GLO-RAY®
HEATED GLASS MERCHANDISING WARMERS
Models GR3SDH-27, -33, -39 GR3SDH-27D, -33D, -39D
GR3SDS-27, -33, -39 GR3SDS-27D, -33D, -39D
For s lf-s rv op rations, th Hatco
Glo-Ray H at d Glass M rchandising
Warm rs incr as holding capaciti s
and impuls sal s. F aturing Hatco’s
pat nt d h at d glass sh lv s, product
is plac d at custom rs’ fing rtips, whil
allowing th m to vi w all th ir choic s at
onc . D sign d sp cifically to hold hot
wrapp d or box d product at prop r
s rving t mp ratur s, th addition of a
top sh lf us d to display short t rm h ld
food for which s rving t mp ratur is
not critical, provid s xtra capacity whil
using th sam amount of count rspac .
Th transpar nt sh lf utiliz s a pat nt d
h at d glass, which radiat s h at down
whil conducting h at up, allowing you
to hold foods long r and saf r at
optimum s rving t mp ratur s.
FLEXIBILITY
Availabl with slant or horizontal sh lv s,
th Glo-Ray H at d Glass M rchandis rs
ar off r d in thr widths of 271⁄4", 331⁄4",
and 391⁄4" (692, 845, and 997 mm), with
singl or dual sh lv s.
Th pat nt d h at d glass sh lf provid s
an v n h at sourc for top and bottom
h at to saf ly hold product, along with
sup rior visibility to promot and
display product.
Options and acc ssori s includ
stainl ss st l or Designer color units,
Designer color posts, Designer color
bas pan ls, sign hold r for top and
middl sh lv s, flip up doors, and
4" (102 mm) l gs.
QUALITY
Th following f atur s assur th fin st
p rformanc for y ars to com .
• Th pat nt d h at d glass sh lf
provid s an v n h at sourc for
top and bottom h at to saf ly
hold product.
• High visibility s lf-s rv m rchandis r.
• Th s m rchandis rs f atur a
th rmostatically-controll d, hardcoat d
h at d bas and a cord and plug.
• All mod ls ar shipp d with 21⁄2"
(64 mm) adjustabl l gs and factory
attach d 6' (1829 mm) cord and plug.
HEATED GLASS SHELVES AND BASE BLANKET
HEATING ELEMENTS ARE WARRANTED AGAINST
BURNOUT FOR ONE YEAR.
Divid r Rods
Mod l Width Divid r Rods Provid d Av rag Chut Width
271⁄4" (692 mm) 5 Rods p r Sh lf 4" (102 mm)
331⁄4" (845 mm) 6 Rods p r Sh lf 41⁄4" (108 mm)
391⁄4" (997 mm) 7 Rods p r Sh lf 41⁄2" (114 mm)
Mod l GR3SDS-39 with
optional Designer color and
acc ssory top sign hold r
(graphic not includ d)
Mod l GR3SDH-39 in
optional stainl ss st l
Mod l GR3SDH-39D with
optional Designer color and
acc ssory sh lf sign hold rs
(graphic not includ d)
Mod l GR3SDS-39D in
optional Designer color
Print d in U.S.A.
January 2007

271⁄4", 331⁄4", or 391⁄4"
(692, 845, or 997 mm)
FRONT VIEW
171⁄2"
(446 mm)
267⁄8" (683 mm)
SIDE VIEW
271⁄2"
(699 mm)
21⁄2"
(64 mm)
DIMENSIONS
GR3SDH Singl Sh lf Mod ls: 27
1/4"
, 33
1/4"
, or 39
1/4"
W x
27
1/4"
D x 15
3/8"
H w/l gs (692, 845, or 997 x 692 x 391 mm).
GR3SDH Dual Sh lf Mod ls: 27
1/4"
, 33
1/4"
, or 39
1/4"
W x
27
1/4"
D x 25
1/8"
H w/l gs (692, 845, or 997 x 692 x 638 mm).
GR3SDS Singl Sh lf Mod ls: 27
1/4"
, 33
1/4"
, or 39
1/4"
W x
26
7/8"
D x 20"H w/l gs (692, 845, or 997 x 683 x 508 mm).
GR3SDS Dual Sh lf Mod ls: 27
1/4"
, 33
1/4"
, or 39
1/4"
W x
26
7/8"
D x 30 " H w/l gs (692, 845, or 997 x 683 x 762 mm).
Us abl H at d Sh lf Spac :
GR3SDS or GR3SDH-27, -27D: 231/4"W x 211/4"D (591 x 540 mm).
GR3SDS or GR3SDH-33, -33D: 291/4"W x 211/4"D (743 x 540 mm).
GR3SDS or GR3SDH-39, -39D: 351/4"W x 211/4"D (895 x 540 mm).
