEATHED ELEMENTS GUARANTEED AGAINST
BURNOUT AND BREAKAGE FOR TWO YEARS.
ANSI/NSF 4
Quick access heating element
an thermostat, for easy service
Or ering Instructions
Please specify the following with each or er:
1. Desire Voltage: 120, 208, or 240V
2. Base Size of Heate Well:
Insulate Wells are Rectangular Full Size
(12" x 20" (305 x 508 mm))
3. Drain (with or without)
4. Mounting Style:
A. Top Mounte
B. Bottom Mounte
5. Wattage:
A. High Watt
B. Stan ar Watt
C. Low Watt (120V only)
6. Agency:
A. UL an CUL
B. UL-EPH (sanitary listing)
C. CE Mark available on stan ar an
high watt units
Fully insulate
construction keeps
heat insi e well cavity
Printe in U.S.A.
April 2008
Control Cutout Dimensions for HWBI-FUL an HWBIB-FUL
A. Stan ar Compact Control Panel Cutout: Front 3.25"W (83 mm) x 3.75"H (95 mm),
Back 2.16"W (55 mm) x 3.375"H (86 mm)
B. Optional Recesse Control Panel Cutout: 5.875"W (149 mm) x 6.375"H (162mm)
Control Cutout Dimensions for HWBIB-FULDA
A. Stan ar Control Panel Cutout: 10 .125"W (257 mm) x 4.75"H (121 mm)

Mo el* Volts Watts Amps Shipping Weight
HWBHI-FUL 120 13.8
HWBHI-FULD 208 1650 7.9 27 lbs. (12 kg)
240 6.9 30 lbs. (14 kg)
HWBHIB-FUL 120 13.8
HWBHIB-FULD 208 1650 7.9 30 lbs. (14 kg)
240 6.9 33 lbs. (15 kg)
HWBHIB-FULDA 120 13.9
208 1665 8.0 33 lbs. (15 kg)
240 6.9
Full Size Insulate Rectangular Mo els – High Watt
* “D” a e to mo el name in icates unit with rain.
“A” a e to mo el name in icates unit with auto-fill
“I” a e to mo el name in icates insulate unit.
“B” a e to mo el name in icates bottom mount unit.
Mo el* Volts Watts Amps Shipping Weight
HWBLI-FUL 120 750 6.3 27 lbs. (12 kg)
HWBLI-FULD 30 lbs. (14 kg)
HWBLIB-FUL 120 750 6.3 30 lbs. (14 kg)
HWBLIB-FULD 33 lbs. (15 kg)
HWBLIB-FULDA 120 765 6.4 33 lbs. (15 kg)
SPECIFICATIONS
Full Size Insulate Rectangular Mo els – Low Watt
Mo el* Volts Watts Amps Shipping Weight
HWBI-FUL 120 10.0
HWBI-FULD 208 1200 5.8 27 lbs. (12 kg)
240 5.0 30 lbs. (14 kg)
HWBIB-FUL 120 10.0
HWBIB-FULD 208 1200 5.8 30 lbs. (14 kg)
240 5.0 33 lbs. (15 kg)
HWBIB-FULDA 120 10.1
208 1215 5.8 33 lbs. (15 kg)
240 5.1
Full Size Insulate Rectangular Mo els – Stan ar Watt
ITEM#
INSULATED SINGLE
BUILT-IN HEATED WELLS
Models HWBLI-FUL, -FULD HWBLIB-FUL, -FULD HWBLIB-FULDA HWBI-FUL, -FULD HWBIB-FUL, -FULD HWBIB-FULDA
HWBHI-FUL, -FULD HWBHIB-FUL, -FULD HWBHIB-FULDA
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: [e-mail]
Printe in U.S.A.
Form No. HWBI-FUL Spec Sheet April 2008
OPTIONS (NOT FOR RETROFIT)
❑Flush Mount Control Box Bezel in Designer Colors: Warm
Re , Black, Gray Granite, White Granite, Navy Blue, Hunter
Green (not available for HWBIB-FULDA)
❑A itional High Temp Lea Wire (Lea wire only – con uit
not inclu e ) (Mo els are shippe with 1' (305 mm) of lea
wire – no con uit)
❑Thermostat with 6' (1829 mm) Capillary
❑Larger Recesse Thermostat Control (not available for
HWBIB-FULDA mo els)
ACCESSORIES
❑Mounting Kit for Combustible Countertops (not necessary
for HWBIB-FULDA mo els)
❑A apter to Convert Warmer to Hol Two 7 Quart
(7 Liter) Inserts
❑A apter to Convert Warmer to Hol Three 4 Quart
(4 Liter) Inserts
❑12" (305 mm) an 20" (508 mm) Pan Support Bars
❑Stainless Steel Foo Pans
❑3⁄4" NPT Ball Valve for Unit with Drains.
PRODUCT SPECS
Built-in Heate Well
The Built-in Heate Well shall be a Mo el ….as manufacture
by the Hatco Corporation, Milwaukee, WI 53234 U.S.A.
With 24/7 parts an service assistance (U.S. an Cana a only),
the Built-in Heate Well shall be rate at ….watts, ….volts, an
be ….inches (millimeters) in overall wi th an be ….inches
(millimeters) in overall epth. It shall consist of stainless an
aluminize steel housing with a metal sheathe heating
element, EZ locking har ware for installation, an a remote
thermostat with lighte power switch.
Accessories may inclu e stainless steel mounting kit, a apter
bars, an a apter top.
DIMENSIONS
HWBI-FUL Insulate Top Mount Series:
13.7"W x 21.77"D x 9.45"H (348 x 553 x 240 mm).
HWBIB-FUL Insulate Bottom Mount Series:
13.97"W x 22"D x 9.45"H (355 x 559 x 240 mm).
Control Panel: 3.55"W x 1.91"D x 4.77"H (90 x 48 x 121 mm).
Optional Control Panel: 63⁄8"W x 35⁄8"D x 73⁄4"H
(162 x 92 x 197 mm).
HWBIB-FULDA Insulate Bottom Mount Series:
13.97"W x 22"D x 9.45"H (355 x 559 x 240 mm).
Control Panel: 10.94"W x 3.95"D x 5.5"H (278 x 100 x 140 mm).
VOLTAGE
120, 208, an 240 volts, single phase. Export voltages available.
4.77"
(121 mm)
20.08" (510 mm)
22" (559 mm)
12.09"
(307 mm)
13.97"
(355 mm)
1.91"
(48 mm)
36" (914 mm)
FLEXIBLE CONDUIT
9.45"
(240 mm)
SIDE VIEW
FRONT VIEW
3.55" (90 mm)
4.77"
(121 mm)
21.77" (553 mm)
13.7"
(348 mm)
1.91"
(48 mm)
36" (914 mm)
FLEXIBLE CONDUIT
9.45"
(240 mm)
SIDE VIEW
FRONT VIEW
3.55" (90 mm)
9.45"
(240 mm)
36"
(914 mm)
PVC
TUBING
5.5"
(140 mm)
3.95"
(100 mm)
SIDE VIEWFRONT VIEW
10.94"
(278 mm)
12.09"
(307 mm)
13.97"
(355 mm)
20.08" (510 mm)
22" (559 mm)
36" (914 mm)
FLEXIBLE CONDUIT
Mo el HWBI-FUL
Insulate Top Mount Series
Mo el HWBIB-FUL
Insulate Bottom Mount Series
Mo el HWBIB-FULDA with Auto-fill
Insulate Bottom Mount Series
10°
CONTROL
PANEL
7.73"
(196 mm)
3.63"
(92 mm)
6.33"
(161 mm)
Optional
Control
Assembly