VOLTAGE
Singl Sh lf Mod ls: 120 volts, singl phas
(us s NEMA 5-15P, mod ls GR3SDH-39 and GR3SDS-39
us NEMA 5-20P for Canada).
Dual Sh lf Mod ls:
GR3SDH-27D and GR3SDS-27D: 120 volts, singl phas
(us s NEMA 5-15P, us s NEMA 5-20P for Canada).
GR3SDH-33D, -39D and GR3SDS-33D, -39D: 120/208 or 120/240,
singl phas (us s NEMA L14-20P).
CORD LOCATION
Right r ar on s rv r sid .
PLUG CONFIGURATIONS
OPTIONS (NOT FOR RETROFIT)
❑Designer Color Bas and Sh lv s, Posts and Bas End
Pan ls: Warm R d, Black, Gray Granit , Whit Granit , Navy
Blu , and Hunt r Gr n
❑Stainl ss St l Body, Bas , and Bas End Pan ls
(Unpaint d Posts)
❑Flip-up Doors – Front or Back
ITEM#
PRODUCT SPECS
H at d Glass M rchandising Warm r
Th H at d Glass M rchandis r shall b a Glo-Ray®mod l....
as manufactur d by th Hatco Corporation, Milwauk , WI
53234 U.S.A.
With 24/7 s rvic (U.S and Canada only), th M rchandis r shall
b rat d at ....watts, ....volts, singl phas , and b ....inch s
(millim t rs) in ov rall width.
Th Glo-Ray shall consist of a th rmostatically-controll d,
hardcoat d h at d bas , glass h at d sh lf(v s), and adjustabl
divid r rods.
Acc ssori s shall includ flip up doors, sign hold r for top and
middl sh lv s, br ath prot ctors, 4" (102 mm) l gs, and
additional divid r rods.
ACCESSORIES
❑Paint d Sh lf Sign Hold r – Top or Int rm diat Sh lf
❑Top Sh lf 12" (305 mm) V rtical Sign Hold r – Top Sh lf Only
❑5" (127 mm) Br ath Prot ctor
❑4" (102 mm) L gs
❑Additional Stainl ss St l Divid r Rods
GLO-RAY ®
HEATED GLASS MERCHANDISING WARMERS
Models GR3SDH-27, -33, -39 GR3SDH-27D, -33D, -39D
GR3SDS-27, -33, -39 GR3SDS-27D, -33D, -39D
271⁄4", 331⁄4", or 391⁄4"
(692, 845, or 997 mm)
FRONT VIEW
225⁄8"
(575 mm)
127⁄8"
(327 mm)
21⁄2"
(64 mm)
271⁄4" (692 mm)
SIDE VIEW
HATCO CORPORATION P.O. Box 340500 Milwauk , WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: quipsal [e-mail]
NEMA L14-20PNEMA 5-20PNEMA 5-15P
* NSF r quir s units ov r 36" (914 mm) in width or w ighing mor than
80 lbs. (36 kg) to b ith r s al d, or rais d on th installation surfac with
th 21⁄2" (64 mm) l gs includ d.
GR3SDH Mod ls GR3SDS Mod ls
SPECIFICATIONS
Horizontal Mod ls – Singl Sh lf
Model*Width Watts Amps Shipping Weight
GR3SDH-27D 271⁄4" (692 mm) 1790 14.9 90 lbs. (41 kg)
GR3SDH-33D 331⁄4" (845 mm) 2210 10.3 100 lbs. (45 kg)
GR3SDH-39D 391⁄4" (997 mm) 2660 12.4 112 lbs. (51 kg)
Horizontal Mod ls – Dual Sh lf
Slant Mod ls – Singl Sh lf
Slant Mod ls – Dual Sh lf
Model*Width Watts Amps Shipping Weight
GR3SDH-27 271⁄4" (692 mm) 1010 8.4 50 lbs. (23 kg)
GR3SDH-33 331⁄4" (845 mm) 1240 10.3 58 lbs. (26 kg)
GR3SDH-39 391⁄4" (997 mm) 1490 12.4 66 lbs. (30 kg)
Model*Width Watts Amps Shipping Weight
GR3SDS-27D 271⁄4" (692 mm) 1790 14.9 128 lbs. (58 kg)
GR3SDS-33D 331⁄4" (845 mm) 2210 10.3 140 lbs. (64 kg)
GR3SDS-39D 391⁄4" (997 mm) 2660 12.4 158 lbs. (72 kg)
Model*Width Watts Amps Shipping Weight
GR3SDS-27 271⁄4" (692 mm) 1010 8.4 72 lbs. (33 kg)
GR3SDS-33 331⁄4" (845 mm) 1240 10.3 80 lbs. (36 kg)
GR3SDS-39 391⁄4" (997 mm) 1490 12.4 92 lbs. (42 kg)
Top sh lf should only b us d for non-hazardous foods.
Form No. GR3SD Sp c Sh t
Print d in U.S.A.
January 2007
